Deploying Wireless DSL Cost Effectively with Meshed ATM Architecture

1
Deploying Wireless DSL Cost Effectively with
Meshed ATM Architecture

• Frank W. Massa - Wireless, Inc.
• Broadband Wireless World Forum

2
Goals

• Review the broadband wireless access opportunity
• Explore the two basic wireless coverage models
• Discuss performance measures for wireless base
  stations
• Discuss system growth issues
• Compare ATM and IP as methods for delivering QoS
  and mixed services and for improving reliability
• Discuss backhaul requirements and propose a
  wireless backhaul model

3
The Opportunity
4
The Opportunity

• DSL Homes Passed estimated to be 30 - 50
• at 512 kbps or more
• 1 - 6 Mbps desired
• Even Covered Areas may not offer complete
  coverage
• Cable, Satellite services have comparable
  limitations

San Francisco Bay Area DSL coverage (green),
from DSL Reports http//dslreports.com/shownews/37
3
5
Spot or Cellular Coverage?

• Spot Coverage requires only a single central base
  station
• Line of sight requirements
• Limits on range
• can be quite limited at high frequencies
• Obstruction limits
• no choice of serving base station
• Maximum usable bandwidth

Denver Area Coverage - Sprint Broadband Direct
(sm)http//www.sprintbroadband.com/availability/i
ndex.pl
6
Total Systems Solution
7
Wireless Total System Solution

• Wireless Broadband First Mile Access
• Wireless Transport, Backhaul and Switching
  Solutions
• Network Management Solution
• Megabit plus per second data rates for SOHO and
  residential markets
• Toll grade voice services (QoS)
• Integrated End-to-End solution

8
Total System Solution
9
Into the Core Network
Edge Switch
10
Total Solution Key Requirements

• Pt-Mp waveform
• Superior capacity in multi-cell deployment
• Superior range for given throughput
• Allows operation in any single (TDD) contiguous
  or FDD bands
• Advanced multipath mitigation
• High-order signal processing for excellent
  performance in non-LOS signal paths and areas
  with reflections and dense RF overlap
• Integrated Customer Premise Equipment
• Avoids expensive CPE installation
• Low - cost solution which includes antenna, RF,
  Telephony and Data
• Network architecture
• Allows QoS for voice and other low latency
  applications
• Efficient multiplexing and switching
• Ready integration with DSL-based network
  infrastructure

11
Key Features and Benefits (Cont)

• Efficient Multiple Access Control protocol
• True bandwidth-on-demand
• Demand assignment approach avoids inefficiencies
  of contention-based approaches
• High throughput maintained with heavy loading
• Throughput per user similar to xDSL
• Plain Old Telephony Service
• Support interfaces to industry leading DSL Voice
  Gateway providers
• Integrated access - data and voice in one CPE

12
Wireless RF Spectrum
13
Pt-Mp Frequencies (Below 6 GHz)

• License-Free
• 2.4 GHz ISM
• 5.3 GHz UNII
• 5.8 GHz UNII
• 5.8 GHz ISM

• License
• 700 MHz UHF
• PCS (1.9 GHz)
• MDS/MMDS (2.1/2.6)
• WCS (2.3 GHz)
• 3.5 GHz (3.4 - 4.2 GHz)
• ETSI
• ITU
• Industry Canada

14
FCC 700 MHz Channel Plan
15
FCC PCS Band
16
FCC WCS Band
17
MDS/MDS/ITFS
18
FCC UNII Band
19
PT-MP Techniques
20
Code Division Multiple Access
21
CDMA Spectral Efficiency
22
Time Division Duplex (TDD)
23
Frequency Division Duplex (FDD)
Up Stream and Down Stream - AP sectors transmit
and receive to remotes simultaneously - Requires
separate transmit and receive bands
24
Cellular Deployment

• Significant increase in system capacity
• Tradeoff per cell capacity
• TDMA or FDMA channels
• CDMA codes
• Cell size is a new deployment parameter

25
Burst Rate and User Capacity

• OPNET Heavy HTML Model
• Web browsing
• Email
• FTP
• DSL at 256 kbps downstream
• 1 user
• Wireless aggregated at 1.8 Mbps downstream
• 60 users

26
Download Rates
Download Performance vs. Number of Active Users
per Sector
1400
3.6 Mbps Sector
1200
1000
1 Mbps DSL
800
Average Per-User Download
1.8 Mbps Sector
Burst Rate (Kbps)
600
400
256 kbps DSL
200
0
0
20
40
60
80
100
Number of Active Users
27
Quality of Service

• Why QoS?
• Critical for public shared services
• Allows for different SLAs
• Support for mixed services
• Protocols
• ATM provides rich, mature set of QoS mechanisms
• Switching protocols just beginning to be
  implemented
• IP has emerging QoS mechanisms
• IP has mature routing protocols
• Importance of the MAC

28
Non-Line of Sight Range
Rappaport from "Measurements and Model for Radio
Path Loss and Penetration Loss In and Around
Homes and Trees at 5.85 GHz.", IEEE TRANS COMM, V
41, N 11, Nov. 1998.
29
Range vs. Capacity Balance

• Model based on 1.9 GHz, 10 MHz BW, radio design

Bandwidth Efficiency
30
Deployment
31
Neighborhood Deployment

• Small
• Entirely outdoor
• Mounted on existing structures
• Rooftops
• Power poles
• Light poles
• Modest coverage area
• Modest cost

32
Pt-MP Access Point

• Integrated package for low profile deployment
• Modularity supports single sector or sectorized
  deployment (Omni, 3-sector or 6-sector).
• Master and Slave Configurations
• Master includes Integrated switch functions and
  timing (GPS)
• Standard WAN interfaces for wireless backhaul
• Integral network management

33
Integrated Switching

• Multiplexing and switching functions
• Carrier class features with lower cost per port
• Switching fabric up to 622 Mb/s
• Designed for all-outdoor, full-temperature
  operation
• Small size and weight, low power consumption,
  hardened
• Implements mesh network
• Moving network intelligence into the local loop
• Route and equipment redundancy - all elements can
  be non-redundant
• QOS, traffic prioritization
• QOS Billing options (platinum/gold/silver SLA)
• Dynamic load balancing
• Opportunity for local caching of bandwidth
  intensive data

34
Outdoor CPE

• Outdoor antenna and RF connects to indoor IAD
  over existing twisted pair
• Indoor access not required for installation
• 10BaseT for data and RJ-11 for voice
• Requires LOS or Near - LOS

35
Outdoor CPE with Indoor IAD
Outdoor
Indoor

36
Indoor CPE

• Indoor desktop version
• Fully integrated access device, including antenna
  and RF front end
• Easy installation maximizes potential subscriber
  base
• 10BaseT for data and RJ-11 for voice
• For freq lt 3 GHz

37
Indoor CPE

38
Backhaul Options

• Wired
• Availability
• Recurring cost
• Time to deployment
• Licensed wireless
• Shorter time to deployment
• Spectrum availability
• Unlicensed wireless
• Shortest time to deployment
• No recourse for interference

39
Redundant Wireless Backhaul

• Ring or Mesh Architecture
• Provide multiple paths of egress
• Self-healing nature
• Provides load balancing in network
• Can be designed for incremental cost over minimal
  star network
• Requires switching or routing at node points

40
Backhaul Network Supports Growth
High growth area
POP
POP
41
Meshed Backhaul in Action

• Mesh laid out for line-of-sight
• Connections may include doglegs for line-of sight

Point to Point RadioRelay Point Wireless Access
Point Switch
1 Mi.
USGS Photo Denver Suburb.
42
Wireless Relay

• Field trail element
• Two back-to-back radios
• Light pole mounted

43
Integrating the Pieces

• Voice and data traffic
• Integration with wired access methods

Backhaul Radios
Access Point
EdgeSwitch
Outdoor CPE
To PSTN
VoiceGateway
Class 5Switch
Hardened Switch
To Internet
IAD
SubscriberManagementSystem
Customer Premises
NSP Point of Presence
44
Conclusions

• Wireless broadband system engineering has
  multiple facets
• Coverage
• Capacity
• Integrated services with QOS
• Costs
• A small cell, low footprint design is achievable
• Wireless backhaul
• Self healing mesh networks
• Rapid system deployment

45
