Textile Machines Research Institute Liberec
2
Fluid mechanics applications in textile machinery

• Karel Adámek

3
Air jet weft picking

• Schematics
• Main nozzle
• Relay nozzle
• Stretching nozzle
• Suction nozzle
• Picking channel
• Reed dents

• Friction influence braking nozzle
• U-loop picking
• Pneumatic picking beat-up
• Yarn-flow interaction

4
Principle of air jet weft picking
Main nozzle relay nozzles
stretching suction nozle
5
Main nozzles
Influence of mixing tube shape on velocity field
(cylindrical stepped divergent)
6
Relay nozzles
Hydraulic analogy ? Channel relay jet ?
7
Stretching nozzle
Simple cornered shape (left) gives much higher
noise level (because of flow separation,
vortexes, backflow...)
8
Suction nozzle
Principle of wall effect very simple design,
very silent, economic and reliable operation
9
Flowfield along the reed wall
Interaction of free flow with reed wall
Interactions of mutual interactions of several
free flows
10
Reed dents
Study of influences of various reed wall
parameters on flowfield image (wall filling,
shape of dent edges, angle of attack)
11
Total quantity of motion in reed channell

• The most part of momentum supplied from nozzle
• is flowing outside channel
• (theoretical values without flow reflection by
  reed dents etc.)

12
Reed channel - cross section
Influence of nozzle setting and adjjusting on
total quantity of motion in reed channel
13
Y-shaped reed channel - geometry
14
Braking nozzle
Design Flat cross-section of velocity field from
nozzle outlet
15
Weft picking as U-loop
Air jet picking of very heavy wefts - modelling
verification of hypothesis
16
Pneumatic picking beat-up (principle)
Velocity field of picking phase (up) and
transition phase between picking and beat-up
(down) modelling of hypothesis
17
Other applications of numerical flow modelling
in textile machines / technologies
18
Air flow in carding clothing
Flow during rotation (40 m/s) drum diameter of
1200 mm, dent height 1 mm approx.
19
Ait flow in common suction channel(open-end
spinning machine)
Global flowfield ? and its detail ?
20
Technology melt-blown(velocity field)
Production of very fine fibre fleece from melted
polymer
21
Difusser of gas burner(for glass fibre
production)

• Former shape
• with flow separation

• New shape
• without flow separation

22
Increasing of drying process intensity
Design modification improves the heat transfer
and steam escape together with noise level
reduction
23
Flow paths in impact dryer
Air inlet and outlet in proximity of dried
(bottom) surface - difficult steam effluent
24
Cloth permeability
Pressure field on surface of complicated cloth
structure
25
Make drying before painting
? unsuitable primary design more intense
modification ?
26
Noise level of blow gun
Pressure field of open gun (up) and with strainer
(down)
27
Gas burner
Flow paths in one section of rod burner
28
Velocity field around rotating drums
Flowfield in system of printing machine
29
Surface temperature of heat exchanger
Local overheating of heat transfer surface
30
Air curtain
Curtain air flow separates cold surroundings
(left) and warm inner space (right)
