COOLING SYSTEMS
3
WHAT IS THE PURPOSE OF COOLING SYSTEM?

• KEEP ENGINE AT MOST EFFICIENT OPPERATING
  TEMPERATURE

4

• WHERE DOES THE HEAT COME FROM?

BURNING FUEL
HOW DOES THE ENGINE USE THIS ENERGY?
5
35 LOST OUT EXHAUST
6
35 LOST TO COOLING SYSTEM
7
15 LOST TO FRICTIONAL LOSSES
LOST TO COOLING 35
LOST TO EXHAUST 35
8
APPROXIMATELY 15 LEFT TO MOVE THE CAR.
15
LOST TO EXHAUST 35
9
CYLINDER WALL TEMPERATURE MUST BE KEPT BELOW 500
DEGREES F.WHY?

• OIL BREAKS DOWN (BURNS)

10
THREE TYPES OF HEAT TRANSFER

• CONDUCTION
• CONVECTION
• RADIATION

11
CONDUCTION

• TRANSFER OF HEAT THRU SOLIDS

12
CONVECTION

• TRANSFER OF HEAT THRU LIQUIDS OR VAPORS

13
RADIATION

• TRANSFER OF HEAT THRU LIGHT RAYS

14
HERE ARE THE COMPONENTS OF THE LIQUID COOLING
SYSTEM.
15
FOUR PURPOSES OF USING ANTIFREEZE
1. LOWER FREEZING POINT OF WATER
2. RAISE BOILING POINT OF WATER
3. PREVENT RUST/CORROSION AND DEPOSITS
16
FOUR PURPOSES OF USING ANTIFREEZE
PURE WATER 32F
25 ANTIFREEZE 10F
PURE ANTIFREEZE -10F
50 ANTIFREEZE -34F
68 ANTIFREEZE -92F
17
FOUR PURPOSES OF USING ANTIFREEZE

• 1. LOWER FREEZING POINT OF WATER

2. RAISE BOILING POINT OF WATER
PURE ANTIFREEZE BOILS AT 320F
50 ANTIFREEZE BOILS AT 225F
25 ANTIFREEZE BOILS AT 218F
WATER BOILS AT 212F
18
RUST/CORROSION AND DEPOSIT SLOW DOWN THE HEAT
TRANSFER
ACTS AS A BLANKET
19
THERE ARE DIFFERENT KINDS OF COOLANT

• GREEN (CONVENTIONAL)
• RECOMMENDED TO BE CHANGED ONCE A YEAR
• PINK (DEX COOL)
• RECOMMENDED TO BE CHANGED EVERY 5 YEARS

20
WATER PUMP

• CAUSES COOLANT TO FLOW
• USUALLY DRIVEN BY BELT FROM CRANK
• SHAFT SUPPORTED BY BEARNING
• SEAL PREVENTS COOLANT LEAKAGE

WEEP HOLE TO KEEP LEAKING COOLANT AWAY FROM
BEARING
21
RADIATORS
22
PRESSURE CAPS
SEALS COOLING SYSTEM TO ALLOW PRESSURE TO FORM
FROM EXPANDING COOLANT
PRESSURE RAISES BOILING POINT OF WATER 1 LB OF
PRESSURE RAISES BOILING POINT 3 DEGRES F
PREVENTS A VACUUM FROM FORMING AS COOLANT COOLS
AFTER SHUT DOWN
23
PRESSURE CAP OPERATION
24
WARNING! WARNING! WARNING!
NEVER REMOVE CAP FROM HOT RADIATOR
25
THERMOSTAT OPERATION
NOTE! WATER PUMP CIRCULATES ANYTIME ENGINE IS
RUNNING
26
ENGINE UP TO TEMPERATURE
WAX PELLET EXPANDS PUSHING VALVE OPEN.
VALVE OPEN, COOLANT CAN FLOW TO RADIATOR TO COOL.
27
THERMOSTAT NOTES

• CLOSED COOLANT TRAPED IN ENGINE, GETS HOT
• OPEN COOLANT CAN FLOW TO RADIATOR TO COOL
• ALLOWS JUST THE RIGHT AMOUNT TO FLOW TO KEEP EVEN
  TEMPERATURE
• MOST MODERN VEHICLES CALL FOR 195 F.

• STUCK CLOSED
• ENGINE OVERHEATS
• STUCK OPEN
• MORE EMISSIONS
• HEATER BLOWING COLD AIR

28
SOFT PLUGS

• ALSO CALLED
• FREEZE PLUGS
• EXPANSION PLUGS
• SAND PLUGS
• CORE PLUGS

29
HOSES

• TYPES
• PRE-FORMED
• FLEX
• SPRINGS
• WHEN TO CHANGE
• HARD
• SOFT
• BULGING
• BEFORE THEY BREAK
• RECOMMENDED EVERY 6 YEARS

30
FANS

• PURPOSE
• PROVIDE AIR FLOW THRU RADIATOR AT LOW SPEEDS.
  NOT NEEDED AT HIGH SPEEDS
• TYPES
• SOLID
• ENERGY CONSERVING
• FLEX
• CLUTCH
• ELECTRIC
