Title: Assembler Programming


1
Assembler Programming
  • Chapter 6

2
EEL-4746 Best Practices
3
EEL-4746 Best Practices
  • All programs must begin with the following
    comment
  • EEL-4746 Spring 2004 Semester
  • Homework N Due (Due Date)
  • Problem M
  • Name of Partner A
  • Name of Partner B
  • Description of Program

4
EEL-4746 Best Practices
  • All subroutines must begin with the following
    comment
  • Subroutine Name Mysub
  • Input parameter list
  • Output parameter list
  • Registers changed list
  • Description of Subroutine

5
EEL-4746 Best Practices
  • All lines must contain a comment
  • All labels must end with a semicolon
  • Must use a symbol for all constants

6
EEL-4746 Best Practices
  • Program must have the following format
  • Header Comment
  • Standard Symbols
  • Data EQU 0000
  • Program EQU E000
  • Stack EQU 00FF
  • Reset EQU FFFE
  • Place your symbols here
  • Program
  • Top ORG Program
  • Label Program line comment
  • Data
  • ORG Data
  • Variable Directive Data goes here
  • ORG Reset

7
Additional Comments
  • To Indent or Not Indent
  • Not really used in assembly language programming
  • Upper,Lower, and Mixed Cases
  • Be consistent
  • Symbols for constants in ALLUPPERCASE
  • Labels for in-memory variables in lowercase
  • Code labels in MixedCase
  • Instructions all uppercase or all lowercase
  • Etc
  • Subroutine Headers
  • Develop the habit of placing comments before
    subroutines. The comment should give the
    function of the subroutine, the input values it
    expects, and the registers that it modifies.

8
Pseudo-code
  • A fictitious programming language which allows
    a general algorithm for a computer program to be
    developed.
  • Design process
  • Develop program using pseudo-code
  • Convert pseudo-code to 68HC11 assembly language

9
Structured Assembly Language Programming
  • If Then Else End IF
  • Pseudo-Code Syntax
  • If Variable_A Condition Variable_B Then
  • Pseudo Code for Then condition
  • Else (Optional)
  • Pseudo Code B for Else condition
  • End If

10
Structured Assembly Language Programming
  • LDAA Variable_A
  • CMPA Variable_B
  • B?? Else
    Opposite of condition
  • Code for Then part
  • .
  • BRA END_IF need to skip else
    part
  • Else Code for Else part
  • ..
  • END_IF Rest of Code

11
Structured Assembly Language Programming
  • If-Then-Else-End IF
  • Condition Branch to Use (Opposite of
    condition)
  • ltgt BEQ (Branch if equal)
  • BNE (Branch if not equal)
  • Signed
  • lt BGT (Branch if greater than)
  • lt BGE (Branch if greater than or equal)
  • gt BLT (Branch if less than)
  • gt BLE (Branch if less than or equal)
  • Unsigned
  • lt BHI (Branch if higher)
  • lt BHS (Branch if higher or same)
  • gt BLO (Branch if lower)
  • gt BLS (Branch if lower or same)

12
If-Then-Else Example
  • Pseudo-code
  • IF temp gt max_temp then
  • Then code
  • Else
  • Else code
  • End If

13
If-Then-Else Example
  • Assembly Language
  • LDAA Temp
  • CMPA MAX_TEMP
  • BLS Else
  • Then code here
  • BRA ENDIF
  • ELSE
  • ELSE code here
  • EndIf
  • Rest of program here

14
Structured Assembly Language Programming
  • Loops
  • For Loops
  • While-Do Loop
  • Do-While or (Repeat Until) Loops

15
Structured Assembly Language Programming
  • For Loops
  • Pseudo-code Syntax
  • For loop_index start_index to end_index
  • Begin
  • Code to Execute
  • ..
  • ..
  • End For Loop

16
Structured Assembly Language Programming
  • Assembly Language
  • Use one of the registers for the loop index.
  • A,B8 bit (255 max)
  • X,Y16 bit (65535 max)
  • Must use memory if index value is greater than
    65535
  • Example Code Fragment
  • LDAA start_index
  • Loop Start of Code to Execute (must not change
    A)
  • .
  • INCA
  • CMPA end_index
  • BLS Loop

17
Structured Assembly Language Programming
  • What if you need the loop index register (e.g. A)
    in your code?
  • Example Code Fragment
  • LDAA start_index
  • Loop Start of Code to Execute
  • PSHA Save A on stack
  • Use A
  • .
  • PULA Restore A from stack
  • INCA
  • CMPA end_index
  • BLS Loop

18
Structured Assembly Language Programming
  • For Loops (Count down)
  • Pseudo-code Syntax
  • For loop_index end_index downto start_index
  • Begin
  • Code to Execute
  • ..
  • ..
  • End For Loop

19
Structured Assembly Language Programming
  • Example Code Fragment
  • LDAA end_index
  • Loop Start of Code to Execute
  • .
  • DECA
  • CMPA start_index
  • BHS Loop

20
Structured Assembly Language Programming
  • For Loops (Count down from N to 1)
  • This counts N items
  • Pseudo-code Syntax
  • For loop_index end_index downto 1
  • Begin
  • Code to Execute
  • ..
  • ..
  • End For Loop

21
Structured Assembly Language Programming
  • Example Code Fragment
  • LDAA N
  • Loop Start of Code to Execute
  • .
  • DECA
  • BNE Loop Save one statement

22
TPS Quiz
23
Structured Assembly Language Programming
  • While-Do Loops
  • Pseudo-code Syntax
  • While Variable Condition Constant_VALUE
  • Do Code Here
  • Begin
  • Code to Execute
  • ..
  • ..
  • End While

24
Structured Assembly Language Programming
  • While-Do Loops
  • Loop LDAA Variable
  • CMPA Constant_Value
  • B?? End_While (opposite of
    condition)
  • Do code here
  • ..
  • BRA Loop
  • End_While End of While loop

25
Structured Assembly Language Programming
  • While-Do
  • Condition Branch to Use (Opposite of
    condition)
  • ltgt BEQ (Branch if equal)
  • BNE (Branch if not equal)
  • Signed
  • lt BGT (Branch if greater than)
  • lt BGE (Branch if greater than or equal)
  • gt BLT (Branch if less than)
  • gt BLE (Branch if less than or equal)
  • Unsigned
  • lt BHI (Branch if higher)
  • lt BHS (Branch if higher or same)
  • gt BLO (Branch if lower)
  • gt BLS (Branch if lower or same)

26
Structured Assembly Language Programming
  • Example Temp gt 4F (unsigned)
  • Pseudo-code
  • While Temp gt 4F
  • Do
  • (Execute your code here)
  • End_While End of While loop

27
Structured Assembly Language Programming
  • While Temp gt 4F (unsigned)
  • Assembly Code
  • Loop LDAA Temp
  • CMPA 4F
  • BLS End_While (opposite of
    gt)
  • Do code here
  • ..
  • BRA Loop
  • End_While End of While loop

28
Structured Assembly Language Programming
  • Do-While or (Repeat-Until) Loops
  • Pseudo-code Syntax
  • Do (or Repeat)
  • Begin
  • Code to Execute
  • ..
  • ..
  • While Condition (or Until Condition)

29
Structured Assembly Language Programming
  • Do-While or (Repeat-Until) Loops
  • Assembly Language Syntax
  • Loop
  • Do Code Here
  • ..
  • ..
  • LDAA Variable
  • CMPA Constant
  • B?? Loop (same as condition)

30
Structured Assembly Language Programming
  • Do-While or (Repeat Until)
  • Condition Branch to Use (Same as condition)
  • BEQ (Branch if equal)
  • ltgt BNE (Branch if not equal)
  • Signed
  • gt BGT (Branch if greater than)
  • gt BGE (Branch if greater than or equal)
  • lt BLT (Branch if less than)
  • lt BLE (Branch if less than or equal)
  • Unsigned
  • gt BHI (Branch if higher)
  • gt BHS (Branch if higher or same)
  • lt BLO (Branch if lower)
  • lt BLS (Branch if lower or same)

31
Example
  • Write a 68HC11 assembly language program that
    converts X into an equivalent ASCII signed
    decimal value. Store your result in a memory
    location labeled Result.

32
Pseudo-code
  • X Number_to_convert
  • sign
  • if X lt 0 then
  • sign -
  • X -X
  • end If
  • result0 sign
  • call X2ASC(X)
  • end program
  • X2ASC is a subroutine that converts the X
    register (unsigned) to ASCII

Well put this code intoa subroutine
calledSX2ASC that convertsthe X register
(signed)to ASCII.
33
Lets convert the code
  • For this line of pseudo-code
  • X Number_to_convert
  • Well create the following code
  • NUMBER EQU 8001 -32767
  • ORG CODE_AREA
  • Main LDX NUMBER Put it in regX
  • JSR SX2ASC Signed convert
  • End BRA End Infinite loop

34
Next line
  • At the start of the SX2ASC subroutine, we have
    the pseudocode line
  • sign
  • Well convert this to
  • ORG DATA_AREA
  • sign RMB 1 1 byte for sign char
  • ORG CODE_AREA
  • SX2ASC LDAA Take an ASCII sign.
  • STAA sign Store it in sign var.

35
Next line
  • Next, we have
  • if X lt 0 then end if
  • This converts to the assembly
  • CPX 0 Compare X to 0.
  • BHS endIf If Xgt0, skip if body
  • (IF body goes here)
  • endIf (code after IF goes here)

36
A more difficult case
  • Consider the pseudocode line
  • X -X (X gets negative X)
  • Problem Theres no NEGX instruction!
  • How can we work around this?
  • One solution
  • varX RMB 2 Reserve space for X in mem.
  • STX varX Save X in memory at varX
  • LDD 0 Load accum. D with a 0
  • SUBD varX Let D 0 varX -X
  • XGDX Copy D back to X.

37
Full SX2ASC in assembly
  • SX2ASC LDAA ' Take an ASCII "" sign.
  • STAA sign Store it in "sign"
    variable.
  • CPX 0 Compare X to 0.
  • BHS endIf If X lt 0, then...
  • LDAA '- Take an ASCII "-"
    sign.
  • STAA sign Store it in "sign"
    variable.
  • STX varX Save X in "varX"
    variable.
  • LDD 0 D 0.
  • SUBD varX D 0 - varX -varX
    -X.
  • XGDX Copy D back to X.
  • endIf LDAA sign A sign character.
  • STAA result0 Store sign char. in
    result0.
  • JSR X2ASC Conv. unsigned X to
    result1-5.
  • RTS End of subroutine
    return.

X -X
38
Pseudo-code X2ASC (w. divide)
  • function X2ASC(X,result)
  • D X
  • for B 0 to 3
  • A floor(D / convertB)
  • where convert 10000,1000,100,10
  • D D AconvertB Let D be the
    remainder
  • A A or 30 Convert A from 0-9 to
    ASCII
  • resultB1 A
  • end for
  • A D D should have the ones
  • A A or 30 Convert to ASCII
  • result4 A
  • end function

Note When converting this to working
assemblycode, we must be careful about
overlapping registers.
39
for loop outline
  • The skeleton of our for loop
  • for B 0 to 3 (body of for loop)end for
  • Translates to
  • LDAB 0
  • forBody body code goes here
  • INCB B B 1
  • CMPB 3 Compare B to 3
  • BLS forBody If Blt3, continue
  • But, we must be careful to preserve the value of
    B within the body code!

40
Accessing an array of words
  • We can set up the convert array as follows
  • convert FDB 10000,1000,100,10
  • But, how do we access convertB?
  • CLRA Effectively sets DB
  • ASLD Double D, its 2B.
  • XGDY Transfer this to Y
  • LDX convert,Y X (convert2B)
  • But, this only works if convert array is on page
    0!
  • More generally, wed have to do this after the
    ASLD
  • ADDD convert D convert2B
  • XGDY Transfer D to Y
  • LDX 0,Y X Y convertB

41
Unsigned X2ASC in assembly
  • X2ASC STX varD Initialize variable D
    X.
  • LDAB 0 For B 0 to 3,
  • ForBodySTAB varB Save variable B.
  • CLRA Clear MSB of
    accumulator D.
  • ASLD Double D to get
    2varB.
  • XGDY Move it into Y.
  • LDX convert,Y Let X (convertY)
    convertvarB
  • LDD varD Load old variable D.
  • IDIV (X,D)
    (quotient,remainder) of D/X.
  • STX quot Save quotient
    temporarily.
  • STD varD Save remainder as new
    variable D.
  • CLRA Clear MSB of
    accumulator D.
  • LDAB varB Set LSB of D
    variable B.
  • XGDY Move value of B from D
    into Y.
  • INY Increment Y to be
    varB1.
  • LDAA quot1 A LSB of quotient.
  • ORAA 30 Convert A to ASCII.
  • STAA result,Y resultvarB1 A.
  • LDAB varB Load old value of
    variable B.

XconvertB
resultB1A30
42
Pseudo-code X2ASC (w/o divide)
This version avoids doing divisionand would work
on a processorwithout a divide instruction.
  • Function X2ASC(X,Result)
  • D X
  • For B 0 to 3
  • A 0
  • Count the number of times Convert can be
    subtracted from D
  • While Dgt0 Do
  • A A 1
  • D D ConvertB Convert
    10000,1000,100,10
  • End While
  • D D ConvertB
  • A A 1
  • A A OR 30 Convert A from 0-9 to ASCII
  • ResultB A
  • END For
  • A D D should have the ones
  • A A OR 30 Convert to ASCII
  • Result4 A
  • End Function

Note When converting this to HC11 assemblycode,
we must be careful because the HC11sregister D
overlaps registers A and B.
Write a Comment
User Comments (0)
About PowerShow.com
