Ant

1
Ant Another Neat Tool

• Representation and Management of Data on the
  Internet

2
What is Ant?

• A cross-platform build tool (like make)
• A scripting framework
• Based on industry standards (Java and XML)
• Open Source (development coordinated by the
  Apache Jakarta project)

3
Make versus Ant

• Make OS dependent uses shell commands
• Ant OS independent uses Java
• Make Terrible syntax (infamous tabbing problem)
• Ant XML based syntax
• Make state dependencies between program files
• Ant state dependencies between tasks (not
  between program files)

4
Why Ant?

• Platform independent
• Requires only a JDK 1.1 or later JVM
• Easy to use
• Built-in tasks accomplish all typical build
  functions
• User contributed tasks cover most other needs
• Easy to extend
• Create a new task by writing some Java code

5
What can we do with Ant?

• Can be used to
• compile java programs
• create javadoc documentation
• create jar, zip, tar, war files
• delete and copy files
• send mail
• validate XML files
• etc. (anything you want)

6
Structure of Ant

• Project
• a top level collection of targets
• Property
• an Ant variable
• Target
• a collection of tasks executed to achieve a
  particular purpose (a goal)
• Task
• a unit of Ant execution (a step)

7
How Does Ant Work?

• Each Project will have a build file (build.xml)
• Each build file will contain one or more Targets
• The Target to be executed
• Is either explicitly selected on the command line
• Or a project default Target is executed
• Each Target is executed only once
• Each Target will contain one or more Tasks
• Some Tasks are executed conditionally
• Tasks are implemented as Java classes

8
Using Ant

• Buildfiles are written in XML
• Each buildfile contains a single project
• Projects can have 3 attributes
• name name of project (optional)
• default default target to use (required)
• basedir base directory for paths (optional)

9
A BuildFile Project Element

• ltproject nameMyProject defaultcompilegt
• lt!- properties and targets will come here...--gt
• lt/projectgt

XML Element
Comment
10
Properties

• Properties (similar to global values) are defined
  as follows
• ltproperty namepropName valuepropVal /gt
• Note Properties are XML elements without
  contents, therefore we use /gt
• A property propName can be referred to later
  using the syntax propName
• You can define any properties you want

11
A BuildFile Adding Properties

• ltproject nameMyProject defaultcompilegt
• ltproperty namebuildDir valuebuild/gt
• ltproperty namesrcDir value./gt
• lt!- targets will come here...--gt
• lt/projectgt

12
Targets

• Targets have the attributes
• name name of the target (required)
• depends comma separated list of targets on which
  the target depends (optional)
• if, unless, description details omitted (read
  about it in the Ant documentation)
• Targets contain tasks as subelements. These tasks
  define the actions performed when the target is
  executed.

13
A BuildFile Adding a Target

• ltproject nameMyProject defaultcompilegt
• ltproperty name"buildDir" value"build"/gt
• ltproperty namesrcDir" value."/gt
• lttarget name"compile"gt
• ltjavac srcdir"src" destdir"build"/gt
  lt/targetgt
• lt/projectgt

A Task
We call also have written ltjavac srcdir.
destdirbuild"/gt
14
A More Complex Example

• Note The tstamp task ( lttstamp/gt ) defines the
  properties DSTAMP (with format yyyymmdd),
  TSTAMP (with format hhmm) and TODAY (with
  format month day year)

15

• ltproject name"MyProject" default"dist"
  basedir"."gt
• lt!-- set global properties for this build --gt
• ltproperty name"src" value"."/gt
• ltproperty name"build" value"build"/gt
• ltproperty name"dist" value"dist"/gt
• lttarget name"init"gt
• lt!-- Create the time stamp --gt
• lttstamp/gt
• lt!-- Create the build directory structure
  used by compile --gt
• ltmkdir dir"build"/gt
• lt/targetgt

16

• lttarget name"compile" depends"init"gt
• lt!-- Compile java code from src into
  build --gt
• ltjavac srcdir"src" destdir"build"/gt
• lt/targetgt
• lttarget name"dist" depends"compile"gt
• lt!-- Create the distribution directory --gt
• ltmkdir dir"dist/lib"/gt
• lt!-- Put everything in build into the jar
  file
• MyProject-DSTAMP.jar file --gt
• ltjar jarfile"dist/lib/MyProject-DSTAMP.ja
  r"
• basedir"build"/gt
• lt/targetgt
• lttarget name"clean"gt
• lt!-- Delete the build and dist directory
  trees --gt
• ltdelete dir"build"/gt
• ltdelete dir"dist"/gt
• lt/targetgt

17
More about Depends

• Ant tries to execute the targets in depends
  from left to right.
• However, a target may be executed early when
  another one depends on it.

18
Example 1
lttarget name"A"/gt lttarget name"B"
depends"A"/gt lttarget name"C" depends"B"/gt
lttarget name"D" depends"C,B,A"/gt

• Execute ant D
• In what order will the tasks be performed?

Try D
Try C
Try B
Try A

• Note B is executed before C!
• Note B is executed once!

Do D
Do C
Do B
Do A
19
Example 2
lttarget name"A dependsB/gt lttarget name"B"
depends"A"/gt

• Execute ant A
• In what order will the tasks be performed?
• The build fails, ant reacts with
• Circular dependancy a lt- b lt- a

20
Running Ant

• Type ant
• Ant looks for the file build.xml, and performs
  the default task specified there.
• You can use the buildfile option to specify a
  different buildfile
• You can specify a different task to be performed
• You can define parameters using the D option

21
Examples

• Run Ant using build.xml on the default target
• ant
• Run Ant using the test.xml file on the default
  target
• ant -buildfile test.xml
• Run Ant using the test.xml file on a target
  called dist
• ant -buildfile test.xml dist

22
Examples (cont.)

• Run Ant using the test.xml file on a target
  called dist, setting the build property to the
  value build/classes
•

• ant -buildfile test.xml -Dbuildbuild/classes dist

23
References

• To learn more about Ant
• Look at the documentation on the web. (reference
  from the table of lectures schedule)
• Pay attention to the section Built-in Tasks.
  For each task, the format (e.g., name and
  attributes) appears.
