Memory

1
Memory

• Special Lecture
• Kevin Silber
• University of Derby

2
Overview

• The aim of this topic is to give you an
  introduction to the cognitive psychology of human
  memory.
• In studying memory, you will look at how we
  (humans) encode, store and retrieve information.
  This information can be either visual or verbal.
• We consider the distinction between short-term
  memory (STM) and long-term memory (LTM).
• In this lecture we look in details at short term
  memory.

3
Learning Objectives

• By the end of this topic you will be able to
• Understand what is meant by the encoding, storage
  and retrieval of information.
• Understand the distinction between STM and LTM.
• Understand the distinction between semantic and
  episodic memory.

4
What Is Memory?

• Memory is a set of processes that allow us to
  encode, store and retrieve information.
• William James believed that there were three
  types of memory store
• Sensory memory
• Short term memory
• Long term memory

5
What Is Memory?

• If you were in any doubts as to just how
  phenomenal our memory is, on the next slide I
  will ask you to recall something.
• I will give you a minute to recall as much about
  this thing as possible.

6
What Is Memory?

• Try to remember the last meal that you had at a
  restaurant

7
(No Transcript)
8
What Is Memory?

• Did you recall what the meal was?
• Did you recall the restaurant and features about
  it?
• Did you recall who you were with?
• What else did you recall?

9
What Is Memory?

• Given that I could have asked you just about
  anything, you have to admit that this memory
  retrieval system is pretty impressive
• It is no wonder that psychologists have wanted to
  find out just how this instantaneous retrieval
  processing is achieved
• But to do that we must also consider how the
  information gets in in the first place and then
  how it is stored

10
Psychological Approaches to the Study of Memory

• Given James distinction between the three types
  of memory, psychologists have asked a number of
  questions
• How long does each type last?
• How much information can be stored in each type?
• What is the nature of the processing for each
  type?

11
Sensory Memory

• There is believed to be a sensory store to
  accompany each of the five senses.
• However, the iconic (visual) and echoic
  (auditory) stores have been most studied.
• Sperling (1960) did the following study on the
  iconic store.

12
Sensory Memory

• Look at the x below

P B S R W O V U G
X
X
13
Sensory Memory

• What letters do you remember seeing?
• This is the pattern of letter you saw.
• How many did you get right?

P B S R W O V U G
14
Sensory Memory

• The capacity of sensory memory is thought to be
  the same as for the sensory system itself
• The estimates of the duration of sensory memory
  vary but range from 0.5 to 1 second for iconic
  memory (Sperling) to about 4 to 5 seconds for
  echoic memory.

15
Primary and Secondary Memory

• James described the main types of memory as
  primary memory and secondary memory
• Primary memory is what is in the here and now so
  is the equivalent of short term memory
• Secondary memory is described as the memory of
  the past and so equates to long term memory
• What evidence is there that these two types of
  memory are distinctive?

16
The Serial Position Curve

• I am going to give you a sequence of 20 words
• At the end, I will give you some time to write
  down as many as you can remember
• You can write them down in any order
• Are you ready?

17
Now write down as many words as you can remember
desk
shirt
ball
kerb
stick
piano
house
ball
clock
tree
lamp
door
case
carrot
radio
dog
bed
school
shampoo
bus
18
(No Transcript)
19
The Serial Position Curve

• Here are the words you saw
• Lets see which ones people remembered
• The next slide shows a graph of what we should
  have got (it is a 25 item version)

desk shirt ball kerb stick piano house ball clock
tree lamp door case carrot radio dog bed school sh
ampoo bus
20
The Serial Position Curve
21
The Serial Position Curve

• The curve has a recency effect where you remember
  the final few items.
• This is attributed to a direct output from STM.
• It has a primacy effect where you remember the
  first few items.
• This is attributed to the first few items having
  been rehearsed into LTM.
• It has an asymptote where recall is poor in the
  middle.
• This is because the items could not be rehearsed
  and so failed to be transferred into LTM.

22
Evidence from Neuropsychology

• What evidence is there that the two stores are
  truly separate.
• We can look to brain damage for the verification
• Patient KF had an intact LTM but a badly impaired
  STM
• Patients with Korsakoff syndrome have the
  reverse.
• This separation is called a double dissociation

23
The Modal Model

• Atkinson and Shiffrin (1968) put together the
  evidence that had been collected into a model
  they called the Modal Model
• The model was revised slightly in 1971.
• The next slide presents the model.

24
The Modal Model
25
The Modal Model

• In the model, STM has a short capacity (7 /- 2
  according to Miller, 1956)
• Rehearsal is the key to transferring information
  from STM to LTM
• LTM has an unlimited capacity
• Forgetting from STM occurs via displacement but
  information is never really forgotten from LTM
  the problem is one of retrieval

26
Problems with the Modal Model

• If rehearsal is needed for transfer from STM to
  LTM then how can people have an intact LTM and a
  deficit in STM as in patient KF?
• Also, the idea of a singular STM does not take
  account of differences in STM recall for
  different types of information.

27
Working Memory

• An alternative model to the Modal Model was
  presented by Baddeley and Hitch in 1974

28
Summary

• We have seen what a fascinating process memory is
• We have explored the main types of sensory memory
  (echoic and iconic)
• We have looked at the distinction between STM and
  LTM
• The concept of working memory has been introduced
