Kenntnisbasierte ASR

1
(No Transcript)
2
The definition of sound segments in phonetics
and speech technology
Intensive course Centre of Information
Society Technologies Sofia University St.
Kliment Ohridski 18. - 22. Februar 2002 Jacques
Koreman jkoreman_at_coli.uni-sb.de Bistra
Andreeva andreeva_at_coli.uni-sb.de Trajan
Iliev t_iliev_at_fmi.uni-sofia.bg Institute of
Phonetics University of the Saarland P.O. Box
15 11 50 D - 66041 Saarbrücken Germany
3
Overview of the course

• Monday introduction and discussion of student
  projects
• Tuesday 9-11 ASR techniques hidden
  Markov modelling (JK) 11-13 A formal
  description of Bulgarian sound segments (BA)
• Wednesday 9-11 ASR techniques neural
  networks (JK) 11-13 The acoustic description
  of speech signals (BA)
• Thursday 9-11 The segmentation of
  speech sounds using NNs (TI) 11-13 Sound
  segments and their boundaries (BA)
• Friday discussion of student projects

4
(No Transcript)
5
The definition of sound segments in phonetics
and speech technology

• Preamble

6
Goal of ASR systems

• Automatic speech recognition (ASR) systems take
  the microphone signal as their input and
  recognise utterances as a sequence of words.
• In order to achieve this, speech sounds must be
  recognised from the signal and matched to (a
  sequence of) words in the lexicon. By doing this,
  sound sequences which do not constitute a
  sequence of words are excluded from the search.

7
Goal of ASR systems

• Since the microphone signal (reflecting the
  variations in air pressure which constitute the
  signal) is not a very informative representation,
  we first derive some sort of spectral
  representation from the signal. The spectrum does
  contain all the information we need to identify
  speech sounds.

8
Microphone signal spectrogram
d
e
p0
s
i
m
a
l
z
Y
b0
s
p0
t
e
m


(
9
Finding sounds in the spectrum

• Two problems must be solved to find sounds in the
  speech signal
• segmentation slicing the signal into sounds
• identification determining which sounds
  were spoken

10
Segmentation

• Segmentation is difficult, because speech is
  produced in a single flow, i.e. there are no
  pauses between the words and the articulators are
  constantly moving from one position to the next.
• In some sound types the movement is intrinsic to
  the sound glides and diphthongs. But only when
  people speak slowly, we find so-called steady
  states in the signal. The interpretation of the
  movement depends on context, accentuation,
  speaking rate.

Have you ever tried to identifythe word or phone
boundariesin a language you do not know?!
11
Identification

• Identification is also difficult, because no
  sound is produced the same twice. This is due to
  differences between speakers (and even the same
  speaker will never produce a sound exactly the
  same twice), context, accent and dialect,
  accentuation, situation (e.g. formal or
  informal), etc.etc.
• Example pan span ban
• Conclusion a sound can not always be identified
  on the basis of fixed cues!

12
The history of ASR systems

• The first ASR systems were knowledge-based, i.e.
  they used phonetic knowledge about the
  realisation of speech sounds to identify them in
  the signal. The best results were achieved if
  broad sound classes were detected in a first
  step, and then a set of matching word candidates
  were selected, on the basis of which a fine
  search for distinguishing phonetic properties was
  then carried out.

13
The history of ASR systems

• Although a few people still work with
  knowledge-based systems, most of the systems used
  nowadays are stochastic, i.e. they do not attempt
  to find specific phonetic characteristics of
  speech sounds in an all-or-none approach, but use
  probabilities of general spectral properties to
  compute a model for each speech sound.
• For this reason, we shall only discuss stochastic
  modelling techniques in this course.

14
References knowledge-based ASR

• Broad, D. und Shoup, J. (1975). Concepts for
  acoustic phonetic recognition. In D. Reddy,
  Speech Recognition. New York Academic Press.
• Zue, V. (1990). The use of speech knowledge in
  automatic speech recognition. In A. Waibel and
  K.-F. Lee, Readings in Speech Recognition, pp.
  200-213. San Mateo Morgan Kaufmann Publishers,
  Inc.

15
References knowledge-based ASR

• Stevens, K. (2000). From acoustic cues to
  segments, features and words, Proc. Int. Conf. On
  Spoken Lang. Proc. (ICSLP2000), Beijing.
• Reetz (1999). Converting speech signals to
  phonological features. Proc. of the XIVth Conf.
  Of Phonetic Sciences (ICPhS99), San Francisco,
  1733-1736.
• Lahiri (2000). Underspecified recognition. Proc.
  of the Conf. on Laboratory Phonology
  (LabPhon2000).

16
(No Transcript)
17
The definition of sound segments in phonetics
and speech technology

• ASR techniques hidden Markov modelling

18
Hidden Markov modelling
Hidden Markov modelling is a stochastic
technique, which means that it models variation
(the variation in the signal) by using
probabilities. Usually, each sound (sometimes
word or word sequence) is represented by a hidden
Markov model (HMM). Whole utterances are then
modelled as a sequence of words, each of which
constitutes a sequence of sounds. The sequence of
words with the highest probability is
recognised.
19
Hidden Markov modelling
The a-priori probability of the words (lexicon)
and of word sequences (language) model play an
important role in computing the most likely
sequence of HMMs to have generated an acoustic
signal. I shall come back to this later. But let
us first look at how the match between an
acoustic signal and a sequence of HMMs is
determined.
20
Markov modelling

• Markov models consist of states which are
  connected by transitions.
• When the automaton is in a specific state, it
  emits a symbol (e.g. an acoustic vector)
• Each transitions between two states has a
  probability associated with it.
• Lets first look at a simple example, in which
  the states are represented by containers with
  coloured balls.

stochasticmodelling
21
MMs a simple example

• We start in state S, which does not emit a
  symbol. From there, we go to state 1 with
  probability 1.
• There we take a black ball from the container.

22
MMs a simple example

• Then we either continue to the 2nd state (p
  0.4) and take a red ball or we go to state 1
  again (self-loop) and take another black ball
  from the container.
• We continue until we get to state E and have
  collected a sequence of coloured balls.

23
MMs a simple example

• We can now compute the probabilty that the HMM
  displayed below generated the shown sequence of
  observations as

in fact, we should have written x1 for each ball
takenfrom the container
1x0.6x0.4x0.5x0.5x0.5x05x05x0.5x0.7x0.7x0.7x0.3
24
Hidden Markov modelling

• Hidden Markov models (HMMs) differ from Markov
  models in that the state emissions cannot be
  allotted to only a particular state.
• In our example this would be the case, if all
  three (emitting) containers are filled with red,
  black and yellow balls.
• The percentage of balls of the different colours
  can be different for the three containers, so
  that the colour emissions have different
  probabilities for each of the three states.

25
HMMs a simple example

• We start in state S, which does not emit a
  symbol. From there, we go to state 1 with
  probability 1.
• There we take a ball from the container, which
  can now be red, black or yellow.

26
HMMs a simple example

• Then we go on to the 2nd state (p 0.4) and take
  a ball from the container or we go to state 1
  again and take another ball from that container.
• We continue until we get to state E and have
  collected a sequence of coloured balls.

27
HMMs hidden states

• In the situation that we can see a sequence of
  coloured balls it is now impossible to recognise
  with certainty in which states (from which
  container) each ball has been taken. The states
  are hidden, that is why we speak of hidden
  Markov modelling. 1 1 1 1 1 2 2 2 2 3 3 3 1
  1 1 2 2 2 2 2 3 3 3 3 etc.

28
HMMs speech recognition

• Sequence of coloured balls acoustic frames of
  parameter vectors.
• It is the task of the ASR system to identify the
  sequence of states which is most likely to have
  generated/emitted the frame sequence representing
  an utterance. This is dependent on the transition
  and emission probabilities of the states.

29
HMMs transitions

• In ASR left-to-right models (as in the previous
  graphical representations) are used, because the
  acoustic events are ordered in time. Vowels, for
  instance, are often thought of as a sequence of
  onset transition, steady state and offset
  transition.
• If a model is trained for pauses, transitions are
  allowed from each state to any other state
  (including self-loops), because the sequence of
  acoustic events is random (ergodic model).

30
HMMs emissions

• Emissions can be described using
• a vector codebook a fixed number of vectors are
  used to represent the acoustic space. They are
  related to states by state-specific emission
  probabilities.
• Gaussian mixtures the variation in the acoustic
  realisation in each state is described by a
  normal distribution.

31
HMMs complex models

• More complex models are also used
• parallel states and multiple mixtures can capture
  the variation in the realisation of speech sounds
  (speaker, dialect, context, etc.) more
  effectively.
• Generalised triphones describe a speech sound in
  different contexts. The contexts are grouped
  (e.g. according to place of articulation or on
  the basis of data-driven clustering techni-ques.
  The grouping reduces the requirements in terms of
  the size of the training corpus.

32
HMMs speech recognition

• There are several state sequences which can
  generate the same signal (frame sequence). The
  state sequence with the highest probability is
  found using the Viterbi algorithm.
• This is done for all HMMs. The HMM leading to the
  highest probability is recognised.
• Since we do not usually want to recognise a
  single speech sound, but a sequence of speech
  sounds, the optimisation is performed over
  sequences of HMMs.

33
HMMs lexicon language model

• HMM is now used for continuous, spontaneous
  speech recognition. Besides acoustic (hidden
  Markov) models, we also need a lexicon and a
  language model.
• In the lexicon, all the words (or morphemes)
  which the system must be able to recognise are
  listed with their pronunciation.
• In the language model, all the possible
  combinations of lexical entries are described.

34
HMMs lexicon

• The lexicon entries consist of an orthographic
  word and its realisation in terms of a sequence
  of HMMs for speech sounds.
• In order to better cope with variation in the
  pronunciation of words, pronunciation variants
  are sometimes added to the lexicon which include
  reductions, epentheses and assimilations.

35
HMMs lexicon

• Phonological processes can lead to a change in
  the identity of a speech sound

• deletion
• insertion
• assimilation

36
Phonological variation
HMMs lexicon

• deletion
• A speech sound which is there in the so-called
  canonical form (lexicon form), is not realised.

• ........., isnt it??... ?????
• (G.) Fährst du mit dem Bus??.......... ???????

37
Phonological variation
HMMs lexicon

• insertion
• A speech sound which is not there in the
  canonical form (lexicon form) is inserted.

• tense - tents
• (G.) Gans - Ganz

38
Phonological variation
HMMs lexicon
39
HMMs lexicon

• assimilation
• The phonological identity of a speech sound
  changes under the influence of the (segmental or
  prosodic) context in which it occurs.

• input (cf. spelling immediate)
• but not sometimes, some guys

40
HMMs lexicon

• Pronunciation variants in the lexicon reduce the
  distance between an acoustic realisation and the
  lexical entry.
• At the same time, however, the distance between
  lexical entries becomes smaller, which can lead
  to the misrecognition of words. For this reason,
  we often only add the most frequent pronunciation
  variants, e.g. for function words, to improve
  recognition.

41
HMMs language model

• The language model can be implemented as a
• rule system these have the advantage that they
  can lead to a better understanding of the
  linguistic properties of utterances.
• probabilistic system n-gram probabilities are
  computed for word sequences. They general-ise
  less and need a lot of training data. If the test
  condition matches the training well (text type,
  lexical domain, etc.), they describe the observed
  speech behaviour very well.

42
HMMs language model

• Orthographically distinguishable utterances can
  have identical acoustic realistions. The language
  model can choose one of two possible readings
  dependent on the probabilities of the word
  sequences.
• Example r??????sp???

Recognise speech
Wreck a nice beach
43
HMMs language model

• Orthographically distinguishable utterances can
  have identical acoustic realistions. The language
  model can choose one of two possible readings
  dependent on the probabilities of the word
  sequences.
• Example ???????????????

Get up at eight oclock
Get a potato clock
44
HMMs applications

• HMM systems are used in
• information systems (travel information)
• hands-free telephony
• spoken input, e.g. in navigation systems
• aids for the handicapped
• dictation systems, e.g. NaturallySpeaking
  (Dragon), ViaVoice (IBM), FreeSpeech (Philips)

45
References

• Van Alphen, P. und D. van Bergem (1989). Markov
  models and their application in speech
  recognition, Proceedings Institute of Phonetic
  Sciences, University of Amsterdam 13, 1-26.
• Holmes, J. (1988). Speech Synthesis and
  Recognition (Kap. 8). Wokingham (Berks.) Van
  Nostrand Reinhold, 129-152.

46
References

• Cox, S. (1988). Hidden Markov models for
  automatic speech recognition theory and
  application, Br. Telecom techn. Journal 6(2),
  105-115.
• Lee, K.-F. (1989). Hidden Markov modelling
  past, present, future, Proc. Eurospeech 1989,
  vol. 1, 148-155.

47
(No Transcript)
48
The definition of sound segments in phonetics
and speech technology

• ASR techniques neural networks

49
Neural networks

• Artificial neural networks are particularly
  suited for the classification of input signals,
  e.g. to recognise to what sound an acoustic frame
  belongs.
• They are not suited to integrate information over
  time.

50
NNs biological basis

• The building blocks of a neural net are based on
  the functionality of biological nerve cells, as
  they are found in the brain (about 1010 neurons).
• As a simplifying statement we could say that a
  nerve cell does no more (nor any less) than
  compute a weighted sum of its inputs and create
  an output dependent on this weighted sum.

51
NNs biological neuron
synapses on cell body
axon
propagation of activation
cell body (soma)
A membrane surroundsthe neuron
dendrites
52
NNs biological neuron

• An axon carries the signal. It is long and can
  split itself several times. The ends of an axon
  are connected to dendrites or to the cell body of
  another nerve cell by means of synapses.
• Once the threshold for the electric potential of
  a synapse is exceeded, the impulse propagates
  across the synapse.
• The threshold of a synapse changes, if it is
  rarely/frequently activated.

53
NNs artificial neuron

• Like a biological neuron, an artificial neuron
  has one or more inputs (cf. dendrites and axons
  directly connected to the cell body).
• The function of a synapse is described by the
  activation function.
• The output is generated on the basis of the
  activation.

54
NNs artificial neuron
input vectorx x1, x1,...., xn
output valuey f(z)
weights vectorw w1, w1,...., wn
activationz F(x,w)
x1
w1
y f(z)
z F(x,w)
w2
x2
wn
xn
55
NNs artificial neuron
Just a single neuron can distinguish two
categories. A simple NN consisting of one single
neuron can determine for instance whether water
is contaminated or not. This would be the case,
when specific measures exceed a threshold. Y
output z activation, is dependent on
inputs x and weights w f function linear,
threshold, sine, etc.
yf(z)
output
activation
56
NNs 2 main types
A NN is built up from single neurons. Two main
types of neural networks are distinguished, which
we shall discuss hereafter

• multi-layer perceptrons (MLPs)
• Kohonen networks

57
NNs MLP
By combining many neurons, the NN can learn very
complex relationships. A standard MLP consists of
the following layers

• Input layer number of input units equals the
  number of signal parameters
• Hidden layer (or layers) usually configured so
  that all units are connect to the units in the
  input layer and to each other
• Output layer number of units equals the number
  of categories to be distinguished.

58
MLPs graphic display
Output layer Hidden layer 2 Hidden layer 1 Input
layer
59
MLPs connections
The connections between the units are learnt in
the training. Learning rules determine how the
(initially random) weights are optimised
dependent on the distance to the required output
(supervised learning). Because of the connections
between the units, the computation with NNs is
also called connectionism. Since the
information is processed by many units in
parallel, the expression parallel distributed
processing (PDP) is also used.
60
MLPs time
NNs are very suitable for categorising single
input frames. Change over time is not handled so
well. Several solutions to this problem have been
suggested

• inputframe plus several contextframes
• time-delayed NNs

61
NNs Kohonen networks

• In MLPs the output computed by the NN for each
  input is compared with the required out-put
  (supervised). On the basis of the difference
  between computed and required output, the weights
  of the connections between the units are adapted
  (usually by backpropagation).
• Kohonen networks, on the other hand, are
  unsupervised. For this reason they are also
  called self-organised.

62
NNs Kohonen networks

• Kohonen networks only consist of an input and an
  output layer (competitive layer).
• The units in the input layer are connected to all
  the units in the output layer.
• All connections are weighted.

63
Kohonen networks training

• At the start the weights of each unit are
  initialised with a vector of small random values
  (the vecor size equals the number of input
  parameters).
• In the training the unit whose weights are
  closest (Euclidian distance) to the input vector
  wins.
• The connection weights of the winning neuron are
  adapted in the direction of the input vector,
  without using information about the required
  output (unsupervised learning).

64
Kohonen networks weights

• The units weights are adapted so, that they
  better predict the input vector. A similar, but
  smaller adatation is made for units which are
  close to the winning neuron in the
  self-organising map, while units which are
  farther away are inhibited (mexican hat
  function).
• In this way, clusters build up in the network,
  which organise information in a
  topographical/phonotopic way.

65
Kohonen networks calibration

• At the end of the training the Kohonen network is
  calibrated to each input vector (e.g. of
  acoustic parameters) is attached the required
  output (e.g. speech sound).
• For each neuron, a list is created of the speech
  sounds by which it has been activated, together
  with the number of times each speech sound
  activated the neuron.
• At the end of the calibration, a probability is
  computed for each neuron that it was activated by
  each speech sound.

66
Kohonen nets graphic display
67
Kohonen nets graphic display
Phonotopic map calibrated with speech sounds
(part)
68
Kohonen nets graphic display
Phonotopic map calibrated with speech sounds
(part)
69
Hybrid system

• As we said at the beginning, neural nets are good
  at discriminating, but bad at modelling time.
• One way of overcoming this problem is by using a
  hybrid system, in which the output of the neural
  net is used as input to hidden Markov modelling.

70
Hybrid systems
phone
phone
Kohonen network
MLP
spectral parameters
spectral parameters
71
References

• Lippmann, R.P. (1989). Review of neural
  net-works for speech recognition, in A. Waibel
  und K.-F. Lee, Readings in Speech Recognit-ion,
  374-392. San Mateo Morgan Kaufmann.
• Ritter, H., T. Martinez und K. Schulten (1992).
  Neural Computation and Self-Organizing Maps, Kap.
  2 - 4. Bonn Addison-Wesley.
• Kohonen, T. (1988). The neural phonetic
  typewriter, in A. Waibel und K.-F. Lee,
  Readings in Speech Recognition, 413-424. San
  Mateo Morgan Kaufmann.

72
(No Transcript)
73
Einführung in dieautomatische Spracherkennung

• Dynamic Time Warping
• Sommersemester 2001
• Jacques Koreman

74
Dynamic time warping (DTW)

• Weil das Auffinden von invarianten akustischen
  Cues für Laute im Signal sich als sehr schwer
  herausgestellt hat, wird in vielen Systemen eine
  allgemeine Mustererkennung verwendet.
• Die ersten Mustererkennungssysteme verwendeten
  dynamic time warping (DTW), auch dynamische
  programmierung genannt.
• Die Erkennungseinheit war meistens das Wort (also
  keine kontinuierliche Spracherkennung!).

75
Das Prinzip

• Für jedes Wort, das erkannt werden soll, wird ein
  Referenzmuster (E. template) gespeichert, mit
  dem alle Inputsignale verglichen werden. Das
  Referenzmuster, das die größte Ähnlichkeit zum
  Inputsignal aufweist, wird erkannt.
• Vorteil koartikulatorische Effekte die Variation
  in der Lautrealisierung zufolge haben (Problem
  für kenntnisbasierte Spracherkennung) werden
  mitmodelliert.

76
Das Referenzmuster

• Da wir wissen, daß die reine Schalldruckwelle,
  die mit dem Mikrofon aufgenommen werden kann, von
  Realisierung zu Realisierung stark
  unterschiedlich sein kann, wird eine andere
  Darstellung für das Referenzmuster verwendet. Sie
  besteht aus Parametern, die die Änderung der
  Verteilung der Energie über das Frequenz-spektrum
  darstellen (vgl. Spektrogramm).

77
Das Referenzmuster Abtastrate

• Früher wurden die Parameter wegen dem Anspruch an
  Speicherkapazität einmal pro 10 oder 20 ms.
  abgeleitet. Heutzutage ist die Speicherkapazität
  meistens kein Problem mehr und wird alle 5 ms.
  eine Vektor von Parametern berechnet (manchmal
  sogar ein mal pro Milli-sekunde).

78
Das Referenzmuster Parameter

• Die Parametrisierung des Signals kann bestehen
  aus

• Filterbankparametern (linear rein akustisch
  Beschreibung)
• Filterbankparametern (logarithmisch
  perzeptorische Modellierung)
• LPC Analyseparametern (Modellierung des
  Produktionssystems)

79
Das Referenzmuster Beispiel
Output einer 9-Kanals Filterbank für eine
Realisierung vom Wort three und zwei vom Wort
eight. Wie erwar-tet, sind die beiden eight
ähnlicher (Holmes, S. 104).
80
Der Vergleich
Jedes Referenzmuster wird mit dem Inputsignal
verglichen. Dabei können Unterschiede in
Lautstärke, Intonation und zeitlicher
Realisierung vorliegen. DTW ist vor allem
geeignet, um zeitliche Änderungen zu modellieren.

• Der Effekt von Lautstärke-Unterschieden, die in
  den meisten Fällen für den Unterschied zwischen
  Wörtern nicht relevant sind) wird geringer, wenn
  die Energie logaritmisch dargestellt wird.

81
Der Vergleich

• Die Tonhöhe ist für den Unterschied zwischen
  Wörtern normalerweise nicht relevant (bis auf
  mikroprosodische Effekte). Sie wird dadurch
  ge-glättet, daß man breite Frequenzbänder wählt
  und ein längeres Zeitfenster benutzt, wodurch die
  einzelnen Perioden gepooled werden.
• Zeitliche Änderungen entstehen durch
  unter-schiedliche Sprechgeschwindigkeiten, wobei
  auch lokale Änderungen (innerhalb des Wortes)
  auftreten können.

82
Der vergleich
Für Unterschiede in Sprechgeschwindigkeit kann
man dadurch kompensieren, daß man das
Input-muster ausdehnt (wenn es schnell gesprochen
wurde) oder komprimiert (wenn es langsam
gesprochen wurde), bevor man das Abstands-maß
berechnet. Mögliche Anpassungen (E. matchings)

• Keine
• linear
• non-linear

83
Der Vergleich Visualisierung
Akustisches Muster und Vergleichsmaß (a)(b)
akust. Muster x und y, (c) keine zeitliche
Anpassung, (d) lineare und (e) nicht-lineare
Anpassung (Huang et al., S.72)
84
Der Vergleich die Diagonale
Wenn man das Testwort auf der x-Achse und das
Referenzmuster auf der y-Achse darstellt, stellt
die Diagonale den perfekten Pfad dar, da sie
bedeutet, daß die beiden Wortrealisierungen genau
gleich sind. Jede Abweichung von der Diagonale
wird bestraft. Die Summe dieser Abweichungen (für
die Energie in Filterbändern oft Euklidische
Abstände zwischen Referenzframe und Inputframe)
ergibt ein Abstandsmaß zwischen Inputwort und
Referenzmuster.
85
Der Vergleich Visualisierung
DTW Pfad für Test- und Referenzwort (Holmes, S.
116)
86
Der Vergleich Beschränkung

• Negative Steigungen sind nicht erlaubt (die
  Reihenfolge der Realisierung ist immer von links
  nach rechts).
• Seitenpfade, die einen zu großen Abstandswert
  aufweisen, werden abgeschnitten (E. pruning).

87
Probleme

• Die Wahl des Referenzmusters für ein Wort kann
  die Erkennung stark beeinflussen.
• Die Annahme, daß Anfangs- und Endpunkt des Wortes
  korrekt gefunden werden, ist nicht immer gegeben.
• DTW eignet sich nicht sehr gut für die Erkennung
  kontinuierlich gesprochener Sprache, da jedes
  Frame der Anfang eines neuen Wortes darstellen
  kann, so daß die Zahl der Vergleiche
  explosionsartig zunimmt (z.B. six teenagers
  versus sixteen ages)..

88
Literaturangaben

• Holmes, J. (1988). Speech Synthesis and
  Recognition (Kap. 7).Wokingham (Berks.) Van
  Nostrand Reinhold.
• Holmes, J. (1991). Spracherkennung und
  Sprachsynthese (Kap. 7). München Oldenburg.
• Huang, X.-D., Ariki, Y. und Jack, M. (1990).
  Hidden Markov Models for Speech Recognition, S.
  70-78. Edinburgh Edinburgh University Press.

89
(No Transcript)
