CircuitMaster CFA1000

1
CircuitMaster CFA1000
2
Introduction

• Crimp Force Analysis Overview
• System Overview/Options
• Force Curve Basics
• CFA1000 Analysis Method
• Teaching Phase
• Production Phase
• Operator Control Parameters

3
Introduction continued...

• Machine Interface Options
• Force Calibration Overview
• In the field software upgrades

4
CFA Overview

• Circuitmaster have over 7000 CFA units installed
  around the world.
• Units available for Benchtop (CFA1000B) and
  Automatic machines(CFA1000M)
• Measures the force applied to make the crimp
  terminal and compares it with a known good crimp
  which has been offline tested
• Can detect strip, crimp and misfeed faults.

5
Customer Benefits

• 100 online testing of quality
• Little or no production rate impact
• Virtual eradication of expensive tool damage
• Reduced downtime
• Reduced scrap
• Quality Assurance

6
Customer Benefits Continued

• Powerful tool for your Sales Department
• Retrofitable to all crimp presses thus protecting
  your investment in the future
• CFA will give guidance to novice press operators
  to achieve consistently high results
• Intuitive user interface reduces training costs
• Multilingual menus

7
CFA System Overview
Machine I/F
Control Panel
Processing Unit
Encoder
Force Sensor
8
Force Sensor

• Preloaded and Sealed at the factory
• Uses Piezoceramic technology
• Mounted inline with the press ram
• Output signal is proportional to the applied
  force.

9
Encoder

• Determines angular position of the press
• Produces 1440 pulses per revolution
• Output used to trigger sampling of the force
  sensor output
• Allows force curves to be overlaid exactly from
  crimp to crimp
• Timer triggering is also possible

10
Processing Unit

• Evaluates force curve against reference curve.
• Interfaces with the machine through one of three
  machine interface methods

• Interfaces with the operator via the Graphical
  control panel (GCP)
• Powerful 16Bit Microprocessor allows faster
  evaluation (Evaluation time lt20mS after BDC)

11
Machine Interface

• INTERFACE APPLICATION
• 2 High Speed relays (e.g. Komax 40,
  Opera, Artos TX)
• 2 Power Relays (Benchtop)
• Coaxial Interface (e.g. Komax Alpha
  generation)

12
Graphical Control Panel (GCP)

• Simple to use
• Setup via menus
• Online viewing of force curve
• Can be plugged in at any time
• Magnetic backing provides easy mounting

13
CFA1000 Variants

• Two Different Variants -
• CFA for Machines CFA1000M
• CFA for Benchtop CFA1000B

14
I/O Board
Buzzer
High Speed Relays
Aux Inputs
Coaxial Interface
Power Relays
Mains PSU
15
Force Curve Basics

• Introduction to the force curve
• Differences between a force curve and a K325 type
  force signature.
• Important features
• Typical faults
• Analysis strategies

16
Force Curve
17
Insulation Crimp Phase
18
Main Crimp Phase
19
Peak Force Phase
20
Insulation in main crimp
Force is increased during the main crimp, due
to the trapped insulation increasing the
effective CSA of the wire
21
Cut Fault
Force is reduced in the main crimp phase due to
strands being cut reducing the wire CSA
22
Insulation Crimp Fault
Force is reduced in insulation crimp due to
deformed insulation crimp ears.
23
Interim Summary

• Seen what constitutes a CFA
• Sensor, Evaluation Unit, GCP, Machine Interface
• Applications of CFA1000
• Force curve
• Salient features
• Some typical faults

24
K325 Analysis
25
K325 Analysis continued...

• Advantages
• Simple to evaluate
• Disadvantages
• Big localised error gives small overall error
• Size of the error gives no indication of the
  cause (eg. 3 error over or under crimp?)
• No positional information ( Fault type )

26
CFA1000 Analysis
27
Errors in each zone
28
Zoned Analysis Advantages

• Errors in any one zone are distinct and not
  affected by results in other parts of the curve
• Process limits and controls can be provided for
  each individual zone allowing any zone to be made
  more or less sensitive
• Zones closely match the distinct parts of the
  crimping process

29
Zoned Analysis Advantages

• Signed analysis gives not just the magnitude of
  the error in each zone but also the sign of the
  error (Force lower or higher than the reference
  crimp)

30
CFA1000 Analysis Phases

• Teaching Phase
• Reference curve is recorded and averaged
• The Zone Widths and Limits are calculated
• A static and driftable reference are produced
• Production Phase
• Analysis is performed between the references and
  the force curve
• Drift compensation is performed

31
Teaching Phase

• 1st Cycle Force curve is scaled by the internal
  amplifier to give best possible resolution
• 2nd Cycle The reference curve is stored and the
  zone widths and limits are calculated from the
  reference curve shape and the user entered
  operating parameters

32
Teaching Phase continued

• 3rd - (N-1)th The analyser evaluates against the
  Teach Limit, The reference is averaged to give a
  closer approximation to the process mean.
• Last Teach Cycle The averaged reference is
  copied to form two references
• STATIC REFERENCE
• DRIFTABLE REFERENCE

33
Teach Phase continued

• The unit switches to the production phase.
• NOTE if the teach limit is exceeded at any time
  during the teach sequence, the teach phase will
  start again automatically.

34
Production Phase

• Analysis is performed in each zone against the
  driftable reference. The result is compared with
  the Bad Limit and the Stop Limit for that zone.
• Analysis is performed in each zone against the
  static reference. The result is compared with
  the Drift Limit for that zone.

35
Production Phase continued

• The machine is informed of the result either
  using the high speed relays or the coax
  interface.
• If the crimp passes, the driftable reference is
  drift compensated.

36
Drift Compensation

• All production processes fluctuate randomly due
  to common causes within the process e.g. press
  expansion,terminal and wire tolerances.
• Drift compensation allows the driftable reference
  to follow this fluctuation, in a way that
  maintains sensitivity to special causes within
  the process.

37
Drift Compensation continued

• If the crimp is good, the driftable reference is
  allowed to creep towards the last force curve
• The evaluation against the static reference acts
  as an end stop on this process.
• No drift compensation is applied to crimps which
  exceed the bad or stop limits

38
Operator Controls

• Only one user limit required
• BLO (Bad Limit Overall)
• All other limits set using factors
• S factor (Stop Factor)
• T factor (Teach Factor)
• D factor (Drift Factor)

39
Operator Controls continued

• Stop Limit BLO x S factor
• Teach Limit BLO x T factor
• Drift Limit BLO x D factor
• Note Above are overall limits, the CFA1000 takes
  these values and produces limits for the
  individual zones automatically during teaching
  depending on the zone widths

40
Operator Controls continued

• BLO - Maximum allowable production tolerance
• STOP LIMIT - Value above which tool damage is
  likely and the machine must be stopped
• DRIFT LIMIT - Maximum allowable production drift

41
Operator controls continued

• TEACH LIMIT - Maximum allowable value during the
  teach phase.
• The above values are expressed as PPT or Parts
  Per Thousand . A Limit set at 80 defines a
  tolerance of /- 80/1000 or /-8.

42
Operator controls continued

• Additionally three zone sensitivity parameters
  S1, S2 and S3.
• Allow the zone to be made more or less sensitive
  than the others.
• Useful in problem applications for reducing the
  effects of noise for example.

43
Operator controls continued

• Operating parameters can be edited using the GCP
  (password protected) or coax interface.
• Alternative analysis mode can be selected to
  analyse force curve as a K325 would. Can set
  analyse FROM and UNTIL angles using GCP.

44
Results display
Prod1 screen Graphical results Error bars
Prod2 screen Tabulated results Error highlighting
45
Machine Interface Options

• Signalling via high speed relays
• Coax interface
• Auxiliary inputs and power relays

46
Relays

• Preset modes for benchtop, Komax 40, Alpha
  generation machines and Artos TX
• Relay matrix allows binding a relay action to a
  set of specific events
• Events also generated by auxiliary inputs

47
Relays Continued

• Events include Teach Fail,Prod Fail, Aux1 Low etc
• Relay Actions are -
• x - Do nothing
• 0 - Off (Contacts Open)
• 1 - On (Contacts Close)
• S - Strobe
• T - Toggle

48
Force Calibration

• Alternative to crimp height in specifying
  crimping process.
• Achieved using a special test jig
• Adjustable spring
• NAMAS approved measurement system
• Force calibration allows CFA1000 to read
  accurately the peak force applied.

49
Software Upgrades

• CFA1000 can be reloaded using a laptop computer,
  serial link and windows 95/NT software
• Reduced cost of ownership, easier upgrading at
  lower cost as software is developed
• Introduces possibilities for site specific
  customising of software

50
Contact Us

• Circuitmaster Designs Ltd
• Kingsway West Business Park
• Moss Bridge Road
• Kingsway
• Rochdale
• Lancashire
• OL16 5LW
• United Kingdom

• T - 44(0)1706 630606
• F - 44(0)1706 510401
• E sales_at_circuitmaster.co.uk
• W www.circuitmaster.co.uk
