Title: Probabilistic Reasoning System 2: Bayesian network


1
Probabilistic Reasoning System 2Bayesian network
  • CS 570
  • Team12
  • ??? ??, ???, ???, ???

2
Todays topics
  • 1. Inference in Multiply Connected Network
  • Clustering algorithms
  • Cutset conditioning methods
  • 2. Approximate inference (Monte Carlo Algorithms)
  • Direct sampling methods
  • Rejection sampling in Bayesian networks
  • Likelihood weighting
  • Markov Chain Monte Carlo algorithm
  • 3. Implementation tools and applications of
    Bayesian network

3
Singly connected Network/ Polytree
P(E) ____ .002
P(B) ____ .001
Burglary
Earthquake
  •  A singly connected network is a network in
    which there is at most one undirected path
    between any nodes in it
  • Size is defined as the number of CPT entries.

B E P(A) _______________ t t .95 t f .94 f t .29 f
f .001
Alarm
MaryCalls
JohnCalls
A P(M) _________ t .70 f .01
A P(J) _______ t .90 f .05
4
Multiply connected Network
  •  Network in which two nodes are connected by
    more than one path
  • That means
  • Two or more possible causes for some variable
  • One variable can influence another variable
    through more than one causal mechanism

C P(R) ________ t .80 f .20
Cloudy
P(C).5
Rain
Sprinkler
S R P(W) ________________ t t .99 t f .90 f t .90
f f .00
C P(S) ________ t .10 f .50
WetGrass
5
Clustering Algorithms (1)
  • Combining individual nodes of the network to form
    cluster nodes (meganode) in such a way that the
    resulting network is a polytree (Singly connected
    network)
  • The meganode has only one parent.
  • Time can be reduced to O(n)

6
Clustering Algorithms (2)
P(C).5
Cloudy
P(C).5
Cloudy
C P(R) ________ t .80 f .20
C P(S) ________ t .10 f .50
SprRain
C P(SRx) t t t f f t f f _____________________
_______________ t .08 .02 .72 .18 f .10 .40 .10 40
Rain
Sprinkler
WetGrass
WetGrass
S R P(W) ________________ t t .99 t f .90 f t .90
f f .00
S R P(W) ________________ t t .99 t f .90 f t .90
f f .00
7
Cutset conditioning
  • a cutset is a set of variables that can be
    instantiated to yield polytree
  • each polytree has one or more variables
    instantiated to a definite value
  • the number of resulting polytrees is exponential
    in the size of the cutset, so the smallest cutset
    is the best
  • evaluating the most likely polytrees first is
    called bounded cutset conditioning

8
Cutset conditioning example
9
  • 1. Inference in Multiply Connected Network
  • Clustering algorithms
  • Cutset conditioning methods
  • 2. Approximate inference (Monte Carlo Algorithms)
  • Direct sampling methods
  • Rejection sampling in Bayesian networks
  • Likelihood weighting
  • Markov Chain Monte Carlo algorithm
  • 3. Implementation tools and applications of
    Bayesian network

10
Monte Carlo Algorithms
  • Provide approximate answers whose accuracy
    depends on the number of samples generated
  • Two families
  • Direct sampling
  • Markov Chain sampling

11
Direct sampling methods (1)
  • No evidence associated with the network
  • The algorithm samples each variable in turn
  • For nodes without parents, sample from their
    distribution for nodes with parents, sample from
    the conditional distribution.
  • Example
  • Sample from P(Cloudy) 0.5,0.5 gt true
  • Sample from P(Sprinklercloudy True) 0.1,0.9
    gt false
  • Sample from P(RainCloudy True) 0.8,0.2 gt
    true
  • Sample from P(WetGrassSprinkler false,
    RainTrue)0.9,0.1 gt true

12
P(b).05
FamilyOut
P(f).2
BowelProblems
LightsOn
DogOut
D P(hD) t .6 f .25
F B P(dF,B) t t .994 t f .88 f t .96 f f .2
HearDogBark
F P(lF) t .99 f .1
Query What is the probability of family at home,
dog has no bowel problems and isnt out, the
light is off, and dogs barking can be
heard? We generate 100,000 samples from the
network We obtain NS(f,b,l,d,h)
13740 13740/100000 0.1374 P(f,b,l,d,h)
0.80.950.90.80.25 0.1368
13
Direct sampling methods(2)Prior-Sample algorithm
  • Function PRIOR-SAMPLE(bn) returns an event
    sampled from the prior specified by bn
  • inputs bn, a Bayesian network specifying joint
    distribution P(X1,,Xn)
  • x lt- an event with n elements
  • for i 1 to n do
  • xi lt- a random sample from P(Xi parents(Xi))
  • return x

14
Direct sampling methods(3)
  • Looking at the sampling process, we have
  • Which remind
  • This estimated probability becomes exact in the
    large-sample limit. We call it  consistent

15
Rejection sampling (1)
  • Method to approximate conditional probabilities
    P(Xe) given evidence e
  • P(Xe) Ns(X,e) / Ns(e)
  • 1. First, generates samples from the prior
    distribution specified by the network.
  • 2. Then, rejects all those that do not match the
    evidence
  • 3. Finally, the estimate P(Xxe) is obtained by
    counting how often Xx occurs in the remaining
    samples.

16
Rejection sampling (2) algorithm
  • Function Rejection-Sampling(X,e,b,N) returns
    an estimate of P(Xe)
  • Inputs X, the query variable
  • e, evidence specified as an event
  • bn, a Bayesian network
  • N, the total number of samples to be
    generated
  • Local variables N, a vector of counts over X,
    initially zero
  • For j1 to N do
  • x lt- PRIOR-SAMPLE(bn)
  • if x is consistent with e then
  • Nx lt- Nx 1 where x is the value of X in x
  • return NORMALIZE(NX)

17
Rejection sampling (3)Example
  • Let us assume we want to estimate
    P(rainSprinkler true)
  • 100 samples
  • 73 samples gt Sprinkler false
  • 27 samples gt Sprinkler true
  • 8 samples gt Rain true
  • 19 samples gt Rain false
  • P(RainSprinkler true) NORMALIZE(8,19)
    0.296,0.704.
  • The true answer is 0.3,0.7
  • As more samples are collected, the estimate will
    converge to the true answer

18
Rejection sampling (4) Problems
  • Problems
  • Rejection sampling rejects too many samples.
  • The fraction of samples consistent with the
    evidence e drops exponentially as the number of
    evidence variable drops.
  • Procedure unusable for complex problems

19
Likelihood weighting (1)
  • Avoids the inefficiency of rejection sampling by
    generating only events that are consistent with
    the evidence e.
  • That is, It fixes the values for the evidence
    variable E and samples only the remaining
    variables X and Y.
  • Each event generated is consistent with the
    evidence
  • Also, it weights each sample by product of
    conditional probabilities of evidence variables,
    given its parents

20
Likelihood weighting (2)Example for one sample
  • Example
  • Query P(RainSprinklertrue, WetGrass true)
  • The weight is set to 1.0
  • 1. Sample from P(Cloudy) 0.5,0.5 gt true
  • 2. Sprinkler is an evidence variable with value
    true
  • w lt- w P(Sprinklertrue Cloudy true) 0.1
  • 3. Sample from P(RainCloudytrue)0.8,0.2 gt
    true
  • 4. WetGrass is an evidence variable with value
    true
  • w lt- w P(WetGrasstrue Sprinklertrue, Rain
    true) 0.1

21
Likelihood-Weighting(3) algorithm
  • function LIKELIHOOD-WEIGHTING(X,e,bn,N) returns
    an estimate of P(Xe)
  • inputs X, the query variable
  • e, evidence specified as an event
  • bn, a Bayesian Network
  • N, the total number of samples to be generated
  • local variables W, a vector of weighted counts
    over X, initially zero
  • for j 1 to N do
  • x, w lt- Weighted-Sample(bn)
  • Wx lt- Wx w where x is the value of X in
    x
  • return NORMALIZE(WX)
  • __________________________________________________
    _______________________________
  • function WEIGHTED-SAMPLE(e,bn) returns an event
    and a weight
  • x lt- an event with n elements w lt- 1
  • for i 1 to n do
  • if Xi has a value xi in e
  • then w lt- w P(Xixi parents(Xi))
  • else xi lt- a random sample from
    P(Xiparents(Xi))

22
Likelihood weighting (4)Example for one query
P(B).05
FamilyOut
P(F).2
BowelProblems
LightsOn
DogOut
D P(HD) t .6 f .25
F B P(HD) t t .994 t f .88 f t .96 f f .2
HearDogBark
F P(LF) t .99 f .1
23
Likelihood weighting (4)Example for one query
  • For N100000, obtain
  • Correct

24
Markov Chain Monte Carlo algorithm(1)
  • Some vocabulary
  • A node is conditionally independent of all other
    nodes in the network, given its parents,
    children, and childrens parents that is, given
    its Markov Blanket. For example, Burglary is
    independent of JohnCalls and MaryCalls, given
    alarm and Earthquake.
  • A sequence of discrete random variables X0, X1,
    is called a Markov chain with state space S iff
  • Thus, Xn is conditionally independent of all
    other variables given Xn-1

25
Markov Chain Monte Carlo algorithm(2)
  • function MCMC-Ask(X,e,bn,N) returns an estimate
    of P(Xe)
  • local variables NX, a vector of counts over
    X, initially zero
  • Z, the nonevidence variables in bn.
  • x, the current state of the network,
    initially copied from e
  • initialize x with random values for the
    variables in Z
  • for j 1 to N do
  • Nx lt- Nx 1 where x is the value of X in x
  • for each Zi in Z do
  • sample the value of Zi in x from P(Zimb(Zi))
    given the values of MB(Zi) in x
  • return NORMALIZE(NX)

26
Markov Chain Monte Carlo algorithm(3)
  • Lets think of the network as being in a
    particular current state specifying a value for
    every variable
  • MCMC generates each event by making a random
    change to the preceding event
  • The next state is generated by randomly sampling
    a value for one of the nonevidence variables Xi,
    conditioned on the current values of the
    variables in the MarkovBlanket of Xi

27
Markov Chain Monte Carlo Example1
  • Query P(RainSprinkler true, WetGrass true)
  • Initial state is true, true, false, true
  • The following steps are executed repeatedly
  • Cloudy is sampled, given the current values of
    its MarkovBlanket variables
  • So, we sample from P(CloudySprinkler true,
    Rainfalse)
  • Suppose the result is Cloudy false.
  • Then current state is false, true, false, true
  • Rain is sampled given the current values of its
    MarkovBlanket variables
  • So, we sample from P(RainCloudyfalse,Sprinkler
    true, Rainfalse)
  • Suppose the result is Rain true.
  • Then current state is false, true, true, true
  • After all the iterations, lets say the process
    visited 20 states where rain is true and 60
    states where rain is false then the answer of the
    query is NORMALIZE(20,60)0.25,0.75

28
Markov Chain Monte Carlo Example2
  • Query P(Fl,d)
  • Start with arbitrary non-evidence settings
    (f,b,h)
  • Pick F, sample from P(Fl,d,b), obtain f
  • Pick B, sample from P(B f,d), obtain b
  • Pick H, sample from P(Hd), obtain d
  • Iterate last three steps 50000 times, keep last
    10000 states
  • Obtain P(fl,d) 0.9016(correct 0.90206)

29
  • 1. Inference in Multiply Connected Network
  • Clustering algorithms
  • Cutset conditioning methods
  • 2. Approximate inference (Monte Carlo Algorithms)
  • Direct sampling methods
  • Rejection sampling in Bayesian networks
  • Likelihood weighting
  • Markov Chain Monte Carlo algorithm
  • 3. Implementation tools and applications of
    Bayesian network

30
Implementation Tool Microsoft Belief Networks
  • MSBNx is a component-based Windows application
    for creating, assessing, and evaluating Bayesian
    Networks, created at Microsoft Research
  • MSBNx http//www.research.microsoft.com/adapt/MSB
    Nx/
  • Why MSBNx?
  • Its free and available on the net.
  • Its easy to learn how to use it.
  • We can specify full and causally independent
    probability distributions
  • If we have sufficient data and use machine
    learning tools to create Bayesian Networks, we
    can use MSBNx to edit and evaluate the results

31
Implementation Tool Microsoft Belief Networks
  • How to use it?
  • First, we make the nodes on the window
  • Then, we specify all the probabilities
  • Finally, we do what we want to do with the
    network

32
Implementation Tool Microsoft Belief Networks
(example) making the network
33
Implementation Tool Microsoft Belief Networks
(example) assessing probabilities(1)
34
Implementation Tool Microsoft Belief Networks
(example) assessing probabilities(2)
CPT
35
Implementation Tool Microsoft Belief Networks
(example) Obtaining results without evidence(1)
To obtain results
36
Implementation Tool Microsoft Belief Networks
(example) Obtaining results without evidence(2)
37
Implementation Tool Microsoft Belief Networks
(example) Obtaining results with evidence(1)
38
Implementation Tool Microsoft Belief Networks
(example) Obtaining results with evidence(2)
Evidence
Evidence
39
Implementation Tool Microsoft Belief Networks
(example) Obtaining results with evidence(3)
40
  • ??? ????? ?????
Write a Comment
User Comments (0)
About PowerShow.com
