Title: Verilog II CPSC 321


1
Verilog IICPSC 321
  • Andreas Klappenecker

2
Todays Menu
  • Verilog,
  • Verilog,
  • Verilog

3
Modules
  • module mod_name (parameters)
  • input
  • output
  • reg
  • endmodule

4
Full Adder
  • module fulladd(cin, x, y, s, cout)
  • input cin, x, y
  • output s, cout
  • assign s x y cin
  • assign cout (x y) (cin x) (cin y)
  • endmodule

5
Full Adder
  • module fulladd(cin, x,y,s, cout)
  • input cin, x, y
  • output s, cout
  • assign cout, s x y cin
  • endmodule
  • The assign statement assigns the MSB to cout
  • and the LSB to s.

6
Hello World
  • module top
  • initial
  • display("Hello, world!")
  • endmodule
  • initial statements are executed once by the
    simulator

7
Vector wires
  • Range msb lsb
  • wire 30 S
  • S 4b0011
  • The result of this assignment is
  • S3 0, S2 0, S1 1, S0 1
  • wire 12 A
  • A S21
  • means A1 S2, A2 S1

8
Variables
  • Variables come in two flavors
  • reg
  • integers
  • reg can model combinatorial or sequential parts
    of the circuits
  • reg does not necessarily denote a register!
  • Integers often used as loop control variables
  • useful for describing the behavior of a module

9
Simple Example
  • module testgate
  • reg b, c // variables
  • wire a, d, e // nets
  • and (d, b, c) // gates
  • or (e, d, c) //
  • nand(a, e, b) //
  • initial begin // simulated once
  • b1 c0 // blocking assignments
  • 10 display("a b", a)
  • end
  • endmodule What value will be printed?

10
Operators
  • 1s complement A
  • 2s complement -A
  • bitwise AND AB
  • reduction A produces AND of all bits in A
  • Concatenate a,b,c
  • a,b,c a b c
  • Replication operators 2A A,A
  • 2A,3B A,A,B,B,B

11
Continuous assignments
  • Single bit assignments
  • assign s x y cin
  • assign cout (x y) (cin x) (cin y )
  • Multibit assignments
  • wire 13 a,b,c
  • assign c a b

12
Always Blocks
  • An always block contains one or more procedural
    statements
  • always _at_(sensitivity list)
  • always _at_(x or y)
  • begin
  • s x y
  • c x y
  • end

13
Mux Structural Verilog
module mux(f, a,b,sel) input a,b,sel
output f wire f1, f2 not(nsel, sel)
and(f1, a,nsel) and(f2, b, sel) or (f, f1,
f2) endmodule
b
f
a
sel
14
Mux Dataflow Model
  • module mux2(f, a,b,sel)
  • output f
  • input a,b,sel
  • assign f (a sel) (b sel)
  • endmodule

15
Mux Behavioral Model
  • module mux2(f, a,b,sel)
  • output f
  • input a,b,sel
  • reg f
  • always _at_(a or b or sel)
  • if (sel1)
  • f b
  • else
  • f a
  • endmodule

16
Sign extension and addition
  • module adder_sign(x,y,s,ss)
  • input 30 x,y
  • output 70 s, ss
  • assign s x y,
  • ss 4x3,x4y3,y
  • endmodule
  • x 0011, y 1101
  • s 0011 1101 00010000
  • ss 0011 1101 00000011 11111101 00000000

17
Demux Example
  • 2-to-4 demultiplexer with active low

enable a b z3 z2 z1 z0
0 x x 1 1 1 1
1 0 0 1 1 1 0
1 1 0 1 1 0 1
1 0 1 1 0 1 1
1 1 1 0 1 1 1
18
Demux Structural Model
enable a b z3 z2 z1 z0
0 x x 1 1 1 1
1 0 0 1 1 1 0
1 1 0 1 1 0 1
1 0 1 1 0 1 1
1 1 1 0 1 1 1
  • // 2-to-4 demultiplexer
  • module demux1(z,a,b,enable)
  • input a,b,enable
  • output 30 z
  • wire abar,bbar
  • not v0(abar,a), v1(bbar,b)
  • nand (z0,enable,abar,bbar)
  • nand (z1,enable,a,bbar)
  • nand (z2,enable,abar,b)
  • nand (z3,enable,a,b)
  • endmodule

19
Demux Dataflow model
enable a b z3 z2 z1 z0
0 x x 1 1 1 1
1 0 0 1 1 1 0
1 1 0 1 1 0 1
1 0 1 1 0 1 1
1 1 1 0 1 1 1
  • // 2-to-4 demux
  • // dataflow model module
  • demux2(z,a,b,enable)
  • input a,b,enable
  • output 30 z
  • assign z0 enable,a,b
  • assign z1 (enable a b)
  • assign z2 (enable a b)
  • assign z3 enable ? (a b) 1'b1
  • endmodule

20
Demux Behavioral Model
  • // 2-to-4 demultiplexer with active-low outputs
  • module demux3(z,a,b,enable)
  • input a,b,enable
  • output 30 z
  • reg z // not really a register!
  • always _at_(a or b or enable)
  • case (enable,a,b)
  • default z 4'b1111
  • 3'b100 z 4'b1110
  • 3'b110 z 4'b1101
  • 3'b101 z 4'b1011
  • 3'b111 z 4'b0111
  • endcase
  • endmodule

enable a b z3 z2 z1 z0
0 x x 1 1 1 1
1 0 0 1 1 1 0
1 1 0 1 1 0 1
1 0 1 1 0 1 1
1 1 1 0 1 1 1
21
Always Blocks
  • The sensitivity list _at_( ) contains the events
    triggering an evaluation of the block
  • _at_(a or b or c)
  • _at_(posedge a)
  • _at_(negedge b)
  • A Verilog compiler evaluates the statements in
    the always block in the order in which they are
    written

22
Assignments
  • If a variable is assigned a value in a blocking
    assignment
  • a b c
  • then subsequent references to a contain the new
    value of a
  • Non-blocking assignments lt
  • assigns the value that the variables had while
    entering the always block

23
D Flip-flop
  • module D_FF(Q,D,clock)
  • output Q
  • input D, clock
  • reg Q
  • always _at_(negedge clock)
  • Q lt D
  • endmodule

24
Clock
  • A sequential circuit will need a clock
  • supplied by the testbed
  • Clock code fragment
  • reg clock
  • parameter period 100
  • initial clock 0
  • always _at_(period/2)
  • clock clock

25
D-Flipflop with Synchronous Reset
  • module flipflop(D, Clock, Resetn, Q)
  • input D, Clock, Resetn
  • output Q
  • reg Q
  • always _at_(posedge Clock)
  • if (!Resetn)
  • Q lt 0
  • else
  • Q lt D
  • endmodule // 7.46 in BV

26
Gated D-Latch
  • module latch(D, clk, Q)
  • input D, clk
  • output Q
  • reg Q
  • always _at_(D or clk)
  • if (clk)
  • Q lt D
  • endmodule
  • Missing else clause gt a latch will be
    synthesized to keep value of Q when clk0

27
Shift Register What is wrong here?
  • module example(D,Clock, Q1, Q2)
  • input D, Clock
  • output Q1, Q2
  • reg Q1, Q2
  • always _at_(posedge Clock)
  • begin
  • end
  • endmodule

Q1 D Q2 Q1
Q1 D Q2 Q1 // DQ1Q2
28
Shift register Correct Version
  • module example(D,Clock, Q1, Q2)
  • input D, Clock
  • output Q1, Q2
  • reg Q1, Q2
  • always _at_(posedge Clock)
  • begin
  • Q1 lt D
  • Q2 lt Q1
  • end
  • endmodule

29
Rule of Thumb
  • Blocking assignments are used to describe
    combinatorial circuits
  • Non-blocking assignments are used in sequential
    circuits

30
n-bit Ripple Carry Adder
  • module ripple(cin, X, Y,
  • S, cout)
  • parameter n 4
  • input cin
  • input n-10 X, Y
  • output n-10 S
  • output cout
  • reg n-10 S
  • reg n0 C
  • reg cout
  • integer k

always _at_(X or Y or cin) begin C0 cin
for(k 0 k lt n-1 kk1) begin
Sk XkYkCk Ck1 (Xk
Yk) (CkXk)(CkYk) end
cout Cn end endmodule
31
Loops and Integers
  • The for loop is used to instantiate hardware
    modules
  • The integer k simply keeps track of instantiated
    hardware
  • Do not confuse integers with reg variables

32
Bit-Counter
  • Count the number of bits having value 1 in
    register X
  • Again an example for parameters
  • Another example of a for loop

33
Bit Counter
  • module bit_cnt(X,Count)
  • parameter n 4
  • parameter logn 2
  • input n-10 X
  • output logn0 Count
  • reg logn0 Count
  • integer k

always _at_(X) begin Count 0
for(k0kltnk k1) CountCountXk
end endmodule
34
Blocks of Procedural Code
  • initial
  • executed once at the beginning of simulation
  • initial display(Hello World)
  • always
  • repeatedly executed
  • begin-end
  • sequential execution of block statements
  • delays add up
  • fork-join blocks
  • concurrent execution of statements

35
Concurrency Example
Block 2 stmt 1 Block 1 stmt 1 Block 1 stmt
2 Block 2 stmt 2 Block 1 stmt 3 Block 2 stmt 3
  • module concurrency_example
  • initial begin
  • 1 display(Block 1 stmt 1")
  • display(Block 1 stmt 2")
  • 2 display(Block 1 stmt 3")
  • end
  • initial begin
  • display("Block 2 stmt 1")
  • 2 display("Block 2 stmt 2")
  • 2 display("Block 2 stmt 3")
  • end
  • endmodule

36
Concurrency Example
Block 2 stmt 1 Block 1 stmt 1 Block 1 stmt
2 Block 2 stmt 2 Block 1 stmt 3 Block 2 stmt 3
  • module concurrency_example
  • initial begin
  • 1 display(Block 1 stmt 1")
  • display(Block 1 stmt 2")
  • 2 display(Block 1 stmt 3")
  • end
  • initial begin
  • display("Block 2 stmt 1")
  • 2 display("Block 2 stmt 2")
  • 2 display("Block 2 stmt 3")
  • end
  • endmodule

37
Concurrency fork and join
Block 1 stmt 2 Block 2 stmt 1 Block 1 stmt
1 Block 1 stmt 3 Block 2 stmt 2 Block 2 stmt 3
  • module concurrency_example
  • initial fork
  • 1 display(Block 1 stmt 1")
  • display(Block 1 stmt 2")
  • 2 display(Block 1 stmt 3")
  • join
  • initial fork
  • display("Block 2 stmt 1")
  • 2 display("Block 2 stmt 2")
  • 2 display("Block 2 stmt 3")
  • join
  • endmodule

38
Displaying Results
  • a 4b0011
  • display(The value of a is b, a)
  • The value of a is 0011
  • display(The value of a is 0b, a)
  • The value of a is 11
  • If you you display to print a value that is
    changing
  • during this time step, then you might get the new
    or
  • the old value use strobe to get the new value

39
Displaying Results
  • Standard displaying functions
  • display, write, strobe, monitor
  • Writing to a file instead of stdout
  • fdisplay, fwrite, fstrobe, fmonitor
  • Format specifiers
  • b, 0b, d, 0d, h, 0h, c, s,

40
Display Example
module f1 integer f initial begin f
fopen("myFile") fdisplay(f, "Hello, bla
bla") end endmodule
41
Moore Machines
next state logic
present state register
output logic
input
  • The output of a Moore machine depends
  • only on the current state. Output logic and
  • next state logic are sometimes merged.

42
Coding Moore Machines
  • The logic in the Moore machine can be described
    by two case statements
  • (one case statement if logic blocks are
    merged)
  • Enumerate all possible states of input and
    current state, and generate the output and next
    state
  • Give states meaningful names using define or
    parameters

43
Moore Machine Example
  • Automatic food cooker
  • Has a supply of food
  • Can load food into the heater when requested
  • Cooker unloads the food when cooking done

44
Automated Cooker
  • Outputs from the machine
  • load signal that sends food into the cooker
  • heat signal that turns on the heater
  • unload signal that removes food from cooker
  • beep signal that alerts that food is done

45
Automated Cooker
  • Inputs
  • clock
  • start start the load, cook, unload cycle
  • temp_ok temperature sensor detecting when
    preheating is done
  • done signal from timer when done
  • quiet Should cooker beep?

46
Cooker
  • module cooker(
  • clock, start, temp_ok, done, quiet, load, heat,
    unload, beep
  • )
  • input clock, start, temp_ok, done, quiet
  • output load, heat, unload, beep
  • reg load, heat, unload, beep
  • reg 20 state, next_state

47
Defining States
  • define IDLE 3'b000
  • define PREHEAT 3'b001
  • define LOAD 3'b010
  • define COOK 3'b011
  • define EMPTY 3'b100

You can refer to these states as IDLE,
PREHEAT, etc.
48
State Register Block
  • define REG_DELAY 1
  • always _at_(posedge clock)
  • state lt (REG_DELAY) next_state

49
Next State Logic
  • always _at_(state or start or temp_ok or done)
  • // whenever there is a change in input
  • begin
  • case (state)
  • IDLE if (start) next_statePREHEAT
  • PREHEAT if (temp_ok) next_state LOAD
  • LOAD next_state COOK
  • COOK if (done) next_stateEMPTY
  • EMPTY next_state IDLE
  • default next_state IDLE
  • endcase
  • end

50
Output Logic
  • always _at_(state)
  • begin
  • if(state LOAD) load 1 else load 0
  • if(state EMPTY) unload 1 else unload 0
  • if(state EMPTY quiet 0) beep 1
  • else beep 0
  • if(state PREHEAT
  • state LOAD
  • state COOK) heat 1
  • else heat 0
  • end
Write a Comment
User Comments (0)
About PowerShow.com
