1
Structural Similarity Index
  • Presented By
  • Bishwa Sheth

Guided By Dr. K. R. Rao
2
Topics to be Covered
  • Why Image quality measure
  • What is Image quality measure
  • Types of quality assessment
  • MSE Mean square error
  • SSIM- Structural similarity index method
  • VIF Virtual information fidelity
  • Simulation results
  • Conclusion
  • References

3
Why Image quality?
  • Digital images are subject to wide variety of
    distortions during transmission, acquisition,
    processing, compression, storage and reproduction
    any of which may result in degradation of visual
    quality of an image.
  • E.g. lossy compression technique used to reduce
    bandwidth, it may degrage the quality during
    quantization process.
  • So the ultimate aim of data compression is to
    remove the redundancy from the source signal.
    Therefore its reduces the no of binary bits
    required to represent the information contained
    within the source.

4
What is Image Quality Assessment?
  • Image quality is a characteristic of an image
    that measures the perceived image degradation
  • It plays an important role in various image
    processing application.
  • Goal of image quality assessment is to supply
    quality metrics that can predict perceived image
    quality automatically.
  • Two Types of image quality assessment
  • Subjective quality assessment
  • Objective quality assessment

5
Subjective Quality Measure
  • The best way to find quality of an image is to
    look at it because human eyes are the ultimate
    viewer.
  • Subjective image quality is concerned with how
    image is perceived by a viewer and give his or
    her opinion on a particular image.
  • The mean opinion score (MOS) has been used for
    subjective quality assessment from many years.
  • In standard subjective test where no of listeners
    rate the heard audio quality of test sentences
    reas by both male and female speaker over the
    communication medium being tested.
  • Too Inconvenient, time consuming and expensive

6
Example of MOS score
  • The MOS is generated by avaragin the result of a
    set of standard, subjective tests.
  • MOS is an indicator of the perceived image
    quality.
  • MOS score 24
  • MOS score of 1 is worst image quality and 5 is
    best.

7
Objective Quality Measure
  • Mathematical models that approximate results of
    subjective quality assessment
  • Goal of objective evalution is to devlope
    quantative measure that can predict perceived
    image quality
  • It plays variety of roles
  • To monitor and control image quality for quality
    control systems
  • To benchmark image processing systems
  • To optimize algorithms and parameters
  • To help home users better manage their digital
    photos and evaluate their expertise in
    photographing.

8
Objective evaluation
  • Three types of objective evaluation
  • It is classified according to the availability of
    an original image with which distorted image is
    to be compared
  • Full reference (FR)
  • No reference Blind (NR)
  • Reduced reference (RR)

9
Full reference quality metrics
  • MSE and PSNR the most widely used video quality
    metrics during last 20 years.
  • SSIM new metric (was suggested in 2004) shows
    better results, than PSNR with reasonable
    computational complexity increasing.
  • some other metrics were also suggested by VQEG,
    private companies and universities, but not so
    popular.
  • A great effort has been made to develop new
    objective quality measures for image/video that
    incorporate perceptual quality measures by
    considering the human visual system (HVS)
    characteristics

10
HVS Human visual system
  • Quality assessment (QA) algorithms predict visual
    quality by comparing a distorted signal against a
    reference, typically by modeling the human visual
    system.
  • The objective image quality assessment is based
    on well defined mathematically models that can
    predict perceived image quality between a
    distorted image and a reference image.
  • These measurement methods consider human visual
    system (HVS) characteristics in an attempt to
    incorporate perceptual quality measures.

11
MSE Mean square error
  • MSE and PSNR are defined as

  • (1)

  • (2)
  • Where x is the original image and y is the
    distorted image. M and N are the width and height
    of an image. L is the dynamic range of the pixel
    values.

12
Property of MSE
  • If the MSE decrease to zero, the pixel-by-pixel
    matching of the images becomes perfect.
  • If MSE is small enough, this correspond to a high
    quality decompressed image.
  • Also in general MSE value increases as the
    compression ratio increases.

13
Original Einstein image with different
distortions, MSE value 6
(a) Original Image MSE0
(b) MSE306
(c) MSE309
(d) MSE309
(e) MSE313
(f) MSE309
(g) MSE308
14
SSIM Structural similarity index
  • Recent proposed approach for image quality
    assessment.
  • Method for measuring the similarity between two
    images.Full reference metrics
  • Value lies between 0,1
  • The SSIM is designed to improve on traditional
    metrics like PSNR and MSE, which have proved to
    be inconsistant with human eye perception. Based
    on human visual system.

15
SSIM measurement system
Fig. 2. Structural Similarity (SSIM) Measurement
System 6
16
Example images at different quality levels and
their SSIM index maps6
17
Equation for SSIM
  • If two non negative images placed together
  • Mean intensity (3)
  • Standard deviation (4)
  • - Estimate of signal contrast
  • Contrast comparison c(x,y) - difference of sx and
    sy (5)
  • Luminance comparison (6)
  • C1, C2 are constant.

18
Equation for SSIM
  • Structure comparison is conducted s(x,y) on
  • these normalized signals (x- µx )/sx and(y- µy )/
    sy

  • (7)

  • (8)

  • (9)

  • (10)
  • a, ß and ? are parameters used to adjust the
    relative importance of the three components.

19
Property of SSIM
  • Symmetry S(x,y) S(y,x)
  • Bounded ness S(x,y) lt 1
  • Unique maximum S(x,y) 1 if and only if xy (in
    discrete representations xi yi, for all i
    1,2.,N ).

20
MSE vs. MSSIM
21
MSE vs. SSIM simulation result
22
MSE vs. MSSIM
MSE226.80 MSSIM 0.4489 MSE 225.91
MSSIM 0.4992
23
MSE vs. MSSIM
MSE 213.55 MSSIM 0.3732 MSE 225.80
MSSIM 0.7136
24
MSE vs. MSSIM
MSE 226.80 MSSIM 0.4489 MSE
406.87 MSSIM 0.910
25
Why MSE is poor?
  • MSE and PSNR are widely used because they are
    simple and easy to calculate and
    mathimatically easy to deal with for optimization
    purpose
  • There are a number of reasons why MSE or PSNR may
    not correlate well with the human perception of
    quality.
  • Digital pixel values, on which the MSE is
    typically computed, may not exactly represent the
    light stimulus entering the eye.
  • Simple error summation, like the one implemented
    in the MSE formulation, may be markedly different
    from the way the HVS and the brain arrives at an
    assessment of the perceived distortion.
  • Two distorted image signals with the same amount
    of error energy may have very different structure
    of errors, and hence different perceptual quality.

26
Virtual Image Fidelity (VIF)
  • Relies on modeling of the statistical image
    source, the image distortion channel and the
    human visual distortion channel.
  • At LIVE 10, VIF was developed for image and
    video quality measurement based on natural scene
    statistics (NSS).
  • Images come from a common class the class of
    natural scene.

27
VIF Virtual Image Fidelity
  • Mutual information between C and E quantifies the
    information that the brain could ideally extract
    from the reference image, whereas the mutual
    information between C and F quantifies the
    corresponding information that could be extracted
    from the test image 11.
  • Image quality assessment is done based on
    information fidelty where the channel imposes
    fundamental limits on how mauch information could
    flow from the source (the referenceimage),
    through the channel (the image distortion
    process) to the receiver (the human observer).
  • VIF  Distorted Image Information / Reference
    Image Information

28
VIF quality
  • The VIF has a distinction over traditional
    quality assessment methods, a linear contrast
    enhancement of the reference image that does not
    add noise to it will result in a VIF value larger
    than unity, thereby signifying that the enhanced
    image has a superior visual quality than the
    reference image
  • No other quality assessment algorithm has the
    ability to predict if the visual image quality
    has been enhanced by a contrast enhancement
    operation.

29
SSIM vs. VIF
30
VIF and SSIM
31
VIF and SSIM
32
VIF and SSIM
33
VIF and SSIM
34
Simulation Result
  • MSE vs. SSIM
  • Lena.bmp
  • Goldhill.bmp
  • Couple.bmp
  • Barbara.bmp
  • SSIM vs. VIF
  • Goldhill.bmp
  • Lake.bmp
  • JPEG compressed image
  • Lena.bmp
  • Tiffny.bmp

35
JPEG compressed Image- Tiffny.bmp
36
Comparison of QF, CR and MSSIM
CR 0 MSSIM 1
Q.F 1 CR 52.79 MSSIM 0.3697
37
Comparison of QF, CR and MSSIM
Q.F 4 CR 44.50 MSSIM 0.4285 Q.F 7
CR 33.18 MSSIM 0.5041
38
Comparison of QF, CR and MSSIM
Q.F 10 CR 26.81MSSIM 0.7190 Q.F 15
CR 20.65 MSSIM 0.7916
39
Comparison of QF, CR and MSSIM
Q.F 20 CR 17.11 MSSIM 0.8158 Q.F
25 CR 14.72 MSSIM 0.8332
40
Comparison of QF, CR and MSSIM
Q.F 45 CR 9.36 MSSIM 0.8732 Q.F
80 CR 4.85 MSSIM 0.9295
41
Comparison of QF, CR and MSSIM
Q.F 45 CR 3.15 MSSIM 0.9578 Q.F
99 CR 1.34 MSSIM 0.9984
42
Conclusion
  • The main objective of this project was to analyze
    SSIM Index in terms of compressed image quality.
  • I explained why MSE is a poor metric for the
    image quality assessment systems 1 6.
  • In this project I have also tried to compare the
    compressed image quality of SSIM with VIF.
  • By simulating MSE, SSIM and VIF I tried to
    obtain results, which I showed in the previous
    slides.

43
Conclusion
  • As shown in the simulation figure 1, where the
    original Einstein image is altered with
    different distortions, each adjusted to yield
    nearly identical MSE relative to the original
    image. Despite this, the images can be seen to
    have drastically different perceptual quality.
  • Only VIF has the ability to predict the visual
    image quality that has been enhanced by a
    contrast enhancement operation.
  • For the JPEG compression, quality factor,
    compression ratio and MSSIM are related with each
    other. So as quality factor increases
    compression ratio decreases and so MSSIM
    increases.
  • The distortions caused by movement of the image
    acquisition devices, rather than changes in the
    structures of objects in the visual scene. To
    overcome this problem to some extent the SSIM
    index is extended into the complex wavelet
    transform domain.
  • The quality prediction performance of recently
    developed quality measure, such as the SSIM and
    VIF indices, is quite competitive relative to the
    traditional quality measure.

44
References
  • 1 Z. Wang and A. C. Bovik, Image quality
    assessment from error visibility to structural
    similarity, IEEE Trans. Image Processing, vol.
    13, pp. 600 612, Apr. 2004. www.ece.uwaterloo.ca
    /z70wang/publications/ssim.html
  • 2 Z. Wang and A. C. Bovik, Modern image
    quality assessment, Morgan Claypool
    Publishers, Jan. 2006.
  • 3 M. Sendashonga and F Labeau, Low complexity
    image quality assessment using frequency domain
    transforms, IEEE International Conference on
    Image Processing, pp. 385 388, Oct. 2006.
  • 4 S. S. Channappayya, A. C. Bovik, and R. W.
    Heath Jr, A linear estimator optimized for the
    structural similarity index and its application
    to image denoising, IEEE International
    Conference on Image Processing, pp. 2637 2640,
    Oct. 2006.
  • 5 Z. Wang and A.C. Bovik, A universal image
    quality index, IEEE signal processing letters,
    vol. 9, pp. 81-84, Mar. 2002.
  • 6 X. Shang, Structural similarity based image
    quality assessment pooling strategies and
    applications to image compression and digit
    recognition M.S. Thesis, EE Department, The
    University of Texas at Arlington, Aug. 2006.

45
References
  • 7 H. R. Sheikh and A. C. Bovik, A visual
    information fidelity approach to video quality
    assessment, The First International Workshop on
    Video Processing and Quality Metrics for Consumer
    Electronics, Scottsdale, AZ, Jan. 23-25, 2005
    http//live.ece.utexas.edu/publications/2005/hrs_v
    idqual_vpqm2005.pdf
  • 8 H. R. Sheikh and A. C. Bovik, Image
    information and visual quality, IEEE Trans.
    Image Processing, vol. 15, pp. 430 444, Feb.
    2006.
  • 9 A. Stoica, C. Vertan, and C.
    Fernandez-Maloigne, Objective and subjective
    color image quality evaluation for JPEG 2000-
    compressed images, International Symposium on
    Signals, Circuits and Systems, 2003, vol. 1, pp.
    137 140, July 2003.
  • 10 H. R. Sheikh, et al, Image and video
    quality assessment research at LIVE,
    http//live.ece.utexas.edu/research/quality/.
  • 11 A. C. Bovik and H. R. Sheikh, Image
    information and visual quality- a visual
    information fidelity measure for image quality
    assessment, http//live.ece.utexas.edu/research/
    Quality/VIF.htm.
  • 12 H. R. Wu and K. R. Rao, Digital video
    image quality and perceptual coding, Boca
    Raton, FL Taylor and Francis 2006.
  • 13 A. M. Eskicioglu and P. S. Fisher, Image
    quality measure and their performance, IEEE
    signal processing letters, vol. 43, pp.
    2959-2965, Dec. 1995.

46
References
  • 14 Z. Wang, H. R. Sheikh and A. C. Bovik,
    Objective video quality assessment, Chapter 41
    in The handbook of video databases design and
    applications, B. Furht and O. Marqure, ed., CRC
    Press, pp. 1041-1078, September 2003.
    http//www.cns.nyu.edu/zwang/files/papers/QA_hvd_
    bookchapter.pdf
  • 15 Z. Wang, A. C. Bovik and Ligang Lu , Why is
    image quality assessment so difficult", IEEE
    International Conference on Acoustics, Speech,
    and Signal Processing, Proceedings. (ICASSP '02),
    vol. 4, pp. IV-3313 - IV-3316, May 2002.
  • 16 T. S. Branda and M. P. Queluza,
    No-reference image quality assessment based on
    DCT domain statistics Signal Processing, vol.
    88, pp. 822-833, April 2008.
  • 17 B. Shrestha, C. G. OHara and N. H. Younan,
    JPEG2000 Image quality metrics
  • 18 http//media.wiley.com/product_data/excerpt/9
    9/04705184/0470518499.pdf
  • 19 http//en.wikipedia.org/wiki/Subjective_video
    _quality
  • 20 H. R. Sheikh, A. C. Bovik, and G. de
    Veciana, "An Information Fidelity Criterion for
    Image Quality Assessment Using Natural Scene
    Statistics," IEEE Transactions on Image
    Processing, in Publication, May 2005.
  • 21 http//www.cns.nyu.edu/zwang/files/research
    /quality_index/demo_lena.html
  • 22 http//live.ece.utexas.edu/research/Quality/v
    if.htm
  • 23 http//www.ece.uwaterloo.ca/z70wang/researc
    h/ssim/
  • 24 http//en.wikipedia.org/wiki/Mean_Opinion_Sco
    re
  • 25 www-ee.uta.edu/dip

47
  • Thank You
Write a Comment
User Comments (0)
About PowerShow.com
