Final PhD Defense

1
Final PhD Defense

• FINITE ELEMENT MODELING
• OF
• HEPATIC RADIO-FREQUENCY ABLATION

DIETER HAEMMERICH  UNIVERSITY OF
WISCONSIN-MADISON DEPARTMENT OF BIOMEDICAL
ENGINEERING
2
Introduction

• Hepatic tumors belong to the most common types of
  cancer
• Estimated annual mortality in US of 56,000
• Surgical resection is only possible less than 30
  of the cases
• The major clinically used alternative treatment
  methods with the US are RF ablation and cryo
  ablation
• Other ablative methods under investigation are
  microwave ablation, laser ablation, ethanol
  injection, ultrasound ablation

3
Cryo Ablation

• Cryo ablation uses cold (- 100C) to kill tumor
  tissue
• Open surgery is necessary (bleeding)
• Local recurrence rates may be lower than RF
  ablation
• Multiple probes can be used simultaneously
• Lesion is more predictable

4
Radio Frequency Ablation

• RF ablation was introduced in the 1990s for
  treatment of hepatic tumors
• RF (500 kHz) is used to heat tissue above 50C
  (-gt coagulation necrosis)
• Current is applied via catheter, that can be
  introduced transcutaneously (minimally invasive)
• Patient under local anesthesia and conscious
  sedation, or light general anesthesia
• Current travels between catheter and dispersive
  electrode (i.e. ground pad)

5
RF Ablation Catheter Types
6
Ablation Procedure
Probe insertion
Extension of prongs
RF current application
7
Parameters

• Treatment time is 10-30 minutes for a single
  application
• Multiple applications are usually necessary for
  treatment of a single tumor
• Current max. lesion sizes are 4 cm
• Applied power of 50 200 W
• Temperature Control (95 C) or Impedance Control
  is used to avoid charring

8
Shortcomings

• High local recurrence rates ( 40)
• Large vessels act as heat sinks, that may prevent
  destruction of tumor cells close to them
• Limited lesion size makes multiple applications
  necessary
• Insufficient imaging modalities

Multiple applications necessary to cover large
tumor
9
FEM models

• We have to solve the Bioheat Equation

J Current Density k Thermal Conductivity E
Electric Field hbl heat transfer coefficient
(determines perfusion) c Heat
Capacity ? Mass Density

• We divide the model (tissue, probe) into small
  tetrahedral elements differential equation -gt
  algebraic equations

10
Rita model 30 umbrella probe
11
1. Bipolar Ablation
12
Modified Catheter
13

• Effect due to more homogenous electric field is
  negligible

14
Results of in-vivo experiments

• Monopolar lesions had 3.9 1.8 cm3 volume (n7)
• Bipolar lesions had 12.2 3 cm3 volume (n10)

Bipolar Lesion
15

• Disadvantage Deposited power cannot be
  controlled independentely at the two probes
• Non-uniform heating can result

16
2. Multiple Probe RF Ablation

• One Advantage of cryo ablation is the option to
  use multiple probes simultaneously
• Large Lesions can be covered better
• Multiple tumors can be treated simultaneously

17
FEM Results
Alternating Monopolar
Monopolar
Bipolar
18

• Bipolar mode creates highest temperature between
  probes, but can only be used with 2 probes.
  Positioning of probes is important. Does not
  allow independent control of power deposition.
• Monopolar mode creates lowest temperature between
  probes due to electric shielding
• Alternating monopolar mode creates slightly lower
  temperature than bipolar. Can be used with any
  number of probes. Allows control of power
  deposition at each probe.

19
ex-vivo Experiments
20
Experimental Conditions

• 2 pieces of liver tissue (26C, 16C) were
  immersed in 0.9 saline solution
• One probe was inserted into each piece
• 12 min. ablation at 95C was performed

21
Results

• Alternating monopolar method allows independent
  control of multiple probes (theoretically
  unlimited number)

22
3. Bipolar RF Ablation next to blood vessels

• Local tumor recurrence is associated with tumor
  cell survival next to blood vessels
• Can Bipolar ablation create lesions closer to
  blood vessels ?

23
Bipolar Ablation with two 10-prong
probes. Distance from vessel 5 mm
24
Results
Monopolar, d2.3 mm
Bipolar asymmetric, d1.8 mm
Bipolar symmetric, d1.0 mm
25
Current Density

• Does blood vessel conductivity have significant
  impact on lesion formation ?

26
Normal blood conductivity
Altered blood conductivity
27

• Lesion shape is not significantly altered by
  modified blood conductivity

28
Conclusion

• Bipolar Ablation creates lesions closer to blood
  vessels
• Symmetric Bipolar Configuration shows best
  performance, but may be difficult to perform in
  practice

29
4. RF ablation at audio frequencies

• Our previous studies of liver metastases in rats
  showed significant differences in conductivity of
  normal vs. tumor tissue in rats

30

• HypothesisIf we perform RF ablation at lower
  frequencies, we might be able to preferentially
  target tumor tissue

Tumor, d40 mm
Tumor, d20 mm
31
Current Density for 20 mm diameter tumor
f 500 kHz
f 20 kHz

• There were no significant differences in lesion
  for the 40 mm diameter tumor

32
Temperature for 20 mm diameter tumor
f 500 kHz
f 20 kHz
33
Additional Lesion for ablation at 20 kHz
34
Conclusion

• If probe is completely submerged in tumor, no
  differences in lesion are observed
• If probe is partially submerged in tumor, RF
  ablation at audio frequencies preferentially
  targets tumor tissue
• Applied frequency should be limited to 20 kHz
  to avoid excitation of tissue

35
Acknowledgements

• Block, W.F.
• Johnson, C.D.
• Lee jr., F.T.
• Mahvi, D.M.
• Staelin, T.S.
• Tompkins, W.J.
• Tsai, J.Z.
• Tungjitkusolmun, S.
• Van der Weide, D.
• Webster, J.G.
• Wright, A.W.
