Advanced Buffer Overflow Technique

1
Advanced Buffer Overflow Technique

• Greg Hoglund

2
Attack Theory

• Formalize the Attack Method
• Re-Use of Attack Code
• Separate the Deployment from the Payload
• Payloads can be chosen for desired effect
• Details and Restraints of both Payload and
  Deployment code

3
Exploits

• A BUG in Software
• New bugs reported every day
• automated testing tools
• USSR Labs
• Exploit is code that takes advantage of a bug
  in order to cause an effect

4
What can happen?

• Machine Crash
• kernel exception
• VIP process
• Application Crash (most common)
• Recoverable Exception
• Mobile Code (deadly)
• File Access (read or write)
• Denial of Service

5
Exploits can be grouped

• Some bugs are all the same
• Some bugs keep coming back
• improper filtering
• bounds checking
• bad authentication
• impersonation
• In other words, need better testing

6
Entry -vs- Effect

• The attack payload is not the same as the entry
  point
• Missle -vs- Warhead analogy
• The Delivery Mechanism can be decoupled from the
  Payload

7
Exploits come in 2 parts

• Injection Vector (deployment)
• the actual entry-point, usually tied explicity
  with the bug itself
• Payload (deployed)
• usually not tied to bug at all - limited only by
  imagination. Some restraints.

8
Injection Vector

• Target Dependant
• OS Dependant
• Application Version Dependant
• Protocol Dependant
• Encoding Dependant

9
Payload

• Independent of Injection Vector
• Still Depends on Machine, Processor, etc.
• With some exceptions
• Mobile Code, Just like a Virus
• Once established, can spread by any means
• trust
• scanning for more bugs

10
Payload

• Denial of Service
• use as launching point (arp spoofing)
• Remote Shell (common)
• covert channel or netcat like
• Worm/Virus
• extremely dangerous
• Rootkit (common - stealth)

11
Injector/Payload Pairs

• One injector works on n qualified hosts
• Example - IIS Injector works on 20 of Web
  Hosts.
• Payload
• Remote Shell for control
• Shutdown Machine
• Shutdown ALL Machines on subnet

12
Types of Injection

• Content Based
• characters inserted into a data stream that
  result in the remote process doing something it
  shouldnt. Process is still in control.
• Buffer Overflow
• poor programming practice subverts architecture
  of code execution. Process loses control.

13
Types of Injection

• Trust Based
• Boot virus/ Floppy/ CD (parasite process)
• MACRO virus
• Email Attachments (Melissa, etc)
• Web Browsing (exploit users trust, etc)
• click thru

14
Governments write Injector Code?

• 1995 US Defense Intelligence Agency Report
• Cuban Military targets US w/ custom virii
• University of Havana, team of less than 20
  computer experts
• Russian KGB
• prior to 1991 coup attempt, KGB has virii
  intended to shut down US computers in times of war

15
Mobile code in Global 2000?

• 1995 EY report
• 67 of companies hit bit virus
• 1996 EY report
• 63 of companies hit by virus
• 1996 UK Information Security Breaches Survey
• 51 of companies hit by virus

16
How hard can it hit?

• NCSA 1997 report
• 33 of all machines infected with virus
• average cost of recovery 8000 US dollars
• November 1988 Morris Worm
• strikes 6,000 computers (10 of Internet at
  time) within hours
• spreads via Buffer Overflow in fingerd
• spreads via Sendmail exploit

17
How hard can it hit?

• 1989, WANK Worm
• Hits NASA Goddard Space Center
• spreads to US DOE High Energy Physics network
  (HEPNET)
• 2 weeks to clean all systems

18
Buffer Overflow Injection

• Overflow the Stack
• Overflow the Heap
• Goal Must control the value of the instruction
  pointer (processor specific)
• Goal Get the Instruction Pointer to point to a
  user-controlled buffer.

19
Challenges

• Injector/Payload size restrictions
• tight coding requirements
• Injector and Payload in same buffer
• cannot step on each other
• Guessing Address Values
• sometimes called offsets
• NULL characters, BAD characters
• use encoding and stack tricks

20
Stack Injection

• Stack is used for execution housekeeping as well
  as buffer storage.
• Stack-based buffer must be filled in direction of
  housekeeping data.
• Must overwrite the housekeeping data

21
Address Housekeeping

• A

• IP

• B

• DI

• code

• C

• SI

• D

• FLAG

• SP

• BP

• heap

• stack

22
Stack Overflow
00 40 20 08 00 40 20 0C 00 40 20 10 00 40 20
14 00 40 20 18 00 40 20 1C
23
The Problem with NULL
00 40 20 08 00 40 20 0C 00 40 20 10 00 40 20
14 00 40 20 18 00 40 20 1C
24
NULL must be PAST housekeeping data
00 40 20 08 00 40 20 0C 00 40 20 10 00 40 20
14 00 40 20 18 00 40 20 1C
25
Little and Big Endian

• On Intel x86 (Little Endian), Values are stored
  backwards - least significant byte goes first
• 00 40 10 FF is stored as
• FF 10 40 00

26
We store address in housekeeping data
00 40 21 04 00 40 21 00 00 40 20 0C 00 40 20
08 00 40 20 04 00 40 20 00
27
Injection is Complete

• We control the instruction pointer

28
Where to put the payload
00 40 21 04 00 40 21 00 00 40 20 0C 00 40 20
08 00 40 20 04 00 40 20 00
29
Confined Payload

• Byte Compression
• Use only preloaded functions
• Payload doesnt need to build jumptables
• Useable functions must be loaded
• Use Hardcoded addresses
• Payload designed for a specific process with
  predictable features
• Data portion of payload needs to be small

30
Using more stack for payload
77 40 20 08 77 40 20 0C 77 40 20 10 77 40 20
14 77 40 20 18 77 40 20 1C
31
Much Larger Payload
32
When does the address contain a NULL character

• Lowland Address - starts with 00
• stack is in lowland on Windows NT
• usually 00 40 XX XX
• limits size of payload
• Highland Address - no zeros in address
• stack is in highland under Linux
• unlimited payload size

33
Large payload, Lowland address

• We cannot use a lowland address directly, because
  it limits our payload
• We can use a CPU register
• We can use stack values that remain undamaged

34
A register points to the stack

• A

• IP

• B

• DI

• code

• C

• SI

• D

• FLAG

• SP

• BP

• heap

• stack

35
Call thru a Register

• Call eax, call ebx, etc
• FF D0 call eax
• FF D3 call ebx
• FF D1 call ecx
• etc, etc

36
Push a register then return

• Push register
• push eax 50
• push ebx 53
• etc
• Then RET
• RET C3

37
Guessing where to go

• We jump to the wrong address
• crashes software
• payload doesnt execute
• Use NOP (no-op) - a single byte instruction
• NOP 90
• Fill buffer with NOPs
• NOP Sled

38
NOP Sled
39
Inject the Payload into the HEAP

• When the stack is limited in size
• Store part on the payload on stack, the other on
  the heap
• Protocol Headers
• HTTP headers
• Recent Transactions
• Open Files

40
Use the CPU

• A

• IP

• B

• DI

• code

• C

• SI

• D

• FLAG

• SP

• BP

• heap

• stack

41
Execute code on the heap

• A

• IP

• B

• DI

• code

• C

• SI

• D

• FLAG

• SP

• BP

• heap

• stack

42
Trespassing the HEAP

• Two C objects near one another
• Any buffer that can overwrite a pointer
• function pointer
• string pointer (alter behavior w/o mobile code)

43
Overwrite the VTABLE

• C objects have a virtual function table

• Vtable pointer

• Member variables grow away from vtable pointer
  (NT)

44
Overwrite VTABLE

• Must have 2 C Objects (on heap)

45
Where do I make the VTABLE point?
46
Your own VTABLE

• The VTABLE has addresses for all virtual
  functions in the class. This usually includes a
  destructor - which will be called when the object
  is destroyed (deallocated from memory)
• Overwrite any function that works

47
Injection is complete

• Kernel level overflows all over in NT
• Off by one errors causing frame pointer overwrite
• Multi-stage attacks where you must first get the
  target into a state before attempting overflow
• The effects of URL or MIME encoding

48
Now for the Payload

• Using Loaded Functions
• Encoding our own data
• Loading new functions DLLs
• Making a shell

49
The Payload
50
Getting Bearings

• Call RELOC
• RELOC pop edi
• EB 00 00 00 00
• edi now has our code address
• we can use this as an offset to our data

51
Reverse Short Call

• NO NULL Bytes
• RELOC jmp RELOC2
• Call RELOC
• RELOC2 pop edi
• EB FF FF FF FE

52
XOR Protection

• Cannot have NULLs in data portion

53
XOR again to decode
54
Hardcoded Function Calls

• code

55
Pros/Cons to hard coding

• PRO makes code smaller
• CON what if function isnt always in same place?
• Dynamically loaded DLLs
• PRO some DLLs are usually always in the same
  place
• KERNEL32.DLL

56
Dynamic Function Loading

• Use LoadLibrary() and GetProcAddress()
• usually always in same place
• hard coding usually works
• Load New DLLs
• Find any function by ASCII name
• handy

57
Load Function by Name

• Function name stored here

58
Build a jumptable
59
Use Jumptable
60
HASH Loading (el8)

• Process already has ASCII names of all loaded
  functions stored in process-header
• We can locate any loaded function by checking the
  CRC of each loaded ASCII name
• We do not need to store function names in our
  DATA section - only CRCs
• makes payload smaller!

61
PE Header

• PE OFFSET

62
Check CRCs

• CRC

63
Limited Character Set means Limited Instruction
Set

• Payload is filtered
• MIME
• URL
• alphanumeric only (email headers)
• short jumps (difficult to maintain)
• pop/push
• subtract

64
The Bridge

• Avoids jump instruction
• size must be calculated exactly

65
Load New DLL
66
WININET.DLL

• Use DLL functions
• InternetOpenURL()
• InternetReadFile()
• Does all the hard work
• Makes payload smaller
• Download and Execute any file, anywhere
• File stored anonymously - hard to trace

67
WS2_32.DLL

• Socket
• bind
• listen
• send
• recv
• accept

68
Interrupt Calls

• Dont require addresses
• Small
• Easy to use
• Load register with call number
• Load register with argument pointer
• interrupt (2 bytes long)
• CD 2E (interrupt 2E)
• CD 80 (interrupt 80)

69
Remote Command Shell

• Spawn a process
• CreateProcessA (kernel32 function)
• INT 80 (linux) (execve syscall)
• Pipe the output thru socket
• Named pipes (5 functions)
• Connect in or out over any TCP socket

70
Covert Channel

• If exploited process is root or SYSTEM
• TDI or NDIS hook
• session over ACK packets or ICMP
• IIS
• Patch any point where URL requests are handled
• no kernel required

71
WORMS

• Payload searches for new hosts to attack
• Trust Exploitation
• sniff passwords on wire
• SMB sessions to other NT hosts
• NT Registry Alteration
• NFS/Drive Sharing
• Consider survivability of Payload
• what of hosts are eligible?

72
Lysine Deficiency

• Worm will die if certain condition is not met
• Existance of File
• Existance of Network Entity
• Floppy in floppy drive (testing lab)

73
RECAP

• Injection is not the same as payload
• Payloads can perform
• Denial of Service
• WORM
• Remote Shell
• Rootkit

74
RECAP

• Injection has many challenges
• NULL characters
• Stack size
• Highland/Lowland address
• Calling thru CPU registers

75
RECAP

• Filters limit what we can use in a payload
• Limited OP-CODE sets can still be used to build
  fully functional programs

76
RECAP

• Our payload is encoded
• We can build jumptables
• We can load new DLLs and Functions
• We can hard-code addresses or load them
  dynamically
• We can use Lysine Deficiency to keep Worms from
  spreading uncontrolled

77
Thank You

• Your mind is your primary weapon
• http//www.rootkit.com
• hoglund_at_ieway.com
