REMM: Riparian Ecosystem Management Model

1
REMM Riparian Ecosystem Management Model

• USDA-ARS, Southeast Watershed Research Laboratory
  Tifton, GA

2
Collaborators

• Richard Lowrance
• Randall G. Williams
• Lee Altier
• Shreeram Inamdar
• David Bosch
• Joseph M. Sheridan
• Dan Thomas
• Robert K Hubbard
• Carrie Graff
• Jennifer Gilberts

3
I. Riparian Buffer Overview
4
Coastal Plain Agricultural Riparian Buffer
System
5
Landscape Management
Riparian Herbaceous Buffer
6
II. REMM Concepts
7
Three Zone Buffer System
8
REMM Components
vegetative growth
hydrology
nutrient dynamics
sediment
9
REMM Hydrologic Processes
10
Litter and Soil Interactions in REMM
11
REMM Vegetation Types
coniferous trees
deciduous trees
herbaceous perennials/ annuals
12
REMM Vegetation
Upper canopy/lower canopy
Multiple vegetation types in both canopies based
on percent cover Any/all vegetation can be in
each zone
13
Carbon Pools in Soil and Litter
Based on Century model, Parton et al. 1987
14
Nitrogen Pools in Soil and Litter
15
Fluxes Among Nitrogen Pools
16
Phosphorus Pools in Soil and Litter

17
Fluxes Among Phosphorus Pools
18
III. Gibbs Farm Experiment
19
(No Transcript)
20
Managed Three Zone BufferGibbs Farm Site
21
(No Transcript)
22
Field Surface area 0.32 ha Field Subsurface
area 0.32 ha
23
Model Predicted and Observed Water Tables 1995
Zone 1 Well
0
80
-0.5
60
Depth Below Surface (m)
Daily Rainfall (mm)
-1
40
-1.5
20
-2
0
0
100
200
300
400
Days
predicted
observed
24
REMM Documentation

• Published as USDA Conservation Research Report
  No. 46 in 2002.
• General article on REMM structure with some
  sensitivity analysis in JSWC
• REMM tested (validation) in two articles in
  Trans. ASAE
• Applications of REMM for coastal plain systems
  published in JAWRA and Trans. ASAE

25
IV. Uses for REMM
26
IV. Uses for REMM

• Evaluation of Buffer scenarios
• Compare buffers with different vegetation
• Predict changes in pollutant removal mechanisms
• Examine behavior of riparian systems as
  represented by REMM

27
Example - Buffer Scenarios

• 14 buffers ranging from minimum Zone 1 buffer (5
  m) to 52 m three zone buffer
• Simulated both conventional row crop loading
  (normal) and dairy lagoon effluent loading
  (high).

28
Loading Scenarios
29
Buffer Scenarios
30
Total Water Output
31
Sediment Output
32
Total N Output
33
Total N load reduction
34
V. Limitations
35
VI. Limitations

• Soil information for each soil layer in each
  zone.
• Vegetation information by plant part.
• Daily weather and field sediment, nutrient,
  surface and subsurface runoff.

• Data intensive

36
VI. Limitations

• Requires another model or real data to develop
  field input files.

• Data intensive
• Field input

37
VI. Limitations

• Steam does not control REMMs subsurface flow.
• Flooding in buffer not simulated.

• Data intensive
• Field inputs
• Stream output

38
VI. Limitations

• Simple input file editors.
• Output to comma separated file.
• User required to analyze data in spreadsheet.

• Data intensive
• Field inputs
• Stream output
• No real user interface

39
VII. Linking REMM with other Models

• GLEAMS/CREAMS

• GLEAMS/CREAMS used to generate REMM daily field
  input files.
• Problem 1 Required manual construction REMM
  field inputs using spreadsheet.
• Problem 2 Required assumption of for of N and P
  transport.
• Problem 3 No stream routing.

40
VII. Linking REMM with other Models
41
VII. Linking REMM with other Models

• GLEAMS/CREAMS
• AnnAGNPS

• AnnAGNPS used to generate REMM daily field input
  files.
• Problem 1 Required manual construction of REMM
  field inputs using spreadsheet.
• Problem 2 Required assumption of for of N and P
  transport.
• Problem 3 No stream routing.

42
VII. Linking REMM with other Models

• GLEAMS/CREAMS
• AnnAGNPS
• AnnAGNPS

• AnnAGNPS used to generate REMM daily field input
  files.
• AnnAGNPS output code modified to ouptut in REMM
  input formats.
• Problem 1 Required assumption of form of N and P
  transport.
• Problem 2 No stream routing.

43
VII. Linking REMM with other Models

• GLEAMS/CREAMS
• AnnAGNPS
• AnnAGNPS
• SWAT

• GIS wrapper put around SWAT and REMM. SWATs
  subbasin output used to generate REMM input
  files. REMM output data written back to SWAT
  reach input files.
• Problem Required assumption of form of N and P
  transport

44
VII. Linking REMM with other Models

• GLEAMS/CREAMS
• AnnAGNPS
• AnnAGNPS
• SWAT
• CONCEPTS

• REMM and CONCEPTS were integrated on a daily time
  step basis.
• Problem 1. REMM input data file.
• Problem 2. No feedback to REMM on stream
  conditions.

45
VII. Linking REMM with other Models

• GLEAMS/CREAMS
• AnnAGNPS
• AnnAGNPS
• SWAT
• CONCEPTS
• AnnAGNPS

• Direct integration of REMM and AnnAGNPS is being
  evaluated. AnnAGNPS field output would be REMM
  inputs and REMM output would be routed through
  AnnAGNPS channel routing scheme.
• Problem 1. Time.

46
VIII. Summary
47
IX. Contact Information

• Randy Williams
• Agricultural Engineer
• USDA-ARS
• Southeast Watershed Research Lab
• 2375 Rainwater Rd.
• P.O. Box 748
• Tifton, GA 31793
• Phone [phone]
• Fax [phone]
• e-mail randy.williams_at_ars.usda.gov
