Title: MCRDS Data Format


1
MCRDS Data Format
  • May 3, 2006

2
File Type Header
  • Data file type
  • 32 byte string (Data-MCRDS) terminated with
    null character \0. Characters after termination
    undefined.
  • 2 bytes unsigned short representing year
  • 1 byte unsigned character representing subyear
    version
  • 5 bytes reserved

3
Data Header Block
  • struct HeaderBlock
  • int dataType
  • double sampFreq 120 MHz
  • int prfCount PRF 1/(prfCount1e-7)
  • int numAve of hardware integrations (i.e.
    coherent averages)
  • int rxAtten824
  • int rxBlank814
  • char calModeEn always false
  • char numWaveforms
  • char pad2 reserved
  • int calNumOfPnts not used during data
    collection
  • double calStartFreq not used during data
    collection
  • double calStopFreq not used during data
    collection
  • double calDelay not used during data
    collection
  • double calDuration not used during data
    collection

4
Fields of interest Rx mode
  • rxAtten and rxBlank
  • Each of the eight receivers are loaded with 4
    different modes. The modes for each receiver are
    independent of one another.
  • E.g. mode 1 for receiver 2 can be different than
    mode 1 for receiver 3.
  • A mode is defined by the settings of the two
    digital step attenuators and the blank delay line
    selection.
  • The receiver has a single blanking switch, but
    two different control lines that can be selected.
  • During any given pulse period, all receivers must
    be in the same mode number.
  • I.e. the radar does not allow receiver 2 to be in
    mode 1 while receiver 3 is in mode 2.

5
Fields of interest Waveforms
  • The radar system transmits a set of waveforms
    defined by the radar operator.
  • The radar loads this sequence of waveforms into
    the system. For example
  • 3 us linear FM chirp, radar mode 0
  • Receiver gain settings are set to allow capture
    of the surface echo and both transmit amplifiers
    are enabled.
  • 10 us linear FM chirp, radar mode 1
  • Receiver gain settings set to maximize dynamic
    range while keeping the lowest noise figure
    possible and satisfying our A2D dithering req.
    Transmit antenna one enabled.
  • 10 us linear FM chirp, radar mode 2
  • Receiver gain settings set to maximize dynamic
    range while keeping the lowest noise figure
    possible and satisfying our A2D dithering req.
    Transmit antenna five enabled.
  • When the radar is enabled, each of the waveforms
    and radar modes is run in sequence.
  • E.g. With three waveforms the effective PRF of an
    individual waveform becomes PRF/3

6
Waveform Headers (part of data header block)
  • struct WaveformHeaderBlock
  • double startFreq 20 MHz (USB mixing with
    120 MHz LO to 140 MHz)
  • double stopFreq 40 MHz (USB mixing with
    120 MHz LO to 160 MHz)
  • double pulseDuration arbitrary (but most
    likely 1 us, 3 us or 10 us)
  • double calFreq 0 (disabled during data
    collection)
  • double calDelay unused
  • double calDuration unused
  • char bandSelect 0 for 150 MHz band, 1 for
    450 MHz band
  • char zeroPiMod 0 for no modulation, 1 for
    zero-pi modulation
  • char txMult unused
  • char rxMode 0, 1, 2, or 3
  • char txAmpEn2 0 control tx amp 0, 1
    controls tx amp 1
  • char pad2
  • int mod0Count transmitter blanking control
    line
  • int mod1Count transmit amplifier blanking
    control line
  • int numSam4 number of samples for each
    DAQ to capture (4 daqs, each with 2 channels)
  • int sampleDelayCount4 delay for DAQ begins
    capturing
  • char recordEn8 per channel record enable

7
AWG Block
  • For predistortion and non-ideal linear FM chirps
  • We are not using this data block for May 06.

8
Data Block
  • 4 byte integer for data type (data type is 2 for
    data blocks)
  • 8 bytes for computer time stamp
  • 4 bytes for seconds since epoch (Jan 1, 1970)
  • 4 bytes for microseconds
  • 8 bytes for radar time (free-running 10 MHz
    counter on the radar board)
  • Used to precisely synchronize to the 1 pps
    provided by the Wallops Flight Facility group.
  • 4 bytes for DAQ errors
  • 1 byte per DAQ
  • Byte is zero when there is no error
  • Most common error is a FIFO error which causes a
    reset of the FIFOs and a few dropped records
  • Binary data follows (2 byte unsigned samples)
  • 12 bit DAQ, 64 integrations 18 bits
  • 2 bits dropped 16 bit sample

9
Overview
File Type
Data Header
Data Block 0
Datatype (2)
Waveform 0
Sample 0
Computer Time
Data Block 1
Waveform 1
Sample 1
Radar Time
Data Block 2
Waveform 2
Sample 2
DAQ Error Bytes
DAQ 0
DAQ 1
DAQ 2
