IEA PVPS Task 2 Status Report Presentation

1
IEA PVPS Task 2 Status Report Presentation
Performance, Reliability and Analysis of
Photovoltaic Systems

• Ulrike Jahn
• 28th Meeting Executive Committee
• Busan, 26-27 October 2006

2
Contents

• 1. Task 2 objectives and strategies
• 2. Key matters for ExCo discussion / action
• 3. Progress with Task 2 activities
• 4. Task 2 website
• 5. Summary of inter-task coordination
• 6. Summary of Task participation contribution
• 7. Meetings

3
1. Task 2 objectives and strategies

• To provide technical information on operational
  and economic performance, long-term reliability
  and technology trends of PV systems and
  components
• To distribute the Performance Database and other
  Task 2 deliverables to target groups, to track
  the use of our products by means of website
  statistics

4

• IEA PVPS Task 2 at arsenal research
• PVPS Task 2 Meeting, Vienna
• 18 20 September 2006

5
2. Key matters for ExCo discussion and/or action

• For action - ExCo members are asked to give
  their approval to the web-based Performance
  Database, which has been developed for faster
  access and for additional user groups.
• Access via www.iea-pvps-task2.org

6
2. Key matters for ExCo discussion and/or action

• For action - ExCo members are requested to
  ensure that the Task 2 representatives will have
  the resources to complete and finalize the
  planned Task 2 documents deliverables until the
  end of the current phase of Task 2 (31st August
  2007).

7
3. Progress with Task 2 activities

• 3.1 Accomplishments of the previous six months
• 3.1.1 Enrichment/Dissemination of Task 2 Database
• 3.1.2 Online Performance Database
• 3.1.3 Technical Analysis of PV systems
• 3.1.4 Dissemination of Task 2 Results

8
3. Progress with Task 2 activities

• 3.1 Accomplishments of the previous six months
• 3.1.1 Enrichment/Dissemination of Task 2 Database
• PV Performance Database
• Data collection for new version
• Entering 30 new PV systems
• Adding performance data of existing systems
• Release in September 2006
• Dissemination via www.iea-pvps-task2.org

9
3. Progress with Task 2 activities

• 3.1 Accomplishments of the previous six months
• 3.1.1 Enrichment PV Performance Database
• 461 PV systems
• 21 Countries
• 15 MW of total installed power
• 85 GCS 15 SAS

10
3. Progress with Task 2 activities

• 3.1 Accomplishments of the previous six months
• 3.1.1 Enrichment/ PV Performance Database (total
  461)

11
3. Progress with Task 2 activities

• 3.1 Accomplishments of the previous six months
• 3.1.1 Enrichment/ PV Performance Database (total
  461)

12
3. Progress with Task 2 activities

• 3.1.1 Dissemination of Task 2 Database
• Database statistics as of 31 August 2006
• 3923 online registrations (3527 in April 2006)
• 3274 downloads 83
• 754 downloads of database update
• 800 distributed CD-ROMs
• 90 countries
• Database promotion by
• websites, newsletters, articles, flyers,
  conference presentations, workshops, training
  courses, etc.

13
3. Progress with Task 2 activities3.1.1 Dissemina
tion of Task 2 Database
Quarterly registrations and downloads, 31 August
2006
14
3. Progress with Task 2 activities3.1.1 Dissemina
tion of Task 2 Database
Registrations by sector, 31st August 2006
15
3. Progress with Task 2 activities3.1.1 Dissemina
tion of Task 2 Database (Top 15)
16
3. Progress with Task 2 activities 3.1.2 Online
PV Performance Database
Original Performance Database
Data delivery
Task 2 Member
Updated database
DatabaseUser
Database on Web Server
Online access
17
Diagram example
18
Diagram example
19
Diagram example
20
(No Transcript)
21
Diagram example
22
Diagram example
23
Diagram example
24
Diagram example
25
Diagram example
26
Diagram example
27
Diagram example
28
3. Progress with Task 2 activities

• 3.1 Accomplishments of the previous six months
• 3.1.2 Online PV Performance Database
• Installation on public server for testing July
• Testing of web application by Task 2 September
• Finalizing and approval by the ExCo October
• Release of online database November
• http//www.pvps-task2.zae.uni-erlangen.de/pvpsweb
  /
• user name iwae00wmpasswort pvpsT2Web

29
3. Progress with Task 2 activities

• 3.1 Accomplishments of the previous six months
• 3.1.3 Technical analysis and assessments
• PV in the built environment
• Long-term reliability of PV systems
• Users awareness of PV system performance
• Performance prediction

30
3. Progress with Task 2 activities

• 3.1 Accomplishments of the previous six months
• 3.1.3 Activity 51 PV in the Built Environment
• Work on-going
• Monitoring Messages to PV in the built
  environment
• Best practise on performance, acceptance
  technical standardisation in BIPV
• To provide recommendations for BIPV on avoiding
  thermally improper integration into buildings
  hull
• Draft report to be delivered in December 2006

31
3. Progress with Task 2 activities

• 3.1 Accomplishments of the previous six months
• 3.1.3 Activity 52 Long-term Reliability of PV
  Systems
• Work on-going
• Analysis of high-resolution data of 21 PV systems
• Performance ratio over time
• Failure statistics
• First results presented at EU Conference
• Technical report to be prepared

32
Analysis of Data of 21 Plants
Total
Total 106
33

• 3.1 Accomplishments of the previous six months
• 3.1.3 Activity 52 Long-term Reliability of PV
  Systems

RESULTS AND OUTLOOK

• 11 plants show no long-term variations of PR
• Various defects were found and reported
• Footprint method valuable for temporary effects
• PR at identical climatic conditions suitable for
  detecting small system failures

• Clear sky index
• Focus on modules
• Performance data for larger PV Systems required

34

• 3.1 Accomplishments of the previous six months
• 3.1.3 Activity 53 Japan (AIST, JET, PVTEC)
• Work on-going
• Questionnaire survey of Japanese GCS, Nov 2004
• Questionnaire survey of Mongolian SHS, July 2005
• Analysis of end-users responses
• Collecting and checking field complaints
• Understanding performance and expected yields
• Internal report will be prepared

35
3. Progress with Task 2 activities

• 3.1 Accomplishments of the previous six months
• 3.1.3 Activity 54 Performance prediction
• To evaluate the global solar horizontal
  irradiation via satellite images and validation
  with ground based measurements (meteo stations)
  on-going activity
• To calculate solar irradiation for inclined
  surfaces and validation with ground based
  measurements at different time scales
  (Performance Database and other PV systems)

36
3. Progress with Task 2 activities

• 3.1 Accomplishments of the previous six months
• 3.1.3 Activity 54 Performance prediction
• Next steps
• To compare the calculated irradiation/irradiance
  on tilted surfaces with Performance Database or
  other PV systems, for these different cases
• - hourly, daily, monthly
• - From global horizontal using well known
  algorithms
• - From diffuse and direct horizontal components
  and the calculation to the tilt (heliosat3)

37
3. Progress with Task 2 activities

• 3.1 Accomplishments of the previous six months
• 3.1.4 Dissemination of Task 2 results
• Conference seminar presentations
• - European PV Conference, Dresden, 2006
• - PV Module Seminar, Augsburg, Germany, 2006
• New Task 2 Flyer distribution at exhibitions
• - Intersolar (Germany)
• - EU PVSEC (Germany)
• - RE2006 (Japan)
• European Master course (France)
• Training courses (Italy)
• Database presentations

38
3. Progress with Task 2 activities

• 3.2 Plans for the next six months
• 3.2.1 Enrichment of Task 2 Database
• Data collection for Performance Database, 2007
  balancing country contribution, type of systems,
  PV components technologies and types of
  buildings.
• New approach of data import of industry provided
  information and from websites of operators (DEU)
• Dissemination of PV Performance Database on
  national and international level.

Release of new Performance Database June 2007
39
3. Progress with Task 2 activities

• 3.2 Plans for the next six months
• 3.2.2 Technical analysis and assessments
• PV in the built environment
• Long-term reliability of PV systems
• Users awareness of PV system performance
• Performance prediction

40
3. Progress with Task 2 activities

• 3.2 Plans for the next six months
• 3.2.2.2 Performance prediction
• Description of the potential transfer criteria of
  PV monitoring system insolation data into
  existing insolation mapping databases (2006)
• PV systems monitoring input to PV systems
  performance prediction Technical Report
  (first version 12/2006, final draft 3/2007 )

41
3. Progress with Task 2 activities

• 3.2 Plans for the next six months
• 3.2.3 PV system cost over time
• Collecting and investigating performance data and
  economic data of PV systems
• Collecting data and information about real life
  maintenance costs of PV systems
• Predicting performance life expectancy of key
  components

42
3. Progress with Task 2 activities

• 3.2 Plans for the next six months
• 3.2.3 PV system cost over time
• In total 218 data sets of useful economic data
• Not sufficient for planned economic analysis
• Internet-based survey tool will be closed on
  31th October 2006
• Each country will edit a national case study
• Prepare final report (April to June 2007)

43
3. Progress with Task 2 activities

• 3.2 Plans for the next six months
• 3.2.4 Educational tools
• Collect case studies on educational tools (Italy)
• Develop an educational tool on the basis of case
  studies, Task 2 issues, Swedish tool
• Adjust the educational tool to different target
  groups in different countries (translation)
• Draft Report on Experiences on educational tools
  including case studies, didactic materials,
  feedback and suggestions.

44

• 3.3 Summary of documents published and
  planned and products released
• Draft report on Recommendations on Temperature
  and Shading Effects on PV System Performance,
  December 2006
• Draft report on Long-term System Performance and
  Reliability, January 2007.
• Draft report on PV System Performance Prediction
  , December 2006

45
4. Task 2 website www.iea-pvps-task2.org

• Public website with PVPS and Task 2 information,
  optional in French, German, Greek, Italian,
  Japanese, Spanish and Swedish
• Download of IEA-PVPS publications (reports,
  papers)
• Download of Performance Database and updates
• Access to Online Performance Database new!
• Registration of Database users
• Examples of PV system performance analysis
• List of national contact persons
• Regular updates, October 2006

46
4. Task 2 website www.iea-pvps-task2.org
Biannual Downloads July 2001 August
2006 Total number of downloaded documents 21
492
47
5. Summary of inter-task coordination

• Task 2 coordinates and cooperates with
• Task 10 on BIPV, perceptions of target groups,
  economic analysis educational tools
• Task 11 on performance indicators of PV hybrid
  systems (T2 participated in Kick-off)
• SHCP Task 36 dealing with Solar Resource
  Knowledge Management on performance prediction
  (OAs exchange on status and work)

48
6. Summary of Task participation
49
7. Task 2 meetings

• 5th arsenal research, Vienna, Austria
  18 20 September 2006
• 6th Hamamatsucho, Tokyo, Japan
  hosted by NEDO, 14 16 March 2007
• 7th Switzerland, September 2007

50
Solar Electricity makes you more independent.
Thank you for your attention!
51
2. Key matters for ExCo discussion and/or action

• For action - ExCo members are asked to give
  their approval to the web-based Performance
  Database, which has been developed for faster
  access and for additional user groups.
• Access via www.iea-pvps-task2.org

52
2. Key matters for ExCo discussion and/or action

• For action - ExCo members are requested to
  ensure that the Task 2 representatives will have
  the resources to complete and finalize the
  planned Task 2 documents deliverables until the
  end of the current phase of Task 2 (31st August
  2007).
• Activity leaders
• AUT, CAN, DEU, EU, FRA, ITA, JPN and CHE

53
Solar Electricity makes you more independent.
Thank you for your attention!
