Cyber Entity Directory Service

1
Cyber Entity Directory Service
2
Goal

• To provide a directory service for rapid location
  of Cyber Entities within the Bionet architecture.
• Tasks
• Prove the directory is scalable.
• Prove the directory is efficient.
• Prove the directory is fault tolerant.

3
Motivation

• In BIONET a CE may only maintain a finite number
  of relations.
• These relationships stabilize based upon
  similarity and usefulness.
• If a CE attempts to locate another CE that is not
  closely related or directly useful, search may
  take a long time.
• What if a CE application provided assistance to
  the search by organizing a distributed directory?
• The CE directory provides a fast look up service
  for other Cyber entities in the hopes of making
  discovery more efficient.
• Note Purpose in Bionet Reduces the amount of
  stabilization time in a network because CEs have
  an ordered lookup directory. This eliminates the
  unbounded search.

4
Motivation (cont.)

• What if network is highly dynamic and is
  constantly undergoing stabilization?
• Suppose a network is designed in such a fashion
  that CEs are born and die frequently.
• These CEs may not have enough time to establish
  meaningful relationships.
• Network may be slow because too many CEs are
  searching too much of the network (Relationships
  developed are not efficient enough)
• Ex PDA / Cellphone network with PDAs and
  Cellphones constantly coming on and off of the
  network.
• The Directory could allow direct access to
  necessary application CEs thus facilitating
  stability.

5
Proposed Purpose

• To provide a mechanism for fast look up of CEs
  based on a CEs published keyword.
• CEs will not have the capacity to publish an
  entire list of keywords. This facilitates
  modular design. Each CE should have a single
  purpose. That purpose is described by the
  keyword.
• It would become extremely much more demanding in
  terms of directory load to allow CEs to use
  multiple keywords.
• The mechanism is NOT the standard query method.
  It is meant only to enhance the relationship
  method.
• Suppose it takes 30 hops to find something in the
  directory while it takes 4 hops to find the same
  CE you are related to. Clearly the relational
  query is faster.
• Suppose it takes 30 hops to find something in the
  directory but takes 100 hops to find a CE you are
  not directly related to ( or have links
  established to ). Clearly it is better to take
  the directory.
• In the Bionet, CEs must make their own decisions
  on how to use the directory. The choice of when
  to use it is up to the CE designer. However,
  policies should be developed to guide the
  designer towards the most efficient use.
• Use the directory to look up CEs not closely
  related to currently established relationships.
• Use currently established relationships as a
  cache mechanism.
• Use the directory at CE birth to establish
  relationships.

6
Approach

• The directory is composed entirely of the CEs
  that choose to be a part of the directory.
• The choice is made be the CE designer.
• In order to be a part of the directory, a CE must
  inherit properties from a special CE class.
• The system has 3 types of CEs.
• The base level CE that contains methods and
  properties to maintain the database. The other 2
  CEs inherit from this CE/class.
• Daemon CEs that facilitate communication across
  platforms. ( Daemon CEs implement the base level
  directory CE ).
• Application level CEs. ( Application level CEs
  implement the base level directory CE ).

7
Approach

• How it works
• All CEs in the system have special relationships.
  These relationships are permanent.
• Left Child
• Right Child
• Parent
• When a platform is started, it connects to other
  platforms. A bootstrap process establishes a
  Daemon directory CE on the platform. Only one
  instance of a Daemon may run on a platform at a
  time. The Daemon may not die.
• Daemon CEs work to setup and maintain distributed
  tree structure. The concept must be thought of
  recursively.

8
Approach

• If a distributed tree exists then new Daemons /
  platforms insert themselves into the tree by
  contacting a Daemon on the platform where the
  Daemon migrated from.
• CEs in the directory are ordered off of a single
  published Keyword.
• They insert themselves in binary tree fashion.
  Since each CE in the directory has a left,right,
  and parent it can search for the location the new
  CE should be located.
• When the location is found, the CE is inserted at
  that spot, and a balancing algorithm progresses
  up to balance the tree.
• If no tree exists ( the first instance of the
  directory structure ) then create a new tree with
  the current Daemon as the top of the tree.

9
Approach

• When the Daemon has been established on a
  platform, CEs that implement the base level
  directory CE may now insert themselves into the
  directory. They do so in the same fashion that
  the Daemon CEs did as described above by
  contacting the local Daemon.
• When a CE is dying it sends a message to its
  children and parent. The message tells the
  parent and children to coordinate in such a
  fashion as to replace the dying node ( ie. The
  left child moves up ). At this point a
  rebalancing occurs.
• When a CE migrates it sends a message to its
  children and parent. The message tells the
  parent and children the new location that the CE
  is migrating too.

10
Approach

• Tree balancing.
• Tree balancing is needed to handle the following
  cases
• Host failure When a host goes down the tree
  cannot fall apart. Sub trees must realize that
  there has been a host failure and merge with the
  main tree. The main tree can be found using the
  Daemon nodes.
• Multiple directory locations If a failure occurs
  in such a fashion that the Bionet splits and
  multiple directories reestablish themselves, the
  directories must be able to merge themselves
  together efficiently.
• Insertion / Deletion When insertion and deletion
  happen there needs to be a weight balance
  algorithm that ensures the tree has O(log(n))
  depth.
• Unexpected CE death If a CE dies for some reason
  without completing its death state, the sub trees
  of the CE must be merged back into the tree. (
  similar to a host failure ).

11
Approach

• Tree balancing should guarantee some type of
  bound on the time for
• Insertion
• Deletion
• Search
• Merging
• The bound can either be rigid or amortized.

12
Approach

• Tree synchronization and locking
• Due to balancing and merging functionality
  certain locking procedures must be in place.
• What if a CE is searching the tree while a local
  node is rebalancing? The CE may take the wrong
  path down the tree.
• What if 2 sub trees try and merge to the same
  point in the tree?

13
Approach

• I am currently looking at algorithms for
  maintaining parallel trees, mergeable trees, and
  amortized trees. A suitable algorithm must be
  designed out of these fields to build the
  balancing algorithm the directory tree will
  implicitly maintain.

14
Approach (cont.)

• Distribute the CEs over the network.
• The CEs are now free to behave like all other
  CEs. They can migrate over the network as much as
  they want because each migration requires only 3
  updates to the tree. ( Left child, right child,
  parent ). The updates are done in constant time
  because a direct relationship is maintained.

15
Approach (cont.)

• Make the application an extension of Bionet that
  CEs chose to participate in rather than be
  forced to.
• If CEs can satisfy all their needs effectively
  without the directory, then they can exclude
  themselves from the directory. This leaves fewer
  CEs in the directory, thus reducing search
  resources overall.

16
Efficiency

• Search, insert, delete Time Sufficient
  algorithms exist to allow search times to be
  guaranteed at O(log(n)) to O( square root(n) ).
• Weight balance trees ( BBalpha, AVL ).
• Red-Black trees / 2 3 4 trees.

17
Efficiency

• Merge Time Using the datastructures listed
  previously we can guarantee a bound on merging
  two trees
• a is the number of nodes in tree A.
• b is the number of nodes in tree B.
• Inserting each value of A into B takes
• O(a log(a)) O( a log(b))
• If a is larger O(a log(a) )
• If b is larger O( a log(b) )

18
Efficiency

• This is the naive algorithm however. Do better
  algorithms exist? ( probably ) I am looking into
  this.
• However, we can assume that large merge
  operations do not occur frequently since they
  only occur during host failure or CE failure.
• Given M hosts who equally distribute CEs, the
  probability of a top level failure is 1 / M for
  any given host failure. For a top level failure
  we must merge two trees of n/2 size. This takes
  O(n/2 log(n)) O(n/2 log(n) ) time. Resulting
  in O(nlog(n)).
• Furthermore, if a failure occurs, the sub trees
  exist in a special state that may be more easily
  repaired then just merging two random binary
  trees.

19
Efficiency
Failure occurs at the red relationship.
If a failure occurs at the red relationship the
resulting sub trees have a special property The
left and right sub tree each maintain a Somewhat
disjoint domain.
20
Efficiency
A
B
lt
The two trees can be merged together because
their domains to not overlap ( provided the tree
has not changed ).
21
Alternate Solutions

• Allow only BIONET relationships and current
  discovery mechanisms to handle discovery.
• Does not allow for rapid lookup of unrelated
  entities.
• Requires a period of time before the network
  becomes stable enough to search efficiently.

22
Alternate Solutions

• Distributed Consistent Hashing ( Chord protocol
  applied to BIONET. http//pdos.ics.mit.edu/chord/
  )
• Provides good upperbound on both maximum number
  of links to other agents as well as search time.
  approx O(log( n ))
• n agents requires nlog(n) total relationships in
  the system.
• Our system needs 3 n.

23
Alternate Solutions (cont.)

• Adapt a graph theory approach like the HITS or
  HyperClass algorithm for webcrawling.
• Must be implemented at the CE level so all CEs
  are a part of the directory, not just a subset.
• Similar to Freenet, but instead of node becoming
  good at searching an area, a node gets ranked on
  how well it searches.

J. Kleinberg, S.R. Kumar, P. Raghavan, S.
Rajagopalan, and A. Tomkins, The web as a graph
Measurements, models and methods, Proceedings of
the International Conference on Combinatorics and
Computing 1999.
24
Advantages

• Applications that wish to be diverse may
  implement a protocol to talk to the CE directory
  service. This would link highly mobile and
  diverse agents together, while leaving relatively
  stagnant agents out of the directory, keeping the
  size of the directory limited and thus faster.

25
Advantages

• Provable bounds
• Search times of O(log(n)).
• Insertion / Deletion times of O(log(n)).
• Merge times of O(nlog(n)) with unrelated trees (
  two independent directories merging )
• Merge times of O(log(n)) with tree failures.

26
Summary

• To provide a directory service for rapid location
  of Cyber Entities within the Bionet architecture.
• Tasks
• Prove the directory is scalable.
• Prove the directory is efficient.
• Prove the directory is fault tolerant.

27
Summary

• This all boils down to finding good merging
  algorithms.
