Security

1
Security
Tom Philpott IT Architect Software AG
2
Natural Security

• Controls and checks access to the Natural
  Environment
• Four types of objects
• Users
• Libraries
• DDMs/files
• Utilities

3
Types of Users
4
Linking a User to a Library
5
Concept of Environment Protection

• A Natural environment is a combination of FNAT,
  FUSER, FSEC, and FDIC.
• A logon to an environment occurs when a user logs
  onto an library in another FUSER.
• Both access to the library and authorization to
  the environment is checked.

6
Protecting DDMs On Mainframes
7
RPC Service Requests

• Protect RPC Services as well as the requests are
  handled.
• User authentication are possible in two modes
• Validation with Impersonation
• Validation without Impersonation
• Impersonation must be set in the security profile
  of the Natural RPC Server.

8
RPC Service Requests

• Validation without Impersonation
• Logon performed using Natural RPC user ID.
• Validation is performed by Natural Security, and
  depends on the Logon Option.
• N or E, both user ID and password verified
• A or S, only user ID is verified, (like
  Autoon)
• E or S, Natural RPC user ID must be the same
  as the EntireX user ID.

9
RPC Service Requests

• Validation with Impersonation
• Natural RPC server must run under Z/OS in batch
  mode.
• Natural server front-end passes Natural RPC user
  ID to SAF-compliant external security system.
• A successful authentication is followed by a
  logon according to the Natural Security rules for
  that user.
• Again, if the Logon Option is set to E or S,
  the EntireX user ID must be the same as the
  Natural RPC user ID.

10
Natural SAF Security

• SAF System Authorization Facility
• OS/390, z/OS and compatible operating systems
• Integrates ADABAS with SAF compliant security
  packages
• RACF
• CA-ACF2
• CA-TopSecret
• All your security definitions are in a single
  repository
• Only need to define User in external SAF system
• Group definitions done in both NSC and NSF.
• Security mappings done in Natural Security.

11
NDV Requests

• User authentication are possible in four modes
• Validation with Impersonation Locally
• Validation with Impersonation Remotely
• Validation with Impersonation
• No Validation
• The SECURITY_MODE parameter is used to define the
  types of authentication

12
NDV Requests

• Security_Mode Impersonate_Local
• The client credentials are checked against the
  Security system of the NDV server
• Natural Security treats client as if Autoon is
  used.
• Security_Mode Impersonate_Remote
• The NATUXRFE user exit obtains credentials from
  the NDV server
• Authenticates using CICS VERIFY PASSWORD

13
Adabas Security
Tom Philpott IT Architect Software AG
14
Adabas Security

• Data Encryption
• Access/Update Security
• Security by Value

15
Adabas Security- Data Encryption

• Utilizes pre-specified key to encode Adabas Data
  Storage
• Encryption is by file, with data compressed and
  then encrypted
• Data access requires cipher code, usually
  inserted through an Adabas User Exit
• If you lose the key, you lose the data.

16
Adabas Security- Access/Update Level

• Adabas password is really an access/update
  profile.
• Defined at a file level, as well as fields within
  a file.
• Threshold protection levels are set for either
  the file and/or the field.
• Permission levels are attached to a password.

17
File Level Protection
18
Field Level Protection
19
File Level Protection Results
20
Adabas Security- Value Level

• Defined for one or more fields on a file.
• Different settings for access vs. update.
• Can include as many as 99 fields.
• Comprise multiple values and/or value ranges per
  field.
• Can either accept or deny values.

21
Adabas SAF SecurityIntroduction

• SAF System Authorization Facility
• OS/390, z/OS and compatible operating systems
• Integrates ADABAS with SAF compliant security
  packages
• RACF
• CA-ACF2
• CA-TopSecret
• All your security definitions are in a single
  repository
• Tamper-proof
• components in router and nucleus

22
Adabas SAF SecurityIntroduction

• One of a suite of SAF security options
• Natural SAF
• secure applications
• Network SAF
• secure remote usage
• EntireX Security
• secure Broker services

23
Adabas SAF SecurityIntroduction

• Two different Adabas SAF licenses
• ADAESI compatability
• No license charge/no maintenance charge
• ADASAF full functionality
• No license charge until March 31, 2003
• Maintenance charges will apply

24
Adabas SAF SecurityIntroduction

• ADASAF limited license
• Secure database nucleus, files and commands
• Utilities
• Operator Commands

25
Adabas SAF SecurityIntroduction

• ADASAF full functionality
• All of ESI functionality, plus
• Cross-level checking
• Protection of Transaction Data
• Adabas Passwords and Cipher Codes
• Protection of AOS
• On-line Administration via AOS
• Remote User Protection
• Adabas SQL Server Protection
• Adabas Cluster Services
• Adabas Parallel Services

26
Adabas SAF SecurityArchitecture
User
Administrator
ADABAS 1
ADABAS 2
ADASAF
Router (ADASVC) with ADASAF
ADASAF
SAF RACF, CA-ACF2 CA-Top Secret

• 3 main components
• Router/SVC
• SAF module
• AOS subsystem

Tamperproof runtime code in the router and
database
27
AdaSAF Security Operation
28
AdaSAF Security Operation
29
ADABAS SAF SecurityWhere from
CICS
ADABAS ADASAF
Job ACEE
Router Obtain userids
User 2 ACEE
User 1 ACEE
Check CICS
Check User
ADATRUE
RACF
30
ADABAS SAF SecurityCaching Checks

• First call from user
• create security environment for user
• RACROUTE VERIFY,ENVIRCREATE
• File-specific call
• check cache if file not found perform SAF check
  cache successful checks
• CL command or user timeout
• delete users security environment and release
  cache

31
ADABAS SAF SecuritySecure ADABAS Resources

• ADABAS data
• commands require read or update access
• some commands are ignored
• with RACF you only need define sensitive files
• option to allow access to any undefined resource
• security based on where from as well as who
• access allowed from production CICS but not from
  test
• successful checks cached
• optionally across user sessions
• ET Data (optional)

32
ADABAS SAF SecuritySecure ADABAS Resources

• ADABAS jobs
• check that user who submitted nucleus is allowed
  to
• check also used to establish fail/warn mode
• check that user who submitted a utility is
  allowed to run that utility against this database
• Steve may run ADAREP but not ADASAV
• Operator commands
• check that this operator command is permitted for
  this nucleus
• DUQ is allowed, but not STOPU

33
ADABAS SAF SecurityCipher Codes and Passwords

• ADASAF
• extracts them from RACF file profiles at nucleus
  initialization
• inserts them into any ADABAS call for the
  relevant files
• as long as security checks are ok
• Advantages
• sensitive data now stored in RACF repository
• application doesnt have to manage them
• no longer transmitted with call, so more secure

34
ADABAS SAF SecurityRACF Definitions

• Define and activate the class(es)
• ADASEC ICHERCDE CLASSADASEC,
  X
• ID149,
  X
• MAXLNTH80,
  X
• FIRSTANY,
  X
• OTHERANY,
  X
• RACLISTALLOWED,
  X
• GENLISTALLOWED,
  X
• POSIT35,
  X
• OPERNO,
  X
• DFTUACCNONE
• SETROPTS CLASSACT(ADASEC)
• SETROPTS GENCMD(ADASEC)
• SETROPTS GENERIC(ADASEC)

35
ADABAS SAF SecurityRACF Definitions

• Make security definitions
• define and protect resources
• RDEFINE ADASEC CMD00001.FIL01234 UACC(NONE)
• PERMIT CMD00001.FIL01234 CLASS(ADASEC)
  ACCESS(READ) ID(uid)
• RACLIST the profiles for better performance
• Ensure that userids under which ADASAF runs are
  allowed to issue RACROUTE AUTH/EXTRACT/VERIFY

36
ADABAS SAF SecurityFlexible Customization

• ADASAF operation governed by parameters
• assembled configuration module
• AAFCFG GWSTYP1, SECURITY SYSTEM
  X
• DBCLASSADASEC, DATABASE CLASS
  X
• DBFLEN1, 5 DIGIT DBID/FNR
  X
• MAXFILES32, MAX CACHED FILES
  PER USER X
• LOGOFFTIMEOUT, LOGOFF ONLY ON
  TIMEOUT X
• ABS1, ABS MAIN FUNCTION
  PROTECTION X
• REMOTEPOPUP, POP-UP WINDOW FOR
  REMOTE USERS X
• GWSIZE128, AAFKRN CACHE SIZE
  X
• GWMSGL1 TRACE SAF ERRORS
• DDSAF dataset to override configuration options
  on a nucleus-by-nucleus basis
• Configuration options can be changed on-the-fly
• no interruption of service

37
ADABAS SAF SecurityOnline Administration

• Standard Natural application (SYSAAF)
• performance and configuration details
• user activity
• problem diagnosis
• log user off from RACF
• restart ADASAF

38
ADABAS SAF SecurityStatus

• 7.4.4 released
• compatible with ADABAS 7.1.x
• 8.1.1 scheduled for 3rd qtr 2006
• Support for Adabas v8.1

39
ADABAS SAF SecurityOnline System
40
ADABAS SAF SecurityOnline System
41
ADABAS SAF SecurityOnline System
42
