WHYP Test Files

1
WHYP Test Files

• Lab 9

2
The WC16 WHYP Core Modifications
for Multiplication and Division
y1
3
7 different test programs
Used only for DIO2 Board
4
Table 1 New Funit Instructions
5
opcodes.vhd
-- Function Unit instructions constant plus
opcode X"0010" -- constant minus
opcode X"0011" -- - constant plus1
opcode X"0012" -- 1 constant minus1
opcode X"0013" -- 1- constant invert
opcode X"0014" -- INVERT constant andd
opcode X"0015" -- AND constant orr
opcode X"0016" -- OR constant xorr
opcode X"0017" -- XOR constant
twotimes opcode X"0018" -- 2
constant u2slash opcode X"0019" -- U2/
constant twoslash opcode X"001A" --
2/ constant rshift opcode X"001B" --
RSHIFT constant lshift opcode X"001C" --
LSHIFT constant mpp opcode X"001D" --
mpp constant shldc opcode X"001E" --
shldc
6
mpp
Multiply partial product
when mpp gt tload lt '1' nload lt '1'
nsel lt "10" fcode lt icode(5 downto
0)
7
variable AVector STD_LOGIC_VECTOR (width
downto 0) variable BVector STD_LOGIC_VECTOR
(width downto 0) variable CVector
STD_LOGIC_VECTOR (width downto 0) variable
yVector STD_LOGIC_VECTOR (width downto 0)
variable y1_tmp STD_LOGIC_VECTOR (width-1 downto
0)
begin
In Funit2
AVector '0' a BVector '0'
b CVector '0' c y1_tmp false
yVector '0' false
8
mpp (multiply partial product) if N(0) 1
then adsh else sh end if
when "011101" gt -- mpp if b(0) '1' then
yVector AVector CVector else yVector
AVector end if y lt yVector(width downto
1) y1 lt yVector(0) b(width-1 downto 1)
T
N
N2
9
16 x 16 32 Multiplication
UM ( u1 u2 - upL upH ) 0 mpp mpp mpp mpp
mpp mpp mpp mpp mpp mpp mpp mpp mpp mpp mpp
mpp ROT_DROP
10
shldc
Shift left and decrement conditionally
when shldcgt tload lt '1' nload lt '1'
nsel lt "10" fcode lt icode(5 downto
0)
11
Division
N2
T
N
UM/MOD ( unumL unumH udenom -- urem uquot )
N2
T
N
-ROT \ udenom unumL unumH SHLDC SHLDC SHLDC SHLD
C \ denom quot rem ROT_DROP_SWAP
All other signed and unsigned division operations
can be derived as WHYP words from UM/MOD
12
when "011110" gt -- shldc yVector a
b(width-1) y1_tmp b(width-2 downto 0)
'0' if yVector gt CVector then yVector
yVector - CVector y1_tmp(0) '1' end
if
y lt yVector(width-1 downto 0) y1 lt y1_tmp
for I in 0 to 3 loop sll T N if T84 gt
N2 then T T - (0 N2) N(0)
1 end if end loop
T
N
sll
100001110 1101
N2
13
32 / 16 1616 Division
UM/MOD ( unL unH ud -- ur uq ) -ROT shldc
shldc shldc shldc shldc shldc shldc shldc shldc
shldc shldc shldc shldc shldc shldc shldc
ROT_DROP_SWAP
14
WHYP Test Files
  sdigtest.whp -- tests the switches and
7-segment displays hex2asc.whp -- converts hex
to ascii minmax.whp -- finds the min and max of
two numbers mul.whp -- multiplies two 16-bit
numbers div.whp -- divides a 32-bit number by a
16-bit number fact16.whp -- computes the
factorial of a number leap.whp -- checks if a
year is a leap year
15
SDigtest.whp
\ Test of JB4HI, JB4LO, S_at_ and DIG!
main ( -- ) BEGIN waitB4 S_at_
DIG! AGAIN
16
Hex2asc.whp
\ Convert hex to ASCII HEX   hex2asc
( n -- asc ) 0F AND \
mask upper nibble DUP 9 gt
\ if n gt 9 IF
37 \ add 37 ELSE
30 \ else add 30
THEN   main ( -- ) BEGIN
waitb4 S_at_ DUP DIG! waitb4
hex2asc DIG! AGAIN
17
Minmax.whp
\ MIN MAX   MIN ( n1 n2 -- min ) OVER OVER
gt \ n1 n2 f IF \ n1 n2 SWAP \ n2
n1 THEN DROP \ min   MAX ( n1 n2 -- max
) OVER OVER lt \ n1 n2 f IF \ n1 n2
NIP \ n2 ELSE DROP \ n1 THEN
main ( -- ) BEGIN waitB4 S_at_ DUP DIG!
waitB4 S_at_ DUP DIG! waitB4 OVER OVER MIN
DIG! waitB4 MAX DIG! AGAIN
18
Mul.whp
UM ( u1 u2 - upL upH ) 0 mpp mpp mpp mpp
mpp mpp mpp mpp mpp mpp mpp mpp mpp mpp mpp
mpp ROT_DROP   MAIN ( -- ) BEGIN
waitB4 S_at_ \ get u1HI DUP DIG! 8 LSHIFT
waitB4 S_at_ \ get u1LO OR DUP DIG! waitB4 S_at_ \
get u2HI DUP DIG! 8 LSHIFT waitB4 S_at_ \ get
u2LO OR DUP DIG! waitB4 UM \
multiply DIG! \ display upH waitB4 DIG! \
display upL AGAIN
19
Div.whp
UM/MOD ( unL unH ud -- ur uq ) -ROT shldc
shldc shldc shldc shldc shldc shldc shldc shldc
shldc shldc shldc shldc shldc shldc shldc
ROT_DROP_SWAP   MAIN ( -- ) BEGIN
waitB4 S_at_ \ get unHHI DUP DIG! 8
LSHIFT waitB4 S_at_ \ get unHLO OR DUP
DIG! waitB4 S_at_ \ get unLHI DUP DIG! 8 LSHIFT
waitB4 S_at_ \ get unLLO OR DUP DIG! SWAP \
numerator waitB4 S_at_ \ get udHI DUP DIG! 8
LSHIFT waitB4 S_at_ \ get udLO OR \
denominator DUP DIG! waitB4 UM/MOD \
divide DIG! \ display uq waitB4 DIG! \ display
ur AGAIN
20
Fact16.whp
\ Example of BEGIN...WHILE...REPEAT   UM
( u1 u2 - upL upH ) 0 mpp mpp mpp mpp mpp
mpp mpp mpp mpp mpp mpp mpp mpp mpp mpp mpp
ROT_DROP   ( n1 n2 -- n3 ) UM DROP
  factorial ( n -- n! ) 1
2 ROT \ x i n
BEGIN \ x i n
OVER OVER lt \ x i n f
WHILE \ x i n
-ROT TUCK \ n i x i
SWAP \ n x' i
1 ROT \ x' i' n
REPEAT \ x i n
DROP DROP \ x   main ( --
) BEGIN waitB4 S_at_ DUP DIG! waitB4
factorial DIG! AGAIN
21
Leap.whp
\ leap year   UM/MOD ( unumL unumH
udenom - urem uquot ) -ROT 16 FOR
shldc NEXT ROT_DROP_SWAP   U/MOD ( n1
n2 -- urem uquot ) gtR 0 Rgt UM/MOD
MOD ( n1 n2 -- urem ) U/MOD DROP
22
Leap.whp (cont.)
?leap ( year -- flag )
DUP 400 MOD 0 IF
DROP TRUE ELSE
DUP 100 MOD 0 IF
DROP FALSE ELSE
4 MOD 0
IF TRUE
ELSE FALSE
THEN THEN
THEN   main ( -- ) BEGIN
waitB4 S_at_ DUP DIG! 8 LSHIFT
waitB4 S_at_ OR DUP DIG! waitB4
?leap DIG! AGAIN
Note A year is a leap year if it is divisible by
4, but not by 100, or if it is divisible by 400.
