Machine Learning and its Applications in Bioinformatics

1
Machine Learning and its Applications in
Bioinformatics

• Yen-Jen Oyang
• Dept. of Computer Science and Information
  Engineering

2
Observations and Challenges in the Information
Age

• A huge volume of information has been and is
  being digitized and stored in the computer.
• Due to the volume of digitized information,
  effectively exploitation of information is beyond
  the capability of human being without the aid of
  intelligent computer software.

3
An Example ofSupervised Machine Learning (Data
Classification)

• Given the data set shown on next slide, can we
  figure out a set of rules that predict the
  classes of objects?

4
Data Set
5
Distribution of the Data Set
6
Rule Based on Observation
7
Rule Generated by a Kernel Density Estimation
Based Algorithm

• Let and
• If then
  predictionO.
• Otherwise predictionX.

8
(No Transcript)
9
Identifying Boundary of Different Classes of
Objects
10
Boundary Identified
11
Problem Definition ofData Classification

• In a data classification problem, each object is
  described by a set of attribute values and each
  object belongs to one of the predefined classes.
• The goal is to derive a set of rules that
  predicts which class a new object should belong
  to, based on a given set of training samples.
  Data classification is also called supervised
  learning.

12
The Vector Space Model

• In the vector space model, each object is
  described by a number of numerical
  attributes/features.
• For example, the outlook of a man is described by
  his height, weight, and age.
• It is typical that the objects are described by a
  large number of attributes/features.

13
Transformation of Categorical Attributes into
Numerical Attributes

• Represent the attribute values of the object in a
  binary table form as exemplified in the following

14

• Assign appropriate weight to each column.
• Treat the weighted vector of each row as the
  feature vector of the corresponding object.

15
Transformation of the Similarity/Dissimilarity
Matrix Model

• In this model, a matrix records the
  similarity/dissimilarity scores between every
  pair of objects.

16

• We may select P2, P5, P6 as representatives and
  use reciprocals of the similarity scores to these
  representatives to describe an object.
• For example, the feature vectors of P1 and P2 are
  lt1/53, 1/35, 1/180gt and
• lt0, 1/816, 1/606gt, respectively.

17
Applications ofData Classificationin
Bioinformatics

• In microarray data analysis, data classification
  is employed to predict the class of a new sample
  based on the existing samples with known class.
• Data classification has also been widely employed
  in prediction of protein family, protein fold,
  and protein secondary structure.

18

• For example, in the Leukemia data set, there are
  72 samples and 7129 genes.
• 25 Acute Myeloid Leukemia(AML) samples.
• 38 B-cell Acute Lymphoblastic Leukemia samples.
• 9 T-cell Acute Lymphoblastic Leukemia samples.

19
Model of Microarray Data Sets
20
Alternative Data Classification Algorithms

• Decision tree (Q4.5 and Q5.0)
• Instance-based learning(KNN)
• Naïve Bayesian classifier
• RBF network
• Support vector machine(SVM)
• Kernel Density Estimation (KDE) based classifier.

21
Instance-Based Learning

• In instance-based learning, we take k nearest
  training samples of a new instance (v1, v2, ,
  vm) and assign the new instance to the class that
  has most instances in the k nearest training
  samples.
• Classifiers that adopt instance-based learning
  are commonly called the KNN classifiers.

22
Example of the KNN Classifiers

• If an 1NN classifier is employed, then the
  prediction of ? X.
• If an 3NN classifier is employed, then prediction
  of ? O.

23
Decision Function of the KNN Classifier

• Assume that there are two classes of samples,
  positive and negative.
• The decision function of a KNN classifier is

24
Extension of the KNN Classifier

• We may extend the KNN classifier by weighting the
  contribution of each neighbor with a term related
  to its distance to the query vector

25
A RBF Network Based Classifier withGaussian
Kernels

• It is typical that all are radial
  basis functions of the same form.
• With the popular Gaussian function, the decision
  function is of the following form

26
The Common Structure of the RBF Network Based
Data Classifier
v
27
(No Transcript)
28
Regularization of a RBF Network Based Classifier

• The conventional approaches proceed with either
  employing a constant s for all kernel functions
  or employing a heuristic mechanism to set si
  individually, e.g. a multiple of the average
  distance among samples, and attempt to minimize
• where is a learning sample.

29

• The term
• is included to avoid overfitting and ? is to be
  set through cross validation.

30
(No Transcript)
31
(No Transcript)
32
Decision Function of a SVM

• A prediction of the class of a new sample located
  at v in the vector space is based on the
  following rule

33
The Kernel Density Estimation (KDE) Based
Classifier

• The KDE based learning algorithm constructs one
  approximate probability density function for one
  class of objects.
• Classification of a new object is conducted based
  on the likelihood function

34
Identifying Boundary of Different Classes of
Objects
35
Boundary Identified
36
Problem Definition of Kernel Density Estimation

• Given a set of samples
• randomly taken from a probability distribution.
  We want to find a set of symmetric kernel
  functions and the corresponding
  weights such that

37
The Proposed KDE Based Classifier

• We determined to employ the Gaussian function and
  set the width of each Gaussian function to a
  multiple of the average distance among
  neighboring samples

38

• can be estimated as follow

39
Accuracy of Different Classification Algorithms
40
Comparison of Execution Time(in seconds)
41
Parameter Setting through Cross Validation

• When carrying out data classification, we
  normally need to set one or more parameters
  associated with the data classification
  algorithm.
• For example, we need to set the value of k with
  the KNN classifier.
• The typical approach is to conduct cross
  validation to find out the optimal value.

42

• In the cross validation process, we set the
  parameters of the classifier to a particular
  combination of values that we are interested in
  and then evaluate how good the combination is
  based on alternative schemes.
• With the leave-one-out cross validation scheme,
  we attempt to predict the class of each sample
  using the remaining samples as the training data
  set.

43

• With 10-fold cross validation, we evenly divide
  the training data set into 10 subsets. Each
  time, we test the prediction accuracy of one of
  the 10 subsets using the other 9 subsets as the
  training set.

44
Overfitting

• Overfitting occurs when we construct a classifier
  based on insufficient quantity of samples.
• As a result, the classifier may works well for
  the training dataset but fail to deliver an
  acceptable accuracy in the real world.

45

• For example, if we toss a fair coin two times,
  there is a 50 chance that we will observe either
  side up in both tosses.
• Therefore, if we draw our conclusion on how fair
  the coin is with just two tosses, we may end up
  with overfitting the dataset.
• Overfitting is a serious problem in analyzing
  high-dimensional datasets, e.g. the microarray
  datasets.

46
Alternative Similarity Functions

• Let lt vr,1, vr,2 ,, vr,ngt and lt vt,1, vt,2 ,,
  vt,n gt be the gene expression vectors, i.e. the
  feature vectors, of samples Sr and St,
  respectively. Then, the following alternative
  similarity functions can be employed
• Euclidean distance

47

• Cosine
• Correlation coefficient--

48
Importance of Feature Selection

• Inclusion of features that are not correlated to
  the classification decision may make the problem
  even more complicated.
• For example, in the data set shown on the
  following page, inclusion of the feature
  corresponding to the Y-axis causes incorrect
  prediction of the test instance marked by ?, if
  a 3NN classifier is employed.

49
y
x
x10

• It is apparent that os and x s are separated
  by x10. If only the attribute corresponding to
  the x-axis was selected, then the 3NN classifier
  would predict the class of ? correctly.

50
Linearly Separable and Non-Linearly Separable

• Some datasets are linearly separable.
• However, there are more datasets that are
  non-linearly separable.

51
An Example of Linearly Separable
y
x
52
An Example of Non-Linearly Separable
53
A Simplest Case ofLinearly Separable
y
x
x10
54
Feature Selection Based on the Univariate Analysis
Class 1
Class 2
Class 3
55
(No Transcript)
56
An Example of Univariate Analysis
57
Joint p.m.f. of X, Y, and C
58
(No Transcript)
59
Blind Spot of the Univariate Analysis

• The univariate analysis is not able to identify
  crucial features in the following example

y
x
60
The Demonstrative Data Set
61
Joint p.m.f. of X, Y, and C
62

• For Gene X,
• For Gene Y,

63

• However, if we apply the following linear
  transformation, then we will be able to identify
  the significance of these two genes
• 2?(GeneX)?(GeneY)

64

• For 2 Gene X Gene Y,

65

• On the other hand, if we employ linear operator
  (x2y), then we obtain

66

• Accordingly, the issue now is that how we can
  figure out the optimal linear operator of form
  axßy for the projection.
• In the 2-D case, given a set of samples
• (x1,y1), (x2,y2),, (xn,yn),
• then vi cos?xisin?yi
• is the value obtained by projecting (xi,yi) on
• sin?x-cos?y0
• or on the component along vector
• (cos?, sin?) as shown on the following page.

67
(No Transcript)
68
Feature Selection with Independent Components
Analysis (ICA)

• In recent years, ICA has emerged as a promising
  approach for carrying out multivariate analysis.

69
Basic Idea

• The ICA algorithm attempts to identify a plane so
  that when we project the data set on the plane
  the distribution is most non-gaussian.

70
A Measure of Non-Gaussianity

• The kurtosis is commonly employed to measure the
  non-Gaussianity of a data set.
• The kurtosis of a dataset v1, v2 , , vn is

71

• The expected value of the kurtosis of a set of
  random samples taken from a standard normal
  distribution is 0.
• If the kurtosis of a set of random sample is
  larger than 0, then the p.d.f. of the
  distribution is sharper than the standard normal
  distribution.
• If the kurtosis of a set of random sample is
  smaller than 0, then the p.d.f. of the
  distribution is flatter than the standard normal
  distribution.

72

• Let kurt(?) denote the kurtosis of v1, v2 , ,
  vn

73

• The issue now is to find the value of ? that
  minimizes kurt(?).
• This is an optimization problem.

74
The Optimization Problem

• The optimization problem is to find the global
  maximum/minimum of a function.
• There are several heuristic algorithms designed
  for solving the optimization problem, e.g.
• gradient descend
• genetic algorithms
• simulated annealing.

75
The Gradient Descend Algorithm

• In the gradient descend algorithm, a number of
  random samples are taken as the starting points.
• Then, we compute the gradient at each point and
  make a move in the direction of which the slope
  is maximum.
• This process is repeated a number of times until
  the convergent criterion is met.

76
An 1-D Example
d is a parameter that controls the stepsize
77

• The gradient descend algorithm can be applied to
  multidimensional functions. In such cases,
  partial differentiation is involved.
• If the gradient descend algorithm is to be
  employed, then we must be able to compute the
  gradient of the function at any point in the
  vector space.

78
Blind Spot of ICA

• However, ICA may fail in the following
  non-linearly separable dataset

79
Data Clustering

• Data clustering concerns how to group a set of
  objects based on their similarity of attributes
  and/or their proximity in the vector space.

80
Model of Microarray Data Sets
Class 1
Class 2
Class 3
81
Applications of Data Clustering in Microarray
Data Analysis

• Data clustering has been employed in microarray
  data analysis for
• identifying the genes with similar expressions
• identifying the subtypes of samples.

82

• For cluster analysis of samples, we can employ
  the feature selection mechanism developed for
  classification of samples.
• For cluster analysis of genes, each column of
  gene expression data is regarded as the feature
  vector of one gene.

83
The Agglomerative Hierarchical Clustering
Algorithms

• The agglomerative hierarchical clustering
  algorithms operate by maintaining a sorted list
  of inter-cluster distances/similarity.
• Initially, each data instance forms a cluster.
• The clustering algorithm repetitively merges the
  two clusters with the minimum inter-cluster
  distance or the maximum inter-cluster similarity.

84

• Upon merging two clusters, the clustering
  algorithm computes the distances between the
  newly-formed cluster and the remaining clusters
  and maintains the sorted list of inter-cluster
  distances accordingly.
• There are a number of ways to define the
  inter-cluster distance
• minimum distance/maximum similarity
  (single-link)
• maximum distance/minimum similarity
  (complete-link)
• average distance/average similarity
• mean distance (applicable only with the vector
  space model).

85

• Given the following similarity matrix, we can
  apply the complete-link algorithm to obtain the
  dendrogram shown on the next slide.

86

• Assume that the complete-link algorithm is
  employed.
• If those similarity scores that are less than 0.3
  are excluded, then we obtain 3 clusters P1, P4,
  P2, P5, P6, P3.

0.018
0.137
0.494
0.862
0.816
P1
P4
P2
P5
P6
P3
87

• If the single-link algorithm is employed, then we
  obtain the following result.

88
Example of the Chaining Effect
Single-link (10 clusters)
Complete-link (2 clusters)
89
Effect of Bias towards Spherical Clusters
Single-link (2 clusters)
Complete-link (2 clusters)
90
K-Means A Partitional Data Clustering Algorithm

• The k-means algorithm is probably the most
  commonly used partitional clustering algorithm.
• The k-means algorithm begins with selecting k
  data instances as the means or centers of k
  clusters.

91

• The k-means algorithm then executes the following
  loop iteratively until the convergence criterion
  is met.
• repeat
• assign every data instance to the closest cluster
  based on the distance between the data instance
  and the center of the cluster
• compute the new centers of the k clusters
• until(the convergence criterion is met)

92

• A commonly-used convergence criterion is
• If the difference between the values of two
  consecutive iterations is smaller than a
  threshold, then the algorithm terminates.

93
Illustration of the K-Means Algorithm---(I)
94
Illustration of the K-Means Algorithm---(II)
95
Illustration of the K-Means Algorithm---(III)
96
A Case in which the K-Means Algorithm Fails

• The K-means algorithm may converge to a local
  optimal state as the following example
  demonstrates

Initial Selection
97
Conclusions

• Machine learning algorithms have been widely
  exploited to tackle many important bioinformatics
  problems.
