SPECIAL RELATIVITY FOR JET MODELERS

• Mitch Begelman
• JILA, University of Colorado

2
2 DISTINCT EFFECTS

• Lorentz transformation
• Connects observers in different frames
• Rest (jet) frame ? Lab (observer) frame
• Depends on relative speed but not location of
  sources
• For radiation use Doppler factor
• Light travel-time effects
• Connects different observers in same frame
• Depends on location of sources (nearer, further)

3
VARIABILITY TIMESCALE COMPRESSION A LIGHT
TRAVEL-TIME (LTT) EFFECT

• Suppose source emits flashes 1 day apart, while
  moving toward you at

4
SUPERLUMINAL MOTION THE MOST FAMOUS LIGHT
TRAVEL-TIME EFFECT

• Consider continuously glowing blob, moving almost
  directly toward you at

Actual dist. traveled 0.8 lt-day Apparent
travel time (1- 0.8 cos?) day Sideways dist 0.8
sin? Apparent sideways speed 0.8 sin ? / (1-
0.8 cos ?) c
0.8c
0.8 lt-day
Day 0
5
ANOTHER LTT EFFECT ASYMMETRIC EXPANSION OF A
SYMMETRIC SOURCE
Approaching
Receding
... as seen in Sco X-1! (Fomalont et al. 2001)
6
ULTRARELATIVISTIC LIMIT ?gtgt1

• Doppler factor
• Light travel-time factor
• LTT effect is more intense why?
• Because Doppler factor has extra ?-1 factor, due
  to time dilation transverse Doppler shift (not
  present in Newtonian Doppler shift)

7
SS 433 Mixture of LTT Doppler
precessing jets 0.26 c
jets in plane of sky offset from rest
wavelength due to transverse Doppler effect

skywriting with LTT asymmetry (VLA Blundell
Bowler 2004)
8
ABERRATION OF LIGHT
Aberration of rain (Galilean effect)
Aberration of light (Newtonian idea, corrected by
Einstein)




9
Synchrotron emission from a single electron
another combination of DopplerLTT
10
DOPPLER BEAMING
Amazing fact power radiated (over all ? and all
directions) is Lorentz-invariant! Doppler boost
of each photons energy exactly compensates
decrease in rate of photon emission due to
time-dilation. Doppler Beaming effect primarily
due to transformation of solid angles!!
11

• ... but its more complicated if one looks at
  spectral flux or surface brightness

12
RADIATIVE TRANSFER
Complication conditions in jet frame can change
in time it takes ray to cross emitting region
(simultaneity different in different frames).
13
JET-COUNTERJET RATIOS
Steady jets path length through jet and
counterjet the same. Surface brightness and flux
ratios both proportional to Expanding
hotspots add LTT effect emission from
near-side is received sooner, faster (and decay
is sooner)
obs.
14
BRIGHTNESS TEMPERATURES

• Direct observation of surface brightness
  (resolved source)
• Deducing brightness temp. from variability
  (unresolved source)
• Applications synchrotron self-absorption,
  induced Compton scattering, intraday variability
  (scintillation vs. intrinsic) (radio, sub-mm)
  compactness to pair production (X-ray, gamma,
  TeV) synchrotron efficiency (cooling times,
  energy requirements) (X-ray, gamma)

15
COMPTON SCATTERING

• Compton power ? radiation energy density in jet
  frame. 2 generic sources of seed photons
• Synchrotron self-Compton
• External radiation Compton
• isotropic ambient radiation density boosted by
  factor ?2 (? for photon density ? ? for photon
  energy)
• Applications gamma-ray blazars, large-scale
  X-ray jets, Compton emission from compact radio
  lobes
