COMPUTING AGGREGATES FOR MONITORING WIRELESS SENSOR NETWORKS

1
COMPUTING AGGREGATES FOR MONITORING WIRELESS
SENSOR NETWORKS

• Jerry Zhao, Ramesh Govindan, Deborah Estrin
• Presented by
• Hiren Shah

2
Outline

• Motivation and Goals
• Contributions
• Architecture
• Computing Network Digests
• Impact of Packet Loss
• Experiments
• Conclusion

3
Motivation and Goals

• Every Network requires monitoring.
• Sensor Network is no exception !!!
• Monitoring in traditional networks SNMP.
• Need for a new architecture.

4
Architecture
5
Architecture (contd.)

• Three software components of the architecture.
• Dumps
• Detailed node states. E.g. logs with raw data
  reading, packet level details, energy details for
  a node.
• Dumps are costly to collect.
• Scans
• Abstract views of resource consumption in the
  network without referring to individual node.
• Derived using in-network aggregation.

6
Architecture (contd.)

• Network Digests
• Energy cost of computing scans over entire
  network is very high.
• Scans should be invoked only when necessary.
• A digest is an aggregate of some network
  property.
• E.g. size of the network, average energy left at
  a node etc.

7
Architecture (contd.)

• Digests indicate WHEN should scans be invoked.
• Scans indicate WHERE should dumps be collected
  from.

8
Computing Digests

• Naive centralized approach does not scale well
  and has a single point of failure.
• Some Requirements of Digest Computation
• Should be energy efficient.
• Digests should be available all the time and
  everywhere in the network.
• Typical Digest functions are Node with max
  energy, count of no. of nodes, Sum of node
  energies, Avg. residual energy.

9
Computing Digests (contd.)

• These functions are decomposable.
• Hence partial result can be added to get overall
  result.
• Hence one can use in-network aggregation.

10
Computing Digests (contd.)

• One can use hierarchical approach for computing
  the digests. E.g. clusters like LEACH.
• However this involves overhead in computing
  leaders and maintaining the hierarchy.
• Authors propose Digest Diffusion.

11
Digest Diffusion

• Nodes periodically send tuple (Mi, Si, Hi).
• Initially node sets Mi to its perceived maximum
  value e.g. its own residual energy.
• Si is source of maximum. Initialized to i.
• Hi is hop distance of the source of maximum.

12
Digest Diffusion

• Upon receiving a tuple from neighbor a node
  performs following processing.
• If Mj gtMi then set MiMj SiSj HiHj1
• Also set parent Pij
• Algorithm converges in steps proportional to
  network diameter.
• Approach is scalable. Periodic messages can be
  PIGGYBACKED.

13
Computing other digests
14
Computing other digests

• Hence a tree is needed without any overlaps.
• Digest diffusion establishes a tree rooted at the
  node with the maximum value.
• Every node i aggregates values from its children
  and passes the partial result to its parent along
  the tree.
• The root will have the final aggregate value.

15
Computing other digests

• Metric for establishing the tree should be
  carefully chosen such that the tree is relatively
  stable. E.g. link degree of a node is a bad
  choice since it fluctuates a lot with node
  failures.

16
Digest Tree Maintenance

• With node failures the tree should be suitably
  changed.
• Packet loss needs to be taken into account since
  absence of heartbeat does not mean the neighbor
  has failed.
• Let T0 be the interval between broadcasts.
• If heartbeat is not received from a parent or
  child in Tp 4To seconds change the tree.

17
Impact of Packet Loss

• Packet losses are frequent in wireless
  environments.
• Packet losses make aggregation tree unstable and
  hence affect the quality of aggregate digest.

18
Impact of packet loss
19
Impact of packet loss
20
Impact of packet loss
21
Solution

• Link Quality Profiling and Rejection
• blacklist links with poor quality and
  asymmetry.
• A node chooses as parent a node with which it has
  good and symmetric communication.
• Use packet sequence number to estimate how many
  of the packets sent by the neighbor are getting
  lost.
• Exchange I CAN HEAR YOU lists to identify
  asymmetric links.

22
Experiments

• Used REAL Berkley Motes !!!
• Studied performance of various schemes against
  packet loss.
• Used root mean square error to quantify
  performance.

23
Experiments
24
Conclusion

• Proposed an architecture for monitoring sensor
  network.
• Suggested design for computing network digests.
• Carefully handling lossy and asymmetric links
  reduces error in digest computation.
• Future work includes experiments on larger
  testbed and designing a full-fledged monitoring
  suite.

25
Questions ?
