A Crash Course in CVS

1
A Crash Course in CVS

• 19 November 2003
• Joe Vornehm
• Northwestern UniversityECE Department

2
Overview

• The need for version control
• Version control basics
• CVS basics adding, updating, committing...
• Controlling the project
• Things that dont work well
• QA

3
Assumptions

• Basic familiarity with Unix shells
• GUI tools also available
• For Unix on Windows www.cygwin.com
• For more info www.cvshome.org
• This presentationhttp//www.ece.northwestern.edu
  /jev283/talks/cvs/

4
The Need for Version Control

• Tracking changes during development
• Seeing how, when things changed
• The Oops factor
• Coordinating among multiple developers
• Access control (not CVS)
• Solution Keep a history of each file in a
  central location called the repository

5
Version Control Systems

• Big Repository in the Sky
• Local copies of files in working directory
• Develop program in working directory
• Copy files to/from repositorycalled checking
  in/out or committing/updating

Repository
Alicesworkingdirectory
Bobsworkingdirectory
6
Interacting with CVS

• cvs command
• GUIs also available
• CVS interface built into editors, MATLAB, etc.
• CVSROOT environment variable specifies location
  of CVS repository
• Can be local directory, network disk, CVS
  pserver, rsh/ssh tunnel
• Can also use cvs -d

7
CVS Commands

• cvs global-opts command command-opts
• cvs --help-commands, cvs -H command
• cvs --help-options (not for beginners)
• Examples
• cvs add hello.c
• cvs add -m Created hello.c hello.c
• cvs -d MY_CVSROOT add -m Created hello.c
  hello.c

8
CVS Commands (concl.)

• Most CVS commands accept a filename, many
  filenames, or no filename to mean the current
  directory (and -R to recurse below the current
  directory)

9
One Important Global Option

• cvs -n command causes CVS to execute the
  command without changing any files on disk (or in
  the repository)
• Good for seeing what something will do before you
  try it
• Certain behaviors are different with -n, so you
  may get strange errors that go away when you
  dont use -n

10
Getting Started

• Easiest way import an existing project, then
  create a new working directory
• Make a repository
• mkdir /project/cvsroot
• export CVSROOT/project/cvsroot
• Probably want this in .profile or .cshrc
• cvs init

11
Getting Started (cont.)

• Import original source directory
• cd /project/myproj
• cvs import myproj mygroup start
• myproj is the name of the CVS module
• mygroup is some tag indicating where the sources
  came from (not used very much)
• start is some tag indicating that this is the
  very first import of this project into CVS

12
Getting Started (concl.)

• Create a local working directory
• cd /work
• cvs checkout myproj
• Gets a clean copy of myproj source code, puts it
  in directory myproj
• cd myproj
• Start developing!

13
The Daily Grind

• cvs commit, update, and add make up the vast
  majority of day-to-day CVS usage
• cvs commit Take changes made to working
  directory, commit them to CVS repository
• cvs update Get latest versions from CVS
  repository, update working directory
• cvs add Add a file from the working directory to
  the repository

14
cvs commit

• Make changes to a file, then commit the file
  using cvs commit filename
• CVS prompts for a log message, something short
  and descriptive of changes, like, Changed
  frobnitz operator to support multiple
  inheritance.
• Alt. specify message using cvs commit -m msg
• cvs commit with no filename commits all changed
  files in current directory

15
cvs update

• cvs update filename updates a file in the working
  directory so it matches the latest version in the
  repository
• cvs update with no filename updates all changed
  files in current directory
• CVS actually updates files by merging
  version-to-version changes with the working
  directory file more later.

16
cvs add

• cvs add filename tells CVS to add a file to the
  repository during the next commit operation
• cvs commit filename (or cvs commit) actually adds
  the file same syntax as before.

17
Status information

• cvs log filename gives a history of all commit
  log messages for a particular file
• cvs status filename gives status information
  about a particular file (version number, whether
  it needs an update or a commit, etc.)
• cvs history gives history information about
  repository accesses

18
Useful Commands

• cvs diff filename compares a local file to a
  repository version, compares two versions, etc.
• cvs update -p filename prints the updated file to
  the screen without changing the file on disk
  useful for pipe commands

19
CVS Keywords

• CVS generally does not independently change the
  contents of files you commit or update
• Keywords are an exception Id, Revision,
  Log, etc.
• CVS updates these strings with the appropriate
  information at each revision

20
CVS Keywords (cont.)

• Example / hello.c -- Guess what it does.
  / include ltstdio.hgt / Revision / int
  main(int argc, char argv) etc.

21
CVS Keywords (concl.)

• After check-in, the file reads / hello.c --
  Guess what it does. / include ltstdio.hgt /
  Revision 1.1 / int main(int argc, char
  argv) etc.

22
Adding another person

• Ideal development cycle
• Alice works on functions.c, Bob works on main.c
• Alice makes a change to functions.c, commits
• Alice Bob, I added that thingy to functions.c.
• Bob OK.
• Bob runs cvs update functions.c (or just cvs
  update) and continues developing main.c

23
Adding Another Person (cont.)

• More realistic development cycle
• Alice is working on sum() in functions.c
• Bob is working on product() in functions.c
• Alice finishes sum() and commits functions.c
• Bob finishes product() and tries to commit
• CVS refuses, because it knows Bob is working on
  an old version of functions.c

24
Adding Another Person (cont.)

• What is Bob to do?
• Bob runs cvs update functions.c
• If Bob is lucky, he and Alice havent changed the
  same lines anywhere
• CVS merges Alices changes with Bobs in Bobs
  copy of functions.c
• Now Bob can commit his copy of functions.c with
  both his changes and Alices
• and Bob should tell Alice that he committed
  functions.c again!

25
Adding Another Person (cont.)

• What if Alices and Bobs changes conflict?
• If Bob is unlucky, he and Alice have changed some
  of the same lines in different ways
• cvs update In the conflicting areas, CVS puts
  both sets of changes into Bobs copy of
  functions.c, set off by angle brackets
• Bob has to merge the changes manually (typically
  deciding whether to keep his changes or Alices)
  and then commit the file.

26
Adding Another Person (cont.)

• Other ways to handle conflicting updates
• Alice and Bob can have a meeting to discuss which
  changes Bob should make
• Bob can postpone the merge and just continue
  development with his own functions.c (without
  Alices changes)
• Bob can overwrite his functions.c with the
  repository copy (that has Alices changes but not
  his)

27
Adding Another Person (concl.)

• One developer never (rarely) any conflicts
• A few developers (2-20) occasional conflicts
• Either each piece of code is one persons
  responsibility, or developers are working
  together anyway
• Many developers conflicts arise
• Need more than just CVS to resolve issues

28
Tag! Youre It

• Sometimes you want a snapshot of the project
  state
• Symbolic tags are a way to do that
• One tag means the version of each file that was
  current when this tag was created
• Good for external releases, forks, big decision
  points, experimenting
• cvs tag tagname or cvs tag tagname files

29
Working with Old Versions

• Most CVS commands (commit, update, diff) accept
  the -r revision flag to deal with a specific
  version instead of the most recent version
• Example cvs update -r 1.3 functions.c will go
  back to version 1.3 of functions.c
• But beware this creates a sticky tag that may
  bite you later

30
Sticky Tags

• Sticky tags are CVS attributes that stick to a
  file across commit/update cycles
• Most common sticky tag is revision number
• After cvs update -r revision filename, future
  updates of filename will still update it to
  version revision, not the current version
• To undo cvs update -A filename
• Note Regular tags (cvs tag) are sticky, too

31
Branches

• Sometimes, development needs to go down two
  different paths simultaneously (e.g.,
  experimental features)
• Tag the project, but make the tag a branch tag
  using cvs tag -b
• Tags are sticky CVS will know to commit to the
  branch instead of to the main development line

32
Branches (concl.)

• Branches can be merged or brought into sync
• Branches can cause some headaches if not used
  properly
• Its often easier to develop a branch in a
  separate working directory from your main working
  directory

33
Advanced Topics

• Editing repository files or CVS-directory
  directly (text editor, format is simple)
• Writing scripts that run every time something
  happens to the repository (commit, update, etc.)
• Unix, Windows, Cygwin, end-of-line compatibility

34
Some Things Dont Work (Well)

• Deleting files works but with artifacts
• Renaming files not easy but possible
• Renaming directories good luck!
• Version numbers can be confusing (1.1 vs.
  1.1.1.1)
• Cant use CVS for access control (except maybe
  via repository scripts)

35
Other Version Control Solutions

• subversions (GNU)
• RCS (GNU)older, not as flexible
• SCCS (vendors), PVCS
• Clearcase, MS Visual SourceSafe
• Try http//www.gnu.org/directory/
• Look for CVS add-ons (e.g. GUIs) at
  http//www.cvshome.org/
