3D codes: TraFiC4 and CSRtrack

1
3D codes TraFiC4 and CSRtrack

• Torsten Limberg
• DESY
• Zeuthen 2003

2
As an introduction a few slides fromCSR code
benchmarking3-D vs. 1-D models(M. Dohlus)
3
Simulation Models
projected model (Borland, Emma, ...)
phase space (eg. particle tracking)
1d charge density, 1d self-field
neglect transverse forces neglect transverse beam
dimensions neglect deformation of retarded
distribution (?(s,t) ? ?(s-c0t)
local rigid bunch approximation) extract 1d
singularity
4
?-bunch instability (Borland, Emma, Saldin,
Schneidmiller, Yurkov, Kim, Stupakov ...)
initial shape and energy distortions are
amplified transverse emittance uncorrelated
enegy spread are counteracting
5
Simulation Models
sub-bunch models (trafic4, R.Li, tredi...)
field generating sub-bunches with fixed shape (so
far) sampling particles (field monitors) selfconsi
stent calculation of generating sub-bunches and
sampling particles
6
reasons to mistrust the projected model
transverse bunch shape neglected transverse
cross-section of bunch neglected transverse
dependence of longitudinal forces neglected no
space charge fields no compression work no
transverse forces
7
charge distribution at end of magnet 3
retarded charge distribution at end of magnet
3 (observer is center particle)
retarded projected distribution
head is neglected !
retarded 2d charge distribution
8
500 MeV case longitudinal profile
projected model
tilted 4x10001
conditions for non-selfconsistent model are not
fulfilled for q gt 0.2nC
9
Conclusions
projected model

• fast efficient
• misses important physical effects
• some results seem to be correct (eg. ?-bunch
  instab.,
•
  benchmark bc transv. phase space)
• it is not clear under what conditions

trafic4-like tilted models

• complete field calculation for generating
  distribution
• transverse dimensions forces are not
  negligible
• modeling of slice dimensions not quite satisfying

10
First Version of 3D CSR Tracking Code Wake
Simple Input Deck
3D-CSR Solver from first principles With 1-3 D
distributed sub-bunches M. Dohlus
Fortran Tracking Code (no quads...)
Plot Beam Parameters with GNUPLOT
Output file
T. Limberg
11
TraFiC4 (A. Kabel)
http//www.stanford.edu/akabel
Readable Input Deck (Bison Parser) Variable Bunch
Set Up
3D-CSR Solver from first principles With 2-3 D
distributed sub-bunches M. Dohlus
Self-consistent C Tracking Code (parallel
processing with MPI)
Plot Beam Parameters with GNUPLOT T4P2 (P. Piot)
Big structuredOutput file containing phase
space, fields, RMS values etc.
12
CSRtrack
Simple Input Files for Calculation
Parameters,Lattice, Mesh, Initial Particle
Distribution
1D projected method 3D-CSR Solver With variable
sub-bunch length Greens-function method
Self-consistent Fortran Tracking Code (parallel
processing with MPI)
Separate File for Fields and Phase Space at each
Mesh Point
13
CSRtrack Interfaces

• Provide Matlab (or Octave) routines to interface
  the simple CSRtrack files and to other codes like
  elegant and ASTRA

F. Stulle
14
Status

• All necessary Interface routines exist in a basic
  form
• First calculations for S2E done. Performance on a
  linux cluster with 20 cpus (900 MHz)
• XFEL bc-3 with 50 mesh points, 200 field
  generating particles, 200 test particles
  distributed transversely to calculate slice
  emittance growth and optics mismatch ca.5min
• 200 field generating particles, 5000 test
  particles ca.2.5h

15
To be done

• Introduce Quadrupole Magnets
• Track vertical plane
• Improve Interface routines for comfortable S2E
  simulations
• ...
