By Ajith U Kamath 60-564 Project

1
ByAjith U Kamath60-564 Project
Survey onAreas of standardizationForSecuring
Ad hoc networks

2
Based on

• Standardization Areas for securing Ad hoc
  networks
• By Rajesh Talpade and Anthony McAuley
• Data Security in Ad hoc networks using Multipath
  routing
• By Souheila Bouam and Jalel Ben-Othman

3
AGENDA

• Introduction
• Attacks in Ad hoc networks and Areas of
  standardization
• Node configuration
• Key Management
• Routing protocol security
• Data security based on multipath routing
• Intrusion Detection
• Conclusion

4
Introduction

• What are Mobile Ad hoc networks ?
• Characteristics
• Problems encountered

5
Attacks in Ad hoc networks

• Passive attacks
• Active attacks
• Black hole attack
• Worm hole attack
• Routing tables overflow attacks

6
Attacks in Ad hoc networks

• Active attacks
• Sleep deprivation attacks
• Location disclosure attacks
• Denial of service attacks
• Impersonation attacks
•   "Problems worthy of attack prove their worth by
  hitting back. By Piet Hein

7
Areas of Standardization

• It is expected in future, multi vendor ad hoc
  devices would inter-operate securely on a large
  scale.
• Standardization Areas,
• Node configuration
• Key management
• Routing protocol security
• Intrusion detection

8
Node Configuration

• In realistic deployment scenarios nodes of ad
  hoc network should support auto-configuration.
• Link Local IP address assignment
• Private address spaces (e.g. 169.254/16 prefix)
• IPv6 address generation based on hardware
  interface
• Problems different designs for different
  link-layers, non-unique interface addresses in
  some link-layers or vendors, and changeable
  interface addresses.

9
Node Configuration

• Distributed dynamic host configuration protocol
• MANET Initialization
• New node joining the MANET
• Graceful departure of the node
• Migration of Requester
• tolerate message losses, network partitioning and
  mergers
• does not account for the possibility of nodes
  behaving maliciously

10
Key Management

• For enforcing confidentiality, integrity,
  authentication and non-repudiation of messages in
  ad hoc networks.
• Key management Service through CA
• A centralized CA-based approach is not
  applicable to ad hoc networks.
• Replicating the CA, introduces the problem of
  maintaining the synchronization across the
  multiple CAs

11
Key Management

• Threshold cryptography
• An (n t 1) threshold cryptography scheme
  allows n parties to share the ability to
  perform a cryptographic operation, so that any t
  1 parties can perform this operation jointly,
  whereas it is infeasible for at most t parties
  to do so, even by collusion.

12
Key Management

• But places unreasonable requirement of forcing
  some nodes to volunteer for specific roles.

Ref Parallel reliable threshold multisignature
by Yair Frankel and Yvo G
13
Key Management

• Self organized public key infrastructure
• Public key certificates are issued by the users.
• When user u wants to obtain the authentic public
  key of user v, it acquires a chain of public key
  certificates such that the first certificate of
  the chain can directly be verified by u using a
  public key that u holds and trusts.
• Similar to PGP but self organized.
• The approach is probabilistic.

14
Key Management
Ref The Quest for Security in Mobile Ad Hoc
Networks by Jean-Pierre Hubaux, Levente Buttyan
and Srdan Capkun
15
Routing Protocol Security

• An attacker can inject incorrect routing
  information, replay old information, or cause
  excessive load to prevent proper routing protocol
  functioning.
• Data security based on multipath routing.
• Exploit the feature of existence of multiple
  paths between nodes in an Ad hoc network.

16
Routing Protocol Security

• Assumptions made by the protocol
• The sender A and the receiver B are
  authenticated.
• WEP (Wireless Equivalent Privacy) is used for the
  encryption/decryption of all the frames at MAC
  layer and the authentication of the terminals.
• A mechanism of discovering the topology of the
  network is available.
• The used routing protocol supports multi-routes.

17
Routing Protocol Security

• Description
• It uses n routes (n 3) among N available.
• There exist two types of channels
• The original message m is divided into (n-1)
  parts.
• The protocol generates, then, a random number x
  (1lt x (n-1), x integer).
• Algorithm can be run with both reactive and
  proactive routing protocols.

18
Routing Protocol Security
Ref Data Security in Ad hoc Networks Using
MultiPath Routing By Souheila BOUAM and Jalel
BEN-OTHMAN
19
Routing Protocol Security

• Position of SDMP

• The SDMP header

20
Routing Protocol Security

• Improvements
• (Accepted in the 2004 International Workshop on
• Mobile Ad Hoc Networks and Interoperability
  Issues.)
• Error and Retransmit management

Ref Securing Data Transmissions and
Retransmissions Management in Ad hoc Networks By
Souheila BOUAM and Jalel BEN-OTHMAN
21
Routing Protocol Security

• Experimental results
• Sending data using the algorithm (n8 and n4)
  and using classical method with one channel are
  compared. The transmitted file is 4.48 MB length
  and length of each block is 64 Kbytes.

Ref Data Security in Ad hoc Networks Using
MultiPath Routing By Souheila BOUAM and Jalel
BEN-OTHMAN
22
Routing Protocol Security

• In the second test, different block sizes at each
  data transmission were used. A base file of 19200
  Bytes was used.

Ref Data Security in Ad hoc Networks Using
MultiPath Routing By Souheila BOUAM and Jalel
BEN-OTHMAN
23
Routing Protocol Security

• Drawbacks of the protocol
• Diversity coding provides single line failure
  with only one extra line instantaneously without
  communicating with the transmitter. But this
  feature is not made use of in the protocol.
• A particular sequence has to be followed to get
  each message parts. If a message part is lost,
  all the remaining parts cannot be obtained until
  receiver receives the lost message part.
• More bandwidth is consumed for transmitting the
  message.

24
Routing Protocol Security

• Protocols based on multi path routing
• SPREAD (Security Protocol for Reliable data
  delivery) uses threshold secret sharing system.
  Provides maximum security along with reliability
  of some extent.
• Split multi path routing - uses the source
  routing. The message parts are sent on maximum
  routes with maximally disjoint paths. The
  protocol builds multiple routes using
  request/reply cycles.
• M-TCP Multipath TCP

25
Routing Protocol Security

• Dynamic Source Routing
• Source routing is a routing technique in which
  the sender of a packet determines the complete
  sequence of nodes through which to forward the
  packet.
• Assumes that all hosts wishing to communicate
  with other hosts within the ad hoc network are
  willing to participate fully in the protocols of
  the network.
• Route Discovery protocol

26
Routing Protocol Security

• Grudging Nodes in DSR
• Once non-cooperative behavior has been detected
  and exceeds threshold values, an ALARM message is
  sent.

27
Intrusion Detection

• In an ad hoc network, there does not exists
  natural traffic concentrators such as
  firewalls/gateways and localized communication
  pattern.
• Intrusion Detection in Ad hoc networks
• Every node in the ad-hoc network participates in
  intrusion detection and response.
• Each node is responsible for detecting signs of
  intrusion locally and independently.
• Neighboring nodes can collaboratively investigate
  in a broader range.

28
Intrusion Detection

• The conceptual IDS model at every system in the
  ad hoc network.

Ref Intrusion Detection in Wireless Ad Hoc
Networks By Yongguang Zhang and Wenke Lee
29
Intrusion Detection

• Standardization of the intrusion detection
  mechanisms and processes enables nodes from
  multiple vendors to share information and
  collectively determine the intruding node(s).

30
Conclusion

• Even though significant research work exists in
  the above areas of ad hoc networks, little or no
  attempt has been made to standardize mechanisms
  that would enable multi vendor nodes to
  inter-operate on a large scale and permit
  commercial deployments of ad hoc networks. Based
  on the requirements for each of the identified
  areas, candidate proposals will need to be
  evaluated.

31
Thank You

• Questions ? Comments ?
