Multispectral Imaging Using Linear Arrays
2
Jensen, 2007
3
Remote Sensing System used for Multispectral and
Hyperspectral Data Collection
Jensen, 2007
4
SPOT Satellite System Components
Courtesy of SPOT Image, Inc.
Jensen, 2007
5
Scanning Electron Microscope Image of the Front
Surface of a CCD Linear Array Like that Used in
the SPOT HRV Sensor Systems
100 mm
Courtesy of SPOT Image, Inc.
10 mm
Jensen, 2007
6
Jensen, 2007
7
Jensen, 2007
8
Jensen, 2007
9
Comparison of the Detail of 30 x 30 m Landsat TM
Band 3 Data and SPOT 10 x 10 m Panchromatic Data
of Charleston, SC
Courtesy of SPOT Image, Inc.
Jensen, 2007
10
Geographic Coverage of the SPOT HRV and Landsat
Thematic Mapper Remote Sensing Systems
Jensen, 2007
11
Columbia Reef on Cozumel Island, Mexico
Courtesy of SPOT Image, Inc.
Jensen, 2007
Perimeter 80,880 ha Area 398 m2
SPOT XS Band 1 (0.50 - 0.59 ?m) April 19, 1988
12
Portion of the First Global 10-day Synthesis
Image Produced Using the SPOT Vegetation Sensor
May 11-20, 1998
Courtesy of SPOT Image, Inc.
Jensen, 2007
13
Earth Observing System - Terra Instruments
ASTER - Advanced Spaceborne Thermal Emission and
Reflection Radiometer CERES - Clouds and the
Earths Radiant Energy System MISR - Multi-angle
Imaging Spectroradiometer MODIS -
Moderate-resolution Imaging Spectroradiometer MOPI
TT - Measurement of Pollution in the Troposphere
Jensen, 2007
14
Earth Observing System - Terra Instruments
ASTER - Advanced Spaceborne Thermal Emission and
Reflection Radiometer Spectral Range VNIR
0.4 - 14.4 mm, SWIR 1.6 - 2.5 mm, TIR 8 - 12
mm Spatial Resolution 15 m (VNIR 3
bands) 30 m (SWIR 6 bands) 90
m (TIR 5 bands)
Jensen, 2007
15
Advanced Spaceborne Thermal Emission and
Reflection Radiometer (ASTER) Onboard Terra
Oahu, HI 15 x 15 m (RGB 1,4,3)
16
Advanced Spaceborne Thermal Emission and
Reflection Radiometer (ASTER) Onboard Terra
North Shore Oahu, HI 15 x 15 m (RGB 1,4,3)
17
Advanced Spaceborne Thermal Emission and
Reflection Radiometer (ASTER) Onboard Terra
Pearl Harbor, Hawaii, 15 x 15 m (RGB 1,4,3)
18
Jensen, 2007
19
Jensen, 2007
20
Earth Observing System - Terra Instruments
ASTER - Advanced Spaceborne Thermal Emission and
Reflection Radiometer CERES - Clouds and the
Earths Radiant Energy System MISR - Multi-angle
Imaging Spectroradiometer MODIS -
Moderate-resolution Imaging Spectroradiometer MOPI
TT - Measurement of Pollution in the Troposphere
Jensen, 2007
21
Multi-angle Imaging Spectroradiometer (MISR)
Onboard Terra
Jensen, 2007
22
Imaging Spectrometry Using Linear and Area Arrays
23
Remote Sensing System used for Multispectral and
Hyperspectral Data Collection
Jensen, 2007
24
EROS A1 Panchromatic Image of Brest, France
1.8 x 1.8 m spatial resolution
ImageSat International, Inc.
25
Jensen, 2007
ImageSat International, Inc.
26
IKONOS Panchromatic Images of Washington, DC
Jensen, 2007
1 x 1 m spatial resolution
27
IKONOS Panchromatic Stereopair of Columbia, SC
Airport
November 15, 2007
Jensen, 2007
28
IKONOS Imagery of Columbia, SC Obtained on
October 28, 2007
Panchromatic 1 x 1 m
Pan-sharpened multispectral 4 x 4 m
29
IKONOS
30
Indian Remote Sensing Satellite (IRS-1D)
Panchromatic Image of Downtown San Diego, CA at 5
x 5 m
Jensen, 2007
31
Characteristics of the Leica Geosystems, Inc.,
Airborne Digital Sensor System ADS-40
32
Remote Sensing System used for Multispectral and
Hyperspectral Data Collection
Jensen, 2007
33
Imaging Spectrometry
Jensen, 2007
34
Jensen, 2007
35
Airborne Visible Infrared Imaging Spectrometer
(AVIRIS) Datacube of Sullivans Island Obtained
on October 26, 1998
Jensen, 2007
36
Hyperspectral
37
Hyperspectral Data of the Savannah River Site
38
One healthy (37) and three stressed Bahia grass
image-derived endmember spectral profiles (15,
25 and 36) derived using a pixel purity index
image and n-dimensional visualization endmember
analysis.
healthy
39
Healthy vegetation derived from endmember 37.
Stressed vegetation derived from endmember 36.
healthy
stressed
40
Hardened classification derived from four
endmembers using the Spectral Angle Mapper
algorithm
Second-order derivative image extracted from
AVIRIS data
healthy vegetation
41
Extraction of Biophysical Information
n 40
42
AISA Hyperspectral Imagery of Forest Test Plots
Subjected to Controlled Fertilizer Treatments on
the Savannah River Site
Rectified flightline
Unrectified flightline
43
Hyperspectral Crop Classification Using AVIRIS
Data
Jensen, 2007
44
Jensen, 2007
45
Earth Observing System - Terra Instruments
MODIS - Moderate-resolution Imaging
Spectroradiometer Spectral Range 0.4 -
14.4 mm Spectral Coverage 55, 2330 km
swath Spatial Resolution 250 m (2 bands),
500 m (5 bands), 1000 m (29 bands)
Jensen, 2007
46
Moderate Resolution Imaging Spectroradiometer
(MODIS) Onboard Terra
First day global coverage 2,330 km swath width
47
Moderate Resolution Imaging Spectroradiometer
(MODIS) Onboard Terra
Nile River and Nile Delta
48
Moderate Resolution Imaging Spectroradiometer
(MODIS) Onboard Terra
Nile River and Nile Delta
49
Digital Frame Cameras Based on Area Arrays
50
Remote Sensing System used for Multispectral and
Hyperspectral Data Collection
Jensen, 2007
51
Digital Frame Camera Imagery
Green
Red
Near-Infrared
System Components
Jensen, 2007
52
Digital Frame Camera Imagery of Dunkirk, New York
Green
Red
Near-Infrared
Jensen, 2007
53
Litton Emerge Spatial, Inc., CIR image (RGB
NIR,R,G) of Dunkirk, NY, at 1 x 1 m obtained on
December 12, 1998
Natural color image (RGB RGB) of a N.Y. Power
Authority lake at 1 x 1 ft obtained on October
13, 1997
Jensen, 2007
54
Digital Frame Camera Imagery of Harbor Town,
Hilton Head, SC
1 x 1 ft spatial resolution
Jensen, 2007
55
Panchromatic 3 x 3-in Image of Popular Bluff, MO
Obtained On February 15, 2007 at 5,000 ft AGL
Using A Digital Array Panoramic Camera with
32,000 x 8,000 Detectors
Swath width 1.5 mi
Courtesy of Image America, Inc.
Jensen, 2007
56
Jensen, 2007
57
Increased Demand for Suborbital Oblique Digital
Frame Camera Imagery

• Pictometry

58
What is this object?
59
(No Transcript)
60
North
Vertical
East
West
South
61
North
Pictometry Imagery of Columbia, SC
E
W
Vertical
Note Photography was obtained from multiple
flightlines
South
62
(No Transcript)
63
Uses of Oblique Imagery

• 911
• Fire
• Police
• Rescue
• Investigations
• Military

• Environmental
• Airport safety
• Facility mgt.
• Training
• Public affairs
• Navigation

64
(No Transcript)
65
(No Transcript)
66
Intelligent imagery
67
Earth Observing System Measurements
Discipline
EOS-AM Instruments
Measurement
Atmosphere Cloud Properties
MODIS, MISR, ASTER Radiative Energy
Fluxes CERES, MODIS, MISR Precipitation Tropo
spheric Chemistry MOPITT Stratospheric
Chemistry Aerosol Properties MISR,
MODIS Atmospheric Temperature MODIS Atmospher
ic Humidity MODIS Lightning
Jensen, 2007
68
Earth Observing System Measurements
Discipline
EOS-AM Instruments
Measurement
Land Land Cover/Land Use Change MODIS, MISR,
ASTER Vegetation Dynamics MODIS, MISR,
ASTER Surface Temperature MODIS, ASTER Fire
Occurrence MODIS, ASTER Volcanic
Effects MODIS, MISR, ASTER Surface Wetness
Jensen, 2007
69
Earth Observing System Measurements
Discipline
EOS-AM Instruments
Measurement
Ocean Surface Temperature MODIS Phytoplankton
MODIS, MISR Dissolved Organic Matter MODIS,
MISR Surface Wind Fields Ocean Surface
Topography
Cryosphere Land Ice Change ASTER Sea Ice
MODIS, ASTER Snow Cover MODIS, ASTER
Solar Radiation Total Solar Radiation Ultrav
iolet Spectral Irradiance
70
SPIN-2
Jensen, 2007
