Genetic Programming

1
Genetic Programming

• Chapter 6

2
GP quick overview

• Developed USA in the 1990s
• Early names J. Koza
• Typically applied to
• machine learning tasks (prediction,
  classification)
• Attributed features
• competes with neural nets and alike
• needs huge populations (thousands)
• slow
• Special
• non-linear chromosomes trees, graphs
• mutation possible but not necessary (disputed!)

3
GP technical summary
4
Preparatory Steps of Genetic Programming

• The preparatory steps (shown at the top of the
  figure) are the human-supplied input to the
  genetic programming system. The computer program
  (shown at the bottom) is the output of the
  genetic programming system.
• The first two preparatory steps specify the
  ingredients that are available to create the
  computer programs. A run of genetic programming
  is a competitive search among a diverse
  population of programs composed of the available
  functions and terminals.

5
Preparatory Steps of Genetic Programming

• The set of terminals (e.g., the independent
  variables of the problem, zero-argument
  functions, and constants) for each branch (or
  leaf) of the to-be-evolved program tree
• The set of primitive functions for each node of
  the to-be-evolved program tree
• The fitness measure (for explicitly or implicitly
  measuring the fitness of individuals in the
  population)
• Certain parameters for controlling the run
• The termination criterion and method for
  designating the result of the run

6
Genetic Programming Flowchart
7
GP flowchart
GA flowchart
8
Introductory example Symbolic Regression

• Genetic programming circumvents the potential for
  syntactical errors (e.g. when changing C code)
  via only considering the relevant part of the
  syntax in a computer friendly format -- the parse
  tree.
• double solution(double x, double y)
• return x y sqrt(0.3)
• For all practical purposes the C-style function
  above can be described by the parse tree
• . . x y .sqrt 0.3

9
Introductory example Symbolic Regression

• Symbolic Regression tries to find a function
  that fits some input data. Think of linear or
  logistic regression, where the structure of the
  target is unknown
• In the case of the symbolic regression we
  typically use problem fundamentals such as
  addition, subtraction, multiplication and
  division.

10
Introductory example Symbolic Regression
Symbolic Regression Applet
11
Tree based representation

• Trees are a universal form, e.g. consider
• Arithmetic formula
• Logical formula
• Program

(x ? true) ? (( x ? y ) ? (z ? (x ? y)))
i 1 while (i lt 20) i i 1
12
Tree based representation
Original function
Tree representation
LISP Code (parse-tree) ( (.2 ) ( - ( x 3
) ( / y ( 5 1) ) ) ).
13
Tree based representation
Tree representation
Original function
i 1 while (i lt 20) i i 1
LISP Code (parse-tree)
( . ( .equals ( i 1 ) ( .while ( ( .lt i 20
) ( .equals ( i (. i 1 ) ) ) ) ) ) )
14
Tree based representation

• In GA, ES, EP chromosomes are linear structures
  (bit strings, integer string, real-valued
  vectors, permutations)
• Tree shaped chromosomes are non-linear structures
• In GA, ES, EP the size of the chromosomes is
  fixed
• Trees in GP may vary in depth and width

15
Tree based representation

• Symbolic expressions can be defined by
• Terminal set T
• Function set F (with the aritys of function
  symbols)
• Adopting the following general recursive
  definition
• Every t ? T is a correct expression
• f(e1, , en) is a correct expression if f ? F,
  arity(f)n and e1, , en are correct expressions
• There are no other forms of correct expressions
• In general, expressions in GP are not typed
  (closure property any f ? F can take any g ? F
  as argument)

16
Offspring creation scheme

• Compare
• GA scheme using crossover AND mutation
  sequentially (be it probabilistically)
• GP scheme using crossover OR mutation (chosen
  probabilistically)

17
Mutation

• Most common mutation replace randomly chosen
  sub-tree by randomly generated tree

18
Mutation

• Mutation has two parameters
• Probability pm to choose mutation vs.
  recombination
• Probability to chose an internal point as the
  root of the sub-tree to be replaced
• Remarkably pm is advised to be 0 (Koza92) or
  very small, like 0.05 (Banzhaf et al. 98)
• The size of the child can exceed the size of the
  parent

19
Recombination

• Most common recombination exchange two randomly
  chosen sub-trees among the parents
• Recombination has two parameters
• Probability pc to choose recombination vs.
  mutation
• Probability to chose an internal point within
  each parent as crossover point
• The size of offspring can exceed that of the
  parents

20
Parent 1
Parent 2
Child 2
Child 1
21
Selection

• Parent selection typically fitness proportionate
• Over-selection in very large populations
• rank population by fitness and divide it into two
  groups
• group 1 best x of population, group 2 other
  (100-x)
• 80 of selection operations within group 1, 20
  within group 2
• for pop. size 1000, 2000, 4000, 8000 x 32,
  16, 8, 4
• motivation to increase efficiency, s come from
  rule of thumb
• Survivor selection
• Typical generational scheme (thus none)
• Recently steady-state is becoming popular for its
  elitism

22
Initialization

• Maximum initial depth of trees Dmax is set
• Full method (each branch has depth Dmax)
• nodes at depth d lt Dmax randomly chosen from
  function set F
• nodes at depth d Dmax randomly chosen from
  terminal set T
• Grow method (each branch has depth ? Dmax)
• nodes at depth d lt Dmax randomly chosen from F ?
  T
• nodes at depth d Dmax randomly chosen from T
• Common GP initialisation ramped half-and-half,
  where grow full method each deliver half of
  initial population

23
Bloat

• Bloat survival of the fattest, i.e., the tree
  sizes in the population are increasing over time
• Ongoing research and debate about the reasons
• Needs countermeasures, e.g.
• Impose maximum tree-depth size, and pass
  threshold onto variation operators
• Parsimony pressure penalty for being oversized

24
Problems involving physical environments

• Trees for data fitting vs. trees (programs) that
  are really executable
• Execution can change the environment ? the
  calculation of fitness
• Example robot controller
• Fitness calculations mostly by simulation,
  ranging from expensive to extremely expensive (in
  time)
• Evolved controllers are often very good

25
Example RoboCup Soccer Evolving team behaviors

• In contrast to other learning methods, the
  automated programming nature of Genetic
  Programming automatic makes it a natural approach
  for developing algorithmic robot behaviors.
• Team of soft-bots evolved bottom-up to the
  level of coordinating behaviors and cooperating
  so as to play a game of soccer.
• Team was able to beat hand-coded heuristic
  competitors

26
Primordial soup for GP soccer function
set (sample)

• Function Returns
  Description
• (s1) bool
  Returns my internal state flag (1 or 0).
• (mate-closer) bool 1 if a
  teammate is closer than I am to the ball, else 0.
• (near-opp) bool 1 if
  there is an opponent within r distance from me,
  else 0.
• (squadn) bool 1
  if I am squad mate n, else 0.
• (rand) bool 1
  or 0, depending on a random event.
• (home) vect A
  vector to the my home position.
• (ball) vect
  A vector to the ball.
• (defgoal) vect A
  vector to goal I am defending.
• (goal) vect
  A vector to the goal I am attacking.
• (closest-mate) vect A
  vector to my closest teammate.
• (/2 vect1) vect
  Divides the magnitude of vect1 by 2.
• (dribble vect1) vect
  Sets the magnitude of vect1 to some constant c.
• (avg vect1 vect2) vect
  Returns the average of vect1 and vect2.

27
GP for evolving team behavior

• Example GP tree is shown
• A GP individuals tree can be thought of as a
  chunk of LISP program code each node in the tree
  is a function, which takes as arguments the
  results of the children to the node.
• Hence, figure equates with the LISP code
• (if (maggt1/2 (/2 goal))
• (if near-opp goal closest-mate)
• (dribble goal))

28
GP for evolving team behavior Mutation

• The point mutation operator in action. This
  operator replaces some sub-tree in an individual
  with a randomly generated sub-tree.

29
GP for evolving team behavior Crossover

• The sub-tree crossover operator in action. This
  operator swaps sub-trees among two individuals

30
Fitness function(s)

• Fitness functions tried
• Maximize number of goals scored
• Maximize time in possession of the ball
• Maximize number of successful passes
• Minimize number of kicks going out of bounds
• Evolved teams played against each other
  (competitive fitness)

31
Algorithm specifics

• Player representation
• Homogenous
• Each GP program was a single soccer playing
  program that every player in the team used.
• Heterogeneous
• Each GP program had different branches assigned
  to different players
• OR
• Each GP program represented a different player
• Control parameters
• 200 individuals in population
• 50 generations

32
Initial Random Population
33
Kiddies Soccer
34
Learning to Block the Goal
35
Becoming Territorial
36
Evolved tree for passing behavior
37
Problems ?

• Population Size Was Too Small (Not enough
  diversity)
• Teams Competed Too Infrequently (Evaluations not
  sufficiently spread)
• Evolved Teams versus Individuals (Credit
  assignment problem)
