Title: THE OXYACETYLENE TORCH


1
THE OXYACETYLENE TORCH
  • AENT2803
  • ASSIGNMENT 10
  • DR.CURTIS BORNE

2
1 PART I CUTTING TORCH RIG
  • LABELLING O/A EQUIPMENT
  • 1. WORKING PRESSURE GAUGE
  • 2. CYLINDER PRESSURE GAUGE
  • 3. OXYGEN REGULATOR

1
2
1
2
3
O x y g e n
gas
3
LABELLING PARTS CONTINUED
  • 4. ACETYLENE REGULATOR
  • 5. HOSES
  • 6. TIP
  • 7. TORCH
  • 8. SPARKLIGHTER
  • 9. WRENCH

3
O x y g e n
gas
5
4
2. PRESSURE READINGS
  • HIGH PRESSURE IN CYLINDER
  • CYLINGER PRESSURE
  • LOW PRESSURE IN TORCH
  • WORKING PRESSURE

5
TORCH HOSES
  • 3. OXYGEN HOSE IS GREEN
  • 4. ACETYLENE HOSE IS RED

6
5. CUTTING PRESSURE SETTING
  • RATIO OF 2.5 PSI OF OXYGEN
  • TO 1 PSI OF ACETYLENE
  • NEVER OVER 15 PSI OF ACETYLENE
  • THICKNESS OF METAL AND TIP SIZE DETERMINES
    PRESSURE

7
5 PSI OF ACETYLENE AND 12.5 PSI OXYGEN
8
OXYACETYLENE WELDING
  • USES LOWER PRESSURE
  • 3 PSI ACETYLENE
  • 7.5 PSI OXYGEN

9
6. OPEN OXYGEN CYLINDER
  • OPEN ALLTHE WAY

10
7. OPEN ACETYLENE CYLINDER
  • NOT MORE THAN1-1/2 TURNS

11
8. GAUGES
  • ON REGULATORS

12
9. MANIFOLD TORCH SYSTEM
  • AT FVSU CYLINDERS OUTSIDE
  • GASES PIPED INTO MULTIPLE STATIONS

13
10. OXYGEN CYLINDERS
  • RIGHT HAND CONNECTOR THREAD

14
11. OXYACETYLENE GOGGLE
  • 6 FILTER LENS USED FOR TORCH WORK
  • DONT BE STUBBURN REMEMBER TO WEAR GOGGLES

15
12. CHECKING FOR TORCH LEAKS
  • USE SOAP AND WATER

16
13. HOSE CONNECTIONS
  • SHOULD BE HAND TIGHT

17
14. PARTS OF CUTTING TORCH
6
5
3
2
  • 1. CUTTING TIP
  • 2. MIXING CHAMBER
  • 3. TORCH HEAD
  • 4. OXYGEN SET AT TWO PLACES
  • 5. ACETYLENE AT ONE PLACE
  • 6. OXYGEN LEVER

1
4
18
SETTING CUTTING FLAME
  • WEAR GLOVES 6 LENS GOGGLES
  • HOLD TORCH IN BOTH HANDS
  • USE NEUTRAL FLAME
  • TOO MUCH ACETYLENE SENDS FLAME AWAY FROM TIP
  • TOO LITTLE CAUSES BLACK SMOKE

19
OBTAINING NEUTRAL FLAME
  • 1. OPEN ACETYLENE 1/2 TURN
  • 2. USE STRIKER TO LIGHT
  • 3. OPEN OXYGEN SLOWLY UNTIL FLAME IS NEUTRAL

Flame Tip
20
CUTTING PROCEDURE
  • PREHEAT UNTIL CHERRY RED
  • PRESS OXYGEN LEVER
  • MOVE STEADLY ACROSS METAL
  • IF YOU MOVE TOO FAST CUTTING STOPS AND MUST
    PREHEAT AGAIN

21
TORCH SAFETY
  • 6 FILTER LENS
  • FASTEN CYLINDERS WITH CHAIN
  • KEEP SAFETY CAPS ON CYLINDERS
  • CHECK FOR LEAKS WITH SOAPY WATER
  • NEVER PUT OIL ON EQUIPMENT

22
SAFETY CONTINUED
  • OPEN ACETYLENE CYLINDER 1-1/2 TURNS
  • POINT TIP AWAY FROM YOU AND OTHERS
  • USE PROPER PRESSURE (LESS THAN 15 PSI)
  • USE STRIKER NOT MATCHES
  • NEVER LAY LIGTHED TORCH DOWN

23
SHUTTING DOWN PROCEDURE
  • TURN OFF ACETYLENE FIRST AT TORCH
  • TURN OFF OXYEN AT TORCH
  • CLOSE CYLINDERS
  • DRAIN HOSES
