Title: MANAGING PERFORMANCE IN ORACLE APPLICATIONS RELEASE 11 USING STATSPACK


1
MANAGING PERFORMANCE IN ORACLE APPLICATIONS
RELEASE 11 USING STATSPACK
Rocky Mountain Oracle Users Group20 February,
2002Tim Gorman - SageLogix, Inc.Mary Crystal -
Echostar Communications Corporation
2
Introduction
  • Managing performance in any database is an
    iterative, proactive and reactive exercise
  • DBA perspective on performance tuning
  • User calls Why is it so slow?
  • Where do you look first?
  • How do you know if it is worth pursuing?
  • Whats changed recently?
  • What can help?

3
Introduction
  • Lots of big expensive tools around
  • Need something cheap, easy, and effective
  • STATSPACK is a package included with the Oracle8i
    RDBMS
  • Not installed automatically
  • Not well understood
  • Not designed specifically for Ora Apps R11
  • It is the focus our discussion today

4
Agenda
  • Total Performance Management
  • Typical Oracle Apps R11 environment
  • Choosing STATSPACK
  • Installing and gotchas
  • Reporting
  • Adjusting the package for Oracle Apps R11
  • Improving the package

5
Total Performance Management
  • Know your environment.
  • Based on a description, can you identify the
    components that are probably involved?
  • Have a Baseline
  • You cant determine whats abnormal until you
    know whats normal
  • And you have to PROVE it with factual data!
  • By retaining evaluating consistent metrics
  • Trends can be identified

6
Total Performance Management
  • Have a Baseline (contd)
  • Keep history
  • Start now!
  • Even if you dont evaluate your data daily
  • Beyond the database
  • Use the same time intervals for Network O/S
    metrics allows for easier correlation
  • Keep in mind the end-users experience.

7
The Typical R11 environment
  • Several areas of complexity exist
  • 3 Tiered architecture
  • Browser-based end-user interface.
  • Dont forget the Jinitiator!
  • Application Server which includes the Forms and
    Web servers.
  • Database Server
  • Concurrent Managers

8
Choosing STATSPACK
  • What is right about STATSPACK?
  • Cheap
  • as in FREE
  • Portable across all Oracle platforms
  • Written entirely in SQL and PL/SQL
  • Easy to install and use
  • and de-install and disable, then re-enable, if
    you wish
  • Safe
  • Oracle Support uses it to process TARs logged on
    tuning problems

9
Using STATSPACK
  • Evolved from venerable BSTAT/ESTAT
  • BSTAT/ESTAT has been around forever
  • Simply displays delta (changes) of statistics in
    V views between two snapshots
  • Report in file report.txt
  • STATSPACK does the same as BSTAT/ESTAT
  • Takes snapshots of statistics in V views
  • But stores the information in tables
  • Report is much more informative than report.txt
  • But curiously as difficult to use as report.txt!

10
Using STATSPACK
  • Everything resides within an account / schema
    named PERFSTAT
  • Snapshots are scheduled and run using the
    DBMS_JOB package
  • By default, takes a snapshot every hour
  • configurable (of course!)
  • Unlike BSTAT/ESTAT, also captures info from
    VSQLAREA
  • Vital tuning information!

11
Using STATSPACK
  • STATSPACK produces only one report
  • But it is much more useable and comprehensive
    than BSTAT/ESTATs report.txt
  • Contains some interpretations and advice
  • Oracle9i contains an extra detailed report for
    drilling down on the history of a single SQL
    statement
  • thats all folks!

12
Installing STATSPACK
  • Use either the v8.1.7 or v9.0.1 versions of
    STATSPACK
  • Regardless of version RDBMS you are using
  • shouldnt bother with the v8.1.6 version of
    STATSPACK
  • No worries! Each new version contains an upgrade
    script from the previous version
  • Files in ORACLE_HOME/rdbms/admin
  • Named stats. in v8.1.6 version
  • Named sp. in v8.1.7 and v9.0.1 versions

13
Installing STATSPACK
  • Read online documentation spdoc.txt first!
  • - Overview of STATSPACK
  • - Detailed installation instructions
  • - Gathering data manually or through automated
    tools
  • - Running a report interactively or via batch
  • - Setting thresholds
  • - Purging data
  • CONNECT INTERNAL in SQLPlus

14
Installing STATSPACK
  • Run SQLPlus script spcreate.sql
  • Calls spcusr.sql to create PERFSTAT
  • Assigns DEFAULT and TEMP tablespaces
  • Prompts for tablespace names
  • Good time to think about sizing
  • performs GRANTS
  • create session, alter session
  • create table, create procedure, create sequence
  • create public synonym, drop public synonym
  • Adds new X tables to SYS schema

15
Installing STATSPACK
  • Run SQLPlus script spcreate.sql (contd)
  • Re-connects as PERFSTAT to continue
  • Calls spctab.sql to create tables, sequences,
    synonyms
  • NOTE indexes are created in DEFAULT tablespace
  • Might have to re-create them in a more desirable
    tablespace
  • Calls spcpkg.sql to create package STATSPACK
  • Creates public synonyms for package

16
Installing STATSPACK
  • Check spooled output files for errors
  • grep i err spc.lis
  • If you have any errors
  • Correct them
  • De-install and start over again
  • CONNECT INTERNAL in SQLPlus
  • Run SQLPlus script spdrop.sql
  • Calls scripts spdtab.sql and spdusr.sql
  • Check spooled output files spd.lis for errors!
  • Then repeat installation steps

17
Installing STATSPACK
  • Automatic job submission
  • CONNECT PERFSTAT in SQLPlus
  • Run SQLPlus script spauto.sql
  • Configures STATSPACK.SNAP once an hour
  • Edit the script if youd like a different
    frequency
  • Purging data
  • CONNECT PERFSTAT in SQLPlus
  • Run SQLPlus script sppurge.sql
  • Purges a range of snap-ids
  • Gathering hourly, purging every 3 days retains
    300Mb in source database.

18
Special tasks
  • Clearing out the STATSPACK tables
  • CONNECT PERFSTAT in SQLPlus
  • Run SQLPlus script sptrunc.sql
  • Exporting the PERFSTAT schema
  • Perhaps to send it to Oracle Support?
  • Use parameter file spuexp.par
  • exp parfilespuexp.par
  • Password

19
Reporting from STATSPACK
  • CONNECT PERFSTAT in SQLPlus
  • Run SQLPlus script spreport.sql
  • Will either prompt interactively for parameter
    values
  • OR
  • Can be run in batch mode when parameter values
    are supplied as SQLPlus substitution variables

20
Reporting from STATSPACK
  • SQLgt connect perfstat/perfstat
  • Connected.
  • SQLgt _at_spreport
  • DB Id DB Name Inst Num Instance
  • ----------- ------------ -------- ------------
  • 2618106428 PRD1 1 prd1
  • Completed Snapshots
  • Snap
    Snap
  • Instance DB Name Id Snap Started
    Level Comment
  • ------------ ------------ ----- -----------------
    -----
  • prd1 PRD1 1 11 May 2001 1207
    5
  • 2 11 May 2001 1208
    5

21
Reporting from STATSPACK
  • Specify the Begin and End Snapshot Ids
  • Enter value for begin_snap 1
  • Begin Snapshot Id specified 1
  • Enter value for end_snap 2
  • End Snapshot Id specified 2
  • Specify the Report Name
  • The default report file name is sp_1_2 To use
    this name,
  • hit ltreturngt to continue, otherwise enter an
    alternative.
  • Enter value for report_name ltreturn or enter new
    namegt
  • Using the report name sp_1_2

22
Reporting from STATSPACK
  • Running from batch mode
  • SQLgt connect perfstat
  • Enter password
  • Connected
  • SQLgt define begin_snap1
  • SQLgt define end_snap2
  • SQLgt define report_namesp_1_2
  • SQLgt _at_spreport

23
Reporting from STATSPACK
  • Cache Sizes
  • db_block_buffers 40960000 log_buffer
    1048576
  • db_block_size 8192 shared_pool_size
    104857600
  • Load Profile Per Second Per
    Transaction
  • ---------------
    ---------------
  • Redo size 54,378.06
    23,189.73
  • Logical reads 128,947.97
    54,990.36
  • Block changes 239.97
    102.33
  • Physical reads 2,384.38
    1,016.83
  • Physical writes 25.07
    10.69
  • User calls 182.21 77.71

24
Reporting from STATSPACK
  • Parses 29.49
    12.58
  • Hard parses 0.35
    0.15
  • Sorts 37.63
    16.05
  • Logons 0.22
    0.09
  • Executes 180.99
    77.18
  • Transactions 2.34
  • Blocks changed per Read 0.19
  • Recursive Call 57.54
  • Rollback per transaction 5.65
  • Rows per Sort 68.35

25
Reporting from STATSPACK
  • Instance Efficiency Percentages (Target 100)
  • Buffer Nowait 99.98 Redo NoWait
    100.00
  • Buffer Hit 98.15 In-memory Sort
    99.97
  • Library Hit 99.89 Soft Parse
    98.80
  • Execute to Parse 83.71 Latch Hit
    99.98
  • Parse CPU to Parse Elapsed 77.98
  • Non-Parse CPU 100.00
  • Shared Pool Statistics Begin End
  • ------ ------
  • Memory Usage 74.94 71.95
  • SQL with executionsgt1 80.60 80.55
  • Memory for SQL w/execgt1 83.33 83.55

26
Reporting from STATSPACK
  • Top 5 Wait Events
  • Event Waits Time (cs) Wt
    Time
  • -------------------- ------------ ------------
    -------
  • enqueue 24,345 7,194,663
    49.50
  • db file sequential r 40,848,049 3,490,281
    24.01
  • db file scattered re 3,175,741 2,320,214
    15.96
  • SQLNet message from 277,128 968,395
    6.66
  • latch free 164,340 155,845
    1.07

27
Reporting from STATSPACK
  • Buffer Gets Execs Gets/Exec Total Hash
    Value
  • -------------- ------- ------------ -------
    -----------
  • 1,537,435,479 90 17,082,616.4 33.2
    1394818125
  • select a.report_id, decode(a.batch_id,null,
    b.batch_id, a.batch_id) rbatch_id, c.NAME,
    c.NUMBER, a.NAME, b.BANK_NAME, c.ACCOUNT_NAME,a.RE
    CEIPT_NUMBER, aps.
  • DUE_DATE, decode(acr.selected_remittance_batch_id,
    null

28
YAPP Reports
  • Yet Another Performance Profiler
  • Available from http//www.oraperf.com
  • Unofficial website run by members of Oracle
    Server Technologies division
  • Upload either BSTAT/ESTAT report.txt file or
    STATSPACK report file
  • Returns an HTML page containing an amazing
    response-time analysis report

29
YAPP Reports
  • Organized from overview to hyperlinked detail
    sections
  • Header (version info, time span of report, etc)
  • Response-time breakout
  • CPU Time or time spent processing SQL
  • Parse, recursive, and other CPU Time breakouts
  • Wait Time or time not spent processing SQL
  • Initialization parameter settings
  • Tuning advise summary

30
YAPP Reports
  • General Information
  • The following comments were generated while
    processing file C\Temp\sp_5349_5350.lst
  • Disclaimer Use information at own risk !
  • All timing information is in 1/100 sec, unless
    stated otherwise.
  • The timing period in this report is too long to
    get any useful tuning advise.
  • End Buffer Gets Threshold 100000
  • Note that resources reported for PL/SQL includes
    the resources used by all SQL statements called
    within the PL/SQL code. As individual SQL
    statements are also reported, it is possible and
    valid for the summed total 10021160010 exceed 100
  • End Executions Threshold 1000
  • only latches with sleeps are shown
  • ordered by name, sleeps desc NoWait Waiter
  • Please be advised that running STATSNAP on
    releases before Oracle8i can give problems.
  • Please be advised that Oracle8 version 8.0.6 is
    the terminal release for Oracle8. You are on an
    older release.
  • Uploaded 167060 bytes in 5.10 seconds

31
YAPP Reports

Response Time
32
YAPP Reports

CPU Time

33
YAPP Reports

Wait Time
34
YAPP Reports
35
Customizing STATPACK
  • How should STATSPACK be altered for Ora Apps
    R11/R11i?
  • Capture OraApps Concurrent Manager info
  • Display MODULE (from VSESSION and VSQLAREA) in
    reports
  • For OraApps and other applications using the
    DBMS_APPLICATION_INFO package
  • Increase thresholds when data gathering
  • filter out huge amounts of unnecessary data
  • Consume less space

36
Capture ConcMgr data
  • Table FND_CONCURRENT_REQUESTS in Ora Apps
    foundation schema APPLSYS
  • Contains valuable elapsed time information for
    batch jobs and reports
  • Only elapsed time information from interactive
    forms is missing in Ora Apps
  • Leaving a gap in the record of the total end-user
    experience
  • It is a standard best-practice in Ora Apps
    administration to purge this table periodically

37
Capture ConcMgr data
  • Customization Suggestion
  • Replicate data to the back-end reporting and
    analysis database
  • Retain ConcMgr job statistics for several
    business cycles
  • Allowing analysis of ConcMgr activity
  • Allows frequent purging of FND_CONCURRENT_REQUESTS
    table in Ora Apps foundation schema
  • Optimizing ConcMgr performance

38
Display MODULE in reports
  • Standard v8.1.6, v8.17, and v9.0.1 STATSPACK
    script spreport.sql does not include value of
    column MODULE (i.e. Ora Apps executable name)
  • Helps in associating a poorly-performing SQL
    statement to a form, report, or program
  • Metalink note 153502.1 fixes v8.1.7 spreport.sql
  • Metalink note 153503.1 fixes v8.1.6 statsrep.sql
  • Metalink note 153505.1 fixes v9.0.1 sprepins.sql

39
Increase thresholds
  • When capturing SQL statement tuning information
    from VSQLAREA
  • STATSPACK installed by default has very low
    statistics thresholds for selecting SQL
    statements
  • Gathers info about rather unimportant SQL
    statements
  • Advisable to set them higher for Ora Apps
  • Reduces the amount of storage consumed by
    STATSPACK dramatically

40
Increase thresholds
  • Metalink note 153507.1 contains good suggested
    thresholds
  • But does not suggest a good method for setting
    the parameter
  • Instead of adding new thresholds as parameters to
    STATSPACK.SNAP procedure call
  • Update the table STATSSTATSPACK_PARAMETER with
    the threshold values to make the settings
    permanent

41
Customizing STATSPACK
  • How can STATSPACK be improved?
  • Automated ANALYZE of PERFSTAT
  • Automated purge of PERFSTAT tables
  • More data warehouse-like architecture
  • Replicate data to a decision-support database
  • More reporting capabilities
  • More reports
  • Ability to perform ad-hoc queries

42
Automated ANALYZE
  • Just like anything else, the PERFSTAT schema
    should be analyzed periodically
  • To optimize the performance of report processing
    and other queries in PERFSTAT
  • Performance of STATSPACK.SNAP procedure not
    affected
  • Only SELECTs from V views and INSERTs into
    PERFSTAT schema
  • Customization Suggestion
  • Run DBMS_STATS.GATHER_SCHEMA_STATS using the
    DBMS_JOB systems

43
Automated purge
  • SQLPlus script sppurge.sql cannot be run from
    automated DBMS_JOB system
  • Must run from an external job-scheduling facility
  • UNIX cron, NT/2000 at, CA AutoSys or Unicenter,
    etc
  • Customization Suggestion
  • Rewrite the sppurge.sql script as a PL/SQL stored
    procedure
  • Called from DBMS_JOB once per day

44
More DW-like architecture
  • Reporting/analysis systems (DWs) are usually
    separated from operational systems
  • STATSPACK data should be replicated to another
    system for reporting / analysis
  • Customization Suggestion
  • Leave standard STATSPACK on database being
    monitored
  • Build custom replication package to customized
    STATSPACK on a back-end database

45
More DW-like architecture
  • Customization Suggestion (contd)
  • Purge data in PERFSTAT schema in front-end
    database (the one being monitored) to minimize
    the impact of storage
  • Allow PERFSTAT schema in back-end database to
    retain more data for long-term analysis (i.e.
    trending, summaries, anomalies)
  • Best to retain performance data across numerous
    distinct business cycles

46
More DW-like architecture
  • Customization Suggestion (contd)
  • Store data from multiple front-end databases in a
    single back-end database
  • Standard STATSPACK labels all data by DBID and
    INSTANCE_NUMBER anyway
  • The standard STATSPACK installation in the
    front-end database is not altered in any way
  • Except by frequent data purges

47
More reporting capabilities
  • Standard STATSPACK only captures snapshots of
    cumulative statistics
  • So each row has the current total value
  • Script spreport.sql has logic to calculate deltas
    or changes in value between two snapshots
  • But this type of data prevents most reporting and
    analysis
  • Cannot summarize
  • Cannot analyze across instance restarts
  • All statistics reset to zero

48
More reporting capabilities
  • Customization Suggestion
  • In the back-end (reporting and analysis)
    database, add and populate new columns for
    holding delta values between snapshots
  • For example
  • ALTER TABLE STATSSYSSTAT
  • ADD (VALUE_INC NUMBER)
  • Does not affect standard STATPACK installation in
    front-end database that is being monitored

49
More reporting capabilities
  • Availability of delta data values allows simple
    queries across all snapshots
  • select trunc(s.snap_time),
  • sum(f.phyrds_inc)
  • from statssnapshot s,
  • statsfilestatxs f
  • where s.snap_id f.snap_id
  • group by trunc(s.snap_time)

50
Conclusion
  • Cannot improve that which you dont measure!
  • STATSPACK is a cheap tool for gathering
    measurement metrics
  • Still needs some improvements
  • but even out-of-the-box it is an excellent start!
  • Use the YAPP report from www.oraperf.com
  • Better than the standard report
  • High-Performance Tuning with STATSPACK by Donald
    K. Burleson

51
QA
Write a Comment
User Comments (0)
About PowerShow.com
