The biological meaning of pairwise alignments

1
The biological meaning of pairwise alignments

• Arthur Gruber

Instituto de Ciências Biomédicas Universidade de
São Paulo
AG-ICB-USP
2
What is a pairwise alignment?

• Comparison of 2 sequences nucleotide or protein
  sequences
• We can compare a sequence to an entire database
  of sequences one pairwise alignment at a time
• Different types of alignments global and local
  alignment
• Different algorithms Needleman-Wunsch,
  Smith-Waterman, FastA, BLAST

AG-ICB-USP
3
Pairwise alignment

• Output alignment of similar blocks or whole
  sequences

gi3323386gbU85705.1IFU85705 Isospora felis
28S large subunit ribosomal RNA gene, complete
sequence Length 3227 Score 218 bits (110),
Expect 2e-54 Identities 146/158 (92) Strand
Plus / Minus Query 3 cacttttaactctctttccaaa
gtccttttcatctttccttcacagtacttgttcactat 62

Sbjct 386 cacttttaactctctttccaaag
aacttttcatctttccctcacggtacttgtttgctat 327
Query 63 cggtctcacgccaatatttagctttacgtgaaacttatca
cacattttgcgctcaaatcc 122

Sbjct 326 cggtctcgcgccaatatttagctttatg
tgaaacttatcacacattttgcgctcaaatcc 267 Query 123
caatgaacgcgactcaataaaagcgcaccgtacgtgga 160

Sbjct 266 cgatgaacgcgactctataaaggcgtaccgtacgtgga
229
AG-ICB-USP
4
Some applications of pairwise alignments

• Annotation description of the characteristics
  of a sequence
• Function ascribing similar sequences MAY share
  similar functions
• Identification of structural domains similar
  sequences MAY share similar structures
• Identification of protein domains defines
  protein architecture
• Phylogenetic inference identification of
  similar sequences that MAY have a common ancestry

AG-ICB-USP
5
Some applications of pairwise alignments

• Identification of contaminant sequences in a
  sequencing project query sequence x databases
  (bacterial, ribosomal, mitochondrial, etc.)
• Identification of vector sequences in sequencing
  reads alignment and masking

AG-ICB-USP
6
Identity, similarity, homology

• Identity refers to nucleotide or amino acid
  residues that are identical
• Similarity - measurable quantity percentage of
  identities between two sequences, percentage of
  similar amino acid residues (conserved along the
  evolution).
• Homology based on a evolutionary conclusion
  that implies that two sequences has a common
  ancestral sequence. They are said to share the
  same evolutionary history. Homology is not
  quantitative. Two sequences can be or not to be
  homologous.

AG-ICB-USP
7
Identity, similarity, homology

• A high degree of similarity between two sequences
  MAY suggest that they share a common
  evolutionary history. Other analyses and
  experimental work should be done to validate such
  hypothesis

AG-ICB-USP
8
Contaminant removal
Libraries can be contaminated by different sources
Genomic libraries

• Other organisms and/or cells co-purification
• Bacterial DNA - E. coli used as the host cell
• Human contamination during manipulation
• Other genomes being manipulated in the lab
  cross-contamination

AG-ICB-USP
9
Contaminant removal
Libraries can be contaminated by different sources
EST libraries

• All sources already mentioned
• Ribosomal RNA co-purification with the polyA
  fraction
• Organelle transcripts mitochondrion, plastid

AG-ICB-USP
10
Vector masking
A typical read contains sequence stretches that
are not originally part of the insert
insert
Sequencing reaction
Vector sequence
Vector sequence
AG-ICB-USP
11
Vector masking
Masking consists in a substitution of bases that
are not part of the insert by Xs
insert
Vector sequence
Vector sequence
insert
xxxxxxxxx
xxxxxxxxxxxxxxxx
Vector sequence
Vector sequence

• X bases will not be taken into account by
  assembly/clustering programs

AG-ICB-USP
12
Aligning Two Sequences

• Human Hemoglobin (HH)
• VLSPADKTNVKAAWGKVGAHAGYEG
• Sperm Whale Myoglobin (SWM)
• VLSEGEWQLVLHVWAKVEADVAGHG

AG-ICB-USP
13
Aligning Two Sequences

• (HH) VLSPADKTNVKAAWGKVGAHAGYEG
• (SWM) VLSEGEWQLVLHVWAKVEADVAGHG
• Gap Weight 12
• Length Weight 4
• Gaps 0
• Percent Similarity 40.000
• Percent Identity 36.000
• Matrix blosum62

AG-ICB-USP
14
Gap Insertion/Deletion

• (HH) VLSPADKTNVKAAWGKVGAH-AGYEG
• ??? ? ? ?? ? ?? ?
• (SWM) VLSEGEWQLVLHVWAKVEADVAGH-G
• - gap insertion/deletion
• Gap Weight 4
• Length Weight 1
• Gaps 2
• Percent Similarity 54.167
• Percent Identity 45.833
• BLOSUM62

AG-ICB-USP
15
Scoring

• (HH) VLSPADKTNVKAAWGKVGAH-AGYEG
• (SWM) VLSEGEWQLVLHVWAKVEADVAGH-G
• The score of the alignment is
• Matrix value at (V,V) (L,L) (S,S) (P,E)
  (penalty for gap insertion/deletion)gaps
  (penalty for gap extension)(total
  length of all gaps)

AG-ICB-USP
16
Scoring System

• Identity An objective and quite well defined
  measure Count the number of identical matches,
  divide by length of aligned region
• Similarity A less well defined measure
• Category Amino acid
• Acids and Amides Asp (D) Glu(E) Asn (N) Gln (Q)
• Basic His (H) Lys (K) Arg (R)
• Aromatic Phe (F) Tyr (Y) Trp (W)
• Hydrophilic Ala (A) Cys (C) Gly (G) Pro (P) Ser
  (S) Thr (T)
• Hydrophobic Ile (I) Leu (L) Met (M) Val (V)

AG-ICB-USP
17
Scoring system

• Rates of amino acid substitution are not uniform
• Some amino acids are more conserved than others
  (e.g. C, H, W compared to A, L, I)
• Some substitutions are more common than others
• (e.g. A I, A L compared to D L)
• Conclusion there are evolutionary pressures that
  probably reflect structural and functional
  constraints
• Scoring matrices matrices that are used for
  scoring amino acid substitutions in pairwise
  alignments
• They reflect substitution rates that are
  originated by evolutionary events

AG-ICB-USP
18
Amino acids - chemical relationships
Tiny
Alphatic
A
G
P
Hydrophobic
OH
L
I
S
C
V
Polar
T
Y
F
M
Hydrophilic
W
K
D
N
H
NH2
R
E
K
Aromatic
Charged
Positive
Negative
AG-ICB-USP
19
PAM

• Stands for Point Accepted Mutation
• Dayhoff Matrix, 1978
• A series of matrices describing the extent to
  which two amino acids have been interchanged in
  evolution
• Very similar sequences were aligned, phylogenetic
  trees were built, and ancestral sequences were
  reconstructed
• Out of these alignments, the frequency of
  substitution between each pair of amino acids was
  calculated. Using this information, PAM matrices
  were built (PAM1 i.e. one accepted point mutation
  per 100 amino acids).

AG-ICB-USP
20
PAM250 - amino acid substitution matrix
GAP_CREATE 12 GAP_EXTEND 4
A B C D E F G H I K
L M N P Q R S T V
W A 2 0 -2 0 0 -4 1 -1
-1 -1 -2 -1 0 1 0 -2 1 1
0 -6 B 0 2 -4 3 2 -5 0
1 -2 1 -3 -2 2 -1 1 -1
0 0 -2 -5 C -2 -4 12 -5 -5
-4 -3 -3 -2 -5 -6 -5 -4 -3 -5
-4 0 -2 -2 -8 D 0 3 -5 4
3 -6 1 1 -2 0 -4 -3 2 -1
2 -1 0 0 -2 -7 E 0 2 -5
3 4 -5 0 1 -2 0 -3 -2
1 -1 2 -1 0 0 -2 -7 F -4
-5 -4 -6 -5 9 -5 -2 1 -5 2
0 -4 -5 -5 -4 -3 -3 -1 0 G
1 0 -3 1 0 -5 5 -2 -3 -2
-4 -3 0 -1 -1 -3 1 0 -1
-7 H -1 1 -3 1 1 -2 -2 6
-2 0 -2 -2 2 0 3 2 -1 -1
-2 -3 I -1 -2 -2 -2 -2 1 -3
-2 5 -2 2 2 -2 -2 -2 -2
-1 0 4 -5 K -1 1 -5 0 0
-5 -2 0 -2 5 -3 0 1 -1 1
3 0 0 -2 -3 L -2 -3 -6 -4
-3 2 -4 -2 2 -3 6 4 -3
-3 -2 -3 -3 -2 2 -2 M -1 -2
-5 -3 -2 0 -3 -2 2 0 4 6
-2 -2 -1 0 -2 -1 2 -4 N 0
2 -4 2 1 -4 0 2 -2 1
-3 -2 2 -1 1 0 1 0 -2
-4 P 1 -1 -3 -1 -1 -5 -1 0
-2 -1 -3 -2 -1 6 0 0 1 0
-1 -6 Q 0 1 -5 2 2 -5 -1
3 -2 1 -2 -1 1 0 4 1
-1 -1 -2 -5 R -2 -1 -4 -1 -1
-4 -3 2 -2 3 -3 0 0 0 1
6 0 -1 -2 2 S 1 0 0 0
0 -3 1 -1 -1 0 -3 -2 1 1
-1 0 2 1 -1 -2 T 1 0 -2
0 0 -3 0 -1 0 0 -2 -1
0 0 -1 -1 1 3 0 -5 V 0
-2 -2 -2 -2 -1 -1 -2 4 -2 2
2 -2 -1 -2 -2 -1 0 4 -6 W
-6 -5 -8 -7 -7 0 -7 -3 -5 -3
-2 -4 -4 -6 -5 2 -2 -5 -6
17
AG-ICB-USP
21
BLOSUM

• Stands for Blocks Substitution Matrices
• Henikoff and Henikoff, 1992
• A series of matrices describing the extent to
  which two amino acids are interchangeable in
  conserved structures
• Built by extracting replacement information from
  the alignments in the BLOCKS database.

AG-ICB-USP
22
BLOSUM

• The number in the series (BLOSUM62) represents
  the threshold percent similarity between
  sequences, for considering them in the
  calculation.
• For example, BLOSUM62 is derived from an
  alignment of sequences that share 62 similarity,
  BLOSUM45 is based on 45 sequence similarity in
  aligned sequences

AG-ICB-USP
23
BLOSUM62 - amino acid substitution matrix
Reference Henikoff, S. and Henikoff, J. G.
(1992). Amino acid substitution matrices from
protein blocks. Proc. Natl. Acad. Sci. USA 89
10915-10919. A R N D C Q E G H I L
K M F P S T W Y V B Z X A 4 -1 -2
-2 0 -1 -1 0 -2 -1 -1 -1 -1 -2 -1 1 0 -3 -2
0 -2 -1 0 -4 R -1 5 0 -2 -3 1 0 -2 0 -3 -2
2 -1 -3 -2 -1 -1 -3 -2 -3 -1 0 -1 -4 N -2 0
6 1 -3 0 0 0 1 -3 -3 0 -2 -3 -2 1 0 -4 -2
-3 3 0 -1 -4 D -2 -2 1 6 -3 0 2 -1 -1 -3
-4 -1 -3 -3 -1 0 -1 -4 -3 -3 4 1 -1 -4 C 0
-3 -3 -3 9 -3 -4 -3 -3 -1 -1 -3 -1 -2 -3 -1 -1
-2 -2 -1 -3 -3 -2 -4 Q -1 1 0 0 -3 5 2 -2
0 -3 -2 1 0 -3 -1 0 -1 -2 -1 -2 0 3 -1 -4 E
-1 0 0 2 -4 2 5 -2 0 -3 -3 1 -2 -3 -1 0
-1 -3 -2 -2 1 4 -1 -4 G 0 -2 0 -1 -3 -2 -2
6 -2 -4 -4 -2 -3 -3 -2 0 -2 -2 -3 -3 -1 -2 -1 -4
H -2 0 1 -1 -3 0 0 -2 8 -3 -3 -1 -2 -1 -2
-1 -2 -2 2 -3 0 0 -1 -4 I -1 -3 -3 -3 -1 -3
-3 -4 -3 4 2 -3 1 0 -3 -2 -1 -3 -1 3 -3 -3
-1 -4 L -1 -2 -3 -4 -1 -2 -3 -4 -3 2 4 -2 2
0 -3 -2 -1 -2 -1 1 -4 -3 -1 -4 K -1 2 0 -1 -3
1 1 -2 -1 -3 -2 5 -1 -3 -1 0 -1 -3 -2 -2 0
1 -1 -4 M -1 -1 -2 -3 -1 0 -2 -3 -2 1 2 -1 5
0 -2 -1 -1 -1 -1 1 -3 -1 -1 -4 F -2 -3 -3 -3
-2 -3 -3 -3 -1 0 0 -3 0 6 -4 -2 -2 1 3 -1
-3 -3 -1 -4 P -1 -2 -2 -1 -3 -1 -1 -2 -2 -3 -3
-1 -2 -4 7 -1 -1 -4 -3 -2 -2 -1 -2 -4 S 1 -1
1 0 -1 0 0 0 -1 -2 -2 0 -1 -2 -1 4 1 -3 -2
-2 0 0 0 -4 T 0 -1 0 -1 -1 -1 -1 -2 -2 -1
-1 -1 -1 -2 -1 1 5 -2 -2 0 -1 -1 0 -4 W -3
-3 -4 -4 -2 -2 -3 -2 -2 -3 -2 -3 -1 1 -4 -3 -2
11 2 -3 -4 -3 -2 -4 Y -2 -2 -2 -3 -2 -1 -2 -3
2 -1 -1 -2 -1 3 -3 -2 -2 2 7 -1 -3 -2 -1 -4 V
0 -3 -3 -3 -1 -2 -2 -3 -3 3 1 -2 1 -1 -2 -2
0 -3 -1 4 -3 -2 -1 -4 B -2 -1 3 4 -3 0 1 -1
0 -3 -4 0 -3 -3 -2 0 -1 -4 -3 -3 4 1 -1 -4
Z -1 0 0 1 -3 3 4 -2 0 -3 -3 1 -1 -3 -1
0 -1 -3 -2 -2 1 4 -1 -4 X 0 -1 -1 -1 -2 -1 -1
-1 -1 -1 -1 -1 -1 -1 -2 0 0 -2 -1 -1 -1 -1 -1
-4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4
-4 -4 -4 -4 -4 -4 -4 -4 -4 1
AG-ICB-USP
24
Guidelines

• Lower PAMs and higher Blosums find short local
  alignment of highly similar sequences
• Higher PAMs and lower Blosums find longer weaker
  local alignment
• No single matrix answers all questions

AG-ICB-USP
25
BLAST Basic Local Alignment Search Tool

• Algorithm first described in 1990
• Altschul, S.F., Gish, W., Miller, W., Myers, E.W.
  Lipman, D.J. (1990) "Basic local alignment
  search tool." J. Mol. Biol. 215403-410.
• And improved in 1997
• Altschul, S.F., Madden, T.L., Schäffer, A.A.,
  Zhang, J., Zhang, Z., Miller, W. Lipman, D.J.
  (1997). Gapped BLAST and PSI-BLAST a new
  generation of protein database search programs.
  Nucleic Acids Res. 25 3389-3402.

AG-ICB-USP
26
Blast search four components

• Search purpose/goal
• Program
• Query sequence
• Database

AG-ICB-USP
27
BLAST search purpose/goal

• What is the biological question? Examples
• Which proteins of the database are similar to my
  protein sequence?
• Which proteins of the database are similar to
  the conceptual translation of my DNA sequence?
• Which nucleotide sequences in the database are
  similar to my nucleotide sequence?
• Which proteins coded by the conceptual
  translation of the database sequences are similar
  to my protein sequence?
• Which proteins coded by the conceptual
  translation of the database sequences are similar
  to the conceptual translation of my DNA sequence?

AG-ICB-USP
28
BLAST search purpose/goal

• Which proteins of the database are similar to my
  protein sequence?
• I have sequenced a gene and derived the protein
  sequence by concetpual translation.
  Alternatively, I obtained the protein sequence
  directly. I am now interested to find out its
  possible fnction.
• Using a similarity search, I can find protein
  sequences in databases that are similar to mine
  orthologs and paralogs.
• BLASTP protein query x protein database

AG-ICB-USP
29
BLAST - search purpose/goal

• Which proteins of the database are similar to the
  conceptual translation of my DNA sequence?
• I have sequenced an EST (expressed sequence tag)
  that contains a protein coding region.
• I am interested to find out which proteins of
  the database are similar to the conceptual
  translation of my nucleic acid sequence.
• BLASTX nucleotide (translated) query x protein
  database

AG-ICB-USP
30
BLAST search purpose/goal

• Which nucleotide sequences of the database are
  similar to my DNA sequence?
• I have sequenced a DNA fragment.
• I am interested to find out which DNA sequences
  of the database are similar to my nucleic acid
  sequence.
• BLASTN nucleotide query x nucleotide database

AG-ICB-USP
31
BLAST - search purpose/goal

• Which proteins translated from a nucleic acid
  database are similar to the conceptual
  translation of my DNA sequence?
• I have sequenced an EST (expressed sequence tag)
  that contains a protein coding region.
• I am interested to find out which ESTs of other
  organisms may be coding for homologous proteins.
• TBLASTX nucleotide (translated) query x
  nucleotide (translated) database

AG-ICB-USP
32
BLAST search purpose/goal

• Which proteins coded by the conceptual
  translation of the database sequences are similar
  to my protein sequence?
• I have a protein sequence on hands and am
  interested to find out which genes of other
  organisms may be coding for homologous proteins.
• TBLASTN protein query x nucleotide
  (translated) database

AG-ICB-USP
33
BLAST - programs

• BLASTP protein query x protein database
• BLASTN nucleotide query x nucleotide database
• BLASTX nucleotide (translated) query x protein
  database
• TBLASTN protein query x nucleotide (translated)
  database
• TBLASTX nucleotide query (translated) x
  nucleotide (translated) database

AG-ICB-USP
34
FastA format
BLAST query sequence

• The first line begins with the symbol 'gt'
  followed by the name of the sequence
• The sequence is on the remaining lines.
• The sequence must not contain blanks.
• The sequence could be in upper or lower case.
• Below is an example sequence in FASTA format\
• gtDNA sequence
• GCCCCCGGCCCCGCCCCGGCCCCGCCCCCGGCCCCGCCCCGCAAGGGTC
• ACAGGTCACGGGGCGGGGCCGAGGCGGAAGCGCCCGCAGCCCGGTACCG
• GCTCCTCCTGGGCTCCCTCTAGCGCCTTCCCCCCGGCCCGACTCCGCTG
• GTCAGCGCCAAGTGACTTACGCCCCCGACCTCTGAGCCCGGACCGCTAG

AG-ICB-USP
35
BLAST database

• Nucleotide databases
• nr, refseq, est_human, est_mouse, est_others,
  wgs, etc.
• Protein databases nr, Swiss-Prot, refseq, etc.

AG-ICB-USP
36
AG-ICB-USP
37
AG-ICB-USP
38
AG-ICB-USP
39
AG-ICB-USP
40
AG-ICB-USP
41
AG-ICB-USP
42
AG-ICB-USP
43
AG-ICB-USP
44
AG-ICB-USP
45
AG-ICB-USP
46
Blast programs

• PSI-BLAST Position-Specific Iterated BLAST
  program - performs an iterative search in which
  sequences found in one round of searching are
  used to build a score model for the next round of
  searching. In PSI-BLAST the algorithm is not tied
  to a specific score matrix.
• PHI-BLAST Pattern-Hit Initiated BLAST - a
  search program that combines matching of regular
  expressions with local alignments surrounding the
  match.
• MEGABLAST uses the greedy algorithm for
  nucleotide sequence alignment search - it can be
  up to 10 times faster than more common sequence
  similarity programs and handles much longer DNA
  sequences than the blastn program

AG-ICB-USP
