Project Overview

1
(No Transcript)
2
Optimisation of Data Access in Grid Environment

• Darin Nikolow1 Renata Slota1
• Lukasz Dutka1 Jacek Kitowski12
• Piotr Nyczyk1 Mariusz
  Dziewierz1
• 1Institute of Computer Science - AGH
• 2Academic Computer Centre CYFRONET - AGH
• University of Mining and Metallurgy, Cracow,
  Poland

CrossGrid Project - Task 3.4
Cracow Grid Workshop, Nov.5-6, 2001
3
Outline

• Background
• Bottom-top approach
• Media management software
• middleware for existing HSM
• dedicated VTSS
• Local component-expert systems
• Global policy for migration/replication

FOR MORE INFO...
http//www.icsr.agh.edu.pl/
4
Motivation

• Big and growing stuff of data
• Multimedia database systems (applications -
  medical, educational, virtual reality, virtual
  laboratories, digital libraries, advanced
  simulations, ...)
• Solution Tertiary Storage Systems (TSS) Media
  Libraries Management Software
• Examples of existing TSS
• HPSS, DataCutter, APRIL, Condor, OmniStore,
  UniTree, ......
• Possible directions
• Data access time estimation system - efficient
  usage
• Data distribution and grid implementation - large
  scale experiments
• Expert system for data management
• Replication policies

5
Background

• PARMED Project(Uni. of Klagenfurt - Uni. of
  Mining Metall. Cracow)
• to support physicians with telematic services
  for
• long distance collaboration of medical centers,
• medical teleeducation
• case archives

6
Bottom-top approach -Major Components

• Assumptions
• mechanism neutrality
• policy neutrality
• compatibility with grid infrastructure
• uniformity of information infrastructure

Replica Selection
Replica Management
Resource Management
Storage System
Metadata Repository
HSM
UniTree
Castor
HPSS
LDAP .....
7
Media Management Software

• Nikolow, D., Slota, R., Kitowski, J., Nyczyk, P.,
  Otfinowski, J., "Tertiary Storage System for
  Index-Based Retrieving of Video Sequences",
  Proc. Int. Conf. HPCN, Amsterdam, June 25-27,
  2001, Lect.Notes in Comp. Sci. 2110, pp. 62-71,
  Springer, 2001.
• Nikolow, D., Slota, R., Kitowski, J.,
  Benchmarking TertiaryStorage Systems with File
  Fragmentation, PPAM Conf., Naleczów, Lect.Notes
  in Comp.Sci., accepted.

8
Media Management Softwareand its usage in X

• Darin Nikolow
• darin_at_uci.agh.edu.pl

9
Motivation

• Main purpose of the developed TSS efficient
  index-based retrieving of video fragments
  (instead of file fragments)
• specific requirements for frequent data reading
• startup latency
• transfer time
• minimal transfer rate gt video bitrate
• Two prototypes proposed and benchmarked
• middleware layer for existing HSM
• dedicated TSS
• The developed systems are of general use -gt
  possible grid implementations

10
Multimedia Storage and Retrieval System (MMSRS)

• Requirements
• use existing software (UniTree HSM)
• reduce latency (start-up delay), i.e. -reduce
  file granularity
• file fragmentation (subfiles)
• Implementation
• splitting files into pieces of similar size

• Middleware layer on HSM
• Consists of
• Automated Media Library
• UniTree HSM managing system
• MPEG extension for HSM (MEH)
• MEH receives the name of video file and the frame
  range - start/end frames
• output stream via HTTP

11
Video Tertiary Storage System (VTSS)

• Repository Daemon REPD
• keeps repository information
• Tertiary File Manager Daemon TFMD
• managesfiledb - tape ident and startup position
  of the fragmenttapedb - information about tape
  usage

• Dedicated TSS
• Client requests to VTSS can be of the following
  kinds
• write a new file to VTSS, read a file fragment
  from VTSS, delete a file from VTSS.
• The fragment range is defined in the frame units
• Two daemons implemented in C using Unix sockets

12
MMSRS and VTSS performance

• Hardware (AML QuantumATL)
• ATL 4/52 (DLT 2000)
• ATL 7100 (DLT 7000)
• HP D-class server (with UniTree HSM)
• Data
• 790 MB MPEG1 file with B0.4 MB/s bitrate (33
  min.)
• subfile for MMSRS - 16 MB (8,16, 32 MB tested)
• as short as possible to keep reproducing smooth
  (low latency)
• optimal subfile length depends on
• positioning time
• drive transfer rate
• bitrate of the video file

13
Benchmarks

• Startup latency - time elapsed from issuing the
  request to receiving the first byte
• Transfer time - time from receiving the first
  byte till the end of transmission
• Minimal rate - minimal transfer rate experienced
  by a client with endless buffer (should be
  greater than the bitrate of the video stream to
  have smooth reproduction)

14
Startup latency
VTSS (DLT2000)
MMSRS (DLT2000)
UniTree reference startup latency 718 s
VTSS (DLT7000)
15
Transfer time(beginning part shown only)
VTSS (DLT2000)
MMSRS (DLT2000)
UniTree reference transfer time 135 s
VTSS (DLT7000)
16
System performance for the whole video file
transfer (DLT2000)
17
Minimal transfer rate

• Definitions (for VTSS)
• Minimal transfer rate
• Time offset for tape changing direction

• n - number of packets
• Bj - number of bytes in j-th packet
• ti - time when i-th packet was received

• T - tape capacity in MB
• N - number of tracks
• Br - bitrate of video file in MB/s
• no bad blocks

18
Minimal transfer rate
VTSS (DLT2000)
MMSRS (DLT2000)

• For DLT2000
• T 10 GB
• N 64
• Br 0.4 MB/s

• For DLT7000
• T 35 GB
• N 52
• Br 0.4 MB/s

Qdt 400 s
Qdt 1723 s
VTSS (DLT7000)
19
Access Time Estimation Motivation for X

• Retrieving a file from TSS could last few seconds
  or few hours
• Users satisfaction increases when the access
  time of data is known (e.g. user waiting to watch
  selected video administrator recovering from
  backup)
• Efficient use of storage resources in Grid
  environment (data replication subsystem)

20
Access Time Estimation Approaches

• Open TSS approach
• source code changes
• will be used as experimental platform
• Black Box TSS approach - for existing HSMs in X
  sites
• retrieving TSSs state info via its native tools
  and available internal files

21
Access Time Estimation - Open TSS Approach
TSS
TSS Symulator
events
req. 1
ETA 4
data
ETA of req. id? 3
Client
req. id 2
TSS source code changes - adding event reporting
functions
22
Access Time Estimation - Black Box TSS Approach
events collecting
TSS Monitor
update 4
TSS
TSS state 5
databases
logs
TSS Simulator
conf. files
fileid 9
ETA 6
Monitoring tools
fileid 2
data 10
Disk cache
queue state 3
Request Monitor Proxy
feedback 12
ETA 7

• Needed info by Simulator
• nr of drives
• tape labels
• media types
• position of file in media
• nr of requests
• ...

fileid 8
data 11
Client
fileid ETA? 1
23
Conclusions

• MMSRS and VTSS more efficient than standard
  UniTree HSM
• MMSRS efficient enough to be used as a middleware
  for existing HSM of UniTree type (in X sites)
• Proposed measurements could be used for
• building more sophisticated distributed storage
  systems (faster access to files stored in TSS)
• building access time estimation subsystem
• Access time estimation subsystem ---gtgtgt an
  information provider for X replication and
  migration of data

http//www.icsr.agh.edu.pl/
24
(No Transcript)
25
Component-expert Systems

• Dutka, L., and Kitowski, J., Implementation of
  expert technologies in information systems based
  on a component methodology, MSK 2001 Conf.,
  Nov. 19-21,2001 Cracow, accepted (in Polish).
• Dutka, L., and Kitowski, J., Component-expert
  technology in mass-storage grid applications,
  ICCS 2002 Conf., April 2002, Amsterdam, in
  preparation.

26
Basics of Component-Expert Technology and its
usage in X

• Lukasz Dutka
• dutka_at_agh.edu.pl

27
Classical component strategy
28
Component-expert strategy
29
Component structure
30
Component header structure
31
Structure of component code
32
Call-Environment

• Describe state of the call place
• Describe call place requirements
• Caries information about user or programmer
  wishes
• Expert system processes Call-Environment and
  finds best component for given Call-Environment

33
Expert Subsystem

• Rule-based expert system
• Typical rule looks like If log-expr Then action1
  Else action2
• The rules describe what is meant by The best
  component for given Call-Environment
• Expert system logs calls and stores deduction
  results for further analysis

34
Profits from Component-Expert technology

• Dynamic expanding system possibility
• Ease of solving new problems
• Minimising programmer responsibility for
  component choice
• Ease of programming in heterogeneous environment
• Maximal reusable of components
• Internal simplicity of components code
• Increase efficiency of programming process

35
Component-Expert Technology for X Task 3.4
36
Basic analysis of Data-access problems in X

• Different data set types
• Huge data files
• Distributed environment
• Long distance connections
• Mission critical applications
• Heterogeneous data storing systems
• Heterogeneous computing systems
• Open system
• Unpredictable file types

37
Basic connection diagram
38
Sequence Diagram
39
Example of Component-Expert technology usage for
data access in X

• Sample Attributes
• User ID
• Computing Node ID
• Preferred replica localisation
• Required throughput
• Application purpose
• Data sharing
• Critical level
• Replica expiration .....

• Example of local decisions
• Devices choosing (according to availability and
  type)
• Storing format (blocks, multimedia
  streams,......)
• Available delivering performance (network,
  storage devices,....)
• ... And much more ...

40
Control System for Migration/Replication
Strategies (1/2)

• Assumptions
• replica lt--gt file instances
• read only
• no update, no coherence

From replica manager
41
System Management for Migration/Replication
Strategies (2/2)

• In cooperation with other projects
• High-level control system (e.g. cooperating with
  LDAP)
• Two possible realizations
• heuristic reinforcement learning based on
  heuristic strategies for migration/replication
  and system state
• classical rule-based expert system

42
Conclusions

• Some elements have been defined and implemented
• Working on higher level structure and cooperation
  with other X modules and services

43
