Security and Reliability Issues in Distributed Systems

1
Security and Reliability Issues in Distributed
Systems

• Chan Hing Wing, Anthony
• MPhil Term 1,
• CSE CUHK
• December 11, 1998

2
Presentation Outline

• Introduction
• Distributed system security
• Common requirements and approaches
• The SSL protocol
• CORBA Security
• Distributed system reliability
• Common requirements and approaches
• Summary
• Questions and Answers

3
Introduction

• Distributed systems developed rapidly over the
  past two decades
• E.g., WWW, automatic teller machines, distant
  learning
• As distributed systems become widely used, their
  security and reliability becomes very important
• Distributed Systems hardware (autonomous
  computers, the linking network) and software
  (distributed system software)
• ? Security and Reliability both have hardware
  aspect and software aspect

4
Distributed System Security

• Hardware Vs Software
• Hardware security keys, locks, cards, visitor
  monitoring, etc. (not main focus)
• Software security
• (in terms of user requirements)
• integrity message transmitted over network must
  be identical to the original
• confidentiality message transmitted must not be
  readable to unintended entities
• availability the system must not be unavailable
  due to security attacks
• accountability user actions that is
  security-critical must be traceable

5
Common Approaches

• Cryptography

encryption
Data
Secret-form data
decryption

• The secret-form data must be unreadable without
  prior knowledge of a secret / key
  (confidentiality), but recoverable with knowledge
  of the secret (availability)
• Usually the secret-form data cannot be decrypted
  successfully if it is tampered
• ?it can be used to ensure the integrity of data,
  (e.g., message authentication codes (MACs),
  digital signatures)

6
Common Approaches

• Cryptography (contd)
• Secret-key cryptography the same key is used in
  encryption and decryption, e.g., DES,
  block/stream ciphers, MACs
• Public-key cryptography different keys are used,
  e.g., RSA, digital signatures
• Public keys (PK) Vs Secret keys (SK)
• PK do not require distribution of shared secret
• ? more convenient for distributed systems
• PK rely heavily on the computational
  unfeasibility to solve some hard problems (e.g.,
  factoring, travelling salesman)
• ? breakable if these problems were solved

7
Common Approaches

• Authentication
• the process of verifying a claimed identity
• the entity to be authenticated may be a person
  (e.g., in password checking), a message (i.e.,
  integrity) or a program (e.g., client/server
  authentication)
• usually make use of cryptography, in which a
  secret (key) of the entity of the owner of it is
  used to verify its identity
• authentication protocols
• ways for two components in a DS to ensure each
  other is the intended entity
• usually by negotiating a short-term key for
  communication (e.g., Needham/Schroeder)

8
Common Approaches

• Authorization / Access Control
• the process of granting suitable rights to
  legitimate users
• usually by means of access control lists (ACLs)
  (e.g., permissions in UNIX NFS)
• Logging
• logging security-critical activities of users
  (e.g., su logs in UNIX), so that any internal
  security attacks can be accounted for

9
The SSL protocol

• Secure Socket Layer, by Netscape
• Provides security for applications over the
  insecure Internet
• Overview

Application 2
Application 1 (e.g., telnet, ftp)
Application data protocol
Application data protocol
SSL handshake protocol
SSL handshake protocol
SSL record protocol
SSL record protocol
Reliable transport protocol (e.g., TCP)
10
The SSL Protocol -The Three Components

• Record protocol
• encapsulate higher level protocols
• divide messages into blocks
• compresses message blocks
• applies MAC to message blocks
• encrypts and transmits message blocks
• SSL handshake protocol
• allow the client to authenticate the server, and
  the server to authenticate the client
• negotiate an encryption algorithm and key for
  application data transmission
• Application data protocol
• transmits data from applications to the record
  layer, which then sends the data securely

11
The SSL Handshake Protocol

• An authentication protocol
• A sample session

Hello! I want to connect with you. I understand
encryption algorithms like DES, RC4, IDEA, etc.

CLIENT
SERVER
Hello, then lets use DES. This is my
certificate. Please check. Please also send
yours.
(Client authenticate server by verifying
servers certificate...)
Alright, here is my certificate, and Ive
generated a DES master key. Here I encrypt it
with your public key and send it to you Im
finished..
(Server authenticate client by verifying
clients certificate...)
(Server decrypts the DES key received from
client)
Ok, I received your key. Im finished.
Data encrypted with the DES master key
. . .
12
The SSL Protocol - Implementation

• SSLeay
• A commonly used implementation of the SSL
  protocol (2.0 and 3.0)
• Written by Eric Young in Australia
• Contains library functions for making SSL
  communications (e.g., SSL_connect, SSL_free,
  SSL_get_certificate, SSL_get_cipher)
• Includes many encryption algorithms
• ciphers (e.g., DES, RC4, RC2, IDEA)
• digests (MD5, MD4, SHA-1)
• public keys (RSA, DSA, Diffie-Hellman)
• Applications built on top of SSLeay SSLtelnet,
  SSLftp, SSLhttpd, etc., by Tim Hudson in
  Australia
• Patches (lt 100 K size) to some existing server
  and client programs that support SSLeay

13
CORBA Security

• Security is provided as a kind of CORBA services
  (not part of the core ORB)
• Two levels of security defined
• level 1 does not change IDL definition
  applications are unaware of the security
  mechanism. Users may be authenticated before
  calling an application, and then security is
  enforced automatically during object invocation
• level 2 new IDL definition introduced
  applications can make use of objects such as
  credentials and Principal-Authenticators to
  define their own security policies

14
CORBA Security

• The security model

Server
Client
User
requests
Message protection, access control device, etc.
ORB
Message protection, access control device, etc.
Security Implementation enforcing security policy

• All object invocations are mediated by the
  security implementation
• No specific security policy defined in the model,
  so that a wide variety of different policies can
  be defined according to different needs

15
CORBA Security

• Principals
• Human users or system entities (e.g., the client
  acting for a user) registered in and authentic to
  the system
• Credentials
• Each principal in a CORBA environment with
  Security Service is associated with credentials
• Credentials contain security attributes of an
  object, e.g., its identity and privileges (like
  gate-passes)
• Credentials are used for access controls,
  authentication, etc.
• An object may have several credentials,
  representing privileges in different domains

16
CORBA Security
invoker

• Delegation
• Passing of credentials from one object to
  another, so that the receiving object
  (intermediate) can invoke a third object (target)
  on behalf of the passing object (invoker)
• Options of delegation
• no delegation
• simple delegation
• composite delegation
• combined delegation
• traced delegation

Client credentials
intermediate
Client credentials / intermediate credentials /
mixed, according to different options
targe
17
CORBA Security

• Non-repudiation service
• provide services that make users / principals
  accountable for their actions
• Implementation SSL services come with Orbix
  separate purchase for Visigenic

Object A
Object B
Dispute/judgement
Adjudicator
Non-repudiation service
Evidence generation verification
Evidence storage retrieval
Delivery Authority
Service requests / responses
18
Distributed System Reliability

• Reliability
• broad meaning (dependability)
• security
• availability
• fault tolerance
• recoverability
• correctness
• consistency
• timeliness

19
Reliability

• A narrower definition (J. Stankovic)
• Fault a mechanical or algorithmic defect which
  may generate an error
• Error an item of information which will produce
  a failure
• Failure an event at which a system violates its
  specifications
• ?Reliability the degree of tolerance against
  errors and faults

20
Reliability

• Hardware Vs Software
• Hardware reliability
• hardware redundancy, high-quality IC, wires, UPS,
  etc. (not main focus)
• Software reliability
• fault tolerance
• error recovery
• data / code redundancy

21
Common Approaches

• Replication
• keeping gt 1 copies of data / programs in system,
  increase availability
• Fault masking
• masking out the effects of faults by data /
  program redundancy in replicas
• Majority voting
• process requests on different servers, and
  produce the most possible results by voting on
  results from different servers
• Crash recovery
• E.g., by logging, checkpointing

22
Common Approaches

• Reliable transmission protocols
• protocols with error detection, correction e.g.,
  TCP/IP
• Concurrency control
• locking
• ordering

23
Summary

• Security requirements and approaches in
  distributed systems
• The SSL protocol
• CORBA Security Service
• Reliability requirements and approaches in
  distributed systems

24
Next Steps

• Know more about distributed system reliability
• Study the CORBA Security Service specification
  investigate existing implementations of the spec.
• Probably implement a system that demonstrates
  security reliability in the CORBA environment

25
The End

• Questions and Answers session
