Monitors

1
Monitors
2
Semaphores unstructured

• Semaphores are the gotos of concurrent
  programming
• Why?
• Can we do better?

3
Bounded buffer (4.9)
proctype Producer( ) byte I 0 byte
Local_Count 0 loop Produce( I )
if_then( Local_Count N )
WaitSemaphore( Not_Full ) end_if_then
B In_Ptr I WaitSemaphore( S )
Count Local_Count Count
SignalSemaphore( S ) if_then( Local_Count
1 ) SignalSemaphore( Not_Empty )
end_if_then In_Ptr ( In_Ptr 1 ) N
end_loop

• Where do the calls to Signal and Wait go?
• Not_Full Not_Empty are a team, yet they are
  used all over the place

4
Idea

• An operating system monitors the use of the
  resources with HW support
• Priorities
• interrupt enable/disable
• Generalise this with SW only
• Provide one monitor for one specific purpose
• Encapsulate the resources and operations

Resources Count, B, In_Ptr, Out_Ptr
5
Bounded buffer
proctype Producer( ) byte I loop
Produce( I ) Append( I )
end_loop proctype Consumer( ) byte X
loop Take( X ) end_loop
Take
Append
Consumer process
Producer process
6
Mutex and synchronisation

• Semaphore
• Mutex S
• Synchronisation Not_Empty, Not_Full

• Monitor
• Automatic
• Condition variables Not_Empty, Not_Full

7
Class for data and operations
DeclareMonitor( Producer_Consumer ) byte
BN 0 byte In_Ptr 0 byte Out_Ptr 0
byte Count 0 DeclareCondition(
Not_Empty ) DeclareCondition( Not_Full )
inline Append ( I ) inline Take( X )
/ End Monitor Producer_Consumer /
Encapsulation
Synchronisation
Interface
8
Take Append
Check out the errata
inline Append ( I ) EnterMonitor
if_then( Count N ) WaitCondition(
Not_Full ) end_if_then B In_Ptr
I In_Ptr ( In_Ptr 1 ) N
Count SignalCondition( Not_Empty )
LeaveMonitor
inline Take( I ) EnterMonitor
if_then( Count 0 ) WaitCondition(
Not_Empty ) end_if_then I B
Out_Ptr Out_Ptr ( Out_Ptr 1 ) N
Count-- SignalCondition( Not_Full
) LeaveMonitor
9
SPIN demo

• See fig5_1.prom, for.h
• Simulate
• Data vales, Message Sequence Chart
• Check Safety
• Deadlock, assert
• Check Liveness

10
Condition variables (1)

• Wait( C )
• Suspend calling process on a FIFO queue
  associated with C leave the monitor
• Signal( C )
• If the queue for C is non empty, run the process
  at the head of the queue
• Non_Empty( C)
• Return true if the queue for C is non empty

P1 signals P2 who is in and who is out?
11
Immediate Resumption Requirement
Signal and leave, and reschedule the woken
process
Consumer1
Consumer2
inline Append ( I ) EnterMonitor
if_then( Count N ) WaitCondition(
Not_Full ) end_if_then B In_Ptr
I In_Ptr ( In_Ptr 1 ) N
Count SignalCondition( Not_Empty )
LeaveMonitor
inline Take( I ) EnterMonitor
if_then( Count 0 ) WaitCondition(
Not_Empty ) end_if_then I B
Out_Ptr Out_Ptr ( Out_Ptr 1 ) N
Count-- SignalCondition( Not_Full
) LeaveMonitor
Producer
12
Condition variables (2)

• A condition variable C is memoryless, there is no
  counter associated with C
• A signal on an empty queue does nothing
• If you want to know how many processes are in the
  queue, maintain a separate counter

13
Emulating semaphores
Semaphore_Wait ? WaitSemaphore ? WaitCondition
inline Semaphore_Wait () EnterMonitor
if_then( S 0 ) WaitCondition(
Not_Zero ) end_if_then S--
LeaveMonitor inline Semaphore_Signal ()
EnterMonitor S SignalCondition(
Not_Zero ) LeaveMonitor
What type of semaphore do we have here?

• Monitor variable holds semaphore value S
• Condition variable for synchronisation
• Semaphore invariant
• S 0
• S S0 Signals - Completed Waits
• Proof by induction

Check out the errata
14
SPIN demo

• See fig5_3.prom, monitor.h, critical.h
• Simulate
• Data vales, Message Sequence Chart
• Check Safety
• Deadlock, assert
• Check Liveness

15
Monitor emulation

• See monitor.h, gensem.h
• Semaphore to guarantee mutex
• One semaphore per condition variable
• Immediate resumption

16
Readers Writers

• Readers dont exclude other readers
• Writers exclude everyone else
• Readers gt 0 ? Writing
• Writing ? Readers 0

proctype Writer( ) loop Start_Write( )
... End_Write( ) end_loop
proctype Reader( ) loop Start_Read( )
... End_Read( ) end_loop
17
Monitor solution

• Count the number of readers
• Writing flag
• Ok_to_Read to control reading
• Ok_to_Write to control writing

18
SPIN demo

• See fig5_5.prom, monitor.h, for.h
• Simulate
• Data vales, Message Sequence Chart
• Check Safety
• Deadlock, assert
• Checking liveness takes long

19
Monitors in Java

• A Class with qualified declarations
• private for all variables
• synchronized for all methods
• No conditions but every object has
• public final void notifyAll()
• public final void wait() throws
  interruptedException

20
Conclusions

• A monitor is
• A synchronisation primitive
• High level, structured
• A decentralised version of the monolithic monitor
• A means to encapsulate data and operations
• Caveats
• Make sure conditions persist when (re)-entering
• Compiler support needed
• Same power as semaphores
• Variations possible
