p2p06

1
CAN, CHORD, BATON (extensions)
2
Structured P2P

• Additional issues
• Fault tolerance, load balancing, network
  awareness, concurrency
• Replicate cache
• Performance evaluation
• CHORD
• ?????

3
Summary Design parameters and performance (CAN)
Only on replicated data
4
CHORD

• Additional issues discussed for CHORD
• Fault tolerance
• Concurrency
• Replication
• (Data) Load balancing

5
CHORD Stabilization
Need to keep the finger tables consistent in the
case of concurrent inserts Keep the successors
of the nodes up-to-date Then, these successors
can be used to verify and correct the finger
tables
6
CHORD Stabilization

• Thus
• Connect to the network by finding your successor
• Periodically run stabilize (to fix successors)
  and less often run fix table

What about similar problems in CAN? If we forget
performance, in general, it suffices to keep the
network connected
7
CHORD Stabilization

• A lookup before stabilization
• All finger tables reasonably current, an entry
  is found in O(logN) steps
• Successors are correct but finger tables are
  inaccurate, correct but maybe slow lookups
• Incorrect successors pointers or keys have not
  moved yet, lookup may fail and needs to be retried

8
CHORD Stabilization

• Works
• Concurrent joins
• Lost and reordered messages
• May not work (?)
• When system is split into multiple disjoint
  circles
• A single cycle that loops around the identifier
  space
• Caused by failures, network partitioning, etc
  in general, left unclear

9
CHORD Stabilization
Join
Upon joining, node n calls a known node n and
asks n to locate its successor
n.join(n) predecessor nil successor
n.find_succesor(n)
Note, the rest of the network does not know n yet
to achieve this run stabilize
10
CHORD Stabilization
Stabilize

• Every node n runs stabilize periodically
• n asks its successor for its predecessor, say p
• n checks whether p should be its successor
  instead
• (this is, if p has joined the network in between)
  this is how nodes find out of new nodes

n.stabilize() x successor.predecessor
if(x ? (n, successor)) successor x
successor.notify(n)
11
CHORD Stabilization
Notify

• successor(n) is also notified and checks whether
  it should make n its predecessor

n.notify(n) if (predecessor is nil or
n ? (predecessor, n)) predecessor n
12
CHORD Stabilization
Node n joins
np
np.successor ns
n.predecessor nil n.successor ns
n
ns.predecessor np
ns
13
Example n.stabilize
n runs stabilize
np
np.successor ns
n.predecessor nil n.successor ns
n
ns.notify(n)
ns.predecessor np
ns.predecessor n
ns
14
Example - np.stabilize
np runs stabilize
np
np.successor ns
np.successor n
np.stabilize()
n.predecessor nil n.successor ns
n
ns.predecessor n
ns
15
Example - np.stabilize
np
np.successor n
n.notify(np)
n.predecessor nil n.successor ns
n.predecessor np n.successor ns
n
ns.predecessor n
ns
16
Chord Stabilization Fix fingers

• Finger tables are not updated immediately
• Thus, lookups may be slow by find_predecessor and
  find_successor work
• Periodically run fix_fingers
• pick a random entry in the finger table and
  update it

n.fix_fingers() i random_index gt 1 into
finger fingeri.node find_successor(finge
ri.start)
17
Stabilization

• Finger tables
• Must have a finger at each interval, then the
  distance halving argument still holds
• Lookup finds the predecessor of the target t,
  say p, then p finds the target (it is its
  successor)
• Problem only when a new node enters between p
  and t
• Then we may need to scan these nodes linearly, ok
  if O(logN) such nodes

18
Stabilization
Eventually succeed Invariant Once a node can
reach a node r via successor pointers, it always
can Termination argument Assume two nodes (n1,
n2) that both think that they have the same
successor s Both attempt to notify s s will
eventually choose the one that is closer of the
two as its predecessor, say n1 The farthest of
the two n2 will then learn by s of a better
successor than s (n1) Thus, there is progress to
a better successor each time
19
Failures

• When a node n fails
• Nodes that have n as their successors in the
  finger table must be informed and find the
  successor of n to replace it in their finger
  table
• Lookups in progress must continue
• Maintain correct successor pointers

20
Failures

• Replication
• Each node maintain a successor list of its r
  nearest successors
• Upon failure, use the next successor in the list
• Modify stabilize to fix the list

21
Failures
Other nodes may attempt to send requests through
the failed node Use alternate nodes found in the
routing table of preceding nodes or in the
successor list
22
Example r3
Failures
3, 5, 6
15, 3, 5
5, 6, 9
14, 15, 3
6, 9, 12
9, 12, 14
12, 14, 15
23
Failures

• Theorem If we use a successor list with r
  ?(logN) in an initially stable network and then
  every node fails with probability 1/2, then
• with high probability, find_successor returns
  the closest living successor
• the expected time to execute find_successor in
  the failed network is O(logN)

A lookup fails, if all r nodes in the successor
list fail. All fail with probability 2-r
(independent failures) 1/N
24
Replication
Store replicas of a key at the k nodes succeeding
the key Successor list helps to keep the number
of replicas per item known Other approach store
a copy per region
25
Load balance
K keys, N nodes ideal allocation, each node gets
K/N
104 nodes, 105 106 keys, step of 105
Mean 1st and 99th percentiles (t? p?s?st? t??
?ata??µ?? p?? e??a? µ????te?? ? ?s?) of the
number of keys per node Large variation which
increases with the number of keys
26
Load balance
K keys, N nodes ideal allocation, each node K/N
104 nodes, 5 x 105 keys
Probability Density Function
27
Load balance
Node identifiers do not uniformly cover the
entire identifier space Assume N keys and N
nodes If we divide the space in N equal-sized
bins, then we would like to see one key per
node The probability that a particular bin is
empty is (1 1/N)N For large N, this approaches
e-1 0.368
28
Load balance Virtual Nodes

• Introduce virtual nodes
• Map multiple virtual nodes with unrelated
  identifiers to each real node
• Each key is hashed into a virtual node which is
  next mapped to an actual node
• Increase number of virtual nodes from N -gt N logN
• Worst-case path length O(N logN)
• Each actual node needs r times as much space for
  the finger tables of its virtual nodes.
• If r log N, then log2N entries, for N 106
  then 400 entries
• The routing messages per node also increase

29
Load balance
30
Load balance
CAN One virtual node (zone) -gt Many physical
nodes reduce virtual nodes -gt decrease path
length physical network awareness Many virtual
nodes -gt One physical node increase virtual
nodes -gt increase path length data load balance
31
Performance Evaluation
CAN Simulation Knobs-on full vs Bare bones Use
network topology generators CHORD Simulation
(runs in iterative style, note how does this
affect network proximity) Also a small size
distributed experiment that reports latency
measurements 10 sites in the USA, simulate more
than 10 nodes by running more than one copies of
CHORD at each of the sites
32
Metrics for System Performance

• Path length overlay hops to route between two
  nodes in the CAN space
• Latency
• End-to-end latency between two nodes
• Per-hop latency end-to-end latency for the whole
  path length
• Neighbor-state
• Volume per node (indicative of data and query
  load)
• Load per node

lookup
33
Metrics for System Performance

• Routing fault tolerance
• Data fault tolerance
• Maintenance cost cost of join/leave, replication
  etc
• How? Either separately or as the overall network
  traffic
• Churn (dynamic behavior)

34
CHORD Magic Constants
Period of stabilize Period of fix_finger Maximum
number of virtual nodes m Number of virtual
nodes per physical node (O(logN)) Size of the
successor list (O(logN)) Hash function
35
Path Length
Actually is ½ log N Follow half the log N bits
212 nodes
36
CHORD more

• Simultaneous Node Failures
• Randomly select a fraction p of nodes that fail
• The network stabilizes
• Lookup failure rate is p (could be worst if say
  network partition)
• Lookups during stabilization

37
CHORD future

• Detect malicious participants
• Or take a false position in the ring to steal
  data
• Physical network awareness

38
BATON

• Additional issues
• Fault tolerance
• Other ways to restructure/balance the tree
• (Workload) load balance

39
Failures
There is routing redundancy

• Upon node departure or failure, the parent can
  reconstruct the entries
• Assume node x fails, any detected failures of x
  are reported to its parent y
• y regenerates the routing tables of x Theorem 2

• Messages are routed
• Sideways (redundancy similar to CHORD)
• Up-down (can find its parent through its
  neighbors)

40
AVL-like Restructuring
The network may be restructured using AVL-like
rotations No data movement is needed, but some
routing tables need to be updated
41
Load Balance
Each node keeps statistics about the number of
queries or messages it receives Adjust the data
range to equalize the workload between adjacent
nodes for leaves, find another (less loaded
leaf) say v have it transfer its load to its
parent and make v join again as the nodes
child Performance results (simulation) are
reported not surprises
42
Replication - Beehive

• Proactive model-driven replication
• Passive (demand-driven) replication such as
  caching objects along a lookup path
• Hint for BATON
• Beehive
• The length of the average query path reduced by
  one when an object is proactively replicated at
  all nodes logically preceding that node on all
  query paths
• BATON
• Range queries
• Many paths to data
