Secure Remote Access

1
Secure Remote Access
For telecommuters and roaming users

• Craig McGregor
• Security Specialist
• The Treasury

2
Secure Remote Access Requirements

• Authentication (Knock, knock, whos there?)
• Access to the laptop
• Access to your network
• Physical Security
• Lost or mislaid laptops
• Unauthorised Access to a laptop
• Network Security
• Network-based attacks/intrusions
• Information confidentiality
• Malware Protection
• Management/Low support cost
• Ease of Use

3
Authentication

• Authentication is needed to
• Prevent unauthorised access to the laptop
• Prevent unauthorised access to your network
• The Authentication Scheme needs to
• Be easy and seamless to the user
• Use multiple factors to prevent capture and
  replay of credentials (e.g. key-logging of
  passwords)
• Prevent man-in-the-middle attacks
• Rainbow iKey cryptographic tokens

4
Physical Security

• Laptops contain your agencys information
• Try and keep as little information on the laptop
  as possible - Dont use a laptop as a mass
  file-store
• Make it difficult to obtain information even with
  physical access to the laptop Boot time
  authentication
• Media could be removed and read from elsewhere
  Disk Encryption
• Procedures Citrix WinMagic Rainbow Crypto
  Tokens

5
Disk Encryption Implementation Choices

• Disk vs File Encryption
• File Encryption
• Choose a file, decrypt, use, encrypt, secure
  erase unencrypted file
• Disk Encryption
• Encrypts and decrypts all files (including
  temporary files) on the fly. This process is
  extremely transparent to the end user.

• Issues for pooled resources
• If laptop L is encrypted with user As key then
  users B,C,D cannot use the laptop.
• Use a device access key rather than a user
  authentication key

• Master Keys
• If a user loses their key, or is not present can
  IT Support read the disk?
• Encrypt the disk encryption key using the users
  key and a key owned by IT Support staff

6
Network Security

• Your Agencys information travels over the
  Internet.
• Make sure that nobody can watch it go past
  Prevent unauthorised access to your information
  resources.
• Packet sniffing Session encryption e.g. IPSEC
  or SSL
• Man-in-the-middle
• Authenticate both the Server and the client!
• Capture-and-replay Network Attack Prevention
• Protect the client system
• Disable unneeded services
• Use a personal firewall to only allow access from
  applications that should be using the
  network/internet
• Agency owned systems versus staff owned (or
  internet café) systems
• Filter traffic from the client to your network
  it should only be trying to access expected
  services!
• E.g. CodeRed, MSBlaster, SQLSlammer!
• Cisco VPN Client Rainbow Crypto Token
  ZoneAlarm

7
Malware Prevention

• Personal Firewall
• Use a personal firewall that authenticates which
  applications connect to the internet or your
  network this prevents rogue software from
  spreading over the network
• Anti-virus
• Prevents detected Malicious Software from
  executing on the laptop
• Does it update automagically?
• System Resources
• Multiple instances of security software for disk
  encryption, network encryption, authentication,
  firewall, anti-virus... Is this a DoS attack in
  itself?
• ZoneAlarm McAfee WinMagic Cisco VPN ..
  RAM

8
Management and Support

• Managing and supporting LAN clients and Remote
  clients can be very different
• Physical access to hardware
• Access to bandwidth for downloading patches
• Login scripts and domain management tools may be
  unavailable
• Thin-client one update for all users
• The biggest support headache
• Getting roaming connected to the internet

9
Ease of Use and End-User Awareness

• A Secure Remote Access System needs to be
  really easy to use so that
• End Users use it and not circumvent it!
• E.g. Choose to use WebMail instead of secure
  Remote Access connections
• Make it intuitive
• Dont rely on all end users to read the
  documentation
• If possible train/demo the system before they
  leave

10
New Days and Other Ways?

• PDAs, SmartPhones
• Key-based computing http//key-computing.com/exhan
  ge_edition.asp
• Xkey addresses the challenges traditionally
  associated with work from non-company-issued
  computers. Information on Xkey is encrypted
  (128-bit AES) in case the device is lost or
  stolen. All communications to and from the
  Exchange server are encrypted (128-bit SSL).
• Keystroke recorders are neutralized.
• Unintentional traces of work are wiped clean.
• Certificates (X.509) can be stored on Xkey and
  used for 2-factor authentication.
• Bootable CDs
• Virtualisation

11
Questions and More Information?

• More information can be found from
• WinMagic SecureDoc
• http//www.winmagic.com
• sylvia_at_winmagic.com
• Cisco VPN Clients and Concentrators
• http//www.cisco.com/warp/public/44/jump/vpn_devic
  es.shtml
• Rainbow Technologies
• www.safenet-inc.com/products/ikey/ikey2000.asp
• Common Criteria
• www.commoncriteriaportal.org
• An excellent article on laptop security
• http//www.networkcomputing.com/1320/1320f43.html

• Or you can contact me
• craig.mcgregor_at_treasury.govt.nz
