JSP Java Server Page

1
JSP Java Server Page

• DBI Representation and Management of Data on
  the Internet

2
What is JSP

• http//java.sun.com/products/jsp
• A way to create dynamic web pages
• Based on Java Technology
• Large library base
• Platform independence
• Server side processing
• Separates the graphical design from the dynamic
  content

3
Relationships

• In servlets,
• HTML code is printed from java code
• In JSP pages
• Java code is embadded in HTML code

Template text
Java
HTML
Java
HTML
4
In General Lines

• JSP-enabled server
• picks up .jsp page
• parses it
• converts it to runnable form
• runs it
• Converts page to a Java servlet (JspPage), with
  your code inside the _jspService() method
• compiles it
• runs servlet protocol

5
Separating Graphical Design and Dynamic Content

• Not a new idea (e.g. PHP, mod_perl, shtml, ASP)
• Graphical Design and System Design are two
  separate and distinct specialities
• Different languages (HTML vs. Java)
• Different goals
• Different Training
• Should be separated for optimal project
  management
• JSP does this by allowing special Java tags in
  HTML

6
An Example

• lt!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.0
  Transitional//EN"gt
• ltHTMLgt
• ltHEADgt
• ltTITLEgtHello World Examplelt/TITLEgt
• lt/HEADgt
• ltBODYgt
• ltH2gtHello World Examplelt/H2gt
• ltBgtlt out.println("Hello World") gtlt/Bgt
• lt/BODYgt
• lt/HTMLgt

7
(No Transcript)
8
Translating and Executing JSP Pages

• A JSP page is executed in a JSP container,
  generally installed in a Web server
• Think of a JSP container as a JVM with suitable
  software installed
• The underlying semantic model is that of a
  servlet
• A typical JSP container will translate the JSP
  page to a Java servlet
• By default, translation and compilation of a JSP
  page is likely to occur the first time the page
  is accessed

9
The Source Code

• In Tomcat 3.2.1, you can find the generated Java
  and the class files in a subdirectory under
  tomcat_home/work.

10
Translation
ltH1gtA Random Numberlt/H1gt lt Math.random() gt
11
JSP Features

• Standard directives guiding translation of a JSP
  page to a servlet
• Standard actions in the form of predefined JSP
  tags
• Script language declarations, scriptlets, and
  expressions for including Java (or other
  language) fragments that embed dynamic content
• A portable tag extension mechanism, for building
  tag librarieseffectively extending the JSP
  language

12
More Details

• Writing JSP Pages

13
Template HTML

• The HTML code that wraps the code is like a
  template
• Created as an ordinary HTML
• The dynamic parts are created on runtime and are
  inserted into the template

14
JSP Scripting Elements

• JSP scripting elements let you insert Java code
  into the servlet that will be generated from the
  JSP page
• There are three forms
• Expressions of the form lt expression gt that
  are evaluated and inserted into the output,
• Scriptlets of the form lt code gt that are
  inserted into the servlet's service method, and
• Declarations of the form lt! code gt that are
  inserted into the body of the servlet class,
  outside of any existing methods

15
JSP Expressions

• A JSP expression is used to insert Java values
  directly into the output
• It has the following form
• lt Java Expression gt
• The Java expression is
• evaluated,
• converted to a string, and
• inserted into the page
• This evaluation is performed at runtime (when the
  page is requested), and thus has full access to
  information about the request

16
Predefined Variables

• The following predefined variables can be used
• request, the HttpServletRequest
• response, the HttpServletResponse
• session, the HttpSession associated with the
  request (if any)
• out, the PrintWriter (a buffered version of type
  JspWriter) used to send output to the client

17
Examples

• For example, the following shows the date/time
  that the page was requested
• Current time lt new java.util.Date() gt
• For example, the following shows the hostname
• Your hostname
• lt request.getRemoteHost() gt

18
ltHTMLgt ltHEADgt ltTITLEgtJSP Expressionslt/TITLEgt lt/
HEADgt ltBODYgt ltH2gtJSP Expressionslt/H2gt ltULgt ltLIgtCur
rent time lt new java.util.Date() gt ltLIgtYour
hostname lt request.getRemoteHost() gt ltLIgtYour
session ID lt session.getId() gt ltLIgtThe
ltCODEgttestParamlt/CODEgt form parameter lt
request.getParameter("testParam")
gt lt/ULgt lt/BODYgt lt/HTMLgt
19
(No Transcript)
20
JSP Scriplets

• JSP scriptlets let you insert arbitrary code into
  the servlet method that will be built to generate
  the page ( _jspService )
• Scriptlets have the following form
• lt Java Code gt
• Scriptlets have access to the same automatically
  defined variables as expressions

21
Producing Code

• Scriplets produce output HTML by printing into
  the out variable
• Example
• lt
• String queryData request.getQueryString()
• out.println("Attached GET data " queryData)
• gt

22
HTML Code in Scriptlets

• HTML code before and after the scriplets is
  converted to print methods

lt if (Math.random() lt 0.5) gt You ltBgtwonlt/Bgt
the game! lt else gt You ltBgtlostlt/Bgt the
game! lt gt
if (Math.random() lt 0.5) out.println("You
ltBgtwonlt/Bgt the game!") else
out.println("You ltBgtlostlt/Bgt the game!")
23
lt foo() gt lt bar() gt
public void _jspService(HttpServletRequest
request,
HttpServletResponse response) throws
ServletException, IOException request.setConten
tType("text/html") HttpSession session
request.getSession(true) JspWriter out
response.getWriter() out.println(foo()) bar()
...
24
Example of Using Scriplets (1)
lt!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.0
Transitional//EN"gt ltHTMLgt ltHEADgt ltTITLEgtColor
Testinglt/TITLEgt lt/HEADgt lt String bgColor
request.getParameter("bgColor") boolean
hasExplicitColor if (bgColor ! null)
hasExplicitColor true else
hasExplicitColor false bgColor
"WHITE" gt
25
Example of Using Scriplets (2)
ltBODY BGCOLOR"lt bgColor gt"gt ltH2
ALIGN"CENTER"gtColor Testinglt/H2gt lt if
(hasExplicitColor) out.println("You supplied
an explicit background color of " bgColor
".") else out.println("Using default
background color of WHITE. Supply the
bgColor request attribute to try a
standard color, an RRGGBB value, or to see
if your browser supports X11 color
names.") gt lt/BODYgt lt/HTMLgt
26
(No Transcript)
27
JSP Declaration

• A JSP declaration lets you define methods or
  fields that get inserted into the main body of
  the servlet class (outside of the service method
  processing the request)
• It has the following form
• lt! Java Code gt
• Declarations do not produce output
• They are used, for example, to define variables

28
Example

• We want to print out the number of times the
  current page has been requested since the server
  booted (or the servlet class was changed and
  reloaded)
• lt! private int accessCount 0 gt
• Accesses to page since server reboot
• lt accessCount gt

29
Predefined Variables

• As we have seen before, there are variables that
  can be used in the code
• There are eight automatically defined variables,
  sometimes called implicit objects
• The available variables are request, response,
  out, session, application, config, pageContext,
  and page

30
request

• This is the HttpServletRequest associated with
  the request
• It lets you
• look at the request parameters (via
  getParameter),
• the request type (GET, POST, HEAD, etc.), and
• the incoming HTTP headers (cookies, etc.)

31
response

• This is the HttpServletResponse associated with
  the response to the client
• The output stream is buffered,
• Thus, it is legal to set HTTP status codes and
  response headers, even though this is not
  permitted in regular servlets once any output has
  been sent to the client

32
out

• This is the PrintWriter used to send output to
  the client
• However, in order to make the response object
  useful, this is a buffered version of PrintWriter
  called JspWriter
• Note that you can adjust the buffer size, or even
  turn buffering off, through use of the buffer
  attribute of the page directive

33
session

• This is the HttpSession object associated with
  the request
• Sessions are created automatically, so this
  variable is bound even if there was no incoming
  session reference (unless session was turned off
  using the session attribute of the page
  directive)

34
application

• This is the ServletContext as obtained via
  getServletConfig().getContext()
• Servlets and JSP pages can hold constant data in
  the ServletContext object
• Getting and setting attributes is with
  getAttribute and setAttribute
• The ServletContext is shared by all the servlets
  in the server

35
config

• This is the ServletConfig of the page

36
pageContext

• JSP introduced a new class called PageContext
• It encapsulate use of server-specific features
  like higher performance JspWriters
• The idea is that, if you access the
  server-specific features through this class
  rather than directly, your code will still run on
  "regular" servlet/JSP engines

37
page

• This is simply a synonym for this
• page is not very useful in Java codes in JSP
  pages
• It was created as a placeholder for the time when
  the scripting language could be something other
  than Java

38
JSP Directives

• A JSP directive affects the overall structure of
  the servlet class that is created from the JSP
  page
• It usually has the following form
• lt_at_ directive attribute"value" gt
• Multiple attribute settings for a single
  directive can be combined
• lt_at_ directive
• attribute1"value1"
• attribute2"value2"
• ...
• attributeN"valueN" gt

39
Directives

• There are three main types of directive
• page, which lets you do things like
• import classes
• customize the servlet superclass
• include, which lets you
• insert a file into the servlet class at the time
  the JSP file is translated into a servlet
• taglib directive
• indicates a library of custom tags that the page
  can include

40
The page Directive

• The page directive lets you define the following
  attributes
• import"package.class
• lt_at_ page import"java.util." gt
• contentType"MIME-Type"
• lt_at_ page contentType"text/plain" gt
• (it is the same as
• lt response.setContentType("text/plain") gt)

41
More Page Directives

• isThreadSafetruefalse
• Normal servlet processing or implementing
  SingleThreadModel
• sessiontruefalse
• Allowing/disallowing sessions
• buffersizekbnone
• specifies the buffer size for the JspWriter out
• autoflushtruefalse
• Flush buffer when full or throws an exception
  when buffer isfull

42
And More Directives

• extendspackage.class
• infomessage
• A message for the getServletInfo method
• errorPageurl
• Define a JSP page that handles uncaught
  exceptions
• isErrorPagetruefalse
• languagejava

43
The include Directive

• This directive lets you include files at the time
  the JSP page is translated into a servlet
• The directive looks like this
• lt_at_ include file"relative url" gt

44
Writing JSP in XML

• We can replace the JSP tags with XML tags that
  represent
• Expressions
• Scriptles
• Declarations
• Directives

45
ltjspexpressiongt Java Expression
lt/jspexpressiongt
lt Java Expression gt
ltjspscriptletgt Code Java lt/jspscriptletgt
lt Code gt
ltjspdeclarationgt Java Declaration
lt/jspdeclarationgt
lt! declaration gt
ltjspdirective.type Attribute value/gt
lt_at_ directive gt
46
Actions

• JSP actions use constructs in XML syntax to
  control the behavior of the servlet engine
• You can
• dynamically insert a file,
• reuse JavaBeans components,
• forward the user to another page, or
• generate HTML for the Java plugin

47
Available Actions

• Available actions include
• jspinclude - Include a file at the time the page
  is requested
• jspuseBean - Find or instantiate a JavaBean
• jspsetProperty - Set the property of a JavaBean
• jspgetProperty - Insert the property of a
  JavaBean into the output
• jspforward - Forward the requester to a new page

• jspplugin - Generate browser-specific code that
  makes an OBJECT or EMBED tag for the Java plugin

48
The jspinclude Action

• This action lets you insert files into the page
  being generated
• The file inserted when page is requested
• The syntax looks like this
• ltjspinclude page"relative URL"
• flush"true" /gt

49
The jspforward Action

• Forwards request to another page
• Syntax
• ltjspforward page"relative URL"/gt
• It has a single attribute, page, which should
  consist of a relative URL
• This could be a static value, or could be
  computed at request time
• Examples
• ltjspforward page"/utils/errorReporter.jsp" /gt
• ltjspforward page"lt someJavaExpression gt" /gt

50
Using Beans

• JavaBeans are reusable software components that
  can be manipulated visually in a builder tool
• Introspaction analyze how the bean works
• Customization the user can customize the look
  of the bean
• Events support
• Properties support
• Persistence allowing saving the bean on a
  persistent mechanism and loading it

51
Some Facts about Beans

• The bean Class should include a constructor with
  no arguments
• The bean class should not include public
  variables (fields)
• Access to the attributes of the bean is through
  methods that look like
• getName / setName for non-boolean fields
• isName / setName for boolean fields

52
The jspuseBean Action

• This action lets you load in a JavaBean to be
  used in the JSP page
• The simplest syntax for specifying that a bean
  should be used is
• ltjspuseBean id"name
• class"package.class" /gt

53
Using a Bean
ltjspuseBean id"name class"package.class" /gt

• Create an object of the given class
• Bind the object to a variable with the given name

54
Using a Bean
ltjspuseBean iddb classdbiClasses.WebDatabas
e" /gt
55
Using a Bean
ltjspuseBean idhandler classConnectionHandle
r" typeRunnable/gt
56
More on Beans

• Creating a Bean with jspuseBean is like creating
  an object
• The scope of the bean can be beyond the page
  where it is declared
• Beans are used for resource collaboration

57
Getting the Properties of a Bean

• Use jspgetProperty to get a property of a bean
• Use the attributes name and property to get the
  requested property

ltjspgetProperty namedb propertylogin /gt
lt db.getLogin() gt
58
Setting the Properties of a Bean

• Use jspsetProperty to set a property of a bean
• Use the attributes name, property and value to
  set the value to the property

ltjspsetProperty namedb propertylogin
valuesnoopy/gt
lt db.setLogin(snoopy) gt
59
Example
package dbiTests public class SimpleBean
private String message"No message specified"
public String getMessage()
return(message) public void
setMessage(String message) this.message
message
60
ltHTMLgt ltHEADgt ltTITLEgtReusing JavaBeans in
JSPlt/TITLEgt lt/HEADgt ltBODYgt ltCENTERgt ltTABLE
BORDER5gt ltTRgtltTH CLASS"TITLE"gt Reusing
JavaBeans in JSP lt/TABLEgt lt/CENTERgt ltPgt
ltjspuseBean id"test" classdbiTest.SimpleBean"
/gt ltjspsetProperty name"test"
property"message" value"Hello WWW" /gt
ltH1gtMessage ltIgt ltjspgetProperty name"test"
property"message" /gt lt/Igtlt/H1gt lt/BODYgt
lt/HTMLgt
61
Getting the Values from the Request
ltjspsetProperty namedb propertylogin
valuelt request.getParameter(login)gt /gt
62
Getting the Parameter Automatically

• If we wand that the value of the parameter
  dblogin of the request will be set to the bean db
  automatically we can use

ltjspsetProperty namedb propertylogin
paramdblogin /gt
63
All Input Parameters

• What will the following do?

ltjspsetProperty namedb property /gt
64
Shared Beans

• So far, we assumed that object that were created
  using jspuseBean were bound to to the local
  variables in the _jspService method
• The scope attribute of jspuseBean gives us more
  possibilities

65
The page Value of scope

• The default value of scope
• The object has a binding to the local variable
• The object is positioned in the PageContext for
  the current request
• A servlet can get the value by pageCotext.getAttri
  bute

66
The application Value of scope

• The object has a binding to the local variable
• The object is positioned in the ServletContext
• A servlet can get the value by application.getServ
  letCotext().getAttribute
• Allows both servlets and JSP pages to work with
  the same object
• Allows a servlet to create a bean that will be
  used in JSP pages

67
The session Value of scope

• The object has a binding to the local variable
• The object is positioned in the HttpSession for
  the current request
• A servlet can get the value by session.getAttribut
  e

68
The request Value of scope

• The object has a binding to the local variable
• The object is positioned in the ServletRequest
  for the current request
• A servlet can get the value by request.getAttribut
  e

69
A Conditional Bean

• The jspuseBean component will create a new bean
  only if there is no existing bean with the same
  id and scope
• If an existing bean is found, it will be bound to
  the variable defined by id
• Since bean objects are not always created you can
  have a java code that is executed only if a new
  bean is created

70
Example of Conditional Bean
public class AccessCounterBean private String
firstPage private int accessCount 1
public String getFirstPage()
return(firstPage) public void
setFirstPage(String firstPage)
this.firstPage firstPage public int
getAccessCount() return(accessCount)

71
Example of Conditional Bean
ltjspuseBean idcounter classAccessCounterBean
" scopeapplication/gt ltjspsetProperty
namecounter propertyfirstPage
valueCurrent Page Name/gt lt/jspuseBeangt
72
Comments

• lt-- comment --gt
• A JSP comment
• Ignored by JSP-to-scriptlet translator
• Any embedded JSP scripting elements, directives,
  or actions are ignored
• lt!-- comment --gt
• An HTML comment
• Passed through to resultant HTML
• Any embedded JSP scripting elements, directives,
  or actions are executed normally
• / comment / or // comment
• Java comment
• Part of the Java code

73
Quoting Conventions

• lt\ - used in template text (static HTML) and in
  attributes where you really want lt
• \gt - used in scripting elements and in
  attributes where you really want gt
• \ \ - for using quotes in attributes
• \\ for having \ in an attribute

74
Init and Destroy

• JSP pages, like regular servlets, sometimes want
  to use init and destroy
• Problem the servlet that gets built from the JSP
  page might already use init and destroy
• Overriding them would cause problems
• Thus, it is illegal to use JSP declarations to
  declare init or destroy

75
Init and Destroy

• Solution use jspInit and jspDestroy
• The auto-generated servlet is guaranteed to call
  these methods from init and destroy
• The standard versions of jspInit and jspDestroy
  are empty (placeholders for you to override)

76
JSP vs. Javascript

• Javascript
• Client side
• Less secure
• Browser Dependent
• Unstable

77
JSP vs. ASP

• Active Server Pages (ASP)
• Similarities
• Server side dynamic web page generators
• Share similar syntax lt gt
• Modular programming (e.g. ActiveX, JavaBeans)
• Focus on database connectivity
• Differences
• ASP is a product while JSP is a specification

78
JSP vs. ASP (cont.)

• JSP
• Based on Java Technology
• Platform independence
• Unix, AS400, VMS, Windows
• More vendors choice
• ASP
• Microsoft programming languages
• Near Monopoly

79
JSP vs. Servlets

• But JSP pages are converted to Servlets? Arent
  they the same?
• Similarities
• Provide identical results to the end user
• JSP is an additional module to the Servlet Engine

80
JSP versus Servlets (cont.)

• Differences
• Servlets HTML in Java code
• HTML code inaccessible to Graphics Designer
• Everything very accessible to Programmer
• JSP Java Code Scriptlets in HTML
• HTML code very accessible to Graphics Designer
• Java code very accessible to Programmer

(Seperating content from appearance)
