Hidden Process Models for Analyzing fMRI Data

1
Hidden Process Modelsfor Analyzing fMRI Data

• Rebecca Hutchinson
• Joint work with Tom Mitchell
• May 11, 2007
• Student Seminar Series
• In partial fulfillment of the Speaking
  Requirement
• Carnegie Mellon University
• Computer Science Department

2
Introduction

• Hidden Process Models (HPMs)
• A new probabilistic model for time series data.
• Designed for data generated by a collection of
  latent processes.
• Potential domains
• Biological processes (e.g. synthesizing a
  protein) in gene expression time series.
• Human processes (e.g. walking through a room) in
  distributed sensor network time series.
• Cognitive processes (e.g. making a decision) in
  functional Magnetic Resonance Imaging time series.

3
Process 1
Process P
d1 dN
d1 dN
t
t



t
t
Prior knowledge
There are a total of 6 processes in this window
of data.
An instance of Process 1 begins in this window.
An instance of Process P begins in this window.
An instance of either Process 1 OR Process P
begins in this window.
d1 dN
4
Process 1
Process P
d1 dN
d1 dN
t
t



t
t
Process 1 timings

Process P timings
More questions -Can we learn the parameters of
these processes from the data (even when we
dont know when they occur)? -Would a different
set of processes model the data better?
d1 dN
5
Simple Case Known Timing

• If we know which processes occur when, we can
  estimate their shapes with the general linear
  model.
• The timings generate a convolution matrix X

P
p1
p3
p2
1 0 0 0 0 0 0 0 0 0 1 0 1 0 0 1 0 0 0 0 1
0 1 0 0 1 0 0 0 0 0 0 1 0 0 1
t1 t2 t3 t4
T
6
Simple Case Known Timing
D
p1
p3
p2
D
1 0 0 0 0 0 0 0 0 0 1 0 1 0 0 1 0 0 0 0 1
0 1 0 0 1 0 0 0 0 0 0 1 0 0 1
W(1)
p1

p2
W(2)
Y
T
W(3)
p3
7
Challenge Unknown Timing
D
p1
p3
p2
D
1 0 0 0 0 0 0 0 0 0 1 0 1 0 0 1 0 0 0 0 1
0 1 0 0 1 0 0 0 0 0 0 1 0 0 1
W(1)
p1

p2
W(2)
Y
T
W(3)
p3
Uncertainty about the processes essentially makes
the convolution matrix a random variable.
8
Our Approach

• Model of processes contains a probability
  distribution over when it occurs relative to a
  known event (called a timing landmark).
• When predicting the underlying processes, use
  prior knowledge about timing to limit the
  hypothesis space.

9
fMRI Data
Hemodynamic Response
Features 10,000 voxels, imaged every
second. Training examples 10-40 trials (task
repetitions).
Signal Amplitude
Neural activity
Time (seconds)
10
(No Transcript)
11
Study Pictures and Sentences
Press Button
View Picture
Read Sentence
Read Sentence
View Picture
Fixation
Rest
4 sec.
8 sec.
t0

• Task Decide whether sentence describes picture
  correctly, indicate with button press.
• 13 normal subjects, 40 trials per subject.
• Sentences and pictures describe 3 symbols , ,
  and , using above, below, not above, not
  below.
• Images are acquired every 0.5 seconds.

12
Goals for fMRI

• To track cognitive processes over time.
• Estimate process hemodynamic responses.
• Estimate process timings.
• Allowing processes that do not directly
  correspond to the stimuli timing is a key
  contribution of HPMs!
• To compare hypotheses of cognitive behavior.

13
HPM Modeling Assumptions

• Model latent time series at process-level.
• Process instances share parameters based on their
  process types.
• Use prior knowledge from experiment design.
• Sum process responses linearly.

14
Process 1 ReadSentence Response signature
W Duration d 11 sec. Offsets W 0,1
P(?) q0,q1
Process 2 ViewPicture Response signature
W Duration d 11 sec. Offsets W 0,1
P(?) q0,q1
Processes of the HPM
v1 v2
v1 v2
Input stimulus ?
sentence
Timing landmarks ?
Process instance ?2 Process h 2 Timing
landmark ?2 Offset O 1 (Start time ?2 O)
?1
?2
One configuration c of process instances
?1, ?2, ?k (with prior fc)
?1
?2
?
Predicted mean
N(0,s1)
v1 v2
N(0,s2)
15
HPM Formalism

• HPM ltH,C,F,Sgt
• H lth1,,hHgt, a set of processes (e.g.
  ReadSentence)
• h ltW,d,W,Qgt, a process
• W response signature
• d process duration
• W allowable offsets
• Q multinomial parameters over values in W
• C ltc1,, cCgt, a set of configurations
• c ltp1,,pLgt, a set of process instances
• lth,l,Ogt, a process instance (e.g.
  ReadSentence(S1))
• h process ID
• timing landmark (e.g. stimulus presentation of
  S1)
• O offset (takes values in Wh)
• ltf1,,fCgt, priors over C
• S lts1,,sVgt, standard deviation for each voxel

16
HPMs the graphical model
Configuration c
Timing Landmark l
The set C of configurations constrains the
joint distribution on h(k),o(k) " k.
Process Type h
Offset o
Start Time s
S
p1,,pk
observed
unobserved
Yt,v
t1,T, v1,V
17
Encoding Experiment Design
Processes
Input stimulus ?
Constraints Encoded h(p1) 1,2 h(p2)
1,2 h(p1) ! h(p2) o(p1) 0 o(p2) 0 h(p3)
3 o(p3) 1,2
ReadSentence 1
ViewPicture 2
Timing landmarks ?
?2
?1
Decide 3
Configuration 1
Configuration 2
Configuration 3
Configuration 4
18
Inference

• Over configurations
• Choose the most likely configuration, where

• Cconfiguration, Yobserved data, Dinput
  stimuli, HPMmodel

19
Learning

• Parameters to learn
• Response signature W for each process
• Timing distribution Q for each process
• Standard deviation s for each voxel
• Expectation-Maximization (EM) algorithm to
  estimate W and Q.
• E step estimate a probability distribution over
  configurations.
• M step update estimates of W (using reweighted
  least squares) and Q (using standard MLEs) based
  on the E step.
• After convergence, use standard MLEs for s.

20
Uncertain Timings

• Convolution matrix models several choices for
  each time point.

Configurations for each row
P
D
S
1 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 1
0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0
0 0 1 0 0 0 0 1 0 0 0 1 0 0 0 0
0 1 0 0 0 0 0 1 0 1 0 0 0 0 0 0 1 0 0
1 ...
t1 t1 t2 t2 t18 t18 t18 t18
3,4 1,2 3,4 1,2 3 4 1 2
TgtT
21
Uncertain Timings

• Weight each row with probabilities from E-step.

P
D
S
Configurations
Weights
e1 e2 e3 e4
3,4 1,2 3,4 1,2
1 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 1
0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0

Y

W
e1 P(C3Y,Wold,Qold,sold) P(C4Y,Wold,Qold,s
old)
22
Learned HPM with 3 processes (S,P,D), and d13sec.
S
S
P
P
D?
D?
observed
23
ViewPicture in Visual Cortex
Offset q P(Offset) 0 0.725 1 0.275
24
ReadSentence in Visual Cortex
Offset q P(Offset) 0 0.625 1 0.375
25
Decide in Visual Cortex
Offset q P(Offset) 0 0.075 1 0.025 2 0.025 3
0.025 4 0.225 5 0.625
26
ViewPicture
27
ReadSentence
28
Seconds following the second stimulus
Multinomial probabilities on these time points
Decide
29
Comparing Models
5-fold cross-validation, 1 subject P
ViewPicture S ReadSentence S
ReadAffirmativeSentence S- ReadNegatedSentence
D Decide D DecideAfterAffirmative D-
DecideAfterNegated Dy DecideYes Dn
DecideNo Dc DecideConfusion B Button
- This HPM can also classify Dy vs. Dn with
92.0 accuracy. GNBC gets 53.9. (using the
window from the second stimulus to the end of the
trial)
30
Are we learning the right number of processes?

• Use synthetic data where we know ground truth.
• Generate training and test sets with 2/3/4
  processes.
• Train HPMs with 2/3/4 processes on each.
• For each test set, select the HPM with the
  highest data log likelihood.

31
Related Work

• fMRI
• General Linear Model (Dale99)
• Must assume timing of process onset to estimate
  hemodynamic response.
• Computer models of human cognition (Just99,
  Anderson04)
• Predict fMRI data rather than learning parameters
  of processes from the data.
• Machine Learning
• Classification of windows of fMRI data (Cox03,
  Haxby01, Mitchell04)
• Does not typically model overlapping hemodynamic
  responses.
• Dynamic Bayes Networks (Murphy02, Ghahramani97)
• HPM assumptions/constraints are difficult to
  encode in DBNs.

32
Future Work

• Incorporate spatial prior knowledge. E.g. share
  parameters across voxels (extending Niculescu05).
• Smooth hemodynamic responses (e.g. Boynton96).
• Improve algorithm complexities.
• Apply to open cognitive science problems.

33
Conclusions

• Take-away messages
• HPMs are a probabilistic model for time series
  data generated by a collection of latent
  processes.
• In the fMRI domain, HPMs can simultaneously
  estimate the hemodynamic response and localize
  the timing of cognitive processes.

34
References
John R. Anderson, Daniel Bothell, Michael D.
Byrne, Scott Douglass, Christian Lebiere, and
Yulin Qin. An integrated theory of the mind.
Psychological Review, 111(4)10361060, 2004.
http//act-r.psy.cmu.edu/about/. Geoffrey M.
Boynton, Stephen A. Engel, Gary H. Glover, and
David J. Heeger. Linear systems analysis of
functional magnetic resonance imaging in human
V1. The Journal of Neuroscience,
16(13)42074221, 1996. David D. Cox and Robert
L. Savoy. Functional magnetic resonance imaging
(fMRI) brain reading detecting and classifying
distributed patterns of fMRI activity in human
visual cortex. NeuroImage, 19261270,
2003. Anders M. Dale. Optimal experimental
design for event-related fMRI. Human Brain
Mapping, 8109114, 1999. Zoubin Ghahramani and
Michael I. Jordan. Factorial hidden Markov
models. Machine Learning, 29245275,
1997. James V. Haxby, M. Ida Gobbini, Maura L.
Furey, Alumit Ishai, Jennifer L. Schouten, and
Pietro Pietrini. Distributed and overlapping
representations of faces and objects in ventral
temporal cortex. Science, 29324252430,
September 2001. Marcel Adam Just, Patricia A.
Carpenter, and Sashank Varma. Computational
modeling of high-level cognition and brain
function. Human Brain Mapping, 8128136, 1999.
http//www.ccbi.cmu.edu/project
10modeling4CAPS.htm. Tom M. Mitchell et al.
Learning to decode cognitive states from brain
images. Machine Learning, 57145175,
2004. Kevin P. Murphy. Dynamic bayesian
networks. To appear in Probabilistic Graphical
Models, M. Jordan, November 2002. Radu Stefan
Niculescu. Exploiting Parameter Domain Knowledge
for Learning in Bayesian Networks. PhD thesis,
Carnegie Mellon University, July 2005.
CMU-CS-05-147.
