Title: Review


1
Review
2
Time Series Data
A time series is a collection of observations
made sequentially in time.
25.1750 25.1750 25.2250 25.2500
25.2500 25.2750 25.3250 25.3500
25.3500 25.4000 25.4000 25.3250
25.2250 25.2000 25.1750 .. ..
24.6250 24.6750 24.6750 24.6250
24.6250 24.6250 24.6750 24.7500
value axis
time axis
3
Time Series Problems (from a databases
perspective)
  • The Similarity Problem
  • X x1, x2, , xn and Y y1, y2, , yn
  • Define and compute Sim(X, Y)
  • E.g. do stocks X and Y have similar movements?
  • Retrieve efficiently similar time series
    (Similarity Queries)

4
Similarity Models
  • Euclidean and Lp based
  • Dynamic Time Warping
  • Edit Distance and LCS based
  • Probabilistic (using Markov Models)
  • Landmarks
  • How appropriate a similarity model is depends on
    the application

5
Euclidean model
6
Dynamic Time WarpingBerndt, Clifford, 1994
  • Allows acceleration-deceleration of signals along
    the time dimension
  • Basic idea
  • Consider X x1, x2, , xn , and Y y1, y2, ,
    yn
  • We are allowed to extend each sequence by
    repeating elements
  • Euclidean distance now calculated between the
    extended sequences X and Y

7
Dynamic Time WarpingBerndt, Clifford, 1994
8
Restrictions on Warping Paths
  • Monotonicity
  • Path should not go down or to the left
  • Continuity
  • No elements may be skipped in a sequence
  • Warping Window
  • i j

9
Formulation
  • Let D(i, j) refer to the dynamic time warping
    distance between the subsequences
  • x1, x2, , xi
  • y1, y2, , yj
  • D(i, j) xi yj min D(i 1, j),
  • D(i 1, j 1),
  • D(i, j 1)

10
Basic LCS Idea
  • X 3, 2, 5, 7, 4, 8, 10, 7
  • Y 2, 5, 4, 7, 3, 10, 8, 6
  • LCS 2, 5, 7, 10

Sim(X,Y) LCS or Sim(X,Y) LCS /n
Longest Common Subsequence Edit Distance is
another possibility
11
Indexing Time Series using GEMINI
  • (GEneric Multimedia INdexIng)
  • Extract a few numerical features, for a quick
    and dirty test

12
GEMINI - Pictorially
eg,. std
eg, avg
13
GEMINI
  • Solution Quick-and-dirty' filter
  • extract n features (numbers, eg., avg., etc.)
  • map into a point in n-d feature space
  • organize points with off-the-shelf spatial access
    method (SAM)
  • discard false alarms

14
GEMINI
  • Important Q how to guarantee no false
    dismissals?
  • A1 preserve distances (but difficult/impossible)
  • A2 Lower-bounding lemma if the mapping makes
    things look closer, then there are no false
    dismissals

15
Feature Extraction
  • How to extract the features? How to define the
    feature space?
  • Fourier transform
  • Wavelets transform
  • Averages of segments (Histograms or APCA)

16
Piecewise Aggregate Approximation (PAA)
Original time series (n-dimensional
vector) Ss1, s2, , sn
n-segment PAA representation (n-d vector) S
sv1 , sv2, , svn
PAA representation satisfies the lower bounding
lemma (Keogh, Chakrabarti, Mehrotra and Pazzani,
2000 Yi and Faloutsos 2000)
17
Can we improve upon PAA?
n-segment PAA representation (n-d vector) S
sv1 , sv2, , svN
18
Dimensionality Reduction
  • Many problems (like time-series and image
    similarity) can be expressed as proximity
    problems in a high dimensional space
  • Given a query point we try to find the points
    that are close
  • But in high-dimensional spaces things are
    different!

19
MDS (multidimensional scaling)
  • Input a set of N items, the pair-wise (dis)
    similarities and the dimensionality k
  • Optimization criterion
  • stress (?ij(D(Si,Sj) - D(Ski, Skj) )2 /
    ?ijD(Si,Sj) 2) 1/2
  • where D(Si,Sj) be the distance between time
    series Si, Sj, and D(Ski, Skj) be the Euclidean
    distance of the k-dim representations
  • Steepest descent algorithm
  • start with an assignment (time series to k-dim
    point)
  • minimize stress by moving points

20
FastMap Faloutsos and Lin, 1995
  • Maps objects to k-dimensional points so that
    distances are preserved well
  • It is an approximation of Multidimensional
    Scaling
  • Works even when only distances are known
  • Is efficient, and allows efficient query
    transformation

21
Other DR methods
  • PCA (Principle Component Analysis)
  • Move the center of the dataset to the center
    of the origins. Define the covariance matrix ATA.
    Use SVD and project the items on the first k
    eigenvectors
  • Random projections

22
What is Data Mining?
  • Data Mining is
  • (1) The efficient discovery of previously
    unknown, valid, potentially useful,
    understandable patterns in large datasets
  • (2) The analysis of (often large) observational
    data sets to find unsuspected relationships and
    to summarize the data in novel ways that are both
    understandable and useful to the data owner

23
What is Data Mining?
  • Data Mining is
  • (1) The efficient discovery of previously
    unknown, valid, potentially useful,
    understandable patterns in large datasets
  • (2) The analysis of (often large) observational
    data sets to find unsuspected relationships and
    to summarize the data in novel ways that are both
    understandable and useful to the data owner

24
Association Rules
  • Given (1) database of transactions, (2) each
    transaction is a list of items (purchased by a
    customer in a visit)
  • Find all association rules that satisfy
    user-specified minimum support and minimum
    confidence interval
  • Example 30 of transactions that contain beer
    also contain diapers 5 of transactions contain
    these items
  • 30 confidence of the rule
  • 5 support of the rule
  • We are interested in finding all rules rather
    than verifying if a rule holds

25
Problem Decomposition
  • 1. Find all sets of items that have minimum
    support (frequent itemsets)
  • 2. Use the frequent itemsets to generate the
    desired rules

26
Mining Frequent Itemsets
  • Apriori
  • Key idea A subset of a frequent itemset must
    also be a frequent itemset (anti-monotonicity)
  • Max-miner
  • Idea Instead of checking all subsets of a long
    pattern try to detect long patterns early

27
FP-tree
  • Compress a large database into a compact,
    Frequent-Pattern tree (FP-tree) structure
  • highly condensed, but complete for frequent
    pattern mining
  • Create the tree and then run recursively the
    algorithm over the tree (conditional base for
    each item)

28
Association Rules
  • Multi-level association rules each attribute has
    a hierarchy. Find rules per level or at different
    levels
  • Quantitative association rules
  • Numerical attributes
  • Other methods to find correlation
  • Lift, correlation coefficient

29
What is Cluster Analysis?
  • Cluster a collection of data objects
  • Similar to one another within the same cluster
  • Dissimilar to the objects in other clusters
  • Cluster analysis
  • Grouping a set of data objects into clusters
  • Typical applications
  • As a stand-alone tool to get insight into data
    distribution
  • As a preprocessing step for other algorithms

30
Major Clustering Approaches
  • Partitioning algorithms Construct various
    partitions and then evaluate them by some
    criterion
  • Hierarchical algorithms Create a hierarchical
    decomposition of the set of data (or objects)
    using some criterion
  • Density-based algorithms based on connectivity
    and density functions
  • Model-based A model is hypothesized for each of
    the clusters and the idea is to find the best fit
    of that model to each other

31
Partitioning Algorithms Basic Concept
  • Partitioning method Construct a partition of a
    database D of n objects into a set of k clusters
  • Given a k, find a partition of k clusters that
    optimizes the chosen partitioning criterion
  • Global optimal exhaustively enumerate all
    partitions
  • Heuristic methods k-means and k-medoids
    algorithms
  • k-means (MacQueen67) Each cluster is
    represented by the center of the cluster
  • k-medoids or PAM (Partition around medoids)
    (Kaufman Rousseeuw87) Each cluster is
    represented by one of the objects in the cluster

32
Optimization problem
  • The goal is to optimize a score function
  • The most commonly used is the square error
    criterion

33
CLARANS (Randomized CLARA)
  • CLARANS (A Clustering Algorithm based on
    Randomized Search) (Ng and Han94)
  • CLARANS draws sample of neighbors dynamically
  • The clustering process can be presented as
    searching a graph where every node is a potential
    solution, that is, a set of k medoids
  • If the local optimum is found, CLARANS starts
    with new randomly selected node in search for a
    new local optimum
  • It is more efficient and scalable than both PAM
    and CLARA

34
Hierarchical Clustering
  • Use distance matrix as clustering criteria. This
    method does not require the number of clusters k
    as an input, but needs a termination condition

35
HAC
  • Different approaches to merge clusters
  • Min distance
  • Average distance
  • Max distance
  • Distance of the centers

36
BIRCH
  • Birch Balanced Iterative Reducing and Clustering
    using Hierarchies, by Zhang, Ramakrishnan, Livny
    (SIGMOD96)
  • Incrementally construct a CF (Clustering Feature)
    tree, a hierarchical data structure for
    multiphase clustering
  • Phase 1 scan DB to build an initial in-memory CF
    tree (a multi-level compression of the data that
    tries to preserve the inherent clustering
    structure of the data)
  • Phase 2 use an arbitrary clustering algorithm to
    cluster the leaf nodes of the CF-tree

37
CURE (Clustering Using REpresentatives )
  • CURE proposed by Guha, Rastogi Shim, 1998
  • Stops the creation of a cluster hierarchy if a
    level consists of k clusters
  • Uses multiple representative points to evaluate
    the distance between clusters, adjusts well to
    arbitrary shaped clusters and avoids single-link
    effect

38
Density-Based Clustering Methods
  • Clustering based on density (local cluster
    criterion), such as density-connected points
  • Major features
  • Discover clusters of arbitrary shape
  • Handle noise
  • One scan
  • Need density parameters as termination condition
  • Several interesting studies
  • DBSCAN Ester, et al. (KDD96)
  • OPTICS Ankerst, et al (SIGMOD99).
  • DENCLUE Hinneburg D. Keim (KDD98)
  • CLIQUE Agrawal, et al. (SIGMOD98)

39
Model based clustering
  • Assume data generated from K probability
    distributions
  • Typically Gaussian distribution Soft or
    probabilistic version of K-means clustering
  • Need to find distribution parameters.
  • EM Algorithm

40
Classification
  • Given old data about customers and payments,
    predict new applicants loan eligibility.

Previous customers
Classifier
Decision rules
Age Salary Profession Location Customer type
Salary 5 L
Good/ bad
Prof. Exec
New applicants data
41
Decision trees
  • Tree where internal nodes are simple decision
    rules on one or more attributes and leaf nodes
    are predicted class labels.

Salary
Prof teaching
Age
42
Building tree
  • GrowTree(TrainingData D)
  • Partition(D)
  • Partition(Data D)
  • if (all points in D belong to the same class)
    then
  • return
  • for each attribute A do
  • evaluate splits on attribute A
  • use best split found to partition D into D1 and
    D2
  • Partition(D1)
  • Partition(D2)

43
Split Criteria
  • Select the attribute that is best for
    classification.
  • Information Gain
  • Gini Index
  • Gini(D) 1 - ?? pj2

Ginisplit(D) n1 gini(D1) n2 gini(D2)
n n
44
SLIQ (Supervised Learning In Quest)
  • Decision-tree classifier for data mining
  • Design goals
  • Able to handle large disk-resident training sets
  • No restrictions on training-set size

45
Bayesian Classification
  • Probabilistic approach based on Bayes theorem
  • MAP (maximum posteriori) hypothesis

46
Naïve Bayes Classifier (I)
  • A simplified assumption attributes are
    conditionally independent
  • Greatly reduces the computation cost, only count
    the class distribution.

47
Bayesian Belief Networks (I)
Age
FamilyH
(FH, A)
(FH, A)
(FH, A)
(FH, A)
M
0.7
0.8
0.5
0.1
Diabetes
Mass
M
0.3
0.2
0.5
0.9
The conditional probability table for the
variable Mass
Insulin
Glucose
Bayesian Belief Networks
Write a Comment
User Comments (0)
About PowerShow.com
