BGP Inefficiencies

1

• BGP Inefficiencies
• Supplemental slides
• 02/14/2007
• Aditya Akella

2
BGP Complexity

• BGP is a very complicated protocol
• Too many knobs
• Need to accommodate (sub-optimal) ISP policies
• Requires complex, human configuration
• For all its complexity, BGP offers no guarantees
• Performance??
• Reliability??
• Correctness??
• Reachability??
• All of BGPs complexity begets

Headache!
3
BGP Pitfalls and Problems

• Pitfalls and problems
• Misconfiguration
• Convergence
• Performance
• Reliability
• Stability
• Security
• And the list goes on

4
Favorite Scapegoat!
Networkingcommunity
BGP
5
Misconfiguration Mahajan02Sigcomm

• Origin misconfiguration accidentally inject
  routes for prefixes into global BGP tables

6
Misconfiguration

• Export misconfiguration export route to a peer
  in violation of policy

7
Interesting Observations

• Origin misconfig
• 72 of new routes may be misconfig
• 11-13 of misconfig incidents affect
  connectivity
• Pings and e-mail checks
• Self de-aggregation is the main cause
• Export misconfig
• Upto 500 misconfiguration incidents per day
• All forms are prevalent, although
  provider-AS-provider is more likely

8
Effects and Causes
Export Misconfig

• Effects
• Routing load
• Connectivity disruption
• Extra traffic
• Policy violation
• Causes (Origin misconfig)
• Router vendor software bugs announce and
  withdraw routes on reboot
• Reliance on upstream filtering
• New configuration not saved to stable storage
  (separate command and no autosave!)
• Hijacks of address spaces
• Forgotten to install filter
• Human operators and poor interface

P1
P2
A
C

• Intended policy Provide transit to C through
  link A-C
• Configured policy Export all routes originated
  by C to P1 and P2
• Correct policy export only when AS path is C

9
BGP Convergence Labovitz00Sigcomm

• Conventional beliefs
• Path vector converges faster than traditional DV
  (eliminates the count to infinity problem)
• Internet path restoration takes order of 10s of
  seconds
• Convergence
• Recovery after a fault may take as much as ten
  minutes
• Single routing fault could result in multiple
  announcements and withdrawals
• Loss and RTT around times of faults are much
  worse
• Upon route withdrawal, explore paths of
  increasing length
• In the worst case, could explore n! paths
• Depends which messages are processed and when
• Limit between update message could reduce
  messages
• Forces all outstanding messages to be processed

10
End-to-End Routing Behavior Paxson96Sigcomm

• Large scale routing behavior as seen by
  end-hosts, based on analysis of traceroutes
• Pathologies persistent routing loops, routing
  failures and long connectivity outages
• Stability 9 or routes changed every 10s of
  minutes, 30 about 6hrs and 68 took a few days
• Symmetry more than half of paths probed were
  asymmetric at router level

11
Inefficiencies in BGP Internet Routing

• Route convergence and oscillations
• Poor reliability
• No way to exploit redundancy in Internet paths
• Inefficiency sub-optimal RTTs and throughputs
• What are some of the causes?
• Policies in routing Inter-domain and
  Intra-domain
• Lack of direct routes, sparseness of the
  Internet graph

12
Inefficiency of Routes Spring03Sigcomm

• Three classes of reasons for poor performance
  (inflation)
• Intra-domain topology and policy
• Topology no direct link between all cities
• Routing policy shortest paths may be avoided
  due to engineering
• ISP Peering
• Peeering topology limited peering between ISPs
• Peering policy hot-potato routing or early-exit
  routing
• Inter-domain
• Topology AS graph is sparse
• Inter-domain policies policies are policies

13
Path Inflation Summary
14
Internet Bottlenecks
As access technology improves Non-access or
Wide-Area Bottlenecks?
Last-mile, slow access links limit transfer
bandwidth
High-speed core
Big, fatPipe(s)
Slow, flaky home connection
100Mbps home connection
Most bottlenecks are last-mile
15
Wide-Area Bottlenecks
Link with the least available bandwidth
Not the traditional bottlenecks ? may not be
congested
Wide-area bottleneck ? where an unconstrained TCP
flow sees delays and losses
Very Small ISP
Very Small ISP
Tiny ISP
Unconstrained TCP flow
Wide-Area Internet/High-speed core
Small ISP
Small ISP
Small ISP
ATT
Very Small ISP
Sprint
UUNet
Small ISP
Tiny ISP
SmallISP
Tiny ISP
16
Measurement Tool BFind
But no control over destination
Ideally
Emulate the whole processfrom the source!
dest
source
Monitor queues, identify where queues build up?
bottleneck
17
Measurement Tool BFind
Round 1
Round 2
Round j
1Mbps
Rate for round 21d Mbps
Rate for round 3 12d Mbps
Flag 2, keep curent rate for round j1? force
queueing
Rate controlled UDP stream
Round jQueueing on 2!
Round 2No queueing!
Round 1No queueing!
dest
source
Rounds ofTraceroutes
If 2 flagged too many times ? quit. Identify 2
as bottleneck
Monitor links forqueueing
Report toUDP process

• BFind functions like TCP gradually increase send
  rate until hits bottleneck
• Can identify key properties of the bottleneck
• Location, latency, available bandwidth ( send
  rate of BFind before quitting)
• Single-ended control
• Quits after 180s and before send rate hits 50Mbps
• Bfind validation wide-area experiments and
  simulations

18
Results Location
Intra-ISP links
Inter-ISP links
51
49
One of the two peering links with 50 chance
bottlenecks all links
bottlenecks all links
Peering Link
Probability of being the bottleneck 0.25
Intra-ISP Link
Probability of being the bottleneck 0.125
One of the four non-peering links with 50 chance
19
Results Available Bandwidth
Intra-ISP links
Inter-ISP links

• Tier-1 ISPs are the best
• Tier-3 ISPs have slightly higher available
  bandwidth than tier-2

• Tier-1 1 peering is the best
• Peering involving tiers-2,3 similar

20
Performance End-to-End Perspective

• From an end-to-end view
• Is there a way of extracting better performance?
• Is there scope?
• How do we realize this?
• Scope Savage99, CMU Multihoming work
• Reality UWs Detour system, MITs RON,
  Akamais SureRoute, CMUs Route Control
  implementation

21
Quantifying Performance Loss Savage99Sigcomm

• Measure round trip time (RTT) and loss rate
  between pairs of hosts
• Alternate path characteristics
• 30-55 of hosts had lower latency
• 10 of alternate routes have 50 lower latency
• 75-85 have lower loss rates

22
Bandwidth Estimation

• RTT loss for multi-hop path
• RTT by addition
• Loss either worst or combine of hops why?
• Large number of flows? combination of
  probabilities
• Small number of flows? worst hop
• Bandwidth calculation
• TCP bandwidth is based primarily on loss and RTT
• 70-80 paths have better bandwidth
• 10-20 of paths have 3x improvement

23
Possible Sources of Alternate Paths

• A few really good or bad ASs
• No, benefit of top ten hosts not great
• Better congestion or better propagation delay?
• How to measure?
• Propagation 5th percentile of delays
• Both contribute to improvement of performance

24
Overlay Networks

• Basic idea
• Treat multiple hops through IP network as one hop
  in overlay network
• Run routing protocol on overlay nodes
• Why?
• For performance like the Savage 99 paper showed
• For efficiency can make core routers very
  simple
• E.g. CSFQ,
• Also aid deployment. E.g. Active networks
• For functionality can provide new features such
  as multicast, active processing

25
Future of Overlay

• Application specific overlays
• Why should overlay nodes only do routing?
• Caching
• Intercept requests and create responses
• Transcoding
• Changing content of packets to match available
  bandwidth
• Peer-to-peer applications





26
Overlay Challenges

• Routers no longer have complete knowledge about
  link they are responsible for
• How do you build efficient overlay
• Probably dont want all N2 links which links to
  create?
• Without direct knowledge of underlying topology
  how to know whats nearby and what is efficient?
• Do we need overlays for performance?

27
Number of Route Choices
Multiple candidatepaths
Single path
Multiple BGPpaths

• Flexible control of end-to-end path ? many route
  choices

• BGP one path via each ISP ? choices linked to
  ISPs

Few more route choices?
28
Route Selection Mechanism
Best performingpath
Least AS hops Policy compliant
Current best performingBGP path

Smartselection
Multihoming route control

• BGP simple, coarse metrics such as least AS
  hops, policy

• Overlays complex, performance-oriented selection

Sophisticated selection among multiple BGP routes
29
Overlay Routing vs. Multihoming Route Control
Route Control
Overlay Routing
Overlay provider

Genuity
Sprint
ATT
ATT
Connectivity fees
Connectivity fees overlay fee
Announce/20 sub-blocks to ISPs
Overlay nodeforces inter-mediate ISP to
provide transit

If all multihomed ends do this
/18 netblock
Routing table expansion
Bad interactions with policies
