WSI Overview Presentation

1
Enabling Interoperable Secure Web Services
Rich Salz, DataPower Technology July 22, 2004
2
THE CONTEXT

• Businesses need to innovate at an ever increasing
  pace
• Success requires broad interoperability
• Within an enterprise
• Between business partners
• Across a heterogeneous set of platforms,
  applications and programming languages
• Internet technologies are assumed,
  interoperability is required

3
THE CONTEXT

• The shift to Web services is underway
• An Internet-native distributed computing model
  based on XML standards has emerged
• Early implementations are solving problems today
  and generating new requirements
• The Web services standards stack is increasing in
  size and complexity to meet these requirements
• The fundamental characteristic of Web services is
  interoperability

4
WHAT IS NEEDED?

• Guidance
• A common definition for Web services
• Implementation guidance and support for Web
  services adoption
• Interoperability
• Across platforms, applications, and languages
• Consistent, reliable interoperability between Web
  services technologies from multiple vendors
• A standards integrator to help Web services
  advance in a structured, coherent manner

5
ABOUT WS-I

• An open industry effort chartered to promote Web
  Services interoperability across platforms,
  applications and programming languages.
• A standards integrator to help Web services
  advance in a structured, coherent manner
• Approximately 150 member organizations
• 70 vendors, 30 end-user organizations
• 80 North America with active worldwide
  membership

6
WS-I GOALS

• Achieve Web services interoperability
• Integrate specifications
• Promote consistent implementations
• Provide a visible representation of conformance
• Accelerate Web services deployment
• Offer implementation guidance and best practices
• Deliver tools and sample applications
• Provide a implementers forum where developers
  can collaborate
• Encourage Web services adoption
• Build industry consensus to reduce early adopter
  risks
• Provide a forum for end users to communicate
  requirements
• Raise awareness of customer business requirements

7
WORKING GROUPS

• Basic Profile
• Addresses the core set of specifications (e.g.,
  SOAP, WSDL, UDDI, attachments, etc.) that provide
  the foundation for Web services
• Basic Security Profile (New!)
• Addresses transport security, SOAP messaging
  security, and other security considerations
• Requirements Gathering
• Captures business requirements to drive future
  profile selection
• Sample Applications
• Illustrate best practices for implementations on
  multiple vendor platforms
• Testing Tools and Materials
• Develops self-administered tests to very
  conformance with WS-I profiles

8
WS-I, STANDARDS AND INDUSTRY
Standards Specifications
Requirements
Implementation Guidance
Requirements
Businesses, Industry Consortia, Developers, End
Users
9
MILESTONES

• Basic Profile 1.0 Package
• Delivered Basic Profile 1.0, and associated
  sample applications and test tools as Final
  Material
• More than 200 interoperability issues resolved in
  Basic Profile 1.0
• Conventions around messaging, description and
  discovery
• Vendors are incorporating the Basic Profile 1.0
  into products and services
• End-users are requiring conformance

10
CURRENT WORK BASIC PROFILES

• Basic Profile 1.1
• Derived from the Basic Profile 1.0 incorporating
  any errata to date and separating out
  requirements related to the serialization of
  envelopes and their representation in messages
• Attachments Profile 1.0
• Complements Basic Profile 1.1 to add support for
  interoperable SOAP messages with attachments
• Simple SOAP Binding Profile 1.0
• Derived from those Basic Profile 1.0 requirements
  related to the serialization of the envelope and
  its representation in the message, incorporating
  any errata to date
• Board Approval Drafts of these profiles were
  delivered June 3

11
CURRENT WORK BASIC SECURITY PROFILE

• Security Scenarios
• Identifies security challenges and threats in
  building interoperable Web services and
  countermeasures for these risks
• Basic Security Profile
• Addresses transport security, SOAP messaging
  security and other security considerations
• References existing specifications used to
  provide security, including the OASIS Web
  Services Security 1.0 specification
• HTTP over TLS
• SOAP with Attachments
• WS-Security with Username and X.509 token
  profiles
• SAML Token Profile and REL (XRML) Token Profile
  are being considered

12
SECURITY SCENARIOS WORKING DRAFT

• Addresses
• Security Challenges
• Threats
• Security Solutions and Mechanisms
• Scenarios
• February, 2004 draft for public comment
• http//ws-i.org/Profiles/BasicSecurity/2004-02/Sec
  urityScenarios-0.15-WGD.pdf
• Final Security Scenarios expected in August, 2004

13
SECURITY CHALLENGES

• Peer Identification and Authentication
• Data Origin Identification and Authentication
• Data Integrity
• Transport Data Integrity
• SOAP Message Integrity
• Data Confidentiality
• Transport Data Confidentiality
• SOAP Message Confidentiality
• Message Uniqueness
• Out of Scope
• Credentials Issuance

14
THREATS

• Message alteration
• Attachment alteration
• Confidentiality
• Falsified messages
• Man in the middle
• Principal spoofing
• Repudiation
• Forged claims
• Replay of message parts
• Replay
• Denial of service - amplifier

15
SECURITY SOLUTIONS AND MECHANISMS

• Integrity, confidentiality, authentication,
  attributes
• Transport layer (HTTP/HTTPS)
• HTTP and SSL/TLS mechanisms
• Message layer
• WSS mechanisms
• Securing SOAP with Attachments
• Combinations
• Large number of theoretically possible
  combinations
• Identified nine believed to be of practical
  utility
• Security considerations
• Properties, threats addressed, limitations

16
SCENARIOS

• Generic requirements
• Peer authentication
• Integrity
• Confidentiality
• Origin authentication
• Scenario descriptions
• One-way
• Synchronous request / response
• Basic callback
• Others?

17
WS-I BASIC SECURITY PROFILE (BSP) 1.0

• Methodology
• Reviewed WSS Documents (WSS core, username,
  X.509)
• Comments to WSS TC
• Generated potential profiling points (captured as
  issues)
• Reviewed underlying documents
• IETF RFCs covering TLS
• XML Signature, XML Encryption
• Identified 90 potential profiling points by
  looking for anything other than MUST (e.g.
  options in specifications)
• Many have since been dropped
• First public Working Draft published May, 2004
• http//ws-i.org/Profiles/BasicSecurityProfile-1.0-
  2004-05-12.html
• Final BSP expected in September, 2004

18
BSP 1.0 QUESTIONS AND ANSWERS

• Cover SSL?
• Yes, mentioned in WS-I Basic Profile 1.0
• Address SOAP intermediaries?
• Yes, must be considered because of security
  implications
• What will document look like?
• Identify constraints by category, as in Basic
  Profile
• If and how to handle security considerations?
• Added security considerations section even though
  it is not testable
• One profile or several?
• BSP 1.0 will be one document
• Subsequent token profiles can be published
  separately
• How to secure Attachment Profile 1.0?
• Decided to use WSS and to request OASIS TC to do
  this work

19
EXAMPLE REQUIREMENT

• 4. Transport Layer Security
• This section of the Profile incorporates the
  following specifications by reference, and
  defines extensibility points within them
• HTTP over TLS Extensibility points
• E0001 - Ciphersuites - Additional ciphersuites
  may be specified.
• 4.1 SSL and TLS
• The following specifications (or sections
  thereof) are referred to in this section of the
  Profile
• HTTP over TLS Section 2.2.1
• SSL and TLS are both used as underlying
  protocols for HTTP/S. This profile places the
  following constraints on those protocols
• 4.1.1 Use of SSL 2.0
• SSL 2.0 has known security issues and all
  current implementations of HTTP/S support more
  recent protocols. Therefore this profile
  prohibits use of SSL 2.0.
• R2001 A SENDER MUST NOT use SSL 2.0 as the
  underlying protocol for HTTP/S
• R2002 A RECEIVER MUST NOT use SSL 2.0 as the
  underlying protocol for
  HTTP/S

20
OTHER BSP 1.0 DELIVERABLES
sample applications
scenarios and sample applications
web services basic security profile
testing tools
other test materials
testing tools and materials
21
TESTING AND DEMONSTRATING BSP 1.0

• How to test Basic Security Profile 1.0?
• Basic Profile 1.0 testing tools used a man in the
  middle testing strategy
• Will this work for BSP 1.0 since one of its
  objectives is to stop man in the middle attacks?
• What level does the testing take place at?
• Highest level message syntax?
• After parts of the message have been decrypted?
• BSP sample applications and usage scenarios
• Based on sample application for Basic Profile 1.0
  adding security aspects

22
FUTURE WORK PLANS

• Additional token profiles
• Candidates include Kerberos, REL (XRML), SAML
• Depends on progress by OASIS TC
• Final material ETA November, 2004

23
JOIN WS-I TODAY

• Join
• Join a community of more than 150 industry
  leaders and visionaries with a shared vision for
  Web services interoperability
• Foster commitment across the community
• Participate
• Encourage customer participation and buy-in
• Commit to an aggressive schedule for delivering
  resources to aid Web services implementations
• Conform
• Ensure implementations conform with WS-I profiles
• Promote conformance to customers and partners

24
QUESTIONS

• Today
• Later
• E-mail rsalz_at_datapower.com
• Comments on BSP documents
• E-mail wsi_secprofile_comment_at_lists.ws-i.org
• Security Scenarios published February, 2004
• http//ws-i.org/Profiles/BasicSecurity/2004-02/Sec
  urityScenarios-0.15-WGD.pdf
• BSP 1.0 WD published May, 2004
• http//ws-i.org/Profiles/BasicSecurityProfile-1.0-
  2004-05-12.html
• Thanks to Paul Cotton, chair of WS-I Basic
  Security Profile Working Group for much of the
  material in this presentation!
