Cost reflectivity of investment proxies

1
Cost reflectivity of investment proxies

• CAP131 Working Group (2)
• 27 October 2006

2
Action

• Action
• To explore the cost reflectivity of various
  proxies for infrastructure investments, which
  need to be supported bya user commitment
• Aim
• To establish whether there are more
  cost-reflective investment proxies than TNUoS
  tariffs and consider whether these are better
  when assessed against the Applicable CUSC
  Objectives

3
Process Map
Identify groups of projects that require similar
system reinforcements
Establish unit capital investment costs (/kW)
for groups
Compare annual investment proxy to capital
investment costs
Express as a number of years of the investment
proxy
Calculate average spread between project groups
as measure of cost reflectivity
4
Investment costs for groups

• Several groups of projects considered, where each
  group requires similar transmission investments
• represents a sample of 25GW of generation
• Investments consider a range of scenarios within
  group
• One investment group is illustrated below
• Gradient gives average capital investment cost in
  /kW

5
Investment proxies considered

• All proxies been derived from the TNUoS model
• Retained 3/kW p.a. de-minimis for local
  substation works
• Nodal investment proxies
• full tariffs
• locational tariffs
• Zonal investment proxies
• full TNUoS tariffs
• locational TNUoS tariffs
• re-zeroed TNUoS differential tariffs (no
  residual)

Removes the revenue recovery adjustmentsi.e. the
residual
Establishes alternative electrical centre of
system(see next slides)
6
Why consider re-zeroing?

• Additional generation triggers reinforcement to
  load centres
• DCLF model establishes a system centre (the
  slack node)
• The slack node is the most interconnected node
  and is arbitrarily assigned an incremental cost
  of zero (0MWkm)
• The real incremental cost at the slack node
  is not zero
• Investment required to transfer the marginal MW
  to the load

7
Is Thorpe Marsh an appropriate centre?
Thorpe Marsh isthe slack node (SN)
B7
B8
8
Effect of different zero pointsAlternative
zero-points considered

• Investigated the effect of considering different
  zero points
• Have considered
• Peninsula (Zone 21, -5.53 /kW)
• Central London (Zone 16, -1.97 /kW))
• South Yorkshire North Wales (Zone 14, 0.31
  /kW)
• The aim is to identify which zero-point provides
  the best fit to actual investment costs incurred

Contains the slack node, Thorpe Marsh
tariffs presented exclude the residual element
9
Effect of different zero pointsInvestment
proxies with different zero points
10
Effect of different centres of loadIdentifying
the most appropriate zero point
Zonal TNUoS with no locational component, with
different zero points
Standard deviation is used as a measure of cost
reflectivity
Central London gives best fit to investment costs
11
Zonal investment proxies
12
Nodal investment proxies

• Where possible, the nodal marginal km at the node
  where generation is expected to connect has been
  converted to a tariff by considering
• re-referencing quantity
• security factor
• expansion constant
• Has not been applied to all projects, as nodes do
  not presently exist within transport model
• analysis covers 19GW of sample pool (25GW)

same parameters used tocalculate zonal tariffs
13
Establishing number of years of proxy

• For each group, actual investment costs (/kW)
  are compared with applicable investment proxy
  (/kW)
• where a zonal proxy has been used, the zone that
  best represents projects within a group has been
  used

Range of annual proxies tested
ActualCapitalCost (/kW)
Annual ProxyCost (/kW)
Number of years ofproxy


across all investmentgroups
Average and St. Dev.
14
Analysis resultsZonal Nodal investment proxies
15
Observations

• Nodal approach does not add extra
  cost-reflectivity
• no smoothing for lumpiness of a nodal cost
• adds complexity to the methodology for little
  return
• Trade-off between number of years of the
  investment proxy and the magnitude of that proxy
• low number of years, high proxy cost
• high number of years, low proxy cost

16
Wider assessment of investment proxies

• Cost reflectivity is not an applicable CUSC
  objective, it is part of facilitating competition
• Important, therefore, to consider other criteria
  against which the investment proxies should be
  assessed
• transparency of methodology to derive proxy
• ease for both Users and National Grid to
  determine commitment
• ease of application to new entry points i.e.
  nodes that dont exist
• others?

17
Wider assessment a starter for ten
18
Conclusions

• TNUoS tariffs provide a reasonable investment
  proxy
• TNUoS tariffs without the residual re-centred
  on Central London provides a more cost reflective
  investment proxy
• However, would require additional arrangements to
  overcome transparency issues and could be
  confusing for new entrants
