Flexible, HighSpeed Intrusion Detection Using Bro

1
Flexible, High-SpeedIntrusion Detection Using Bro
Vern Paxson Computational Research
Division Lawrence Berkeley National
Laboratory and ICSI Center for Internet
Research International Computer Science
Institute Berkeley, CA USA vern_at_icir.org http//
www-nrg.ee.lbl.gov/bro.html
2
Protect Rather Than Secure

• Modern science critically depends on diverse,
  high-performance Internet communication
• Increasingly difficult given rising security
  threats
• Alternative institutional approach network
  intrusion detection
• Monitor network traffic, look for attacks
• Key point tenable due to threat model at open
  research institutes
• Few jewels
• Low level of compromises is tolerable
• Particularly effective when combined with dynamic
  blocking (reactive firewall)
• Potentially keeps Default Allow viable

3
Bro Design Goals (1990s)

• Monitor traffic in a very high performance
  environment
• Real-time detection and response
• Separation of mechanism from policy
• Ready extensibility of both mechanism and policy
• Resistant to evasion

4
How Bro Works

• Taps GigEther fiber link passively, sends up a
  copy of all network traffic.

Network
5
How Bro Works
Filtered Packet Stream
Tcpdump Filter

• Kernel filters down high-volume stream via
  standard libpcap packet capture library.

libpcap
Packet Stream
Network
6
How Bro Works
Event Stream
Event Control

• Event engine distills filtered stream into
  high-level, policy-neutral events reflecting
  underlying network activity
• E.g., connection_attempt, http_reply,
  user_logged_in

Event Engine
Filtered Packet Stream
Tcpdump Filter
libpcap
Packet Stream
Network
7
How Bro Works
Real-time Notification Record To Disk
Policy Script

• Policy script processes event stream,
  incorporates
• Context from past events
• Sites particular policies

Policy Script Interpreter
Event Stream
Event Control
Event Engine
Filtered Packet Stream
Tcpdump Filter
libpcap
Packet Stream
Network
8
How Bro Works
Real-time Notification Record To Disk
Policy Script

• Policy script processes event stream,
  incorporates
• Context from past events
• Sites particular policies
• and takes action
• Records to disk
• Generates alerts via syslog, paging
• Executes programs as a form of response
• Sends events to other Bros

Policy Script Interpreter
Event Stream
Event Control
Event Engine
Filtered Packet Stream
Tcpdump Filter
libpcap
Packet Stream
Network
9
Signature Engine

• Bro also includes a signature engine for matching
  specific patterns in packet streams
• Conceptually simple
• Easy to share
• Compatible with Snort (widely used freeware IDS)
• E.g., can run on Snorts default set of 1,900
  signatures
• but of limited power basically, a useful hack
• As with other Bro analysis, signature matches
  generate events amenable to high-level policy
  script processing, rather than direct alerts

10
Status

• Operational 24x7 LBNL (border internal),
  NERSC, UC Berkeley, TUM, NCSA
• Runs on commodity Unix PCs but getting hard!
• 80K lines C, 12K lines of policy scripts, 200
  page user manual
• Main LBNL Bro blocks 50-500 remote addresses/day,
  mostly for scanning
• Provides extensive logs, invaluable for forensics
  site traffic analysis

11
RD Support

• Funded variously via overhead, operations,
  research grants
• Current research support
• NSF Strategic Technologies for the Internet
• Likely DOE support soon for developing as a
  potential community resource ...
• Pending RD proposal to DOE for very high-speed
  monitoring

12
RD Support

• Funded variously via overhead, operations,
  research grants
• Current research support
• NSF Strategic Technologies for the Internet
• Likely DOE support soon for developing as a
  potential community resource ...
• Pending RD proposal to DOE for very high-speed
  monitoring

13
Making Bro Broadly Available

• Broader documentation setup, operational
  procedures, analysis techniques, FAQ
• Tutorials (already have in-house)
• Bug-tracking system
• Test suites
• Production vs. research code trees
• Framework for integrating contributions
• GUIs for configuration, log analysis
• Framework for rapid dissemination of new
  scripts/policies/signatures

14
RD Support

• Funded variously via overhead, operations,
  research grants
• Current research support
• NSF Strategic Technologies for the Internet
• Likely DOE support soon for developing as a
  potential community resource ...
• Pending RD proposal to DOE for very high-speed
  (10-40 Gbps) monitoring

15
Prefiltering (Prototyped at SC02, SC03)
16
Shunting
17
Discussion/Questions?

• http//www-nrg.ee.lbl.gov/bro.html
• vern_at_icir.org
