Security on the World Wide Web

1
Security on the World Wide Web
2
Content

• WWW History architecture
• Security issues WWW
• Cryptography principals
• Securing the WWW

3
World Wide Web general architecture
4
Network

• Organized as a layered model
• of layers, content of layers depending from
  network to network
• 2 important reference models
• OSI (7 layers)
• TCP/IP (4 layers, used for the Internet)

5
TCP/IP Reference Model
6
TCP/IP Reference Model

• Layered model
• Each layer offers functionality to layer
  above
• Separation of concerns

7
TCP/IP Reference Model

• inject packets into the network
• Major issue packet routing
• Defines an official packet format and
  protocol, named IP

8
TCP/IP Reference Model

• To let peer entities on source and
  destination communicate
• Major issue packet sequencing, flow control
• 2 protocols TCP / UDP

9
TCP/IP Reference Model

• Applications building on layer below
• Examples telnet, smtp, ftp, DNS, http,

10
TCP/IP Reference Model

• Largely unspecified
• Host should connect to the network using some
  protocol so it can send IP packets

11
TCP/IP Reference Model protocols
12
TCP/IP Reference Model IP protocol
13
TCP/IP Reference Model IP protocol

• Keeps track of which version of the protocol the
  datagram belongs to
• Tells how long the header is

14
TCP/IP Reference Model IP protocol

• Allows the host to tell the subnet what kind of
  service it wants (different possibilities of
  reliability and speed)
• Both header and data (max. is 65535 bytes)

15
TCP/IP Reference Model IP protocol

• All fragments of one datagram have the same
  identification value
• Tells where in the current datagram this fragment
  belongs

16
TCP/IP Reference Model IP protocol

• Unused bit
• DF Dont fragment datagram (e.g. Destination
  cannot reconstruct)
• MF More fragments

17
TCP/IP Reference Model IP protocol

• Counter used to limit packet lifetimes
• When internet layer assembled a complete
  datagram, it needs to give it a transport process
  (TCP, UDP)

18
TCP/IP Reference Model IP protocol

• Is usefull for detecting errors generated inside
  a router
• Verifies the header only

19
TCP/IP Reference Model IP protocol

• Address of sender
• Address of receiver

20
TCP/IP Reference Model TCP protocol
21
TCP/IP Reference Model TCP protocol

• Both sender and receiver create endpoints
  (sockets)
• Socket number IP adress of host 16-bit local
  to that host (port)

22
TCP/IP Reference Model TCP protocol

• Position of data in the original data stream
• Acknowledges the acceptance of data from the
  other device

23
TCP/IP Reference Model TCP protocol

• The number of 32-bit words in the TCP header.
  This indicates where the data begins
• 6-bit field not used (set to 0)

24
TCP/IP Reference Model TCP protocol

• Six 1-bit flags
• URG to indicate if the urgent pointer is in use
• ACK to indicate that the acknowledgement number
  is valid
• PSH request the receiver to deliver the data to
  the application upon arrival instead of buffering
• RST used to reset the connection
• SYN to establish connections
• FIN to release the connection

25
TCP/IP Reference Model TCP protocol

• Defines the size of the sliding window.
• Error checking and correction

26
TCP/IP Reference Model TCP protocol

• Some events may cause TCP to stop accumulate data
  and transmit everything it has for that
  connection immediately ( urgent data)
• Defines the end of the urgent data so that the
  receiving application knows when it is over

27
TCP/IP Reference Model TCP protocol

• Most important option is the one that allows each
  host to specify the maximum TCP payload it is
  willing to accept

28
TCP/IP Reference Model UDP protocol
29
TCP versus UDP

• TCP guarantees a fault-free transportation
  channel to an application
• Packets that didnt reach the destination are
  send again
• Packets arrived in the wrong order are reordered
• ...
• UDP gives no guarantees

30
TCP versus UDP (cont.)

• TCP is a connection oriented protocol
• First establish a connection
• Use the connection for data transmission
• Release the connection
• UDP is a connectionless protocol (UDP packets can
  be send immediately)

31
TCP versus UDP (cont.)

• TCP contains flow control
• Both sides of the connection can tell the other
  party how many data can be send
• So when the sender sends to much data he will be
  slowed down by the receiver

32
TCP/IP Reference Model HTTP protocol

• HTTP client opens connection to server
• HTTP client sends request message
• HTTP server responds
• HTTP server closes connection

33
TCP/IP Reference Model HTTP protocol
From Figure 13.3 in Stevens
34
TCP/IP Reference Model sending http packets

• Application layer

Transport layer
Internet layer
35
World Wide Web security

• WWW was not designed with security in mind
• Problems
• eavesdropping
• spoofing
• altering information in transit
• executing malicious code

36
World Wide Web motivations for hacking

• Students for fun
• Sales representative make false claims
• Businessman steal competitors info
• Ex-employee revenge
• Spy steal military secrets
• Stockbroker deny promise
• Client deny acquisition

37
Security Issues

• Confidentiality
• secrecy of what is send
• Authentication
• identification of who is sending
• Integrity
• message send message received
• Nonrepudiation
• sender cannot deny sending a message

38
Security TCP/IP Reference Model

• Physically secure clients and servers
• Secure wires

39
Security TCP/IP Reference Model

• Filter (IP-) packages

40
Security TCP/IP Reference Model

• Encrypt entire connection (transparent)

41
Security TCP/IP Reference Model

• Explicit cryptography
• Must handle user authentication and
  non-repudiation

42
Cryptography introduction

• What? a collection of techniques to keep
  information secure
• Purpose twofold
• Encrypt the original, understandable message into
  a non-understandable message (using an encryption
  key)
• Ability to decrypt the unreadable message back
  into its original form (using a decryption key)

43
Cryptography basics (1/2)
44
Cryptography Basics (2/2)

• Good encryption/decryption algorithm
• Key length crucial
• How longer the key is, how longer the work for
  the cryptanalyst
• Prevent kid from reading email 64-bit key
• Governmental information at least 256 bits needed

45
Cryptography basic techniquesSubstitution
Cipher

• Substitute one letter by another
• Caesar cipher shift letters 3 positionsA -gt C,
  B -gt D, C -gt E,
• Generalization shift letters k positions
• Improvement monoalphabetic substituionplain
  text a b c d e f g h i j k l m n
  ciphertext q w e r t y u i o p a s
  d f
• Disadvantages statistical attacks, probable word
  attack

46
Cryptography basic techniquesTransposition
Cipher

• Re-order letters, not disguise
• Key is word not containing any repeated letters
  (e.g. MEGABUCK)
• Purpose of the key is to number the columns
• Plain text is written in rows, ciphertext read
  out by means of columns
• Safer than substitution, but still vulnerable

47
Cryptography basic techniquesOne-Time Pad

• 1. Choose a random bit string2. Convert
  plaintext into bitstring (e.g. ASCII)3. Compute
  exclusive OR of these bitstrings
• Potentially unbreakable because each plaintext is
  a candidate
• Disadvantage key cannot be memorized, amount of
  data limited, tedious synchronization

48
Cryptography algorithmsfundamental principles

• Redundancy
• To avoid garbage to be miss-interpreted as a
  valid message
• Freshness
• To avoid resending old messages

49
Cryptography algorithmscategories

• Symmetric key algorithm
• use same key to encrypt and decrypt
• Public key algorithm
• one key to encrypt, another to decrypt
• Hybrid cryptosystems
• public key algorithm for exchange of (symmetric)
  session key

50
Symmetric Key Algorithms

• Very fast
• Fairly easy to implement
• Used for bulk encryption
• Two techniques
• Stream algorithms (encrypt bits of message one at
  a time)
• Block algorithms (encrypt a number of bits as one
  unit)
• often implemented as a network of black boxes
  each imposing a reversible transformation on the
  plaintext

51
Symmetric Key Algorithms how?

• Mutually decide on cryptography algorithm C D
  to use
• Mutually decide which key K to use
• Person A uses key to produce cyphertext from the
  plaintext (CK(T))
• Person B uses key to decrypt cyphertext back into
  plaintext (DK(CK(T))

52
Symmetric Key Algorithms disadvantages

• key must be exchanged secretly (the problem of
  key management)
• Particular hacks are possible

53
Symmetric Key Algorithms Data Encryption
Standard

• Official U.S. government standard, 1977, ANSI
  standard in 1981
• Encrypts block of 64 bits
• Uses 56 bit key
• 19 distinct stages
• No longer safe

54
Symmetric Key Algorithms other examples

• DESX
• two additional steps
• Triple-DES
• DES three times with different keys
• IDEA
• 128 bit key
• believed to be strong
• used by PGP
• RC2, RC4, RC5

55
Public Key Algorithms

• Use of 2 keys (public key and private key)
• Proposed by Diffie and Hellman (Stanford, 1976)
• Slow
• Difficult to produce encryption algorithm
• Few existing algorithms

56
Public Key Algorithms
57
Public Key AlgorithmsRSA

• Named after inventors Rivest, Shamir, Adleman
• Based on prime factorization
• Widely used
• Used primarily for distributing one-time session
  keys for use with e.g. DES

58
Public Key Algorithmsother examples

• Diffie-Hellman key exchange
• ElGamal (based on discrete algorithms)
• Digital Signature Standard (DSS)

59
Hybrid Cryptosystems

• Use slow, public key algorithm to exchange key K
• Use K as key for a symmetric key algorithm
• Combines advantages of both public and private
  key algorithms

60
WWW Security

• Authentication

61
Authentication protocols

• Technique to verify that the communication
  partner is who it is supposed to be
• E.g. Bobs process asks the file server to delete
  the file salaries.txt
• Is it actually Bobs process? ? authentication
• Is Bob authorized to do that? ? authorization

62
Authentication protocolsbased on a shared
secret key

• Suppose Bob and Alice already have a secret key
  KAB
• Based on sending a random number RB (challenge)
  to the one asking a service
• Response going to challenger KAB(RB)
• Known as challenge-response protocols

63
Authentication protocolsChallenge - Response

• Shortened protocol

64
Authentication protocolsChallenge - Response

• Shortened protocol

This is wrong reflection attack!!!
65
Authentication protocolsReflection attack with
multiple sessions
66
Authentication protocolsChallenge Response
Bob doesnt send anything before Alice is
authenticated!!
67
Authentication protocolsChallenge
ResponseRequirements

• Have initiator prove identity first
• Have initiator and responder use different keys
• Use different challenges
• Avoid unrestricted parallel sessions

68
AuthenticationDigital signatures

• To solve the absence of an authorized handwritten
  signature for legal, financial and other
  documents
• Basically 3 things are needed
• The receiver can verify the claimed identity of
  the sender
• The sender cannot later repudiate the contents of
  the message
• The receiver cannot possibly construct the
  message himself

69
Authentication digital signaturesSecret key
signatures

• One central authority that knows everything and
  whom everyone trusts ? Big Brother
• Each user chooses a secret key and caries it by
  hand to BBs office

70
Authentication digital signaturesSecret key
signatures
71
Authentication digital signaturesPublic key
signatures

• No central authority needed
• BB has no access to the messages

72
Message Digests

• Signature methods often couple authentication and
  secrecy
• Crypthography is slow, so it is desirable to be
  able to send signed plaintexts
• De Jonge and Chaum, 1987 authentication scheme
  that does not require encrypting the entire
  message

73
Message Digests

• One-way hash function computes a fixed-length bit
  string from an arbitrarily long piece of
  plaintext
• Hash function is called a message digest
• Given MD(P), it is impossible to find P
• No 2 messages can be generated that have the same
  message digest

74
Authentication Message Digest Digital
SignatureHow?

• If intruder changes P underway, Bob will see this
  when he computes MD(P) himself
• Bob cannot change P since there is no P so that
  MD(P) MD(P)

75
Authentication Message Digest Digital Signature

• Can also be used in the BB signature protocol
• Several message digest functions have been
  proposed (MD5, SHA, ...)

76
WWW Security

• Communication

77
Communicationtransport level security

• Secure Socket Layer (SSL) standard
• SSL creates a secure connection between a client
  and a server
• By convention, URLs that require an SSL
  connection start with https//
• Provides data encryption, server authentication,
  message integrity, and optional client
  authentication for a TCP/IP connection

78
SSL (v. 3.0) how?

• Comes with 2 strengths 40-bit and 128-bit
  session key
• Runs above the transport layer (TCP) and below
  the application layer (http, ...)
• 2 phases
• Handshake
• Data transfer

79
SSL (v.3.0) how?

• Handshake phase
• agree on set of cryptographic algorithms
• establish set of cryptography keys
• Web Server authenticates browser using
  certificates
• Data transfer
• Client and server communicate using SSL Record
  Protocol
• SSL Record Protocol defines a message format used
  to transmit encrypted data

80
Communicationapplication level security

• SSL does not provide non-repudiation
• In addition to SSL, messages should be digitally
  signed

81
WWW Security

• Anonymity and Privacy

82
Anonymity and Privacywhy?

• Not to reveal surfing habits
• Avoid being subject of targeted spam
• Camouflage illegal actions

83
Anonymity at application level

• Browser discloses personal information
• Referring header
• User-Agent header
• Cookies
• enables web server to store information on local
  machine
• ideal for user profiling
• Same username/password for different sites

84
Anonymity at network level

• IP address always revealed
• Web proxy solution, but only for local observers

85
WWW Security

• Current technologies

86
Pretty Good Privacy (1/3)

• PGP is a tool, not a protocol!
• Set of standards for encrypting messages,
  providing keys and digital signatures
• DES, 3DES, CAST, IDEA, ... for symmetric
  encryption
• RSA, DSS or Diffie-Hellman for asymmetric
  encryption
• MD5 or SHA-1 for calculation of digests
• Confidentiality, integrity, authentication,
  nonrepudiation

87
Pretty Good Privacy (2/3)

• PGP is a hybrid cryptosystem
• PGP first compresses the plaintext
• Then PGP creates a session key (one-time only
  secret key)
• This session key is used in a fast symmetric key
  algorithm to encrypt the plaintext
• Session key is encrypted to the receivers public
  key

88
Pretty Good Privacy (3/3)

• Each user maintains 2 data structures
• Private key ring contains one or more personal
  private-public key pairs, so the user can change
  periodically
• Public key ring contains public keys of the
  users correspondents

89
Secure Multi Purpose Internet Mail Extensions
(S/MIME)

• Standard for sending files with binary attachment
  over the internet
• Toolkit for email clients
• Based on the RSA encryption method
• Competitor for PGP
• Confidentiality, integrity, authentication,
  nonrepudiation

90
Secure Electronic Transaction (1/2)

• Cryptographic protocol for ensuring the security
  of financial transactions on the Internet
• Three parts
• User has an electronic wallet (digital
  certificate)
• Merchant also has certificates
• SET payment server (bank)

91
Secure Electronic Transaction (2/2)

• How?
• Encrypted credit card number is sent to merchant
• Merchant digitally signs the payment and forward
  it to bank
• Bank decrypts and executes
• Advantage merchants do not see credit card number

92
WWW Security

• (Client side) Mobile Code

93
(Client side) Mobile Code introduction

• Examples Java applets, ActiveX, Javascript,
  VBScripts,
• Dangerous can potentially do everything the user
  is allowed to do

94
Mobile CodeJava applets

• JDK 1.1
• applet runs in sandbox
• sandbox model is extremely restrictive
• trades functionality for safety
• limited environment
• No acces to file system on client machine
• No opening of other network connection other than
  from which the applet came
• No execution of programs on client machine
• Cannot even find name of users home directory
  (where JVM is located)

95
Mobile CodeJava applets

• JDK 1.2 Security Issues
• uses digital signature
• All code can be subject to a security policy
• Security policy defines a set of permissions
• Runtime system organizes code into individual
  domains
• Each domain encloses a set of classes with the
  same set of permissions
• privileges assigned to pieces of code
