Title: Building Secure Applications, Security Models, and Web Security


1
Building Secure Applications, Security Models,
and Web Security
  • Lesson 26

2
Building Secure Systems
  • Vulnerabilities frequently found in operating
    systems and application programs.
  • Problem is not new, weve always had problems
    with the security of our systems and flaws in the
    operating system.
  • Is it really that hard to build a secure system?

3
Why systems are not secure
  • Security is fundamentally difficult.
  • What is adequate for most functions isnt for
    security
  • good enough doesnt apply for security
  • Security is often (usually) an afterthought.
  • Security is viewed as an impediment.
  • False solutions impede progress
  • industry subject to fads -- quick fixes cause
    us to become complacent.
  • Technology is oversold -- the problem is often
    with the people not the computers.
  • Errors are made and not found (inadequate
    testing, poor programming techniques).

4
Example of poor programming/errors
  • Buffer Overflows
  • result of poor programming practice
  • use of functions such as gets and strcpy
  • these dont check input for boundaries
  • may allow individual to gain root or admin access

5
Sample Buffer Overflow Example
include ltstdio.hgt include ltstring.hgt void
func(char p) char stack_temp20
strcpy(stack_temp, p) printf(stack_temp)
int main(int argc, char argv) func(I AM
MORE THAN TWENTY CHARACTERS LONG!) return
0
6
Exploits
  • Buffer Overflows
  • fingerd, statd, talkd,
  • result of poor programming practice
  • Shell Escapes
  • special character in input string causes escape
    to shell

7
Cover your tracks
  • Adjust log files
  • RootKit
  • contains sniffer, login program that disables
    logging, hacker versions of several system
    utilities (e.g. ps)
  • Looping
  • launch attack from another system youve
    compromised thus hiding trail
  • greatly increases complexity of tracking

8
Security Kernel
  • The HW and SW that implements the reference
    monitor
  • All accesses that subjects make to objects are
    authorized on information in an access control
    database.
  • The specific checks that are made and all
    modifications to the access control database are
    controlled by the reference monitor in accordance
    with the established security policy.

Audit File
Reference Monitor
Subjects
Objects
Access Control Database
9
Three Principles for Security Kernels
  • Completeness it must be impossible to bypass.
  • All access to information must be mediated by the
    reference monitor.
  • Isolation it must be tamperproof
  • The OS and the reference monitor should protect
    themselves from modification.
  • Verifiability it must be shown to be properly
    implemented.
  • Good software engineering practices.
  • Simplicity of function in the kernel.
  • Minimize the size of the kernel.

10
Security Models -- principles
  • Identity can each user, program, object, and
    resource be uniquely identified?
  • Accountability can users be held accountable
    for their actions?
  • Monitoring is a record maintained of users
    actions?
  • Authorization do rules exist to govern which
    entities may access which objects?
  • Least privilege are users restricted to the
    minimal set of resources needed to perform their
    job?
  • Separation are the actions of entities
    prevented from interfering or colluding with the
    actions of other entities?
  • Redundancy are copies of hardware, software,
    and data components maintained to ensure
    consistency, accuracy, and timeliness of results?

11
Security Models Bell La Padula
  • Model used in the Orange Book, Traditional
    approach/concern for the military.
  • Particular emphasis is on preventing unauthorized
    disclosure of information.
  • Simple Security Condition
  • allows a subject read access to an object only if
    the security level of the subject dominates the
    security level of the object.
  • -Property
  • allows a subject write access to an object only
    if the security level of the subject is dominated
    by the security level of the object. Also known
    as the Confinement Property.
  • No Read Up/No Write Down

12
Security Models Biba
  • Supports 5 different integrity principles
  • Low-Water Mark Policy the integrity level of a
    subject immediately following an observed access
    to an object is set to be the lower of the
    integrity levels for the subject and the object.
  • Low-Water Mark Policy for Objects similar to
    previous except works on objects.
  • Low-Water Mark Integrity Audit Policy
    introduces concept of corruption level to measure
    possible corruption of data, corruption level set
    to lowest integrity level of subjects and
    objects.
  • Ring Policy enforces a strict, unmodifiable
    integrity level for the life of subjects and
    objects (you cant modify files of higher
    classification and you cant execute programs of
    a higher classification level).
  • Strict Integrity Policy Includes the previous
    principle (ring policy) and adds another
    stipulation, a subject cant observe an object
    with a higher classification level.

13
Security Models Clark-Wilson
  • Military security model is focused on
    unauthorized disclosure but in some environments
    disclosure is not as important as modification
    (confidentiality vs integrity).
  • For Clark-Wilson, integrity is the focus.
  • Goal is to insure that no user can modify data in
    a manner that would result in the loss or
    corruption of assets.
  • 2 mechanisms used to achieve goal
  • Well-formed transactions data can only be
    modified in very constrained ways.
  • Separation of Duty Separates operations into
    parts and requires each part be performed by a
    different subject.

14
Application Security The Goal
  • define, design, deliver, and operate application
    systems possessing adequate and appropriate
    security and internal controls
  • Application systems are seen as the sum of
    hardware, software, data, communications, and
    other technologies working together to produce
    some product or service in direct fulfillment of
    the organizations business goals.
  • The challenge for the security official is to
    use these principles to promote the creation of a
    developmental environment where future
    application systems can be built possessing
    adequate and appropriate controls.
  • From Computer Security Handbook, 3ed

15
Controls required for trust in an application
system
The application system is viewed as nested within
other technical Systems since it will depend on
their utilities and will rely on their Integrity
features to create a reliable and trusted
environment.
Physical Security
Legal Protections
Network/ Communications Database Manag
ement
  • Security Controls
  • Edits
  • -Correction Routines
  • -Data Validation
  • -Data Views
  • -Permissions
  • -Passwords/access
  • -File Integrity
  • Audit trail
  • -Backup/retention
  • -Reconciliation
  • -Audit/Security
  • -Line control
  • -Encryption

Quality Attributes -Correctness -Reliability -Int
egrity -Usability -Confidentiality
Host/ Distributed Processors
Application System
From Computer Security Handbook 3ed
Procedural Security
Personnel Security
Controls also include interaction with external
elements.
16
Desired Quality Attributes
  • Correctness The degree to which system outputs
    satisfy the accuracy requirements of the business
    activity being supported.
  • Reliability The degree to which the system
    meets the business requirements for operational
    up time.
  • Integrity A measure of completeness and
    soundness of design and construction. A system
    that has integrity can be trusted by the user.
  • Usability A measure of being fit for use by
    the representative employee in the actual
    workplace.
  • Confidentiality A measure of privacy or secrecy
    that is required by nature of the information
    involved or the sensitivity of the business
    process.

17
Security and Internal Controls
  • Edits Edits are defined checks and controls
    that ensure accuracy of input data. The
    sufficiency of edits and their use during the
    business process is based on the stringency of
    the quality attribute metrics. The more severe
    the metric, the more important the edits.
  • Correction Routines Software and/or manual
    routines invoked to correct errors and omissions
    discovered by an edit.
  • Data validation Software and/or manual routines
    to check the accuracy and appropriateness of data
    before entry to a system or database.

18
  • Data Views Subset access to a total data
    collection based on predetermined need of an
    employee or class of employees for the data in
    performance of their duties.
  • Permissions Actions that a user is permitted to
    take once access has been granted to a store of
    data. These permissions may be to READ, WRITE,
    APPEND, DELETE, EXECUTE, or any combination based
    on job requirements.
  • Passwords for Access Access to systems, data,
    and the granting of permitted actions is based on
    recognition by the security software of a unique
    identification code. Passwords must be kept
    secure.
  • File Integrity Routines Software housekeeping
    routines for maintaining the trustworthiness of
    data in a database. The more severe the accuracy
    requirements, the more stringent these routines
    and the more often they should be run.

19
  • Audit Trails Recordings of three types of
    processing activities (1) logs to aid in the
    reconstruction of transactions (2) logs to meet
    the requirements of the audit staff and (3)
    logs recording security accesses, activities, and
    suspected violations.
  • Backup and Retention Policies and procedures
    for ensuring the ability to reconstruct files,
    software, and business transactions in the event
    of a processing interruption or to meet a legal
    requirement.
  • Reconciliation Routines Procedures to bring
    about a settlement or adjustment between
    differing information sources, databases, or
    reports.

20
  • Audit/Security Reports Suspected violation or
    incident reports generated for the purpose of
    adjusting controls and managing system resources.
  • Line Control Physical location and/or placement
    of controls on communication lines to prevent
    unauthorized access to the line.
  • Encryption Encryption is a means of maintaining
    secure data in an insecure environment.

21
Past Development Problems
  • General Accounting Office reports from 60s,
    70s, and 80s described a general lack of
    security in application systems. Reports
    repeatedly found
  • Lack of internal controls in application
    systems, making them subject to unauthorized
    manipulation.
  • Lack of software quality and insufficient
    testing.
  • Systems not properly documented, making it
    extremely difficult to reconstruct processing or
    to make necessary changes over the life of the
    application.
  • Lack of access control on computer processes and
    data files.

22
WHY? Well, at the time
  • Limiting access through physical means and
    simple password schemes was seen as the principle
    control mechanism required in the mainframe and
    nonintelligent terminal environment.
  • Computers were physically limited in the amount
    of available computing resources that could be
    dedicated to security and internal control
    functions.
  • Since compelling business arguments for controls
    were difficult to make, top management was
    generally ambivalent. Controls sounded good, but
    they could not inconvenience anyone, or slow
    anything down, or require significant funding.

23
Model Framework for Management Control over
Automated Information Systems
  • 6 phases
  • Initiation whats the problem to be solved?
  • Definition Develop functional statement of
    users need
  • System Design Detailed specifications
  • Programming and Training Code developed and
    tested, training starts
  • Evaluation and Acceptance Field testing, user
    accepts
  • Installation and Operation Full implementation
    in field
  • Note how this is really describing software
    engineering.
  • Development of secure systems really relies on
    sound SE practices.

24
Application Testing
  • Traditional application testing focuses on issues
    such as
  • data validation, boundary testing
  • load and stress testing, and
  • functionality testing.
  • For security testing we also want to check that
  • a user cannot gain unintended access to data
    belonging to other users
  • a user must not be able to break the application
    and cause a temporary or permanent disruption to
    the service
  • security features work as designed/intended
  • Web applications prime candidates for testing

25
Other tests to consider
  • protocol sniffing and replaying attacks
  • buffer overflow
  • Hidden Manipulation - Changing hidden field
    values
  • Cookie Poisoning - Altering the content of a
    cookie
  • Backdoor and Debug Options - Trying debug syntax
    on URLs
  • Third Party Mis-Configuration - Attempting Web
    server default configuration vulnerabilities
  • Known Vulnerabilities - Trying all publicly know
    vulnerabilities
  • Cross Site Scripting - Entering executable
    commands into Web site buffers
  • Forceful Browsing - Accessing orphan scripts

26
SCADA systems
Supervisory control and data acquisition (SCADA)
is a system that allows an operator to monitor
and control processes that are distributed among
various remote sites. There are many processes
that use SCADA systems hydroelectric, water
distribution and treatment utilities, natural
gas, etc. SCADA systems allow remote sites to
communicate with a control facility and provide
the necessary data to control processes. For many
of its uses, SCADA provides an economic
advantage. As distance to remote sites increase
and difficulty to access increases, SCADA becomes
a better alternative to an operator or
repairmans visiting the site for adjustments and
inspections. Distance and remoteness are two
major factors for implementing SCADA systems
27
SCADA Elements
There are four major elements to a SCADA system
the operator, master terminal unit (MTU),
communications, and remote terminal unit (RTU).
Modem
Modem
RTU 1
RTU 2
Modem
OPERATOR HQ
Radio
Modem
MTU
Radio
Radio
Modem
Modem
RTU 3
RTU 4
28
Web Security
29
Web Defacement
30
Web Defacement -- Hactivism
31
Web Defacement Trends
32
Web Defacements some info
33
Web Defacement OS Stats for 10/2001
34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
Number of defacements by TLD
38
E-commerce
39
Threats at key points to E-commerce
40
A type of Social Engineering
ltscriptgt password prompt(Please enter your
dial-up password,) ltscriptgt
41
Finding well-known vulnerabilities
  • Automated Scripts
  • Phfscan.c
  • an example script that implemented an interface
    to a white-pages like service used to look up
    name and address information. User could,
    however, trick it to execute commands locally by
    escaping the script by using a newline
    character in the input.
  • Cgiscan.c
  • scans for a number of the older scripts such as
  • PHF - (see above)
  • count.cgi - buffer overflow, allow remote
    execution
  • test-cgi - list all files and directories in
    scripts directory (thus may be able to find
    other, more serious, vulnerabilities)
  • PHP - one vulnerability allowed you to view any
    file on systemalso a buffer overflow problem

42
Taking down a web site using only a
browser -from Hacking Exposed
  • Sample ColdFusion problem (problem is in how they
    handle their input validation for passwords)
  • Point your browser to the Administrator logon
    page of a typical ColdFusion server
  • Edit the HTML by using File Edit Page
  • Change the ACTION tag by prepending the server
    name/address to the URL
  • Change the HTML tag holding the password so the
    size and maxlength properties are in the
    1,000,000 range
  • Preview and save the HTML file
  • Generate close to 1,000,000 characters and input
    to password field.
  • Watch CPU utilization go to 100 (or if you make
    it 1,000,000,000 watch it die instantly)

43
(No Transcript)
44
(No Transcript)
45
SET
SET uses a system of locks and keys along with
certified account IDs for both consumers and
merchants. Then, through a unique process of
"encrypting" or scrambling the information
exchanged between the shopper and the online
store, SET ensures a payment process that is
convenient, private and most of all
secure. fromhttp//www.moneymuseum.com/standard_
english/raeume/geld_machen/bank/praxis/ecommerce/e
infuehrung/set/set.html
46
Secure Electronic Transaction (SET)
  • Emerging standard for secure credit card payments
    over the Internet.
  • Industry backed standard (created by MasterCard
    and VISA)
  • Transaction can either be web or email
  • Specifies the mechanisms but not the specific
    implementation
  • Specifies the following security assurances be
    provided
  • Confidentiality
  • Data Integrity
  • Client authentication
  • Merchant authentication

47
What does SET support
  • Currently only supports credit card transactions.
  • Does not support debit card payments
  • Does not support stored-value payment systems.

48
Stored-account payment system
  • Stored-account payment system
  • Modeled after existing electronic payment
    systems such as credit and debit cards in which a
    corresponding account of credit (or deposit) is
    maintained.
  • The money always resides in a bank account.
  • Stored-value payment system
  • Use bearer certificates much like hard cash.
  • The bearer certificate resides within the
    personal computers or smart cards and is
    transferred between the parties, as when cash
    changes hands.
  • Value placed directly on hardware token.
Write a Comment
User Comments (0)
About PowerShow.com
