Radiation Safety Aspects of the Linear Collider

1
Radiation Safety Aspects of the Linear Collider
B. Racky, A. Leuschner, N. Tesch Radiation
Protection Group
TeV Superconducting Linear Accelerator
2
Radiation Safety Aspects of TESLA

• Overview TESLA
• Locations of beam loss
• Protection of the public
• exposure limits
• exposure paths

Protection of the staff
3
Top view , route on map
4
Some data of TESLA
5
Side view with earth cover
6
Main locations of beam loss
7
Calculations of doses and activities
Neutron and Gamma fields

• MC code FLUKA99
• fluence/ dose conversion ICRP

Muon fields

• analytical model
• (1- dimenional transport)

Activity concentrations

• MC code FLUKA99
• (option resnuclei)

8
Protection of the Public(local population and
environment)

• Stray radiation fields
• Radioactivity of released tunnel air
• Radioactivity of drinking water
• Activation of soil

9
Protection of the Public
planning goal
limit
Sum of all exposures Release of radioactive
air Activation of groundwater Activation of
soil
1 mSv/a
0,1 mSv/a
0,03 mSv/a
0,3 mSv/a
0,03 mSv/a
0,3 mSv/a ?
lt natural activity
?
10
Stray radiation fields due to neutrons
11
Stray radiation fields due to myons
12
Release of radioactive air
Produced Nuclei
Main air activation zone in the tunnel, near
IP 100 kW beam loss (collimators)
13
Release of radioactive air
limits
For a mixture of nuclei
ratio lt 0.1
planning goal
14
Release of radioactive air
Overview ventilation system S. II-251 TDR
Should it be operated as a closed or open system?
15
Release of radioactive air
Tunnel ventilation rate 0,8 m/s, 6104
m3/h length of collimator section 100 m
volume of activation zone 2000 m3 distance to
exhaust station 5 km delay time 1.4 h
data
Ventilation switched off during 1 month
operation, air blown out on each monthly
maintenance day
Closed system
Open system
Ventilation switched on during operation, air
blown out permanently
16
Release of radioactive air
Closed system
Sum of all ratios 0.0011 ltlt 1.0 and ltlt 0.1
17
Release of radioactive air
Open system
Sum of all ratios 0.26 lt 1.0 but gt 0.1
18
Release of radioactive air
A closed ventilation system leads to much smaller
release of radioactivity
Conclusions
Also an open system would fulfill the legal
requirements
Compromise ? open system with bypassed release
stations closed to loss points
19
Activation of soil and ground water
in the vicinity of a main dump
wet soil (27 water)
concrete shielding (3 m)
dump
TESLA lumi run Operation time 5000 h (1
year) Energy 250 GeV power 12 MW

20
Activity concentration of wet soil
Most relevant nuclei
Sum of all activity concentrations
Bq/g
rings of 50 cm thickness
21
Activation of Soil and Groundwater
region of 50 cm around a main dump after 5000 h
of operation
3H 2.60 Bq/g 22Na 0.45 Bq/g
7Be ? Bq/g 22Na ? Bq/g
natural activity 0.3 -1 Bq/g
Dose, consuming 800 l/a 2.5 mSv (? 22Na)
22
Transport of ground water
Ground water flow (experts report) area
north dump south
dump descent 1m / 750m
1m/ 900m permeability 5 10-5 m/s
5 10-5 m/s filter velocity 6.7
10-8 m/s 5.6 10-8 m/s distance velocity
2.2 10-7 m/s 1.9 10-7 m/s distance
velocity 6.9 m/ year 6.0 m/ year
error about 80 ?
23
Transport of activated ground water
activation zone north dump 12 m south dump
18 m
At what distance is the activity concentration
so low, that drinking 800 l /a results in a
dose of 30 µSv/a ?
After activation
Distance calculations for the dominant nuclide
Na-22
24
Zones of activated ground water
5.0 10-6 42 0.3 2.0
10-6 230 3.6 2.2 10-7
78 11 1.0 10-7
42 13
5.0 10-6 280 1.8 3.0
10-6 340 3.6 1.9 10-7
76 13 1.0 10-7
44 14
25
Protection of the Staff

• accelerator operation
• stray radiation fields
• (shielding , interlocks)
• maintenance time
• residual radioactivity
• (choice of material, shielding)
• radioactive air
• (ventilation concept)

26
Protection of the Staff
Surveyed Areas
limit
27
Protection of the Staff
Controlled Areas
limit
local dose rates lt 3 mSv / h
Only temporary access
personal doses lt 20 mSv / a
planning goal
ALARA
28
Residual Radioactivity
Hot spots
29
Radioactivity of the tunnel air
30
Conclusions
