Topics Related to Data Mining

1
Topics Related to Data Mining

• CS 4/59995

2
Information Retrieval

• Relevance Ranking Using Terms
• Relevance Using Hyperlinks
• Synonyms., Homonyms, and Ontologies
• Indexing of Documents
• Measuring Retrieval Effectiveness
• Information Retrieval and Structured Data

3
Information Retrieval Systems

• Information retrieval (IR) systems use a simpler
  data model than database systems
• Information organized as a collection of
  documents
• Documents are unstructured, no schema
• Information retrieval locates relevant documents,
  on the basis of user input such as keywords or
  example documents
• e.g., find documents containing the words
  database systems
• Can be used even on textual descriptions provided
  with non-textual data such as images

4
Keyword Search

• In full text retrieval, all the words in each
  document are considered to be keywords.
• We use the word term to refer to the words in a
  document
• Information-retrieval systems typically allow
  query expressions formed using keywords and the
  logical connectives and, or, and not
• Ands are implicit, even if not explicitly
  specified
• Ranking of documents on the basis of estimated
  relevance to a query is critical
• Relevance ranking is based on factors such as
• Term frequency
• Frequency of occurrence of query keyword in
  document
• Inverse document frequency
• How many documents the query keyword occurs in
• Fewer ? give more importance to keyword
• Hyperlinks to documents
• More links to a document ? document is more
  important

5
Relevance Ranking Using Terms

• TF-IDF (Term frequency/Inverse Document
  frequency) ranking
• Let n(d) number of terms in the document d
• n(d, t) number of occurrences of term t in the
  document d.
• Relevance of a document d to a term t
• The log factor is to avoid excessive weight to
  frequent terms
• Relevance of document to query Q

n(d, t)
1
TF (d, t) log
n(d)
TF (d, t)
?
r (d, Q)
n(t)
t?Q
IDF1/n(t), n(t) is the number of documents that
contain the term t
6
Relevance Ranking Using Terms (Cont.)

• Most systems add to the above model
• Words that occur in title, author list, section
  headings, etc. are given greater importance
• Words whose first occurrence is late in the
  document are given lower importance
• Very common words such as a, an, the, it
  etc are eliminated
• Called stop words
• Proximity if keywords in query occur close
  together in the document, the document has higher
  importance than if they occur far apart
• Documents are returned in decreasing order of
  relevance score
• Usually only top few documents are returned, not
  all

7
Synonyms and Homonyms

• Synonyms
• E.g. document motorcycle repair, query
  motorcycle maintenance
• need to realize that maintenance and repair
  are synonyms
• System can extend query as motorcycle and
  (repair or maintenance)
• Homonyms
• E.g. object has different meanings as noun/verb
• Can disambiguate meanings (to some extent) from
  the context
• Extending queries automatically using synonyms
  can be problematic
• Need to understand intended meaning in order to
  infer synonyms
• Or verify synonyms with user
• Synonyms may have other meanings as well

8
Indexing of Documents

• An inverted index maps each keyword Ki to a set
  of documents Si that contain the keyword
• Documents identified by identifiers
• Inverted index may record
• Keyword locations within document to allow
  proximity based ranking
• Counts of number of occurrences of keyword to
  compute TF
• and operation Finds documents that contain all
  of K1, K2, ..., Kn.
• Intersection S1? S2 ?..... ? Sn
• or operation documents that contain at least one
  of K1, K2, , Kn
• union, S1?S2 ?..... ? Sn,.
• Each Si is kept sorted to allow efficient
  intersection/union by merging
• not can also be efficiently implemented by
  merging of sorted lists

9
Word-Level Inverted File
lexicon
posting
10
Measuring Retrieval Effectiveness

• Information-retrieval systems save space by using
  index structures that support only approximate
  retrieval. May result in
• false negative (false drop) - some relevant
  documents may not be retrieved.
• false positive - some irrelevant documents may be
  retrieved.
• For many applications a good index should not
  permit any false drops, but may permit a few
  false positives.
• Relevant performance metrics
• precision - what percentage of the retrieved
  documents are relevant to the query.
• recall - what percentage of the documents
  relevant to the query were retrieved.

11
Measuring Retrieval Effectiveness (Cont.)

• Recall vs. precision tradeoff
• Can increase recall by retrieving many documents
  (down to a low level of relevance ranking), but
  many irrelevant documents would be fetched,
  reducing precision
• Measures of retrieval effectiveness
• Recall as a function of number of documents
  fetched, or
• Precision as a function of recall
• Equivalently, as a function of number of
  documents fetched
• E.g. precision of 75 at recall of 50, and 60
  at a recall of 75
• Problem which documents are actually relevant,
  and which are not

12
Information Retrieval and Structured Data

• Information retrieval systems originally treated
  documents as a collection of words
• Information extraction systems infer structure
  from documents, e.g.
• Extraction of house attributes (size, address,
  number of bedrooms, etc.) from a text
  advertisement
• Extraction of topic and people named from a new
  article
• Relations or XML structures used to store
  extracted data
• System seeks connections among data to answer
  queries
• Question answering systems

13
Probabilities and Statistic
14
Probabilities
1.
2.
Event E is defined as a any subset of
f(x) is called a probability distribution
function (pdf)
15
Conditional Probabilities
Conditional probability of E, provided that G
occurred is
E and G are independent if and only if
.
Expected Value
Expected value of X is
For continuous function f(x), the E(X) is
E(XY) E(X)E(Y) E(aXb) aE(X)b
16
Variance
2

• Var(X) E(X-E(X))
• It indicates how values of random variable are
  distributed around its expected value
• Standard deviation of X is defined as
• VAR(XY) VAR(X) VAR(Y)
• VAR(aXb) VAR(X)b
• P(S - E(S) r) VAR(S)/r
  (Chebyshevs Ineequality)
• Example
• 1,2,3,4,5,6 p(i) 1/6 E(X)
  11/621/631/641/651/661/6
• E(X)1/6213.5
• (1,2,9,16,25,36) VAR(X) E(X2-2XE(X)E2(X)E(X
  2)-E2(X)
• E(X2)1/6(129162536)1/689
• E2(X)3.53.512.25
• VAR(X)89/6 -12.252.58
• Standard deviation sqrt(2.58)1.61

2
2
2
17
Random Distributions
Normal
µ
E(X)
2
Var(X) s
Bernoulli
E(X) np Var(X) np(1-p)
18
Normal Distributions
E(x)
19
Random Distributions
Geometric
2
E(X) 1/p VAR(X) (1-p)/p
Poisson
E(X)VAR(X)m
P(Xx) 1/(b-a)
Uniform
2
E(X)(b-a)/2 VAR(X) (b-a) /12
20
Correlation between age and mortality
21
Systolic Blood Pressure Distribution
22
Distribution of heart rate by systolic blood
pressure
23
Data and their characteristics
24
Types of Attributes

• There are different types of attributes
• Nominal
• Examples ID numbers, eye color, zip codes
• Ordinal
• Examples rankings (e.g., taste of potato chips
  on a scale from 1-10), grades, height in tall,
  medium, short
• Interval
• Examples calendar dates, temperatures in Celsius
  or Fahrenheit.
• Ratio
• Examples temperature in Kelvin, length, time,
  counts

25
Properties of Attribute Values

• The type of an attribute depends on which of the
  following properties it possesses
• Distinctness ?
• Order lt gt
• Addition -
• Multiplication /
• Nominal attribute distinctness
• Ordinal attribute distinctness order
• Interval attribute distinctness, order
  addition
• Ratio attribute all 4 properties

26
(No Transcript)
27
Discrete and Continuous Attributes

• Discrete Attribute
• Has only a finite or countably infinite set of
  values
• Examples zip codes, counts, or the set of words
  in a collection of documents
• Often represented as integer variables.
• Note binary attributes are a special case of
  discrete attributes
• Continuous Attribute
• Has real numbers as attribute values
• Examples temperature, height, or weight.
• Practically, real values can only be measured and
  represented using a finite number of digits.
• Continuous attributes are typically represented
  as floating-point variables.

28
Data Matrix

• If data objects have the same fixed set of
  numeric attributes, then the data objects can be
  thought of as points in a multi-dimensional
  space, where each dimension represents a distinct
  attribute
• Such data set can be represented by an m by n
  matrix, where there are m rows, one for each
  object, and n columns, one for each attribute

29
Data Quality

• What kinds of data quality problems?
• How can we detect problems with the data?
• What can we do about these problems?
• Examples of data quality problems
• Noise and outliers
• missing values
• duplicate data

30
Noise

• Noise refers to modification of original values
• Examples distortion of a persons voice when
  talking on a poor phone and snow on television
  screen

Two Sine Waves
Two Sine Waves Noise
31
Outliers

• Outliers are data objects with characteristics
  that are considerably different than most of the
  other data objects in the data set

32
Data Preprocessing

• Aggregation
• Sampling
• Dimensionality Reduction
• Feature subset selection
• Feature creation
• Discretization and Binarization
• Attribute Transformation

33
Aggregation

• Combining two or more attributes (or objects)
  into a single attribute (or object)
• Purpose
• Data reduction
• Reduce the number of attributes or objects
• Change of scale
• Cities aggregated into regions, states,
  countries, etc
• More stable data
• Aggregated data tends to have less variability

34
Sampling

• Sampling is the main technique employed for data
  selection.
• It is often used for both the preliminary
  investigation of the data and the final data
  analysis.
• Statisticians sample because obtaining the entire
  set of data of interest is too expensive or time
  consuming.
• Sampling is used in data mining because
  processing the entire set of data of interest is
  too expensive or time consuming.

35
Sampling

• The key principle for effective sampling is the
  following
• using a sample will work almost as well as using
  the entire data sets, if the sample is
  representative
• A sample is representative if it has
  approximately the same property (of interest) as
  the original set of data

36
Types of Sampling

• Simple Random Sampling
• There is an equal probability of selecting any
  particular item
• Sampling without replacement
• As each item is selected, it is removed from the
  population
• Sampling with replacement
• Objects are not removed from the population as
  they are selected for the sample.
• In sampling with replacement, the same object
  can be picked up more than once
• Stratified sampling
• Split the data into several partitions then draw
  random samples from each partition

37
Curse of Dimensionality

• When dimensionality increases, data becomes
  increasingly sparse in the space that it occupies
• Definitions of density and distance between
  points, which is critical for clustering and
  outlier detection, become less meaningful

• Randomly generate 500 points
• Compute difference between max and min distance
  between any pair of points

38
Discretization

• Three types of attributes
• Nominal values from an unordered set
• Ordinal values from an ordered set
• Continuous real numbers
• Discretization
• divide the range of a continuous attribute into
  intervals
• Some classification algorithms only accept
  categorical attributes.
• Reduce data size by discretization
• Prepare for further analysis

39
Discretization and Concept hierarchy

• Discretization
• reduce the number of values for a given
  continuous attribute by dividing the range of the
  attribute into intervals. Interval labels can
  then be used to replace actual data values.
• Concept hierarchies
• reduce the data by collecting and replacing low
  level concepts (such as numeric values for the
  attribute age) by higher level concepts (such as
  young, middle-aged, or senior).

40
Discretization

• Three types of attributes
• Nominal values from an unordered set
• Ordinal values from an ordered set
• Continuous real numbers
• Discretization
• divide the range of a continuous attribute into
  intervals
• Some classification algorithms only accept
  categorical attributes.
• Reduce data size by discretization
• Prepare for further analysis

41
Discretization and generation for numeric data

• Binning
• Histogram analysis
• Entropy-based discretization
• Segmentation by natural partitioning

42
Discretization
Sort Attribute
Select cut Point
Evaluate Measure
NO
NO
Satisfied
Yes
DONE
Split/Merge
Stop
43
Simple Discretization Methods Binning

• Equal-width (distance) partitioning
• It divides the range into N intervals of equal
  size uniform grid
• if A and B are the lowest and highest values of
  the attribute, the width of intervals will be W
  (B-A)/N.
• The most straightforward
• But outliers may dominate presentation
• Skewed data is not handled well.
• Equal-depth (frequency) partitioning
• It divides the range into N intervals, each
  containing approximately same number of samples
• Good data scaling
• Managing categorical attributes can be tricky.

44
Discretization

• Three types of attributes
• Nominal values from an unordered set
• Ordinal values from an ordered set
• Continuous real numbers
• Discretization
• divide the range of a continuous attribute into
  intervals
• Some classification algorithms only accept
  categorical attributes.
• Reduce data size by discretization
• Prepare for further analysis

45
Entropy-Based Discretization

• Given a set of samples S, if S is partitioned
  into two intervals S1 and S2 using boundary T,
  the entropy after partitioning is
• The boundary that minimizes the entropy function
  over all possible boundaries is selected as a
  binary discretization.
• The process is recursively applied to partitions
  obtained until some stopping criterion is met,
  e.g.,
• Experiments show that it may reduce data size and
  improve classification accuracy

46
Specification of a set of attributes

• Concept hierarchy can be automatically generated
  based on the number of distinct values per
  attribute in the given attribute set. The
  attribute with the most distinct values is placed
  at the lowest level of the hierarchy.

15 distinct values
country
65 distinct values
province_or_ state
3567 distinct values
city
674,339 distinct values
street
47
Similarity and Dissimilarity

• Similarity
• Numerical measure of how alike two data objects
  are.
• Is higher when objects are more alike.
• Often falls in the range 0,1
• Dissimilarity
• Numerical measure of how different are two data
  objects
• Lower when objects are more alike
• Minimum dissimilarity is often 0
• Upper limit varies
• Proximity refers to a similarity or dissimilarity

48
Similarity/Dissimilarity for Simple Attributes
p and q are the attribute values for two data
objects.
49
Euclidean Distance

• Euclidean Distance
• Where n is the number of dimensions
  (attributes) and pk and qk are, respectively, the
  kth attributes (components) or data objects p and
  q.

50
Euclidean Distance
Distance Matrix
51
Minkowski Distance

• Minkowski Distance is a generalization of
  Euclidean Distance
• Where r is a parameter, n is the number of
  dimensions (attributes) and pk and qk are,
  respectively, the kth attributes (components) or
  data objects p and q.

52
Minkowski Distance
Distance Matrix
53
Covariance

• CovarianceE((x-E(x)(y E(y))
• Describes a some sort of dependency between
  variables.
• Describes how the X and Y change together

54
Common Properties of a Distance

• Distances, such as the Euclidean distance, have
  some well known properties.
• d(p, q) ? 0 for all p and q and d(p, q) 0
  only if p q. (Positive definiteness)
• d(p, q) d(q, p) for all p and q. (Symmetry)
• d(p, r) ? d(p, q) d(q, r) for all points p,
  q, and r. (Triangle Inequality)
• where d(p, q) is the distance (dissimilarity)
  between points (data objects), p and q.
• A distance that satisfies these properties is
  called a metric

55
Common Properties of a Similarity

• Similarities, also have some well known
  properties.
• s(p, q) 1 (or maximum similarity) only if p
  q.
• s(p, q) s(q, p) for all p and q. (Symmetry)
• where s(p, q) is the similarity between points
  (data objects), p and q.

56
Similarity Between Binary Vectors

• Common situation is that objects, p and q, have
  only binary attributes
• Compute similarities using the following
  quantities
• M01 the number of attributes where p was 0 and
  q was 1
• M10 the number of attributes where p was 1 and
  q was 0
• M00 the number of attributes where p was 0 and
  q was 0
• M11 the number of attributes where p was 1 and
  q was 1
• Simple Matching and Jaccard Coefficients
• SMC number of matches / number of attributes
• (M11 M00) / (M01 M10 M11
  M00)
• J number of 11 matches / number of
  not-both-zero attributes values
• (M11) / (M01 M10 M11)

57
SMC versus Jaccard Example

• p 1 0 0 0 0 0 0 0 0 0
• q 0 0 0 0 0 0 1 0 0 1
• M01 2 (the number of attributes where p was 0
  and q was 1)
• M10 1 (the number of attributes where p was 1
  and q was 0)
• M00 7 (the number of attributes where p was 0
  and q was 0)
• M11 0 (the number of attributes where p was 1
  and q was 1)
• SMC (M11 M00)/(M01 M10 M11 M00) (07)
  / (2107) 0.7
• J (M11) / (M01 M10 M11) 0 / (2 1 0)
  0

58
Data Warehousing and OLAP Technology for Data
Mining

• What is a data warehouse?
• Data warehouse architecture
• Data warehouse implementation
• Further development of data cube technology
• From data warehousing to data mining

59
Data Warehousing

• Large organizations have complex internal
  organizations, and have data stored at different
  locations, on different operational (transaction
  processing) systems, under different schemas
• Data sources often store only current data, not
  historical data
• Corporate decision making requires a unified view
  of all organizational data, including historical
  data
• A data warehouse is a repository (archive) of
  information gathered from multiple sources,
  stored under a unified schema, at a single site
• Greatly simplifies querying, permits study of
  historical trends
• Shifts decision support query load away from
  transaction processing systems

60
Data Warehouse vs. Operational DBMS

• OLTP (on-line transaction processing)
• Major task of traditional relational DBMS
• Day-to-day operations purchasing, inventory,
  banking, manufacturing, payroll, registration,
  accounting, etc.
• OLAP (on-line analytical processing)
• Major task of data warehouse system
• Data analysis and decision making
• Distinct features (OLTP vs. OLAP)
• User and system orientation customer vs. market
• Data contents current, detailed vs. historical,
  consolidated
• Database design ER application vs. star
  subject
• View current, local vs. evolutionary, integrated
• Access patterns update vs. read-only but complex
  queries

61
OLTP vs. OLAP
62
Data Warehousing
63
Managing of a warehouse

• When and how to gather data
• Source driven architecture data sources transmit
  new information to warehouse, either continuously
  or periodically (e.g. at night)
• Destination driven architecture warehouse
  periodically requests new information from data
  sources
• What schema to use
• Schema integration

64
Managing of a warehouse(Cont.)

• Data cleansing
• E.g. correct mistakes in addresses
• E.g. misspellings, zip code errors
• Merge address lists from different sources and
  purge duplicates
• Keep only one address record per household
  (householding)
• How to propagate updates
• Warehouse schema may be a (materialized) view of
  schema from data sources
• Efficient techniques for update of materialized
  views
• What data to summarize
• Raw data may be too large to store on-line
• Aggregate values (totals/subtotals) often suffice
• Queries on raw data can often be transformed by
  query optimizer to use aggregate values

65
Conceptual Modeling of Data Warehouses

• Modeling data warehouses dimensions measures
• Star schema A fact table in the middle connected
  to a set of dimension tables
• Snowflake schema A refinement of star schema
  where some dimensional hierarchy to snowflake
• Fact constellations is normalized into a set of
  smaller dimension tables, forming a shape similar
  Multiple fact tables share dimension tables,
  viewed as a collection of stars, therefore called
  galaxy schema or fact constellation

66
Star Schema Example
67
Example of Snowflake Schema
Sales Fact Table
time_key
item_key
branch_key
location_key
units_sold
dollars_sold
avg_sales
Measures
68
Example of Fact Constellation
Shipping Fact Table
time_key
Sales Fact Table
item_key
time_key
shipper_key
item_key
from_location
branch_key
to_location
location_key
dollars_cost
units_sold
units_shipped
dollars_sold
avg_sales
Measures
69
Online Analytical Processing

• The operation of changing the dimensions used in
  a cross-tab is called pivoting
• Suppose an analyst wishes to see a cross-tab on
  item-name and color for a fixed value of size,
  for example, large, instead of the sum across all
  sizes.
• Such an operation is referred to as slicing.
• The operation is sometimes called dicing,
  particularly when values for multiple dimensions
  are fixed.
• The operation of moving from finer-granularity
  data to a coarser granularity is called a rollup.
• The opposite operation - that of moving from
  coarser-granularity data to finer-granularity
  data is called a drill down.

70
Three-Dimensional Data Cube

• A data cube is a multidimensional generalization
  of a crosstab
• Cannot view a three-dimensional object in its
  entirety
• but crosstabs can be used as views on a data cube

71
Cube A Lattice of Cuboids
all
0-D(apex) cuboid
time
item
location
supplier
1-D cuboids
time,item
time,location
item,location
location,supplier
2-D cuboids
time,supplier
item,supplier
time,location,supplier
time,item,location
3-D cuboids
item,location,supplier
time,item,supplier
4-D(base) cuboid
time, item, location, supplier
72
Hierarchies on Dimensions

• Hierarchy on dimension attributes lets
  dimensions to be viewed at different levels of
  detail
• E.g. the dimension DateTime can be used to
  aggregate by hour of day, date, day of week,
  month, quarter or year

73
OLAP Implementation

• The earliest OLAP systems used multidimensional
  arrays in memory to store data cubes, and are
  referred to as multidimensional OLAP (MOLAP)
  systems.
• OLAP implementations using only relational
  database features are called relational OLAP
  (ROLAP) systems
• Hybrid systems, which store some summaries in
  memory and store the base data and other
  summaries in a relational database, are called
  hybrid OLAP (HOLAP) systems.

74
OLAP Implementation (Cont.)

• Early OLAP systems precomputed all possible
  aggregates in order to provide online response
• Space and time requirements for doing so can be
  very high
• 2n combinations of group by
• It suffices to precompute some aggregates, and
  compute others on demand from one of the
  precomputed aggregates
• Can compute aggregate on (item-name, color) from
  an aggregate on (item-name, color, size)
• For all but a few non-decomposable aggregates
  such as median
• is cheaper than computing it from scratch
• Several optimizations available for computing
  multiple aggregates
• Can compute aggregate on (item-name, color) from
  an aggregate on (item-name, color, size)
• Can compute aggregates on (item-name, color,
  size), (item-name, color) and (item-name) using
  a single sorting of the base data

75
Group By cube

• The cube operation computes union of group bys
  on every subset of the specified attributes
• E.g. consider the query
• select item-name, color, size,
  sum(number) from sales group by cube(item-name,
  color, size)
• This computes the union of eight different
  groupings of the sales relation
• (item-name, color, size), (item-name,
  color), (item-name, size),
  (color, size), (item-name),
  (color), (size),
  ( )
• where ( ) denotes an empty group by list.
• For each grouping, the result contains the null
  value for attributes not present in the
  grouping.

76
Group BY Cube (cont)

• The function grouping() can be applied on an
  attribute
• Returns 1 if the value is a null value
  representing all, and returns 0 in all other
  cases.
• select item-name, color, size,
  sum(number), grouping(item-name) as
  item-name-flag, grouping(color) as
  color-flag, grouping(size) as size-flag,from
  salesgroup by cube(item-name, color, size)
• Can use the function decode() in the select
  clause to replace such nulls by a value such as
  all
• E.g. replace item-name in first query by
  decode( grouping(item-name), 1, all, item-name)

77
Alternative A Data Mining Query Language - DMQL

• Cube Definition (Fact Table)
• define cube ltcube_namegt ltdimension_listgt
  ltmeasure_listgt
• Dimension Definition ( Dimension Table )
• define dimension ltdimension_namegt as
  (ltattribute_or_subdimension_listgt)
• Special Case (Shared Dimension Tables)
• First time as cube definition
• define dimension ltdimension_namegt as
  ltdimension_name_first_timegt in cube
  ltcube_name_first_timegt

78
Defining a Star Schema in DMQL

• define cube sales_star time, item, branch,
  location
• dollars_sold sum(sales_in_dollars), avg_sales
  avg(sales_in_dollars), units_sold count()
• define dimension time as (time_key, day,
  day_of_week, month, quarter, year)
• define dimension item as (item_key, item_name,
  brand, type, supplier_type)
• define dimension branch as (branch_key,
  branch_name, branch_type)
• define dimension location as (location_key,
  street, city, province_or_state, country)

79
Defining a Snowflake Schema in DMQL

• define cube sales_snowflake time, item, branch,
  location
• dollars_sold sum(sales_in_dollars), avg_sales
  avg(sales_in_dollars), units_sold count()
• define dimension time as (time_key, day,
  day_of_week, month, quarter, year)
• define dimension item as (item_key, item_name,
  brand, type, supplier(supplier_key,
  supplier_type))
• define dimension branch as (branch_key,
  branch_name, branch_type)
• define dimension location as (location_key,
  street, city(city_key, province_or_state,
  country))

80
Defining a Fact Constellation in DMQL

• define cube sales time, item, branch, location
• dollars_sold sum(sales_in_dollars), avg_sales
  avg(sales_in_dollars), units_sold count()
• define dimension time as (time_key, day,
  day_of_week, month, quarter, year)
• define dimension item as (item_key, item_name,
  brand, type, supplier_type)
• define dimension branch as (branch_key,
  branch_name, branch_type)
• define dimension location as (location_key,
  street, city, province_or_state, country)
• define cube shipping time, item, shipper,
  from_location, to_location
• dollar_cost sum(cost_in_dollars), unit_shipped
  count()
• define dimension time as time in cube sales
• define dimension item as item in cube sales
• define dimension shipper as (shipper_key,
  shipper_name, location as location in cube sales,
  shipper_type)
• define dimension from_location as location in
  cube sales
• define dimension to_location as location in cube
  sales

81
Measures Three Categories

• distributive if the result derived by applying
  the function to n aggregate values is the same as
  that derived by applying the function on all the
  data without partitioning.
• E.g., count(), sum(), min(), max().
• algebraic if it can be computed by an algebraic
  function with M arguments (where M is a bounded
  integer), each of which is obtained by applying a
  distributive aggregate function.
• E.g., avg(), min_M(), standard_deviation().
• holistic if there is no constant bound on the
  storage size needed to describe a subaggregate.
• E.g., median(), mode(), rank().

82
Data Warehouse Design Process

• Top-down, bottom-up approaches or a combination
  of both
• Top-down Starts with overall design and planning
  (mature)
• Bottom-up Starts with experiments and prototypes
  (rapid)
• From software engineering point of view
• Waterfall structured and systematic analysis at
  each step before proceeding to the next
• Spiral rapid generation of increasingly
  functional systems, short turn around time, quick
  turn around
• Typical data warehouse design process
• Choose a business process to model, e.g., orders,
  invoices, etc.
• Choose the grain (atomic level of data) of the
  business process
• Choose the dimensions that will apply to each
  fact table record
• Choose the measure that will populate each fact
  table record

83
Multi-Tiered Architecture
Monitor Integrator
OLAP Server
Metadata
Analysis Query Reports Data mining
Serve
Data Warehouse
Data Marts
Data Sources
OLAP Engine
Front-End Tools
Data Storage
84
Efficient Processing OLAP Queries

• Determine which operations should be performed on
  the available cuboids
• transform drill, roll, etc. into corresponding
  SQL and/or OLAP operations, e.g, dice selection
  projection
• Determine to which materialized cuboid(s) the
  relevant operations should be applied.
• Exploring indexing structures and compressed vs.
  dense array structures in MOLAP

85
Metadata Repository

• Meta data is the data defining warehouse objects.
  It has the following kinds
• Description of the structure of the warehouse
• schema, view, dimensions, hierarchies, derived
  data defn, data mart locations and contents
• Operational meta-data
• data lineage (history of migrated data and
  transformation path), currency of data (active,
  archived, or purged), monitoring information
  (warehouse usage statistics, error reports, audit
  trails)
• The algorithms used for summarization
• The mapping from operational environment to the
  data warehouse
• Data related to system performance
• warehouse schema, view and derived data
  definitions
• Business data
• business terms and definitions, ownership of
  data, charging policies

86
Data Warehouse Back-End Tools and Utilities

• Data extraction
• get data from multiple, heterogeneous, and
  external sources
• Data cleaning
• detect errors in the data and rectify them when
  possible
• Data transformation
• convert data from legacy or host format to
  warehouse format
• Load
• sort, summarize, consolidate, compute views,
  check integrity, and build indicies and
  partitions
• Refresh
• propagate the updates from the data sources to
  the warehouse

87
Discovery-Driven Exploration of Data Cubes

• Hypothesis-driven exploration by user, huge
  search space
• Discovery-driven (Sarawagi et al.98)
• pre-compute measures indicating exceptions, guide
  user in the data analysis, at all levels of
  aggregation
• Exception significantly different from the value
  anticipated, based on a statistical model
• Visual cues such as background color are used to
  reflect the degree of exception of each cell
• Computation of exception indicator (modeling
  fitting and computing SelfExp, InExp, and PathExp
  values) can be overlapped with cube construction

88
Examples Discovery-Driven Data Cubes
89
Data Warehouse Usage

• Three kinds of data warehouse applications
• Information processing
• supports querying, basic statistical analysis,
  and reporting using crosstabs, tables, charts and
  graphs
• Analytical processing
• multidimensional analysis of data warehouse data
• supports basic OLAP operations, slice-dice,
  drilling, pivoting
• Data mining
• knowledge discovery from hidden patterns
• supports associations, constructing analytical
  models, performing classification and prediction,
  and presenting the mining results using
  visualization tools.
• Differences among the three tasks

90
From On-Line Analytical Processing to On Line
Analytical Mining (OLAM)

• Why online analytical mining?
• High quality of data in data warehouses
• DW contains integrated, consistent, cleaned data
• Available information processing structure
  surrounding data warehouses
• ODBC, OLEDB, Web accessing, service facilities,
  reporting and OLAP tools
• OLAP-based exploratory data analysis
• mining with drilling, dicing, pivoting, etc.
• On-line selection of data mining functions
• integration and swapping of multiple mining
  functions, algorithms, and tasks.
• Architecture of OLAM

91
An OLAM Architecture
Layer4 User Interface
Mining query
Mining result
User GUI API
OLAM Engine
OLAP Engine
Layer3 OLAP/OLAM
Data Cube API
Layer2 MDDB
MDDB
Meta Data
Database API
FilteringIntegration
Filtering
Layer1 Data Repository
Data Warehouse
Data cleaning
Databases
Data integration
