Title: Thurmond FFA Chapter


1
Golf Green ConstructionUSGA Specifications
  • Thurmond FFA Chapter
  • Dan Henderson Hugh Bland
  • Advisors

2
The new green is on the site of our student
learning center
3
Student Learning Center Contains
  • 2- 2000 square foot golf greens
  • 1-Tee box and fairway
  • Landscaping Plant Materials Lab
  • Forest Tree ID lab
  • Vegetable Garden Lab
  • Turf ID Lab
  • Wildlife Food Plot Lab
  • Irrigation Lab

4
Step By Step Guide
  • Site Selection
  • Preparing the site
  • Excavating
  • Drainage
  • Filling
  • Irrigation
  • Planting
  • Maintaining

5
Site Selection Preparation
  • Find a sunny location free of large trees.
  • The land should lay so that removing water from
    the drain area will be no problem.
  • Three applications of Round-Up herbicide, three
    weeks apart, will be necessary to remove
    perennial weeds.

6
TOTAL AREA OF THE GREEN
  • We believe that 2000 square feet is an ideal
    green size for the school. It is affordable and
    large enough to maneuver equipment well.

7
BENEFITS OF THE 2000 SQUARE FOOT GREEN
  • All recommendations are in the per 1000 square
    feet format, so calculations are easy.
  • The cost of chemicals and fertilizers are high,
    so the small green will minimize costs.

8
EXCAVATING THE GREEN SITE
  • The first step is to remove 18 inches of soil
    from the green area.

9
A front end loader was used to begin removing the
soil
10
(No Transcript)
11
(No Transcript)
12
A box-blade is handy for piling up soil to be
removed by the loader
13
Tractors are handy, but handwork is also needed.
14
Installing Drain Lines
  • The green must be an even 18 inches deep in all
    locations. (Less than this will not be enough,
    but more requires extra rock, which is costly).
  • Drain lines must be 8 inches deep.
  • Drains should be 8 feet apart, feeding one main
    drain line down the center.
  • There must be enough slope to remove water.

15
Renting a small backhoe makes the job easier,
especially in clay.
16
Branch lines run parallel and empty into the main
line.
17
(No Transcript)
18
The next step is to fill drain lines with 4
inches of gravel.
19
Our green took a total of 3 tantum loads of this
gravel
20
The next step is to lay the 4 inch drain pipe,
hole side down.
21
(No Transcript)
22
8 inches of gravel must be added over the drain
pipes.
23
(No Transcript)
24
(No Transcript)
25
Hand work can reduce problem with soil in the
trench lines.
26
(No Transcript)
27
After leveling the gravel, a 4 inch layer of pea
gravel this size is added.
28
(No Transcript)
