MODELLING AND SIMULATION OF ABSORPTION SOLAR AIR CONDITIONING SYSTEM

1
MODELLING AND SIMULATION OF ABSORPTION SOLAR AIR
CONDITIONING SYSTEM

• Teclemariam Nemariam
• Department of Technology,
• Royal Institiute of Technology,
• Stockholm, Sweden
• email nemariam_at_egi.kth.se

2
Aim

• To obtain best system performance of a solar
  assisted absorption cooling system
• Solar fraction
• Overall system efficiency
• Total cost
• Initial cost
• Maintenance cost
• Operational cost

3
Methodology

• TRNSYS simulation program
• Transient Systems Simulation Program
• EES
• Engineering Equation Solver

4
System Description

• Energy source Refrigeration Load
• cycle

5
System Description

• Solar collector
• Thermal storage tank
• Auxiliary heater
• Absorption refrigeration chiller with cooling
  tower
• Building
• Diverter
• Tee-piece
• Relief valve
• Piping system

6
Trnsys Block Diagram
7
Absorption Refrigeration System
8
Absorption Refrigeration System

• Refrigerant
• water
• Absorbent
• Lithium bromide

• Stages
• Single-effect
• G. temp 80 100 C
• COP 0.6 0.8
• Double-effect
• Gen. Temp 100 160 C
• COP 1.0 1.2
• Triple-effect
• Gen. Temp 160 240 C
• COP ABOUT 1.7

9
Absorption Refrigeration System
Poor refrigerant
Strong refrigerant
10
Absorption Refrigeration System

• Drawbacks
• Water
• Temperature greater than zero
• High water vapour pressure
• Large volume
• Lithium bromide
• Precipitate at low temperature

11
Building

• Details of a building are
• Location latitude, longitude, altitude
• Type Office, recidential, hospital,...
• Size volume, area of walls, roof, floor,
  windows, door, ..etc
• Types of construction materials
• Outside design conditions
• Inside design conditions
• Internal gains

12
Work done so far

• More than 75 course work
• More than 80 literature survey
• Modelling and simulation of a complete system
  using standard TRNSYS components

13
Sample Simulation Results

• Solar collectors
• Evacuated collector, high quality flat plate
  collector and ordinary flat plate colector
• Storage tank cylinderical, vertical stand
• Heater gas fired
• Single-effect absorption machine
• Refrigerant water and absorbent lithium bromide
• Capacity 24.44 kW

14
Sample Simulation Results

• Building
• Location Assab, Eritrea. Latitude 13.07 N,
  longitude 42.6 E, altitude sea level
• Type two storey office
• Size volume, area of walls, roof, floor,
  windows, door, ..etc are given in detail
• Types of construction materials
• Outside design conditions
• Inside design conditions
• Internal gains
• Every detail is given

15
Sample Simulation Results

• System Optimization
• e.g. collector slope

16
Sample Simulation ResultsSolar fraction as a
function of colector area and storage volumee.g.
using evacuated collector
17
Sample Simulation Results

• System efficiency as a function of colector area
  and storage volume
• e.g. using evacuated collector

18
Sample Simulation Results

• Solar fraction and system efficiency as function
  of collector area for a given storage volume

19
Sample Simulation Results

• Yearly insolation energy, max possible solar heat
  gain and cooling load

20
Notice

• The sample simulation result is extracted from a
  paper presented in the ISES Conference June 14-19
  2003 in Götemberg, Sweden.
• If you have more interest please refer the paper.
• Thank you.
