Feature Driven Development

1
Feature Driven Development

• R. Smith
• 7 Oct 2003

2
Feature Driven Development (FDD)

• Java Modeling in Color with UML
• Peter Coad, Eric Lefebvre, Jeff De Luca
• Prentice Hall, 1999

3
Feature Driven Development (FDD)

• S. Ambler, Agile Modeling and Feature-Driven
  Development, Software Development, May 2002.
• J. Highsmith, What is Agile Software
  Development? Crosstalk, October, 2002.
• J. De Luca, The Original FDD Processes,
  http//www.nebulon.com/articles/fdd/originalfdd.ht
  ml
• P. Coad, Agile Processes Developing Your Own
  Secret Recipes, http//www.agilealliance.org/arti
  cles/articles/CoadRecipes18.pdf
• J. De Luca, Feature-Driven Development (FDD)
  Overview Presentation, http//www.nebulon.com/art
  icles/fdd/download/fddoverview.pdf
• S. Palmer and J. Felsing, A Practical Guide to
  Feature-Driven Development, Prentice Hall,
  February 2002.
• S. Palmer, Stephen Palmer on Feature Driven
  Development, http//www.step-10.com/FDD/index.htm
  l
• http//www.featuredrivendevelopment.com/

4
Feature Driven Development (FDD)

• The Buzz Words
• Client Centric
• Development as a decidedly human activity
  Highsmith
• Architecture Centric (Model Centric)
• Pragmatic, straightforward, low-overhead
• Just enough process to ensure scalability and
  repeatability, Ambler
• Encourage creativity and innovation, Ambler

5
Feature Driven Development (FDD)

• Proven on large projects
• 15-month, 50-person project (1997)
• 18-month, 250-person project (shortly after the
  first)
• Simple five step process
• Iterate
• Entry Criteria, Task, Verification, Exit Criteria
  (ETVX)
• Role playing
• Project manager, Chief Architect, Development
  Manager, Chief Programmer, Class Owner, and
  Domain Expert
• Feature Teams
• An individual plays more than one role

6
Feature Driven Development (FDD)
De Lucas Slides
7
Feature Driven Development (FDD)

• Develop an Overall Model
• Entry, Tasks, Verification, Exit (ETVX) structure
• http//www.step-10.com/FDD/FDD1OverallObjectModel.
  html

8
Feature Driven Development (FDD)

• Building a Features List
• Features are granular functions expressed in
  client-valued terms, using the naming template
• ltactiongt ltresultgtltobjectgt
• ltactiongt the ltresultgt ltbyforoftogt a(n)
  ltobjectgt
• For example,
• calculate the total of a sale
• calculate the total quantity sold by a retail
  outlet for an item description.

9
Feature Driven Development (FDD)

• Design By Feature
• Task
• Form Feature Team Chief Programmer Required
• Conduct Domain Walkthrough Domain
  Expert  Optional
• Study Referenced Docs Feature Team  Optional
• Develop Sequence Diagram(s)  Feature
  Team Required
• Refine Object Model  Chief Programmer Required
• Write Class / Method Prologue Feature
  Team  Required
• Design Inspection  Feature Team Required
• Verification
• Design Inspection  Feature Team  Required

10
Feature Driven Development (FDD)
11
Feature Driven Development (FDD)
12
Feature Driven Development (FDD)

• Build by Feature
• Tasks
•  Implement Classes and Methods  Feature
  Team Required
•  Conduct a Code Inspection  Feature
  Team  Required
•  Unit Test Feature Team  Required
•  Promote to the Build  Chief Programmer,
  Required
• Feature Team
• Verification
•  Code Inspection and Unit Test Chief Programmer,
  Required
• Feature Team

13
Feature Driven Development (FDD)
De Lucas Slides
14
Feature Driven Development (FDD)

• Modest amount of time and effort up-front
• Activities
• Develop an overall model (10 up-front, 4
  on-going).
• Build a features list (2 up-front, 1 on-going).

• Plan by feature (2 up-front, 2 on-going).
• Roles
• Model-and-plan teams (domain experts, modelers,
  chief architect, manager)
• Many short design-develop-test iterations
• Activities
• Design, develop, testby featurein up to
  two-week time boxes
• (77 of project time).
• Roles
• Feature teams (chief programmers, class owners)

Coads Slides
15
Feature Driven Development (FDD)
Coads Slides
16
Feature Driven Development (FDD)
Coads Slides
