Relevance Propagation for Web Search

1
Relevance Propagation for Web Search

• Dr. Tie-Yan Liu
• Web Search and Mining Group
• Microsoft Research Asia
• Joint Work with Tao Qin, Tsinghua University.

2
Outline

• Introduction
• Generic framework for relevance propagation
• Evaluations
• Effectiveness analysis
• Complexity analysis
• Conclusions

3
Introduction

• Web Search ? Information Retrieval
• Beside the content relevance, various structure
  information also plays an important role in Web
  search
• Hyperlink graph
• Local sitemap
• Webpage layout

4
Introduction

• Three ways of utilizing the structure information
  for Web search
• Linear combination of content relevance and
  importance scores computed from hyperlink graph
• ßRelevance (1-ß) PageRank
• Enhance link analysis with the help of content
  relevance
• Query-dependent link graph in HITS
• Topic-sensitive PageRank
• Propagate content relevance along the Web
  structure
• The use of anchor text in Search Engines
• Hyperlink-based relevance score propagation (TREC
  2003)
• Sitemap-based feature propagation (TREC 2004)

5
Hyperlink-based Relevance Score Propagation (Zhai
et al, TREC2003)

• Assumption
• Hyperlinked pages have correlated content

outlinks
links
6
Hyperlink-based Relevance Score Propagation (Zhai
et al, TREC2003)

• Assumption
• Hyperlinked pages have correlated content
• Propagation model
• Weighted inlink model
• Weighted outlink model
• Uniform outlink model

7
Sitemap-based Feature Propagation (Liu and Qin,
TREC2004)

• Assumption
• Child pages are extensions of their parent page
• One should consider the contribution of the child
  pages while computing the relevance of the parent
  page to a query.
• Propagation model

8
Generic Relevance Propagation Framework

• Modification of the sitemap-based feature
  propagation model
• Reminder of the hyperlink-based propagation model
• A generic framework to cover both hyperlink-based
  and sitemap-based propagations

9
More Derived Propagation Models
10
Summary All Models Covered by the Generic
Framework
11
Benchmark Datasets

• Corpora
• .GOV
• 1M pages
• Queries TD 2003, 2004
• MSN
• 2M pages
• Query 100 most popular queries from MSN query
  log

• Base Ranking function
• BM2500

12
Experimental Results (1)
TREC 2003
13
Experimental Results (2)
TREC 2004
14
Experimental Results (3)
MSN
15
Conclusions on Effectiveness

• In general, relevance propagation can boost the
  search performance with proper parameter
  settings
• The sitemap-based models are more effective than
  the hyperlink-based models
• Hyperlinks ? Content Correlation, while the pages
  in the same sub site usually talk about
  correlated topics.
• Detailed comparisons
• The two sitemap-based models have similar
  performance.
• Among the hyperlink-based models, the HF-WI model
  performs best.

16
Online Complexity

• w is the size of the working set, q is the number
  of query terms, l is the average number of
  inlinks / outlinks, t is the number of
  iterations.
• For the SS model, the complexity is O(w),
• The SS model needs to propagate the relevance
  score of a page to its parent only once if we
  conduct the propagation from the leaf nodes in a
  bottom-up manner.
• For the SF model, the complexity is O(qw).
• For the HS models, the complexity is O(twl)
• In each step of t iterations of the HS models, we
  need to propagate the relevance score of a page
  along its in-link or out-link in the sub graph of
  the working set.
• For the HF models, the complexity is O(tqwl).

17
Online Complexity
The sitemap-based models are more efficient than
the hyperlink-based models The score-level
propagation models are faster than feature-level
models
18
Offline Complexity

• Score-level propagation is very difficult to
  implement offline
• The score can only be computed online w.r.t the
  query.
• For feature-level propagations,
• The time complexity of the SF model for offline
  implementation is acceptable
• 62.2 hours, or 2.6 days to re-index 8 billion
  pages
• The time complexity of the HF model is out of
  tolerance.
• 1083 hours, or 45 days to re-index 8 billion
  pages
• The ST model is easy for parallel implementation
  while the parallel implementation of the HF model
  is non-trivial

19
Conclusions of this Study

• Generally speaking, relevance propagation can
  boost the performance of web information
  retrieval.
• Sitemap-based propagation models outperform
  hyperlink-based propagation models in terms of
  both effectiveness and efficiency. Notably,
  sitemap-based propagation can be implemented in
  parallel.
• Score-level propagation and feature-level
  propagation have almost similar effectiveness.
  Although the former is more efficient in on-line
  implementations, it is not practical for
  real-world search engines because it can not be
  implemented offline.
• Overall speaking, sitemap-based feature
  propagation model is the best choice for real
  search engines.

20
Thanks!

• tyliu_at_microsoft.com
• http//research.microsoft.com/users/tyliu/
